PM300SS
STAINLESS
21-2/5"
PM300SS
Shown with optional LB30SS liner
Ideal for custom range hood applications, this three-speed
powerpack insert protects cabinetry with an optional stainless steel
liner while providing 300 MAX Blower CFM.
• 300 MAX Blower CFM, 3.0 sones at
normal speed.
• Two-speed rocker controls.
• Bright 1-level LED lighting modules
illuminate evenly and are tested in
cooking environments to ensure long
life without dimming.
• EZ1 clips make it easy for single-person
installation.
• 7" round duct adapter with damper.
SPECIFICATIONS
Width
21-3/8” 300 Internal 3.0 120 2.3 7" RD
* MAX Blower CFM indicates hood blower performance in ope n air. Find HVI ra ted perfo rmance for this model
in the product specification sheet at Broan-NuTone.com
†
Sones at normal (or working) speed.
OPTIONAL ACCESSORIES
Non-Duct
Kit
HARKPM21 S99010464 S99100628-121 Included
• Easy-to-clean, fully enclosed
bottom with dishwasher-safe,
aluminum-mesh filter.
• Optional non-duct operation using
HARKPM21 non-duct kit and charcoal
filter, sold separately.
• Works with optional Universal
Make-up Air Dampers.
• Works with optional stainless LB liners.
• ADA compliant, remote operation is
possible using a standard UL approved
wall switch. Requires ADA adapter kit,
HAWSK3 (sold separately).
MAX
Blower CFM*
Non-Duct
Charcoal
Filter
Replacement
Blower Sones
Aluminum
Filter
LED
Make-Up
Air Dampers
MD6TU
MD8TU
MD10T U
†
Vol ts Amps Duct
Fresh
Air Inlets
641FA
643FA
610 FA
Liners
LB30SS
LB36SS
ADA
Kit
Backdraft
Damper
Adapter
HAWSK3 BP87Q
BROAN-NUTONE.COM | 800-558-1711 | 926 WEST STATE STREET, HARTFORD, WISCONSIN 53027
©2021 Broan | Printed in USA | 99851116A | 07/21
