The slim and refined lines of Sahale bring a refreshing change to today’s kitchens. Bright ENERGY STAR®
certified LED lighting complements your cooking experience and three fan speeds make cooking more enjoyable.
The LED modules included with this hood are the latest in LED cooktop illumination technology specially designed
to operate in the elevated temperatures of cooking - offering bright lighting and lasting up to 25 times as long as a
standard bulb and greater reliability than typical replacement LED bulbs.
SIZE BLACK STAINLESS WHITE
30 in. BKDEG130BL BKDEG130SS BKDEG130WW HPFA3A30 (Type "C3") HPF30 (Type "Xc")
HVI PERFORMANCE
Duct Orientation Size Damper
Vertical - Rectangular
Horizontal - Rectangular
Round - Vertical 7 in. Sold Separately 1.5 3.0 5.5 130 180 115 260
FEATURES
Max. Blower CFM** 375
Control type 3-speed Capacitive Touch
Delay off no
Filter Clean Reminder yes
Heat Sentry™ no
ADA Capable yes
Lighting
Grease Filters Deluxe Micro Mesh (Qty. 2)
Installation Hardware EZ1 brackets
ENERGY STAR
Recirculation Non-ducted filters sold separately
AC INPUT
120 V, 60 Hz - 0.65 AMPS
OPTIONAL ACCESSORIES
7-in. Round Damper BP87Q
ADA Wiring Kit HAWRK3
Make-up Air Dampers MD6TU, MD8TU and MD10TU
MOUNTING HEIGHT
18 in. to 24 in. from cooktop to bottom of hood
LIMITED WARRANTY
1-year
3-year (LED modules only)
(See installation manual for full warranty text.)
FOR INDOOR USE ONLY
0.6
0.5
0.4
0.3
0.2
Stac press ure (in. w.g.)
0.1
0
0 50 100 150 200 250 300 350 400
HVI-2100 CERTIFIED RATINGS comply with new testing technologies and procedures prescribed by the Home Ventilating Institute, for off-the-shelf products, as
they are available to consumers. Product performance is rated at 0.1 in. static pressure, based on tests conducted in AMCA’s state-of-the-art test laboratory. Sones
are a measure of humanly-perceived loudness, based on laboratory measurements.
* Where noted performance rating is not HVI certified but was established in accordance with HVI Standardized test procedure.
** Max. blower CFM indicates the performance of the hood blower in open air.
SPECIFICATION SHEET
SAHALE - BKDEG1 SERIES
Broan-NuTone LLC | 926 West State Street, Hartford, WI 53027 | 1 800-558-1711 | www.Broan-NuTone.com
3¼ in. x 10 in.
3¼ in. x 10 in.
2-level ENERGY STAR
(included)
®
yes (no if installed non-ducted)
Ai rfl ow ( cfm)
Included 1.5 3.0 6.0 120 160 140 230
Included 1.5 3.0 6.5 110 160 150 230
Normal Medium* High Normal Medium*
®
LED
Vercal High Speed,
7-in. round
Vercal High Speed,
with 3¼ in. x 10 in. damper
Horizontal High Speed,
with 3¼ in. x 10 in. damper
Under-Cabinet
GREASE FILTERS
(replacement)
Sones CFM
NON-DUCTED
FILTERS
0.25 in. w.g.
High
0.1 in. w.g.
Dimensions
shown in inches.
99045745G
SAHALE
High
