Page 1
Stainless housing
●
7
3/8
" diameter element = 1,000 watts
●
6" diameter element = 650 watts
Black Porcelain housing
●
7
1/8
" diameter element = 1500 watts
Heavy-Duty
Cast Iron Elements!
● H
eavy-duty cast iron element(s)
●
Solid element surface delivers heat evenly to pot or pan
●
Large element handles up to 12-quart pots
●
Infinite heat control keeps food simmering or boiling
●
Metal housing with easy to clean surface
Model Color Volts Watts Amps Unit Dimensions Unit Wt. Carton Dimensions Ship Wt.
PCR-2S Stainless 120 1650 13.8 w:191/4”, h:21/2”, l:11” 11.3 lbs. w:215/8”, h:31/2”, l:121/2” 13 lbs. .55 022107-00192-6
PCR-1S Stainless 120 1500 12.5 w:111/2”, h:31/4”, l:14” 7.2 lbs. w:141/8”, h:41/8”, l:165/8” 9.1 lbs. .56 022107-00190-2
PCR-1B Black 120 1500 12.5 w:111/2”, h:31/4”, l:14” 7.2 lbs. w:141/8”, h:41/8”, l:165/8” 9.1 lbs. .56 022107-00171-1
BroilKing Corp., 143 Colebrook River Road, Winsted, CT 06098
Tel. (860)738-2200
Due to continual product improvement, product specifications, designs and pricing are subject to change without notice.
●
Fax (860) 738-9404 ● E-mail: [email protected] ● Web site: www.broilking.com
●
COMMON FEATURES
Stainless housing
7
1/8
" diameter element = 1500 watts
● Non-skid feet ●
●
3 prong commercial cordset
● 120 volts
● Two year warranty
●
UL Listed
Power light
Cu. Ft. UPC#
4/21/2005 RV04
