Briggs & Stratton AYP9182A79 PARTS LIST

AYP9182A79 (1997) Page 1 of 24
CHASSIS AND ENCLOSURES

AYP9182A79 (1997) Page 2 of 24
CHASSIS AND ENCLOSURES

Ref # Part Number Qty Description

1 155051 CHASSIS ASM
2 140356 SUB= 145009
3 17490612 SCREW
4 19131216 WASHER
5 155272 BUMPER-HOOD/DASH
6 155923 SADDLE
8 126471X "CLIP,INSULATOR"

9 147627X011 DASH.SILKSCREENED
10 72140608 SUB= 72110608
11 155927 "PANEL-DASH,LH"
12 145660 CLIP.TINNERMAN
13 155934X010 SUB= 169117X010
14 17490608 SCREW LT
15 74180512 SCREW
16 73510500 NUT
17 139394X505 SUB= 159639X505
20 156437 "PLATE-MTG,BATT/FU"
23 124028X SUB= 532124028
24 74780616 BOLT
25 19131312 WASHER
26 73800600 NUT
28 140434 GRILL.BLK
29 140273 LENS GRILLE
30 147310X505 FENDER LT
31 139976 BRACKET SUPT FEND
33 105476X505 FOOTREST LH
34 105475X505 FOOTREST RH
35 72110606 BOLT
37 17490508 SCREW LT
38 139886 BRACKET ASM LH
39 139887 BRACKET ASM RH
40 139977 SPACER FENDER LT
51 73800400 NUT
52 19091416 WASHER
53 144697 BRACKET.GRILLE.LH
54 17030814 SUB= 91817030814
55 144696 BRACKET.GRILLE.RH
57 74780412 SUB= 74780414
58 140547 DUCT.AIR.B&S.18HP

140 158418 BRKT SUSPENSION

5479J PLUG BUTTON T
134014 PLUG DOME

AYP9182A79 (1997) Page 3 of 24
DECALS

AYP9182A79 (1997) Page 4 of 24
DECALS

Ref # Part Number Qty Description

1 145005 DECAL.BATRY.3-3908

2 141517 DECAL DECK WIZ +

3 146676 DECAL.HD.RH.WIZAR

4 146615 DECAL.FENDER.WIZ

5 273063 DECAL, HP, ENGINE

6 157002 "DECAL DANGER,FEND"

7 4900J DECAL T

8 146677 DECAL.HD.LH.WIZAR

9 146615 DECAL.FENDER.WIZ
10 158270 DECAL INSERT HOOD
13 146678 DECAL.INS.STRG.WL
15 136832 DECAL
16 127521 NLA
19 156868 "DECAL INST,SADDLE"

138311 DECAL HANDLE LIFT
142341 DECAL DRAWBAR LH
157972 MANUAL.O.9182A79

AYP9182A79 (1997) Page 5 of 24
DRIVE

AYP9182A79 (1997) Page 6 of 24
DRIVE

Ref # Part Number Qty Description

1 REFER TO IMAGE

2 146682 SPRING.BRAKE.RETU

5 121520X STRAP TORQUE

6 17490512 SCREW

8 141003 ROD SHIFT FEND LT
10 76020416 PIN COTTER 1/8
13 74550412 BOLT.1/4-28.W/PAT
15 74490544 BOLT.HX.FLG.5/16
18 74780616 BOLT
19 73800600 NUT
21 106933X KNOB T (1/2-HOLE)
22 130804 BRAKE ROD
24 73350600 NUT
25 106888X SPRING ROD LT
26 19131316 WASHER
27 76020412 COTTER PIN
28 145204 ROD.BRAKE.PARK.LT
29 71673 PLUNGER CAP T
30 130807 TRANSAXLE MTG BKT
32 74760512 BOLT
34 155071 SHAFT ASM-PEDAL F
35 120183X NYLON BEARING
36 19211616 WASHER LT
37 1572H SUB= 2882J
38 123674X PULLEY.IDLER.FLAT
39 74760644 BOLT
40 4470J SPACER T
41 154777 SUB= 165692
42 19131312 WASHER
47 127783 SUB= 139245
48 154604 BELLCRANK ASM
49 123205X RETAIN BELT
50 74760624 SUB= 74930624
51 73680600 SUB= 73690600
52 73680500 SUB= 73690500
53 105710X "LINK, CLUTCH T"
55 105709X "SPRING, RETURN LT"
56 74760620 SUB= 74780620
57 156971 "V-BELT,GRD DRIVE"
59 140312 KEEPER BELT CNTSP
61 17490612 SCREW
62 8883R PEDAL COVER T
63 140186 PULLEY.ENGINE
64 71170764 BOLT
65 10040700 LOCKWASHER
66 154778 KEEPER-BELT
69 142432 SCREW HEXWSH H-L
70 134683 KEEPER BELT ENG
72 19132012 WASHER
74 156972 "SPACER AXLE,PVST"
75 121749X WASHER
76 12000001 E-RING LT
77 123583X SQUARE KEY
78 121748X WASHER
81 156969 SHAFT ASM CROSS
82 123782X "SPRING,TORSION"
83 19171216 WASHER
84 156962 "ROD TIE, PVST 20"""

AYP9182A79 (1997) Page 7 of 24
DRIVE

Ref # Part Number Qty Description

86 71208 BUSHING
87 19212016 WASHER D
88 12000008 KLIP RING
89 151147 SUB= 164893
95 156970 ROAD ASM BYPASS
96 4497H RETAINER M

100 19111216 WASHER M
113 127285X "STRAP,TORQUE"
116 72110610 BOLT RDHD 3/8-16
118 154774 SPACER-BELLCRANK
121 154419 NYLINER-CLUTCHING
122 156963 "PLATE-BYPASS,PVST"
123 19081016 WASHER
124 156967 SPRING RETURN
125 74780516 SUB= 77394
126 1685H SUB= 68478

AYP9182A79 (1997) Page 8 of 24
ELECTRICAL
