Brocade Communications Systems Brocade 8/12c, Fabric OS v7.0.0 Reference

53-1002151-01

®

29 April 2011

Fabric OS

MIB Reference

Supporting Fabric OS v7.0.0

Copyright © 2000-2011 Brocade Communications Systems, Inc. All Rights Reserved.

Brocade, the B-wing symbol, BigIron, DCFM, DCX, Fabric OS, FastIron, IronView, NetIron, SAN Health, ServerIron, TurboIron, and
Wingspan are registered trademarks, and Brocade Assurance, Brocade NET Health, Brocade One, Extraordinary Networks,
MyBrocade, VCS, and VDX are trademarks of Brocade Communications Systems, Inc., in the United States and/or in other
countries. Other brands, products, or service names mentioned are or may be trademarks or service marks of their respective
owners.

Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning
any equipment, equipment feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to
this document at any time, without notice, and assumes no responsibility for its use. This informational document describes
features that may not be currently available. Contact a Brocade sales office for information on feature and product availability.
Export of technical data contained in this document may require an export license from the United States government.

The authors and Brocade Communications Systems, Inc. shall have no liability or responsibility to any person or entity with
respect to any loss, cost, liability, or damages arising from the information contained in this book or the computer programs that
accompany it.

The product described by this document may contain “open source” software covered by the GNU General Public License or other
open source license agreements. To find-out which open source software is included in Brocade products, view the licensing
terms applicable to the open source software, and obtain a copy of the programming source code, please visit
http://www.brocade.com/support/oscd.

Brocade Communications Systems, Incorporated

Corporate and Latin American Headquarters
Brocade Communications Systems, Inc.
130 Holger way
San Jose, CA 95134
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

European Headquarters
Brocade Communications Switzerland Sàrl
Centre Swissair
Tour B - 4ème étage
29, Route de l'Aéroport
Case Postale 105
CH-1215 Genève 15
Switzerland
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

Asia-Pacific Headquarters
Brocade Communications Systems China HK, Ltd.
No. 1 Guanghua Road
Chao Yang District
Units 2718 and 2818
Beijing 100020, China
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

Asia-Pacific Headquarters
Brocade Communications Systems Co., Ltd. (Shenzhen WFOE)
Citic Plaza
No. 233 Tian He Road North
Unit 1308 – 13th Floor
Guangzhou, China
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]

Document History

Document Title Publication Number Summary of Changes Publication Date

Brocade MIB Reference Manual v2.3 53-0000069-02 December 2000

Brocade MIB Reference Manual v3.0 53-0000134-03 July 2001

Brocade MIB Reference Manual v3.0, 4.0 53-0000184-02 March 2002

Brocade MIB Reference Manual

(v4.1, v4.0.x, v3.1, v3.0.x, v2.6.x)

Brocade MIB Reference Manual

(v4.1.2, v4.1, v4.0.x, v3.1, v3.0.x, v2.6.x)

Brocade MIB Reference Manual

(v4.1.2, v4.1, v4.0.x, v3.1, v3.0.x, v2.6.x)

Brocade MIB Reference Manual

(v4.2.0, v4.1.2, v4.1, v4.0.x, v3.1, v3.0.x,
v2.6.x)

53-0000521-02 Added Brocade-specific Entity

April 2003

and HA-MIBs.

53-0000521-03 Added FICON information. May 2003

53-0000521-04 Revised FICON information. October 2003

53-0000521-06 Updated to support the

December 2003
Brocade 3250, 3850, and
24000 switches.

Document Title Publication Number Summary of Changes Publication Date

Brocade Fabric OS MIB Reference Manual 53-0000521-08 Updated to support the

Brocade 4100.

Brocade Fabric OS MIB Reference Manual 53-0000521-09 Updated to support the

Brocade 48000 and 200E.

Brocade Fabric OS MIB Reference Manual 53-1000045-01 Updated to support the

Brocade 4900, 7500, and
FR4-18i blade.

Brocade Fabric OS MIB Reference 53-1000241-01 Changed name, updated to

support Fabric OS v5.2.x.

Brocade Fabric OS MIB Reference 53-1000439-01 New branding, updated to

support Fabric OS v5.3.0.

Brocade Fabric OS MIB Reference 53-1000602-01 Updated to support the

Brocade DCX Data Center
Backbone Director.

Brocade Fabric OS MIB Reference 53-1000602-02 Updated to support the

Brocade 300, 5100, and
5300 switches.

Brocade Fabric OS MIB Reference 53-1001156-01 Updated to support the

Brocade DCX-4S and Brocade
Encryption Switch.

Fabric OS MIB Reference 53-1001339-01 Updated to support the

Brocade 7800 Extension
Switch, Brocade 8000 Switch,
FCOE10-24 DCX Blade, and
FX8-24 DCX Extension Blade.
Added USM MIB details,
fcipTcpConnTable, and
fcipConnStatsTable.

Fabric OS MIB Reference 53-1001768-01 Updated to support the

Brocade FC8-64 port blade
and Brocade VA-40FC. Added
BD MIB details,
swConnUnitPortStatExtention
Table, swMemUsageLimit1,
swMemUsageLimit3,
swFabricReconfigTrap,
swFabricSegmentTrap, and
swExtTrap.

Fabric OS MIB Reference 53-1002151-01 Updated to support Brocade

6510, Brocade DCX 8510-8
Backbone, and Brocade DCX
8510-4 Backbone. Added
FibreAlliance extension MIB,
SNMPv2 MIB, ipAddressTable,
MIBs for
swConnUnitPortStatExtention
Table, and switch traps.

September 2004

April 2005

January 2006

September 2006

June 2007

October 2007

March 2008

November 2008

July 2009

March 2010

April 2011

Fabric OS MIB Reference iii
53-1002151-01

iv Fabric OS MIB Reference

53-1002151-01

Contents

About This Document

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii

How this document is organized . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii

Supported hardware and software . . . . . . . . . . . . . . . . . . . . . . . . . . xiv

What’s new in this document. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi

Document conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Text formatting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii

Notes, cautions, and warnings . . . . . . . . . . . . . . . . . . . . . . . . . xviii

Key terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

Notice to the reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

Additional information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix

Brocade resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix

Other industry resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix

Getting technical help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix

Document feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xx

Chapter 1 Understanding Brocade SNMP

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Setting the SNMP security level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Understanding SNMP basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Understanding MIBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Understanding SNMP traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Object instances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Loading Brocade MIBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Brocade MIB files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Standard MIBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Before loading MIBs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

MIB loading order. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

SNMP CLI usage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Access Gateway and Brocade MIBs. . . . . . . . . . . . . . . . . . . . . . . . . .19

Firmware upgrades and enabled traps . . . . . . . . . . . . . . . . . . . . . . .20

Fabric OS commands for configuring SNMP . . . . . . . . . . . . . . . . . . .20

Support for Administrative Domains . . . . . . . . . . . . . . . . . . . . . . . . . 23

Support for Role-Based Access Control. . . . . . . . . . . . . . . . . . . . . . .23

Support for IPv6 addressing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Support for Virtual Fabric . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Fabric OS MIB Reference v
53-1002151-01

Chapter 2 MIB-II (RFC1213-MIB)

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

MIB II overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

MIB-II object hierarchy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Textual conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Objects and types imported . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

System group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Interfaces group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

AT group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

IP group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

ICMP group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

TCP group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

UDP group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

EGP group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Transmission group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

SNMP group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

ifMIB group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Generic traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Chapter 3 RMON MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

RMON MIB overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

RMON MIB object hierarchy . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Textual conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

RMON group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

Statistics group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

History group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

History control group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

Ethernet history group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Alarm group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Event group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

RMON Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Chapter 4 FE MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

FE MIB overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

FIBRE-CHANNEL-FE-MIB (MIB-II branch) . . . . . . . . . . . . . . . . . . . . . .68

FIBRE-CHANNEL-FE-MIB organization. . . . . . . . . . . . . . . . . . . . .69

Definitions for FIBRE-CHANNEL-FE-MIB . . . . . . . . . . . . . . . . . . .73

fcFeConfig group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

vi Fabric OS MIB Reference

53-1002151-01

fcFeStatus group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

fcFeError group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

fcFeAccounting group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

fcFeCapabilities group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84

FCFABRIC-ELEMENT-MIB (experimental branch) . . . . . . . . . . . . . . .85

FCFABRIC-ELEMENT-MIB organization . . . . . . . . . . . . . . . . . . . .86

Definitions for FCFABRIC-ELEMENT-MIB . . . . . . . . . . . . . . . . . .89

fcFeConfig group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92

fcFeOp group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

fcFeError group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98

fcFeAcct group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

fcFeCap group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Chapter 5 Entity MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101

Entity MIB overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Entity MIB system organization of MIB objects . . . . . . . . . . . .102

Definitions for Entity MIB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

Textual conventions for Entity MIB. . . . . . . . . . . . . . . . . . . . . . . . . .104

Entity MIB objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

Physical entity group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

Logical entity group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

Entity mapping group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

General group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

Entity MIB trap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114

Entity MIB conformance information. . . . . . . . . . . . . . . . . . . . . . . .115

Chapter 6 SW-MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

SW-MIB overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

SW-MIB system organization of MIB objects . . . . . . . . . . . . . .120

Textual conventions for SW-MIB . . . . . . . . . . . . . . . . . . . . . . . .129

sw traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132

Switch system group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .137

Switch Fabric group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .146

Switch agent configuration group . . . . . . . . . . . . . . . . . . . . . . . . . .148

Fibre Channel port group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149

Name Server database group . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154

Fabric OS MIB Reference vii
53-1002151-01

Event group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .156

Fabric Watch group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .157

End device group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .165

Switch group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166

Bloom performance monitor group . . . . . . . . . . . . . . . . . . . . . . . . .167

Trunking group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168

Toptalker group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170

CPU or memory usage group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Switch connectivity unit port statistics extension table . . . . . . . . .172

Chapter 7 High-Availability MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175

HA-MIB overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175

High-Availability group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .177

FRU table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

FRU history table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .179

CP table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180

HA-MIB traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .181

Chapter 8 FICON MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183

FICON MIB overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183

SNMP traps for FICON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .183

FICON MIB system organization of MIB objects. . . . . . . . . . . .183

Textual conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .185

FICON RNID group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .187

FICON LIRR group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .189

FICON RLIR group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190

LinkIncident MIB traps group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191

Chapter 9 FibreAlliance MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193

FibreAlliance MIB overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193

FCMGMT-MIB system organization of MIB objects . . . . . . . . .193

Definitions for FCMGMT-MIB . . . . . . . . . . . . . . . . . . . . . . . . . . .199

Connectivity unit group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .201

Statistics group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .220

Service group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .225

SNMP trap registration group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .227

Revision number scalar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .228

viii Fabric OS MIB Reference

53-1002151-01

Unsupported tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .228

FibreAlliance MIB traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .229

Chapter 10 FibreAlliance Extension MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .231

FibreAlliance extension MIB overview . . . . . . . . . . . . . . . . . . . . . . .231

Textual conventions for FA-EXT-MIB . . . . . . . . . . . . . . . . . . . . .232

SFP statistics table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .233

Port configuration table for Fabric Assigned PWWN feature . . . . .233

Port configuration table for encryption or compression feature . .234

Chapter 11 FCIP MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .235

FCIP MIB overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .235

FCIP MIB system organization of MIB objects . . . . . . . . . . . . .235

FCIP entity instance table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .237

FCIP link table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .238

FCIP TCP connection table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .239

FCIP extended link table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .240

FCIP connection statistics table . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241

Chapter 12 iSCSI MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .243

iSCSI MIB overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .243

iSCSI MIB system organization of MIB objects . . . . . . . . . . . .243

iSCSI instance attributes table. . . . . . . . . . . . . . . . . . . . . . . . . . . . .246

iSCSI node attributes table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .247

iSCSI session attributes table . . . . . . . . . . . . . . . . . . . . . . . . . . . . .249

iSCSI session statistics table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .251

iSCSI connection attributes table. . . . . . . . . . . . . . . . . . . . . . . . . . .252

Chapter 13 SNMPv2 MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .255

SNMPv2 MIB overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .255

SNMPv2 MIB object hierarchy . . . . . . . . . . . . . . . . . . . . . . . . .255

SNMP target address table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .256

SNMP target parameters table . . . . . . . . . . . . . . . . . . . . . . . . . . . .257

SNMP community table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .258

Fabric OS MIB Reference ix
53-1002151-01

Chapter 14 USM MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .261

USM MIB objects overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .261

USM statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .262

USM user group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .263

Chapter 15 IEEE 802.1x PAE MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .265

IEEE 802.1x PAE MIB objects overview . . . . . . . . . . . . . . . . . . . . . .265

Dot1x PAE system group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .267

Dot1x PAE authenticator group . . . . . . . . . . . . . . . . . . . . . . . . . . . .268

Chapter 16 LLDP MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .273

LLDP MIB objects overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .273

LLDP MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 276

LLDP configuration group . . . . . . . . . . . . . . . . . . . . . . . . . . . . .276

LLDP statistics group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .278

LLDP local system data group. . . . . . . . . . . . . . . . . . . . . . . . . .279

LLDP remote systems data group. . . . . . . . . . . . . . . . . . . . . . .281

LLDP-EXT-DOT1-MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .283

LLDP-EXT-DOT1-MIB organization . . . . . . . . . . . . . . . . . . . . . . .283

lldpXdot1 configuration group. . . . . . . . . . . . . . . . . . . . . . . . . .285

lldpXdot1 local data group . . . . . . . . . . . . . . . . . . . . . . . . . . . .286

lldpXdot1 remote data group . . . . . . . . . . . . . . . . . . . . . . . . . .287

LLDP-EXT-DOT3-MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .289

LLDP-EXT-DOT3-MIB organization . . . . . . . . . . . . . . . . . . . . . . .289

lldpXdot3 configuration group. . . . . . . . . . . . . . . . . . . . . . . . . .290

lldpXdot3 local data group . . . . . . . . . . . . . . . . . . . . . . . . . . . .291

lldpXdot3 remote data group . . . . . . . . . . . . . . . . . . . . . . . . . .292

Chapter 17 IEEE 802.3 LAG MIB Objects

Chapter 18 Bridge-MIB Objects

x Fabric OS MIB Reference

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .295

IEEE 802.3 LAG MIB overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . .295

Aggregator group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .297

Aggregator port group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .299

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .305

Bridge-MIB overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .305

53-1002151-01

Bridge-MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .310

Bridge-MIB traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .310

dot1d base group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .310

dot1d STP group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .311

dot1dTp group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .314

dot1d static group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .315

P-Bridge MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 316

dot1dExtBase group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 317

dot1dPriority group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .318

Q-Bridge MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .318

dot1qBase group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .319

dot1qTp group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .319

dot1qStatic group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .321

dot1qVlan group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .323

RSTP MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .325

Chapter 19 BD MIB Objects

In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .327

BD MIB objects overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .327

BD Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .328

BD configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .329

BD statistics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .329

Appendix A MIB Object Groupings

In this appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .331

Switch variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .331

Sensor variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .331

Port variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .331

Variables for state and status . . . . . . . . . . . . . . . . . . . . . . . . . .331

Variables for statistics and measurement . . . . . . . . . . . . . . . .332

Event variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .332

ISL and end device variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .332

ISL variables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .332

End Device variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .332

SNMP configuration variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . .332

iSCSI instance information variables. . . . . . . . . . . . . . . . . . . . . . . .333

Appendix B Mapping of CLI Counters to MIB Objects

In this appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .335

portStatsShow command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .335

Fabric OS MIB Reference xi
53-1002151-01

portErrShow command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .336

portStats64Show command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .337

Index

portShow command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .338

xii Fabric OS MIB Reference

53-1002151-01

About This Document

In this chapter

• How this document is organized . . . . . . . . . . . . . . . . xiii

• Supported hardware and software . . . . . . . . . . . . . . xiv

• What’s new in this document. . . . . . . . . . . . . . . . . . . xvi

• Document conventions. . . . . . . . . . . . . . . . . . . . . . . . xvii

• Notice to the reader . . . . . . . . . . . . . . . . . . . . . . . . . xviii

• Additional information . . . . . . . . . . . . . . . . . . . . . . . . xix

• Getting technical help. . . . . . . . . . . . . . . . . . . . . . . . . xix

• Document feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . xx

How this document is organized

This document is organized to help you find the information that you want as quickly and easily as
possible.

The document contains the following components:

• Chapter 1, “Understanding Brocade SNMP,” provides an introduction to Brocade SNMP and

MIBs.

• Chapter 2, “MIB-II (RFC1213-MIB),” provides information for MIB-II.

• Chapter 3, “RMON MIB Objects,” provides information for RMON MIB object types.

• Chapter 4, “FE MIB Objects,” provides information for FE MIB object types.

• Chapter 5, “Entity MIB Objects,” provides information for Entity MIB object types.

• Chapter 6, “SW-MIB Objects,” provides information for FC Switch MIB (SW-MIB) object types.

• Chapter 7, “High-Availability MIB Objects,” provides information for High-Availability MIB object

types.

• Chapter 8, “FICON MIB Objects,” provides information for FICON MIB (LINK-INCIDENT-MIB)

object types.

• Chapter 9, “FibreAlliance MIB Objects,” provides information for FibreAlliance MIB

(FCMGMT-MIB) object types.

• Chapter 10, “FibreAlliance Extension MIB Objects,” provides information for FibreAlliance

extension MIB object types.

• Chapter 11, “FCIP MIB Objects,” provides information on FCIP MIB object types.

• Chapter 12, “iSCSI MIB Objects,” provides information on iSCSI MIB object types.

• Chapter 13, “SNMPv2 MIB Objects,” provides information on SNMPv2 MIB object types.

• Chapter 14, “USM MIB Objects,” provides information on USM MIB object types.

Fabric OS MIB Reference xiii
53-1002151-01

Supported hardware and software

• Chapter 15, “IEEE 802.1x PAE MIB Objects,” provides information on IEEE 802.1x PAE MIB

object types.

• Chapter 16, “LLDP MIB Objects,” provides information on LLDP MIB object types.

• Chapter 17, “IEEE 802.3 LAG MIB Objects,” provides information on IEEE 802.3 LAG MIB

object types.

• Chapter 18, “Bridge-MIB Objects,” provides information on Bridge-MIB object types.

• Chapter 19, “BD MIB Objects,” provides information on BD MIB object types.

• Appendix A, “MIB Object Groupings,” is a function-based listing of MIB objects.

• Appendix B, “Mapping of CLI Counters to MIB Objects,” maps the CLI counters to the

corresponding MIB objects.

Supported hardware and software

In those instances in which procedures or parts of procedures documented here apply to some
switches but not to others, this guide identifies exactly which switches are supported and which are
not.

Although many different software and hardware configurations are tested and supported by
Brocade Communications Systems, Inc. for Fabric OS v7.0.0, documenting all possible
configurations and scenarios is beyond the scope of this document.

This document supports Brocade Fabric OS version 7.0.0 and earlier versions, and all switches
supporting these Fabric OS versions, including:

• Brocade 300

• Brocade 4100

• Brocade 4900

• Brocade 5000

• Brocade 5100

• Brocade 5300

• Brocade 5410

• Brocade 5424

• Brocade 5450

• Brocade 5460

• Brocade 5470

• Brocade 5480

• Brocade 6510

• Brocade 7500

• Brocade 7500E

• Brocade 7600

• Brocade 7800 Extension Switch

• Brocade 8000 FCoE Switch

• Brocade Encryption Switch

• Brocade DCX Backbone and Brocade DCX-4S Backbone

xiv Fabric OS MIB Reference

53-1002151-01

Supported hardware and software

- FA4-18 Fibre Channel application blade

- FCOE10-24 DCX Blade

- FS8-18 Encryption Blade

- FC8-16 port blade

- FC8-32 port blade

- FC8-48 port blade

- FC8-64 port blade

- FC10-6 port blade

- FR4-18i router blade

- FX8-24 DCX Extension Blade

• Brocade 48000 director

- FA4-18 Fibre Channel application blade

- FC4-16 port blade

- FC4-16IP blade

- FC4-32 port blade

- FC4-48 port blade

- FC8-16 port blade

- FC8-32 port blade

- FC8-48 port blade

- FC10-6 port blade

- FR4-18i router blade

• Brocade VA-40FC

• Brocade DCX 8510-8 Backbone and Brocade DCX 8510-4 Backbone

- FC8-64 port blade

- FC16-32 port blade

- FC16-48 port blade

- FCOE10-24 DCX Blade

- FS8-18 Encryption Blade

- FX8-24 DCX Extension Blade

The following platforms can interoperate with switches running Fabric OS v7.0.0, but cannot load
Fabric OS v7.0.0:

• Brocade 4100

• Brocade 4900

• Brocade 5000

• Brocade 7500/7500E

• Brocade 7600

• Brocade 48000

Fabric OS MIB Reference xv
53-1002151-01

What’s new in this document

The following blades are not supported in any chassis operating with Fabric OS v7.0.0:

• FA4-18

• FC4-16IP

• FC4-16

• FC4-32

• FC4-48

What’s new in this document

The following changes have been made since this document was last released:

• Information that was added:

- Support for Brocade 6510, Brocade DCX 8510-8 Backbone, and Brocade DCX 8510-4

Backbone

- SNMP traps enhancement

- The following traps included:

 swStateChangeTrap
 swPortMoveTrap
 swBrcdGenericTrap

- The following MIB objects included:

 CEE MIBs
 SNMPv2 MIB
 FibreAlliance extension MIB
 ipAddressTable
 swPortList
 swBrcdTrapBitMask
 swFCPortPrevType
 swVfName
 swConnUnitInterrupts
 swConnUnitUnknownInterrupts
 swConnUnitTimedOut
 swConnUnitProcRequired
 swConnUnitTxBufferUnavailable
 swConnUnitStateChange
 swConnUnitC3DiscardDueToRXTimeout
 swConnUnitC3DiscardDueToDestUnreachable
 swConnUnitC3DiscardDueToTXTimeout
 swConnUnitC3DiscardOther

xvi Fabric OS MIB Reference

53-1002151-01

Document conventions

• Information that was changed:

- fcfxPortBbCreditAvailable of fcfxPortStatusTable

- swFwClassAreaIndex

- swNbBaudRate

- ifSpeed

- connUnitPortSpeed

- ifHighSpeed

- dot1dStaticAllowedToGoTo

- swBlmPerfFltMntTable

- swFwLastEvent

- interfaces group &if-MIB:

- ifInOctet

- ifHCInOctets

- ifOutOctets

- ifHCOutOctets

- Change of version number wherever applicable

For further information about new features and documentation updates for this release, refer to
the release notes.

Document conventions

This section describes text formatting conventions and important notices formats.

Text formatting

The narrative-text formatting conventions that are used in this document are as follows:

bold text Identifies command names

italic text Provides emphasis

code text Identifies CLI output

For readability, command names in the narrative portions of this guide are presented in mixed
lettercase: for example, switchShow. In actual examples, command lettercase is often all
lowercase. Otherwise, this manual specifically notes those cases in which a command is case
sensitive.

Identifies the names of user-manipulated GUI elements
Identifies keywords and operands
Identifies text to enter at the GUI or CLI

Identifies variables
Identifies paths and Internet addresses
Identifies document titles

Identifies syntax examples

Fabric OS MIB Reference xvii
53-1002151-01

Notice to the reader

NOTE

ATTENTION

CAUTION

DANGER

Notes, cautions, and warnings

The following notices and statements are used in this manual. They are listed below in order of
increasing severity of potential hazards.

A note provides a tip, guidance, or advice, emphasizes important information, or provides a
reference to related information.

An Attention statement indicates potential damage to hardware or data.

A Caution statement alerts you to situations that can be potentially hazardous to you or cause
damage to hardware, firmware, software, or data.

A Danger statement indicates conditions or situations that can be potentially lethal or extremely
hazardous to you. Safety labels are also attached directly to products to warn of these conditions
or situations.

Key terms

For definitions specific to Brocade and Fibre Channel, see the technical glossaries on MyBrocade.
See “Brocade resources” on page xix for instructions on accessing MyBrocade.

For definitions of SAN-specific terms, visit the Storage Networking Industry Association online
dictionary at:

http://www.snia.org/education/dictionary

Notice to the reader

This document may contain references to the trademarks of the following corporations. These
trademarks are the properties of their respective companies and corporations.

These references are made for informational purposes only.

Corporation Referenced Trademarks and Products

Microsoft Corporation Windows, Windows NT, Internet Explorer

Oracle Corporation Oracle, Java

xviii Fabric OS MIB Reference

53-1002151-01

Additional information

This section lists additional Brocade and industry-specific documentation that you might find
helpful.

Brocade resources

To get up-to-the-minute information, go to http://my.brocade.com and register at no cost for a user
ID and password.

White papers, online demonstrations, and data sheets are available through the Brocade website
at:

http://www.brocade.com/products-solutions/products/index.page

For additional Brocade documentation, visit the Brocade website:

http://www.brocade.com

Release notes are available on the MyBrocade website and are also bundled with the Fabric OS
firmware.

Additional information

Other industry resources

For additional resource information, visit the Technical Committee T11 website. This website
provides interface standards for high-performance and mass storage applications for Fibre
Channel, storage management, and other applications:

http://www.t11.org

For information about the Fibre Channel industry, visit the Fibre Channel Industry Association
website:

http://www.fibrechannel.org

Getting technical help

Contact your switch supplier for hardware, firmware, and software support, including product
repairs and part ordering. To expedite your call, have the following information immediately
available:

1. General Information

• Switch model

• Switch operating system version

• Software name and software version, if applicable

• Error numbers and messages received

• supportSave command output

• Detailed description of the problem, including the switch or fabric behavior immediately

following the problem, and specific questions

• Description of any troubleshooting steps already performed and the results

Fabric OS MIB Reference xix
53-1002151-01

Document feedback

• Serial console and Telnet session logs

• syslog message logs

2. Switch Serial Number

The switch serial number and corresponding bar code are provided on the serial number label,
as illustrated below:

The serial number label is located as follows:

• Brocade 300, 4100, 4900, 5100, 5300, 6510, 7500, 7500E, 7800, 8000, VA-40FC, and

• Brocade 5000—On the switch ID pull-out tab located on the bottom of the port side of the

• Brocade 5410, 5424, 5450, 5460, 5470, 5480—Serial number label attached to the

• Brocade 7600—On the bottom of the chassis

• Brocade 48000—Inside the chassis next to the power supply bays

• Brocade DCX and 8510-8—On the bottom right on the port side of the chassis

• Brocade DCX-4S and 8510-4—On the bottom right on the port side of the chassis, directly

*FT00X0054E9*

FT00X0054E9

Brocade Encryption Switch—On the switch ID pull-out tab located inside the chassis on the
port side on the left

switch

module

above the cable management comb

3. World Wide Name (WWN)

Use the licenseIdShow command to display the WWN of the chassis. If you cannot use the
licenseIdShow command because the switch is inoperable, you can get the WWN from the
same place as the serial number, except for the Brocade DCX. For the Brocade DCX, access the
numbers on the WWN cards by removing the Brocade logo plate at the top of the nonport side
of the chassis.

Document feedback

Because quality is our first concern at Brocade, we have made every effort to ensure the accuracy
and completeness of this document. However, if you find an error or an omission, or you think that
a topic needs further development, we want to hear from you. Forward your feedback to:

[e-mail]

Provide the title and version number and as much detail as possible about your comment,
including the topic heading and page number and your suggestions for improvement.

xx Fabric OS MIB Reference

53-1002151-01

Chapter

Understanding Brocade SNMP

In this chapter

•Setting the SNMP security level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

•Understanding SNMP basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

•Loading Brocade MIBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

•Access Gateway and Brocade MIBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

•Firmware upgrades and enabled traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

•Fabric OS commands for configuring SNMP . . . . . . . . . . . . . . . . . . . . . . . . . 20

•Support for Administrative Domains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

•Support for Role-Based Access Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

•Support for IPv6 addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

•Support for Virtual Fabric . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

1

Setting the SNMP security level

The Simple Network Management Protocol (SNMP) is an industry-standard method of monitoring
and managing network devices. This protocol promotes interoperability because SNMP-capable
systems must adhere to a common set of framework and language rules.

Understanding the components of SNMP makes it possible to use third-party tools to view, browse,
and manipulate Brocade switch variables (MIBs) remotely as well as to set up an enterprise-level
management process. Every Brocade switch and director supports SNMP.

Recipients for SNMP traps are restricted according to security levels. Security levels are selected
and set for a switch using the snmpconfig --set seclevel command. To select and set SNMP security
levels, issue the command snmpconfig --set seclevel after having logged in to the switch as admin.

The following example sets the SNMP security level to 1 (authentication only). This setting allows all
SNMPv1 users to perform GET and SET operations on MIBs, but creates an exception for SNMPv3
users that do not have authentication and privacy privileges (noAuthnoPriv).

switch:admin> snmpconfig --set seclevel
Select SNMP Security Level
(0 = No security, 1 = Authentication only, 2 = Authentication and Privacy, 3 =
sxNo Access): (0..3) [0]
Select SNMP SET Security Level
(0 = No security, 1 = Authentication only, 2 = Authentication and Privacy, 3 =
No Access): (0..3) [0]

Fabric OS MIB Reference 1
53-1002151-01

Understanding SNMP basics

Agent

Management Station

SNMP

MIB

Management Station

Agent

get, getnext, set

reply

TRAP

Management Station

Agent

1

Tab le 1 shows the security level options.

TABLE 1 Security level options

Security level Protocol Query behavior Traps

No security [0]
(noAuthnoPriv)

Authentication only [1]
(authNoPriv)

Authentication and
Privacy [2]

(authPriv)

No Access [3]SNMPv1

SNMPv1
SNMPv3

SNMPv1
SNMPv3

SNMPv1
SNMPv3

SNMPv3

Understanding SNMP basics

Every Brocade switch carries an agent and management information base (MIB), as shown in

Figure 1. The agent accesses information about a device and makes it available to an SNMP

network management station.

FIGURE 1 SNMP structure

Allowed.
Allowed.

Allowed.
All SNMPv3 users allowed except
noAuthNoPriv users.

Not allowed.
Only SNMPv3 users with authPriv

privilege are allowed.

Not allowed. Not Sent.

Sent.
Sent.

Sent.
Sent for all SNMPv3 users
except noAuthNoPriv users.

Not Sent.
Sent only for authPriv users.

When active, the management station can get information or set information when it queries an
agent. SNMP commands, such as get, set, getnext, and getresponse, are sent from the
management station, and the agent replies once the value is obtained or modified (Figure 2).
Agents use variables to report such data as the number of bytes and packets in and out of the
device, or the number of broadcast messages sent and received. These variables are also known
as managed objects. All managed objects are contained in the MIB.

FIGURE 2 SNMP query

The management station can also receive traps, unsolicited messages from the switch agent if an
unusual event occurs (Figure 3). For more information, refer to “Understanding SNMP traps” on
page 4.

FIGURE 3 SNMP trap

2 Fabric OS MIB Reference

53-1002151-01

Understanding SNMP basics

mgmt (2)

sysObjectID (2)

iso (1)

org (3)

Brocade SW MIB

1.3.6.1.4.1.1588.2.1.1.1

dod (6)

internet (1)

experimental (3)

fcmgmt (94)

connSet (1)

enterprise (1)

private (4)

bcsi (1588)

mib-2 (1)

interface (2)

sysDescr (1)

system (1)

directory (1)

1

The agent can receive queries from one or more management stations and can send traps to up to
six management stations.

Understanding MIBs

The management information base (MIB) is a database of monitored and managed information on
a device, in this case a Brocade switch. The MIB structure can be represented by a tree hierarchy.
The root splits into three main branches: International Organization for Standardization (ISO),
Consultative Committee for International Telegraph and Telephone (CCITT), and joint ISO/CCITT.
These branches have short text strings and integers (OIDs) to identify them. Text strings describe
object names, while integers allow software to create compact, encoded representations of the
names.

Each MIB variable is assigned an object identifier (OID). The OID is the sequence of numeric labels
on the nodes along a path from the root to the object. For example, as shown in Figure 4, the
Brocade SW.MIB OID is:

1.3.6.1.4.1.1588.2.1.1.1

The corresponding name is:

iso.org.dod.internet.private.enterprise.bsci.commDev.fibreChannel.fcSwitch.sw

The other branches are part of the standard MIBs, and the portions relevant to configuring SNMP
on a Brocade switch are referenced in the remainder of this reference.

Fabric OS MIB Reference 3
53-1002151-01

FIGURE 4 Brocade MIB tree location

Understanding SNMP basics

1

Use a MIB browser to access the MIB variables: all MIB browsers perform queries and load MIBs.

Since different vendors vary the information in their private enterprise MIBs, it is necessary to verify
their information. The Fibre Channel MIB standards dictate that certain information be included in
all MIBs: it is the vendors’ responsibility to follow the standards. The standards are as follows:

• FibreAlliance (FA) MIB: Brocade supports v4.4. and later releases.

• Fabric Element (FE) MIB: accepted by the Internet Engineering Task Force (IETF).

Once loaded, the MAX-ACCESS provides access levels between the agent and management station.
The access levels are as follows:

• not accessible

• read create

• read only - Public

Brocade supports FE_RCF2837.mib under the MIB-II branch in Fabric OS v7.0.0, v6.4.1_fcoe,
v6.4.0, v6.3.0, v6.2.0, v6.1.2_CEE, v6.1.0, and v6.0.0. The latest version of the FE MIB
references the FRAMEWORK.MIB and, based on the MIB browser, it is necessary to load this
MIB before the FE.MIB. For more information, refer to “Loading Brocade MIBs” on page 7.

You cannot read or write to this variable.

Specifies a tabular object that can be read, modified, or created as a new row in a table.

You can only monitor information.

• read-write - Private

You can read or modify this variable.

• accessible-to-notify

You can read this information only through traps.

Understanding SNMP traps

An unsolicited message that comes to the management station from the SNMP agent on the
device is called a trap. Brocade switches send traps out on UDP port 162 and to any configured
port. In order to receive traps, the management station IP address and severity level must be
configured on the switch. Up to six trap recipients can be configured using Web Tools or the
snmpConfig command. You can define a different message severity level for each recipient so that
some recipients receive all trap messages and others receive only the most critical.

There are two main MIB trap choices:

• FibreAlliance MIB trap - Associated with the Fibre Alliance MIB (FA-MIB), this MIB manages SAN

switches and devices from any company that complies with Fibre Alliance specifications.

• Brocade-specific MIB trap - Associated with the Brocade-specific Brocade MIB (SW-MIB),

manages Brocade switches only.

There is some overlap in the functionality of these MIBs. If you enable both SW-MIB and FA-MIB
traps, you could receive duplicate messages for the switch events that trigger the trap.

You can also use these additional MIBs and their associated traps: HA-MIB; FICON-MIB; and
SWEXTTRAP. In Fabric OS v6.4.0, you can use the snmpConfig command to enable or disable all
the MIBs.

An event trap (swEventTrap, connUnitEventTrap, or swFabricWatchTrap) is basically an error
message (errShow output) that is SNMP-formatted and delivered.

4 Fabric OS MIB Reference

53-1002151-01

Understanding SNMP basics

1

FA traps

Consider enabling the FA traps if you want to use SNMP to monitor multiple connectivity units,
including Brocade switches.

The switchStatusPolicySet command determines the FA-TRAP switch status-related outputs:

• connUnitStatusChange

This trap is generated by Fabric watch such that only the swUnitsStatusChange is controlled by
switchStatusPolicySet command.

• connUnitSensorStatusChange

This trap is generated by any sensor event.

• connUnitPortStatusChange

This trap sends the instance of connUnitPortName as part of the trap; the instance string is
NULL, if the port name is not defined for the specified port.

• connUnitEventTrap

All the external traps gets converted into swEventTrap except for AN-1006, AUTH-3001 to
AUTH-3008, FW-3001, SEC-3001 to SEC-3034, and SEC-3044 to SEC-3048 RASlog messages.

Events in the Error Log of a severity at or above the configured threshold will generate SNMP traps.

The Fibre Alliance Trap (FA-TRAP) can be configured to send traps using the snmpConfig command.
For more information on this command, refer to the Fabric OS Command Reference.

HA traps

Consider enabling these traps to monitor field-replaceable unit (FRU) status and control processor
(CP) status when you have a Brocade director in your environment:

• fruStatusChanged

This trap is generated by a FRU status change, such as a switch reboot or disabling or enabling
a FRU component such as fandisable, fanenable and so on.

• cpStatusChanged

This trap is generated by a change in the status of a CP, including a reboot or firmware
download.

• fruHistoryTrap

This trap is generated when a FRU is added or removed. It is not generated when standby CP is
removed.

The high availability trap (HA-TRAP) can be configured to send traps using the snmpConfig
command. For more information on this command, refer to the Fabric OS Command Reference.

SW traps

There are fourteen specific traps defined in Brocade SW-TRAP.

1. swfault (no longer supported)

2. swSensorScn (no longer supported)

Fabric OS MIB Reference 5
53-1002151-01

Understanding SNMP basics

1

3. swFCPortScn

4. swEventTrap

5. swFabricWatchTrap

6. swTrackChangesTrap

7. swIPv6ChangeTrap

8. swPmgrEventTrap

This trap is generated by a port state change.

This trap is generated by any switch event reported to the system error log.
The desired severity level is introduced to filter a swEvent trap based on the severity level.

This trap is generated when any Fabric Watch threshold is reached.
The desired severity level is introduced to filter a swFabricWatchTrap based on the severity
level.

This trap is generated by a login or a logout.

This trap is generated when an IPv6 address status change event occurs. It is generated only
when IPv6 stateless state changes to the deprecation state and not for address change
notification.

This trap is generated when any partition manager change happens.

9. swFabricReconfigTrap

The trap to be sent for tracking fabric reconfiguration.

10. swFabricSegmentTrap

The trap to be sent for tracking segmentation.

11. swExtTrap

The trap adds the SSN binding to the traps if it is enabled.

12. swStateChangeTrap

This trap is sent when the switch changes its state to online or offline.

13. swPortMoveTrap

This trap is sent when the virtual ports are moved from one switch to another.

14. swBrcdGenericTrap

This trap is sent for one of the events, such as fabric change, device change, FAPWWN change,
and FDMI events. This trap is for Brocade use.

The Brocade trap (SW-TRAP) can be configured to send traps using the snmpConfig command. For
more information on this command, refer to Table 5 or the Fabric OS Command Reference.

6 Fabric OS MIB Reference

53-1002151-01

Object instances

MIB objects are defined by the OID, which is the type of object, and by the instance number, which
is an instance of that MIB object. A Fibre Channel port is a MIB object, and port 0 is an instance of
that object. The following is an OID number and an instance number:

1.3.6.1.4.1.1588.2.1.1.1.6.2.1.11.5

where:

1.3.6.1.4.1.1588.2.1.1.1.6.2.1.11 is the OID (of swFCPortTxWords) and 5 is the instance

ID for port 4.

You must add 1 to the port number to get its instance number in SNMP because SNMP numbering
starts at 1; switch port numbering starts at 0.

Loading Brocade MIBs

The Brocade MIB is a set of variables that are private extensions to the Internet standard MIB-II.
The Brocade agents support many other Internet-standard MIBs. These standard MIBs are defined
in RFC publications. To find specific MIB information, examine the Brocade proprietary MIB
structure and the standard RFC MIBs supported by Brocade.

Loading Brocade MIBs

1

Brocade MIB files

The Brocade MIB files are as follows:

• bd.mib

• BRCD_REG.mib

• BRCD_TC.mib

• brcdfcip.mib

• CPQ_HOST.mib

• CPQ_RACK.mib

• FA.mib

• FICON.mib

• HA.mib

• IBMBladeCenterTrapMIB.mib

• SW.mib

• faext.mib

Fabric OS MIB Reference 7
53-1002151-01

Loading Brocade MIBs

1

Standard MIBs

Distribution of standard MIBs has been stopped from Fabric OS v6.4.0. Download the following
MIBs from the http://www.oidview.com/ website:

• SNMP-FRAMEWORK-MIB

• IF-MIB

• IANAifType-MIB

• INET-ADDRESS-MIB

• RFC1213-MIB

• SNMPv2-MIB

• ENTITY-MIB

• RMON-MIB

• FC-MGMT-MIB

• FCIP-MGMT-MIB

• ISCSI-MIB

• FIBRE-CHANNEL-FE-MIB

• SNMPv2-PARTY-MIB

• SNMPv2-SMI-MIB

• SNMP-VIEW-BASED-ACM-MIB

• SNMP-USER-BASED-SM-MIB

• SNMP-TARGET-MIB

• IEEE 802.1x PAE MIB

• IEEE 802.3 LAG MIB

• BRIDGE-MIB

• P-BRIDGE MIB

• Q-BRIDGE MIB

• RSTP-MIB

• LLDP MIB

• LLDP-EXT-DOT1-MIB

• LLDP-EXT-DOT3-MIB

• IP MIB

• SNMP-COMMUNITY-MIB

8 Fabric OS MIB Reference

53-1002151-01

Loading Brocade MIBs

1

Before loading MIBs

Before loading Brocade MIB files, ensure that you have the correct version of SNMP for your Fabric
OS version (Table 2).

TABLE 2 Fabric OS-supported SNMP versions

Firmware SNMPv1 SNMPv2 SNMPv3

Fabric OS v5.x Yes Yes

Fabric OS v6.0.0 Yes Yes Yes

Fabric OS v6.1.0 Yes Yes Yes

Fabric OS v6.2.0 Yes Yes Yes

Fabric OS v6.1.2_CEE Yes No Yes

Fabric OS v6.3.0 Yes No Yes

Fabric OS v6.4.0 Yes No Yes

Fabric OS v6.4.1_fcoe Yes No Yes

Fabric OS v7.0.0 Yes No Yes

1. SNMPv2 is supported in Fabric OS v5.0.4 and later, but SNMPv2 traps are not supported.

2. Fabric OS v5.x supports the SNMPv3-USM MIB (snmpUsmMIB), which is available as RFC 3414.

1

Yes

2

MIB loading order

Many MIBs use definitions that are defined in other MIBs. These definitions are listed in the
IMPORTS section near the top of the MIB. When loading the Brocade MIBs, refer to Figure 5 to
ensure any MIB dependencies are loading in the correct order.

Fabric OS MIB Reference 9
53-1002151-01

Loading Brocade MIBs

RFC1155-SMI

BRCD.mib

Brocade-REG-MIB

Brocade-TC

FOS 2.6.x, 3.x, 4.x, 5.x, 6.x

Brocade_RE.MIB

FOS 6.4, 7.0

FICON_v5_0.mib

FICON.MIB

FOS 6.0

Select one

Brocade_TC.mib

FOS 6.4, 7.0

BD.mib

FOS 6.4, 7.0

RFC2571

SNMP-FRAMEWORK-

MIB

ENTITY_RFC2737.mib

ENTITY-MIB

FCIP.mib

FC_RFC4044.mib

IANA IF-TYPE MIB

SNMPv2-MIB

BRCDFCIP.mib

IF.mib

Dependency

Standard MIB File

Module name

Brocade MIB

Module name

FOS supported

Legend

HA.mib

FA_v2_2.mib

FCMGMT-MIB

FOS 2.6.x

FA.mib

FCMGMT-MIB

FOS 3.x, 4.x, 5.x, 6.x

Select one

SW_v5_5.mib

FOS 2.6.x, 3.x, 4.x,

5.x

SW_v5_7.mib

FOS 6.x

SW.mib

FOS 6.4

BRIDEGE-MIB

P-BRIDEGE

MIB

RFC1213-MIB

MIB-II

RMON MIB

FE_RFC2837.mib

FIBRE-CHANNEL-FE-MIB

FOS 3.1.x, 4.x, 5.x, 6.x, 7.0

ISCSI_RFC4544.mib

IANA-ADDRESS-FAMILY

-NUMBERS-MIB

LLDP-MIB

LLDP-EXT-DOT1-

MIB

LLDP-EXT-DOT3-

MIB

INET-Address

- MIB

IEEE LAG MIB

RFC1271-MIB

RMON2-MIB

TOKEN-RING-

RMON-MIB

Q-BRIDEGE

MIB

RSTP-MIB

IEEE 802.1 PAE

MIB

faext.mib

FOS 7.0

FICON.mib

FOS 7.0

1

FIGURE 5 Brocade SNMP MIB dependencies and advised installation order

10 Fabric OS MIB Reference

53-1002151-01
