G B H
Y o u r H e a t i n g Specialist since 1949
Silicone Rubber Griffin Beaker Heaters
Product Highlights
Provides Even Heat for Griffin and
Standard Beaker Heating Applications.
Removable with hook and loop fastener. Easy-Access to Graduation.
Moisture and Chemical Resistant.
No Need to Worry About Spills.
Specifications: |
|
|
|
|
|
|
||
• Maximum exposure temperature: 232°C (450°F) |
|
|
|
|||||
• |
120 or 240VAC |
|
|
|
|
|
|
|
• Power density: 5.0 watts/in2 (0.008 watts/mm2) |
|
|
|
|
||||
• Heating element is laminated between two layers of |
|
|
|
|||||
|
15mil fiberglass reinforced silicone rubber |
|
|
|
|
|||
• 1” (25mm) wide hook and loop fastener |
|
|
|
|
||||
• Moisture, chemical, and radiation resistant |
|
|
|
|
||||
• Dielectric strength of over 2000 volts |
|
|
|
|
||||
• 24” (610mm) long power leads with |
|
|
|
|
||||
|
|
- 120VAC: Standard 2-prong NEMA 1-15 plug |
|
|
<![if ! IE]> <![endif]>A L |
|||
|
|
- 240VAC: Crimped wire ferrule terminated leads |
|
|
||||
Ordering Information: |
|
|
|
|
<![if ! IE]> <![endif]>O B |
|||
|
Size |
Diameter |
Heater Height |
Heater Length |
Total |
Part Number |
Part Number |
<![if ! IE]> <![endif]>R |
|
<![if ! IE]> <![endif]>T A |
|||||||
|
ml |
in (mm) |
in (mm) |
in (mm) |
Watts |
120VAC |
240VAC |
|
|
250 |
2.7 (69) |
3.0 (76) |
12.25 (311) |
150 |
GBH0250-1 |
GBH0250-2 |
<![if ! IE]> <![endif]>O |
|
<![if ! IE]> <![endif]>Y R |
|||||||
|
400 |
3.0 (76) |
3.5 (89) |
13.75 (349) |
200 |
GBH0400-1 |
GBH0400-2 |
|
|
|
|||||||
|
600 |
3.6 (91) |
4.0 (102) |
15.00 (381) |
250 |
GBH0600-1 |
GBH0600-2 |
|
|
1000 |
4.3 (109) |
4.6 (117) |
17.25 (438) |
350 |
GBH1000-1 |
GBH1000-2 |
|
IMPORTANT: Temperature controller is required for this product. See pages 86 through 104 for options.
BriskHeat® offers a wide variety of temperature control options including the SDC Benchtop Digital Temperature Controller.
Need a different size or have a different object to heat? We can design a heater specifically for your application. Contact us or your local distributor for more details.
Toll Free: 800-848-7673 Phone: 614-294-3376 w w w .BriskHeat. c o m |
Email: bhtsales1@briskheat.com |
Fax: 614-294-3807 |
|
|
|
|
45 |
|
|||
© BriskHeat Corporation. All Rights Reserved. 18-04 |
|
|
|
||
|
|
|
|||
|
|
|
|
|
|
