HTC and HWC Heating Cords
Product Highlights
Designed for use on small tubes, vessels, or any application where space is limited
Can be wrapped around objects as small as 1/8” (3mm) diameter
Exceptional flexibility
Rapid thermal response
Exceptional durability: excellent for laboratory, production, maintenance, and R&D applications
<![if ! IE]> <![endif]>E |
Specifications: |
||
• 3/16” (4.8mm) diameter heating cord |
|||
<![if ! IE]> <![endif]>P |
• |
Maximum exposure temperature: |
|
<![if ! IE]> <![endif]>TA |
|
HTC series: 900°F (482°C) |
|
<![if ! IE]> <![endif]>G |
|
HWC series: 1400°F (760°C) |
|
• |
Construction: |
||
<![if ! IE]> <![endif]>I N |
|||
|
HTC series: Double braided fiberglass outer sheath |
||
<![if ! IE]> <![endif]>T |
|
HWC series: Double braided high temperature Samox® |
|
<![if ! IE]> <![endif]>A |
|
fiberglass outer sheath |
|
<![if ! IE]> <![endif]>E |
|
||
• |
Power density: |
||
<![if ! IE]> <![endif]>H |
|||
|
HTC series: 21 W/ft (68 W/m) |
||
|
|
||
|
|
HWC series: 60 W/ft (196 W/m) |
•Suitable for electrically conductive surfaces
•2 to 6ft (0.6 to 1.8m) long power leads with
-120VAC: Separable molded plug
-240VAC: Crimped ferrule wire termination
•Includes high-temperature tie-downs for easy installation
Ordering Information:
HTC Series: Heating Cord
Cord Length |
Total |
Lead |
Part No. |
Part No. |
|
ft |
m |
Watts |
Length |
120VAC |
240VAC |
0.5 |
0.15 |
17 |
2ft (0.6m) |
HTC451007 |
N/A |
1 |
0.3 |
22 |
2ft (0.6m) |
HTC451006 |
N/A |
2 |
0.6 |
43 |
2ft (0.6m) |
HTC451005 |
N/A |
3 |
0.9 |
64 |
2ft (0.6m) |
HTC451001 |
N/A |
4 |
1.2 |
82 |
2ft (0.6m) |
HTC451008 |
N/A |
6 |
1.8 |
125/135 |
2ft (0.6m) |
HTC451002 |
HTC452002 |
8 |
2.4 |
170 |
2ft (0.6m) |
HTC451009 |
N/A |
12 |
3.7 |
260 |
2ft (0.6m) |
HTC451003 |
HTC452003 |
HWC Series: High Temperature Heating Cord
Cord Length |
Total |
Lead |
Part Numbers |
||
ft |
m |
Watts |
Length |
120VAC |
240VAC |
4 |
1.2 |
266 |
2ft (0.6m) |
HWC1040 |
N/A |
6 |
1.8 |
350 |
2ft (0.6m) |
HWC1060 |
N/A |
12 |
3.7 |
750/720 |
6ft (1.8m) |
HWC1120 |
HWC2120 |
18 |
5.5 |
1000 |
6ft (1.8m) |
HWC1180 |
HWC2180 |
24 |
7.3 |
1440 |
6ft (1.8m) |
HWC1240 |
HWC2240 |
IMPORTANT: Temperature controller is required for these products. See pages 86 through 104 for options.
|
|
|
