Lenovo YOGA 900

YOGA 900-13ISK

User Guide

Read the safety notices and important tips in the included manuals before using your computer.

Notes

•

Before using the product, be sure to read Lenovo Safety and General Information Guide ﬁrst.

•

Some instructions in this guide may assume that you are using Windows® 8.1. If you are using another Windows operating system, some operations may be slightly different. If you are using other operating systems, some operations may not apply to you.

The features described in this guide are common to most models. Some features may not

• be available on your computer or your computer may include features that are not described in this user guide.

The illustrations in this manual may differ from the actual product. Please refer to the

• actual product.

Regulatory Notice

•

For details, refer to Guides & Manuals at http://support.lenovo.com.

First Edition (May 2015)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

Contents

Chapter 1. Getting to know your computer..................................................................................... 1

Top view

Left-side view ................................................................................................................................................ 7

Right-side view Bottom view

Chapter 2. Lenovo OneKey Recovery System.............................................................................. 14

Chapter 3. Troubleshooting............................................................................................................ 15

Frequently asked questions Troubleshooting

Trademarks ...................................................................................................................................... 20

......................................................................................................................................................... 1

........................................................................................................................................... 10

................................................................................................................................................ 13

...................................................................................................................... 15

......................................................................................................................................... 17

Chapter 1. Getting to know your computer

1 22

5 5

Top view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Note: The dashed areas indicate parts that are not visible externally.

~Attention:

• When closing the display panel, be careful not to leave pens or any other objects in between the display

panel and the keyboard. Otherwise, the display panel may be damaged.

Chapter 1. Getting to know your computer

Integrated camera

Use the camera for video communication.

(on select models)

Built-in microphone

Multi-touch screen

Windows button

Ventilation slots

(

Note: Make sure that the ventilation slots are not blocked or else the computer may overheat.

Wireless LAN antennas

)

Touchpad

Note: You can enable/disable the touchpad by pressing F6 ( ).

Captures sound which can be used for video conferencing, voice narration, or audio recording.

The LCD display with LED backlight provides brilliant visual output. Multi-touch function is available on this display.

Press this button to: Toggle between the current view and the Start screen.

-or-

Wake up the computer from sleep mode.

Dissipate internal heat.

Connect to a wireless LAN adapter to send and receive wireless radio signals.

The touchpad functions as a conventional mouse.

To uc h p a d : To move the pointer on the screen, slide your fingertip over the pad in the direction in which you want the pointer to move. Touchpad buttons: The functions of the left/right side correspond to that of the left/right mouse button on a conventional mouse.

Chapter 1. Getting to know your computer

 Using the keyboard

Keyboard function keys

You can access certain system settings quickly by pressing the appropriate function keys.

: Mutes/unmutes the sound. : Enables/disables Airplane mode.

: Decreases the volume level. : Displays all currently active apps.

: Increases the volume level. :

Closes the currently active window.

Refreshes the desktop or the

currently active window.

: Enables/disables the touchpad. : Increases the display brightness.

: Enables/disables the paper display feature.

Turns on/off the backlight of the LCD screen.

Toggles the display between the

computer and an external device.

: Decreases the display brightness.

Chapter 1. Getting to know your computer

 Positioning the display panel

The display panel can be opened to any angle up to 360 degrees.

Notebook Mode

Suitable for tasks that require a keyboard and mouse (such as creating documents, writing e-mails, and so on).

Chapter 1. Getting to know your computer

Stand Mode (Theater Mode)

Suitable for tasks that require little or no touch (such as viewing photos or playing videos).

Tablet Mode

Suitable for tasks that require touching the screen often (such as surfing the Web, playing games, and so on).

Chapter 1. Getting to know your computer

Tent Mode (Presentation Mode)

Suitable for tasks that require limited interaction with the touch screen (such as displaying graphs or PowerPoint presentations).

~Attention:

• Do not open the display with too much force, otherwise the panel or hinges may be damaged.

Note: The keyboard and touchpad are automatically locked when the screen is opened beyond 190 degrees

(approximately).

Chapter 1. Getting to know your computer

1 2 3 4

Left-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

AC power adapter jack

USB port

Note: For details, see “Connecting USB device” on page 8.

Thunderbolt connector

Memory card slot

Note: For details, see “Using memory cards (not supplied)” on page 9.

Connects to the AC power adapter.

Connects to USB 3.0 devices.

Connects to a Thunderbolt compatible device, such as CRT monitors, LCD monitors, projectors, or high-definition televisions.

Insert memory cards (not supplied) here.

Chapter 1. Getting to know your computer

 Connecting USB device

Your computer comes with three USB ports compatible with USB devices.

The first time you plug a USB device into a particular USB port on your computer, Windows automatically installs a driver for that device. After the driver has been installed, you can disconnect and reconnect the device without performing any additional steps.

Note: Typically, Windows detects a new device after it has been connected, and then installs the driver

automatically. However, some devices may require you to install the driver before connecting. Check the documentation provided by the device’s manufacturer before connecting the device.

Before disconnecting a USB storage device, make sure your computer has finished transferring data to that device. Click the Safely Remove Hardware and Eject Media icon in the Windows notification area to remove the device before disconnecting.

Note: If your USB device uses a power cord, connect the device to a power source before connecting it.

Otherwise, the device may not be recognized.

Chapter 1. Getting to know your computer

 Using memory cards (not supplied)

Your computer supports the following types of memory cards:

• Secure Digital (SD) card

• Secure Digital High Capacity (SDHC) card

• Secure Digital eXtended Capacity (SDXC) card

• MultiMediaCard (MMC)

Notes:

• Insert only one card in the slot at a time.

• This card reader does not support SDIO devices (e.g., SDIO Bluetooth, etc.).

Inserting a memory card

Insert the memory card until it touches the bottom of the slot.

Removing a memory card

Gently pull the memory card out of the memory card slot.

Note: Before removing the memory card, disable it by using the Windows safely remove hardware and eject

media utility to avoid data corruption.

Chapter 1. Getting to know your computer

1 432 5 6

Right-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Battery status indicator

Power button

Battery status indicator

Power status indicator

Indicator Indicator status Meaning

Press this button to turn on the computer.

On (solid white) The battery has more than 20% charge.

On (solid amber)

Blinking quickly (amber) The battery has less than 5% charge.

Blinking slowly (amber)

Blinking slowly (white)

On (solid white) The computer is powered on.

Blinking The computer is in sleep mode.

Off The computer is powered off.

The battery has between 5% and 20% charge.

The battery is being charged. When the battery charge reaches 20%, the blinking color will change to white.

The battery has between 20% and 80% charge and is still charging. When the battery reaches 80% charge the light will stop blinking, but charging will continue until the battery is fully charged.

Chapter 1. Getting to know your computer

Novo button

Rotation lock button

Note: The screen rotation lock button will be disabled in notebook mode.

Combo audio jack

(

Notes:

• The combo audio jack does not support conventional microphones.

• The recording function might not be supported if third-party headphones or headsets are connected,

due to different industry standards.

USB port

)

Note: For details, see “Connecting USB device” on page 8.

When the computer is off, press this button to start the Lenovo OneKey Recovery System or the BIOS setup utility, or to enter the boot menu.

Keeps the screen locked in portrait or landscape orientation. Locking the screen rotation will disable the gravity sensing function, thereby preventing the screen from changing its orientation automatically depending upon the angle at which it is held.

Connects to headsets.

Connects to USB 2.0 devices.

Chapter 1. Getting to know your computer

 Screen orientation

You can rotate the display panel to your preferred orientation.

• The orientation of the display automatically changes (alternating between portrait and landscape modes) depending on how you hold it.

Landscape

Portrait

• To prevent automatic orientation, press the rotation lock button. It is located on the right edge of the computer (See illustration below).

Note: The screen rotation lock button will be disabled in notebook mode.
