Cutting edge 3G technology
combined with a 520 MHz processor, full QWERTY keyboard
and WiFi means that the 9000 is
build for performance!
The display measures a full 480
x 640 pixel (VGA) and it is able
to swivel and close back up on
itself to allow for either two handed typing or PDA touch screen
use.
The new Microsoft Windows
Mobile 5.0 operating system is
standard as are the Pocket versions of all your favourite MS ap-
plications such as Offi ce, Outlook
and MSN Messenger.
High speed connectivity coupled with dual cameras allow for
Video Telephony while dual speakers, SD expandable memory
and Windows Media Player make
for a fantastic mobile multimedia
experience!
Complete business workstation
and multimedia centre combined
in this, the latest heavy hitter
from Qtek, the 9000!
The available AKU 2 ROM update
offers both Messaging & Security
Feature Pack for Windows Mobile
5.0™ and new applications. The
new Messaging & Security Feature Pack enables business users
to easily stay connected to their
Microsoft Offi ce Outlook Mobile
information while on the go and
helps businesses to better protect e-mails.
The world’s fi rst 3G Windows Mobile device! This new fl agship is designed to work on the latest high speed UMTS networks!
Microsoft Windows Mobile Pocket
PC Phone Edition (5.0)
Processor: 520MHz
Flash ROM 128 MB, RAM 64 MB
SDRAM
3.6” 640x480 transfl ective TFT
touchscreen
Dualmode UMTS/GSM
1,3 megapixelkamera
2nd lense for video telephony
USB 1.1
Bluetooth
IrDA
MP3, AAC ring signals
MMS
PDF Viewer
Java (J2ME, CLDC 1.1, MIDP 2.0,
JTWI)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Features
Brightpoint Sweden AB
Banehagsliden 5
414 51 Göteborg
Tel.: 031-64 57 00
Fax: 031-64 57 01
E-post: [email protected]
www.myQtek.com
Qtek 9000
Page 2
Specifi cations
The information contained herein is subject to change without notice. Brightpoint shall not be liable for technical or editorial errors or omissions contained
herein. Microsoft, Windows, and the Windows Logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other
countries. Qtek is a registered trademark of Qtek Corporation Taiwan. Intel is a registered trademark of Intel Corporation.
General
Data-centric wireless Pocket PC Phone
with full voice capability and clamshell form factor with 180-degree pivot
screen. With 62 keys QWERTY keyboard
incl. 56 alphanumeric and symbol keys.
Ready for UMTS and video calls!
OS
Microsoft Windows Mobile 5.0 (Pocket
PC Phone Edition)
Memory
128 MB Flash ROM, 64 MB SDRAM
Processor
QCT Platinum & Intel Bulverde 520 MHz
LCD
3.6“, 640 x 480 transfl ective TFT-LCD
with backlight LEDs
65K-color, sensitive touch screen
Supports landscape and portrait mode
GSM/EDGE
Dual-Mode UMTS/GSM, TriBand, GSM,
GPRS (class B)
Audio codec: AMR, EFR, FR, HR
SMS, concatenated SMS (640 characters), SMS over GPRS
Call holding/waiting/forwarding/barring
Network selection/lock
Cell broadcast
Multi-party conference
SIM
Over the air programming, 3V of UICC,
SIM Application Toolkit
Buttons
5-way Navigation, Power, Reset, Backlight, Camera, Send/End
Notifi cation
1st lenses - bi-color (green and red)
LED for network, standby, network
message, network status, notifi ca-
tion, and charging status
2nd lenses - bi-color (green and
blue) LED for WiFi and bluetooth
notifi cation
Notifi cation by sound, vibration, and
message on the display
Audio
Built-in microphone, dual receivers
Dual speakers for hands-free supported, full duplex, ear phone/microphone jack (3,5 Ø, stereo)
Supported formats: MP3, AAC, WAV,
WMA, SW polyphonic MIDI ring
tones, SMF/SP MIDI
Camera
Main image sensor: 1.3 Mega pixels
CMOS and second image sensor,
video/fl ash light, full screen preview
Connectivity/
Infrared IrDA FIR
Interfaces
SDIO/MMC card slot
Mini-USB (1.1)
Bluetooth /1.2 compliant)
WiFi 802.11 b (WPA, PSK, EAP-TLS,
PEAP, LEAP), WLAN antenna internal
Software
Word/Excel mobile, Pocket Outlook/
Internet Explorer, MSN Messenger,
Mediaplayer, ActiveSync, Games, Calculator, Voice Notes, Camera Capture
Utility and more.
Accessories
AC adapter w/Mini-USB plug, carrying case, sync cable (Mini-USB/USB),
battery, stereo headset, manual &
QuickStart Guide, software CD-ROM
