Models 01938-0 & 01815-0 Part No. 192384GS Rev.E (05/10/06)

Operator’s Manual

Manual del Operario

Manuel de l'Utilisation

Questions? Help is just a moment away!

Preguntas? La ayuda es justa un momento

lejos!

Vous avez des questions? Vous n'avez pas

besoin d'aller loin pour trouver de l'aide!

Call: Home Generator Helpline

Llamada: Línea Directa de Generador de Hogar

Appelez: Ligne Directe de Génératrice la Maison -

1-800-743-4115 M-F 8-5 CT

Web: www.homegeneratorsystems.com

10kW / 12kW Rated

Home Generator

Briggs & Stratton Power Products Home Generator

Operator’s Manual

TABLE OF CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

SAFETY RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation Assistance . . . . . . . . . . . . . . . . . . . . . . . . . 5

For the Home Owner: . . . . . . . . . . . . . . . . . . . . . 5

For the Installing Dealer/Contractor: . . . . . . . . . 5

OWNER ORIENTATION . . . . . . . . . . . . . . . . . . . . . . . . . 5

Fuel Factors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Power Decrease at High Altitude or High

Temperature . . . . . . . . . . . . . . . . . . . . . 6

Generator Location . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Generator Clearances . . . . . . . . . . . . . . . . . . . . . . . 6-7

Essential Circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Essential Circuit Selection . . . . . . . . . . . . . . . . 7-8

UNPACKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Delivery Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Shipment Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

KNOW YOUR HOME STANBY GENERATOR . . . . . . . . 9

KNOW YOUR SYSTEM CONTROL PANEL . . . . . . . . . 10

Access Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

To remove an access door: . . . . . . . . . . . . . . . . 11

To install an access door: . . . . . . . . . . . . . . . . . . 11

BEFORE INITIAL START-UP . . . . . . . . . . . . . . . . . . . . . . 12

Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Oil Considerations . . . . . . . . . . . . . . . . . . . . . . . 12

Battery Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Gaseous Fuel System . . . . . . . . . . . . . . . . . . . . . . . . 12

AUTOMATIC OPERATION . . . . . . . . . . . . . . . . . . . . . . 13

Checking Automatic Operation . . . . . . . . . . . . . . . . 13

Servicing the System . . . . . . . . . . . . . . . . . . . . . . . . . 13

Setting Exercise Timer . . . . . . . . . . . . . . . . . . . . . . . . 13

FAULT DETECTION SYSTEM . . . . . . . . . . . . . . . . . . . . . 14

Reset Fault Detection System . . . . . . . . . . . . . . 14

No LED - Discharged Battery . . . . . . . . . . . . . . 14

Low Battery Voltage . . . . . . . . . . . . . . . . . . . . . . 14

Low Oil Pressure . . . . . . . . . . . . . . . . . . . . . . . . 14

Low Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Engine Fail To Start . . . . . . . . . . . . . . . . . . . . . . . 15

Low Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Engine Overspeed . . . . . . . . . . . . . . . . . . . . . . . 15

Oil Temperature High . . . . . . . . . . . . . . . . . . . . 15

GENERATOR MAINTENANCE . . . . . . . . . . . . . . . . . . . 16

Changing Engine Oil . . . . . . . . . . . . . . . . . . . . . . . . . . 16

To Clean the Generator . . . . . . . . . . . . . . . . . . . . . . 16

When Calling the Factory . . . . . . . . . . . . . . . . . . . . . 16

STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20-37

FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38-56

Copyright © 2006 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power Products Group, LLC.

Briggs & Stratton Power Products Home Generator

Operator’s Manual

IMPORTANT SAFETY

RULES

The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION,WARNING), a pictorial and/or a safety message to alert you to hazards. DANGER indicates a hazard which, if not avoided, will result in death or serious injury. WARNING indicates a hazard which, if not avoided, could result in death or serious injury. CAUTION indicates a hazard which, if not avoided, might result in minor or moderate injury. CAUTION, when used without the alert symbol, indicates a situation that could result in equipment damage. Follow safety messages to avoid or reduce the risk of injury or death.

The manufacturer cannot possibly anticipate every possible circumstance that might involve a hazard.The warnings in this manual, and the tags and decals affixed to the unit are, therefore, not all-inclusive. If you use a procedure, work method or operating technique that the manufacturer does not specifically recommend, you must satisfy yourself that it is safe for you and others.You must also make sure that the procedure, work method or operating technique that you choose does not render the generator unsafe.

NOTE:Your generator is equipped with a spark arrester muffler.The spark arrester must be maintained in effective working order by the owner/operator. In the State of California, a spark arrester is required by law (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands.

Hazard Symbols and Meanings

SAVE THESE INSTRUCTIONS

Fire

Explosion

Toxic Fumes

Rotating Parts

Electrical Shock

Explosive Pressure

Chemical Burn

Hot Surface

• Operate generator ONLY outdoors.

• Keep exhaust gas from entering a confined area through windows, doors, ventilation intakes or other openings.

Running generator gives off carbon monoxide, an odorless, colorless, poison gas.

Breathing carbon monoxide can cause nausea, fainting or death.

WARNING

• DO NOT dispose of battery in a fire.

• DO NOT allow any open flame, spark, heat, or lit cigarette during and for several minutes after charging a battery.

• DO NOT open or mutilate the battery.

• Wear protective goggles, rubber apron, and rubber gloves.

• Remove watches, rings, or other metal objects.

• Use tools with insulated handles.

Storage batteries give off explosive hydrogen gas during recharging.

Slightest spark will ignite hydrogen and cause explosion.

Battery electrolyte fluid contains acid and is extremely caustic.

Contact with battery contents will cause severe chemical burns.

A battery presents a risk of electrical shock and high short circuit current.

DANGER

• DO NOT touch hot surfaces and avoid hot exhaust gases.

• Allow equipment to cool before touching.

• Keep at least 5 ft. (152 cm) clearance on all sides of generator including overhead.

• Code of Federal Regulation (CFR) Title 36 Parks, Forests, and Public Property require equipment powered by an internal combustion engine to have a spark arrester, maintained in effective working order, complying to USDA Forest service standard 5100-1C or later revision. In the State of California a spark arrester is required under section 4442 of the California Public resources code. Other states may have similar laws.

Running engines produce heat.Temperature of muffler and nearby areas can reach or exceed 150°F (65°C).

Severe burns can occur on contact. Exhaust heat/gases can ignite combustibles or

structures causing a fire.

WARNING

Briggs & Stratton Power Products Home Generator

Operator’s Manual

• DO NOT tamper with governed speed. Generator supplies correct rated frequency and voltage when running at governed speed.

• DO NOT modify generator in any way.

Excessively high operating speeds increase risk of injury and damage to generator.

Excessively low speeds impose a heavy load.

CAUTION

• See “Essential Circuits”.

• Start generator and let engine stabilize before connecting electrical loads.

Exceeding generators wattage/amperage capacity can damage generator and/or electrical devices connected to it.

CAUTION

• Use generator only for intended uses.

• If you have questions about intended use, ask dealer or contact Briggs and Stratton.

• Operate generator only on level surfaces.

• Adequate, unobstructed flow of cooling and ventilating air is critical to correct generator operation.

• The Oil Service door and/or the Control Panel door must be installed whenever the unit is running.

• DO NOT expose generator to excessive moisture, dust,dirt, or corrosive vapors.

• Despite the safe design of the Home Standby Generator, operating this equipment imprudently, neglecting its maintenance or being careless can cause possible injury or death.

• Remain alert at all times while working on this equipment. Never work on the equipment when you are physically or mentally fatigued.

• DO NOT start engine with air cleaner or air cleaner cover removed.

• DO NOT insert any objects through cooling slots.

• DO NOT use the generator or any of its parts as a step. Stepping on the unit can cause stress and break parts.This may result in dangerous operating conditions from leaking exhaust gases, fuel leakage, oil leakage, ect..

• If connected devices overheat, turn them off and disconnect them from generator.

• Shut off generator if:

-electrical output is lost;

-equipment sparks, smokes, or emits flames;

-unit vibrates excessively.

Improper treatment of generator can damage it and shorten its life.

CAUTION

• When using generator for backup power, notify utility company.

• DO NOT touch bare wires or receptacles.

• DO NOT use generator with electrical cords which are worn, frayed, bare or otherwise damaged.

• DO NOT handle generator or electrical cords while standing in water, while barefoot, or while hands or feet are wet.

• If you must work around a unit while it is operating, stand on an insulated dry surface to reduce shock hazard.

• DO NOT allow unqualified persons or children to operate or service generator.

• In case of an accident caused by electrical shock, immediately shut down the source of electrical power and contact the local authorities. Avoid direct contact with the victim.

• Before performing any maintenance on the generator, disconnect the battery cable indicated by a NEGATIVE, NEG or (-) first.When finished, reconnect that cable last.

• After your Home Standby Generator is installed, the generator may crank and start without warning any time there is a power failure.To prevent possible injury, always set the AUTO/OFF/MANUAL switch to OFF AND remove the 15 Amp fuse BEFORE working on the equipment.

Generator produces powerful voltage. Failure to properly ground generator can result

in electrocution. Failure to isolate generator from power utility

can result in death or injury to electric utility workers due to backfeed of electrical energy.

WARNING

• Install the fuel supply system according to applicable fuel-gas codes.

• Before placing the Home Standby Generator into service, the fuel system lines must be properly purged and leak tested.

• After the generator is installed, you should inspect the fuel system periodically.

• NO leakage is permitted.

• DO NOT operate engine if smell of fuel is present or other explosive conditions exist.

• DO NOT smoke around the generator.Wipe up any oil spills immediately. Ensure that no combustible materials are left in the generator compartment. Keep the area near the generator clean and free of debris.

Propane and Natural Gas are extremely flammable and explosive.

Fire or explosion can cause severe burns or death.

WARNING

Briggs & Stratton Power Products Home Generator

Operator’s Manual

SAVE THESE INSTRUCTIONS

This manual contains important instructions that should be followed during installation and maintenance of the generator and battery.

INTRODUCTION

Thank you for your purchase of a Briggs & Stratton

Home Standby Generator (HSG).This product is intended for use as an optional home standby system which provides an alternate source of electric power and to serve loads such as heating, refrigeration systems, and communication systems that, when stopped during any power outage, could cause discomfort, or the like.This product does not qualify for emergency standby as defined by NFPA 70 (NEC).

Briggs and Stratton has made every effort to provide for a safe, streamlined and cost-effective installation. Because each installation is unique, it is impossible to know of and advise the trade of all conceivable procedures and methods by which installation might be achieved. Neither could we know of possible hazards and/or the results of each method or procedure. For these reasons,

Only current licensed electrical and

plumbing contractors should attempt

HSG installations.

Installations must strictly comply with

all applicable codes, industry standards

and regulations.

Your Briggs & Stratton Home Standby Generator is supplied with this “Operator’s Manual” and a separate “Installation Manual” (part number 192385GS).These are important documents and should be retained by the owner after the installation has been completed.

Installation Assistance

For the Home Owner:

To help you make informed choices and communicate effectively with your installation contractor(s),

Read and understand the

Owner Orientation Section of this manual

BEFORE

contracting or starting

your HSG installation.

To arrange for proper installation, contact the store at which you purchased your Briggs & Stratton Home Standby Generator, your dealer, a licensed electrician or your utility power provider.

The HSG Warranty is V

OID unless the system

is installed by licensed electrical and

plumbing professionals.

For the Installing Dealer/Contractor:

For most applications, the Installation manual contains all

the information required to properly install and start the Home Standby Generator.This Operator’s Manual describes essential circuit selection, routine operation and owner maintenance procedures.

If you need more information, call 1-800-743-4115,

between 8:00 AM and 5:00 PM CT.

The Emission Control System for this generator is warranted for standards set by the U.S. Environmental Protection Agency and by the California Air Resources Board (CARB).

OWNER ORIENTATION

This section provides Home Standby Generator owners with the information necessary to achieve the most satisfactory and cost effective installation possible.

The illustrations are for typical circumstances and are meant to familiarize you with the installation options available with your Home Standby Generator.A thorough understanding of these options will provide fundamental control over the cost of your installation, as well as ensure your final satisfaction and security.

Federal and local codes, appearance, noise levels, fuel types, and distances are the factors that must be considered when negotiating with an installation professional. Remember that as the distance from the existing electrical service and gaseous fuel supply increases, equal compensations in piping and wiring materials must be allowed for.This is necessary to comply with local codes and overcome electrical voltage drops and gaseous fuel pressure drops.

The factors mentioned above will have a direct affect on the overall price of your Home Standby Generator installation.

NOTE: In some areas you may need to acquire electrical

permits for installing the Home Standby Generator, building permits for installing gas lines, and permits for noise allowances.Your installer should check your local codes AND obtain the permits before installing the system.

Briggs & Stratton Power Products Home Generator

Operator’s Manual

Fuel Factors

An important consideration affecting the entire installation is the type of fuel used by your Home Standby Generator. The system was factory tested and adjusted using natural gas as a fuel. Liquid propane (LP) may also be used as a fuel (see the Installation Manual).

Although there are specific factors that are inherent to each of these fuels, your location and the duration of possible utility interruptions should guide your selection of fuel type. For urban installations, Natural Gas (if available) should be your fuel of choice. For remote installations, a Liquefied Petroleum (LP) tank might better meet your needs.

For proper engine function, the following fuel guidelines are recommended:

• Use clean, dry fuel, free of moisture or any particulate material. Using fuels outside the following recommended values may cause performance problems.

In engines set up to run on propane (LP) gas, commercial grade HD5 propane with a minimum fuel energy of 2500 BTUs/ft

with maximum propylene

content of 5% and butane and heavier gas content of

2.5% and minimum propane content of 90%.

Power Decrease at High Altitude or High Temperature

Air density is less at high altitudes, resulting in less available engine power. Specifically,engine power will decrease 3.5% for each 1,000 feet (300 meters) above sea level and 1% for each 10° F (5.6°C) above 77°F (25°C). Make sure you and your installer consider these factors when determining total generator load.

Generator Location

The actual physical location of your HSG has a direct affect on:

1. The amount of plumbing required to fuel your generator.

2. The amount of wiring required to control and connect your generator.

NOTE: Specific location guidelines are discussed in the Installation Manual.Acquaint yourself with that information and confer with your installer. Be sure to ask how your site might affect installation costs and compliance with local codes and standards.

Home Standby Generator Location

Before installing generator, consult with homeowner and convey the following guidelines which may affect the desired location.

Generator Clearances

Place generator in a well ventilated area which will allow for removal of deadly exhaust gas. DO NOT install generator where exhaust gas could accumulate and enter inside or be drawn into a potentially occupied building. Ensure exhaust gas is kept away from any windows, doors, ventilation intakes or other openings that can allow exhaust gas to collect in a confined area (Figure 1). Prevailing winds and air currents should be taken into consideration when positioning generator.

General Location Guidelines

• Install the unit outdoors ONLY.

• Place the unit in a prepared location that is flat and has

provisions for water drainage.

• Install the unit in a location where sump pump discharge,

rain gutter down spouts, roof run-off, landscape irrigation, or water sprinklers will not flood the unit or spray the enclosure and enter any air inlet our outlet openings.

• Install the unit where the location of any services such as

phone, electrical, fuel, air conditioning, irrigation, including covered, concealed and underground services will not be affected or obstructed.

• The Home Standby Generator is equipped with an automatic safety gas “fuel shut-off” valve.

• DO NOT operate the equipment if the “fuel shut-off” valve is missing or inoperative.

Propane and Natural Gas is extremely flammable and explosive.

Fire or explosion can cause severe burns or death.

WARNING

• Operate generator ONLY outdoors.

• Keep exhaust gas from entering a confined area through windows, doors, ventilation intakes or other openings.

Running generator gives off carbon monoxide, an odorless, colorless, poison gas.

Breathing carbon monoxide will cause nausea, fainting or death.

WARNING

Briggs & Stratton Power Products Home Generator

Operator’s Manual

• Install the unit where air inlet and outlet openings will not become obstructed by leaves,grass, snow,etc. If prevailing winds will cause blowing or drifting, you may need to construct a windbreak to protect the unit.

• Install the generator as close as possible to the Transfer Switch to reduce the length of wiring and conduit.

• Install the generator as close as possible to the fuel supply to reduce length of pipes.

IMPORTANT: Laws or local codes may regulate the distance to the fuel supply.

The Home Standby Generator is shipped already attached to its mounting pad. Unless mandated by local code, a concrete slab is not required.

If mandated by local code, construct a concrete slab at least 3 inches thick and 6 inches longer and wider than the unit. Attach unit to slab with 1/4” diameter (minimum) masonry anchor bolts long enough to retain the unit.

Essential Circuits

As a Home Standby Generator owner, it is important that you clearly identify the circuits in your building that are "essential" to you.

It is important that your installer understand which

circuits you want to include as "Essential Circuits". Depending on the power consumed by these circuits,most or all of them can be switched to the Home Standby Generator for the duration of normal power interruption.

The wattage reference guide shown in Figure 2 will assist you with your decision-making process.It provides the wattage used by many ordinary household devices. Use it as a guide when selecting your essential circuits. Review this information with your installer and ask about any technical considerations that might affect the cost of your installation.

Figure 1 — Home Standby Generator Clearances

Exhaust

Port

Device

Running

Watts



Air Conditioner (12,000 Btu)*

1700



Air Conditioner (24,000 Btu)*

3800



Air Conditioner (40,000 Btu)*

6000



Battery Charger (20 Amp)

500



Circular Saw (6-1/2")

800 to 1000



Clothes Dryer (Electric)*

5750



Clothes Dryer (Gas)*

700



Clothes Washer*

1150



Coffee Maker

1750



Compressor (1 HP)*

2000



Compressor (1/2 HP)*

1400



Compressor (3/4 HP)*

1800



Curling Iron

700



Dehumidifier*

650



Electric Blanket

400



Electric Range (per element)

1500



Electric Skillet

1250



Freezer*

700



Furnace Fan (3/5 HP)*

875



Garage Door Opener*

500 to 750



Hair Dryer

1200



Hand Drill

250 to 1100



Iron

1200



Jet Pump*

800



Light Bulb

100



Microwave Oven

700 to 1000



Milk Cooler*

1100



Oil Burner on Furnace

300



Oil Fired Space Heater (140,000 Btu)

400



Oil Fired Space Heater (30,000 Btu)

150



Oil Fired Space Heater (85,000 Btu)

225



Radio

50 to 200



Refrigerator

700



Slow Cooker

200



Submersible Pump (1 HP)*

2000



Submersible Pump (1/2 HP)*

1500



Submersible Pump (1-1/2 HP)*

2800



Sump Pump*

800 to 1050



Table Saw (10")*

1750 to 2000



Television

200 to 500



Toaster

1000 to 1650

Figure 2 — Wattage Reference Guide

*Allow three (3) times listed watts for starting device

Briggs & Stratton Power Products Home Generator

Operator’s Manual

Essential Circuit Selection

When selecting the essential circuits that will be switched to “Standby Power,” it is important that the sum of the combined circuit loads does not exceed the wattage/amperage capacity of the generator.To help you with your selection of essential circuits, please consider the following:

Add up the total wattage of all electrical devices to be connected at one time.This total should NOT be greater than the generator’s wattage capacity.

The rated wattage of lights can be taken from light bulbs. The rated wattage of tools, appliances and motors can usually be found on a data plate or decal affixed to the device.

If the appliance, tool or motor does not give wattage, multiply volts times the ampere rating to determine watts (Volts x Amps = Watts).

Some electric motors (induction types) require about three times more watts of power for starting than for running.This surge lasts for only a few seconds. Be sure you allow for this high starting wattage when selecting electrical devices that will be energized by the Home Standby Generator:

• Figure the watts required to start the largest motor.

• Add that to the total running watts of all other connected loads.

This Briggs & Stratton Home Standby Generator complies with the following “stationary standby power rating”:

The standby power rating is applicable for supplying power for the duration of normal power interruption. NO sustained overload capability is available for this rating.

This rating is applicable to installations served by a reliable normal utility source.This rating is only applicable to variable loads with an average load factor of 80% of the standby rating.The standby rating is only applicable for optional standby power where the generator set serves as the backup to the normal utility source.

Use the “Wattage Reference Guide” provided and mark those circuits you consider “critical” or “essential”. Make sure you and your installer consider the system’s altitude above sea level and the ambient temperature range when determining total generator load.

IMPORTANT:When using the 100 Amp or 200 Amp transfer switch with the Home Standby Generator, you must

turn off any non essential loads. Failure to turn off non essential loads could overload the generator causing it to shut down. Some examples of non essential loads are as follows:

• Pool pump

• Hot tub

• Electric hot tub and/or pool heaters

• Central air conditioners

• Electric hot water heaters

• Electric range and/or oven

• Arc welder

• Non essential electric heaters

UNPACKING

Refer to the Installation Manual for detailed unpacking instructions, if desired.

Delivery Inspection

After removing the carton, carefully inspect the Home Standby Generator for any damage that may have occurred during shipment.

IMPORTANT: If loss or damage is noted at time of delivery, have the person(s) making delivery note all damage on the freight bill and affix his signature under the consignor's memo of loss or damage. If loss or damage is noted after delivery, separate the damaged materials and contact the carrier for claim procedures.Missing or damaged parts are not warranted.

Shipment Contents

The Home Standby Generator is supplied with:

• Home standby generator

• Attached mounting pad

• One 24” flexible fuel hook-up hose

• Installation manual (P/N 192385GS)

• Operator’s manual (P/N 192384GS)

• Illustrated parts list manual (P/N 193208GS for model 01815 or P/N 193918GS for model 01938)

• Installation checklist (P/N 190840GS)

• Three access door keys

• Four lifting hole plugs

• Oil fill spout

• Touch-up paint

• One spare 15 Amp fuse

• Diagnostic LED kit (diode/plate/decal/pin connectors (2))

Briggs & Stratton Power Products Home Generator

Operator’s Manual

KNOW YOUR HOME STANDBY GENERATOR

Read this Operator’s Manual and safety rules before operating your generator.

Compare the illustrations with your generator to familiarize yourself with the locations of various controls and adjustments. Save this manual for future reference.

15 Amp Fuse — Protects the DC control circuits. Air Cleaner — Uses a dry type filter element and foam

precleaner to limit the amount of dirt and dust drawn into the engine.

Battery — 12 Volt DC, 33 Amp-Hour sealed battery provides power to start the engine. Battery receives trickle charge whenever generator is not running.

Control Panel — Used for various test,operation and maintenance functions. See “KNOW YOUR SYSTEM CONTROL PANEL” on the next page.

Engine Label — Identifies engine model and type. Exhaust Port — High-performance muffler lowers engine

noise to comply with most residential codes.

Oil Dip Stick — Used to check the engine oil level. Oil Drain Hose — Provided to facilitate oil changing. Oil Fill Cap — Remove to service the engine with

recommended oil.

Oil Filter — Filters engine oil to prolong system life. Unit Data Decal — Identifies unit by serial number.

Air Cleaner

Oil

Filter

Battery Door Opening

Control Panel Door Opening

Unit

Data

Decal

Oil Service Door Opening

Exhaust

Port

Oil Dip Stick

Fuel Inlet

Control Panel

(see page 10)

Battery

Oil Drain Hose

Oil Fill Cap

15 Amp Fuse

Engine Label

Briggs & Stratton Power Products Home Generator

Operator’s Manual

KNOW YOUR SYSTEM CONTROL PANEL

Compare this Control Panel illustration with your generator to familiarize yourself with the location of these important controls:

Hour Meter

Circuit

Breaker

Set Exercise

Switch

AUTO/OFF/MANUAL

Switch

Diagnostic

LED

15 Amp

Fuse

15 Amp Fuse — Protects the Home Standby Generator DC control circuits. If the fuse has ‘blown’ (melted open) or was removed, the engine cannot crank or start. Replace the fuse using only an identical BUS AGC 15A fuse.

AUTO/OFF/MANUAL Switch — This three-position switch is the most important control on the system and is used as follows:

•“AUTO” position is the normal operating position. If a

utility power outage is sensed, the system will start the generator.When utility power is restored, lets the engine stabilize internal temperatures, shuts off the generator, and waits for the next utility power outage.

•“OFF” position turns off running generator, prevents

unit from starting and resets any detected faults.

•“MANUAL” position starts the engine after a short

amount of time. It is used for maintenance or diagnostic functions.

Circuit Breaker — Protects the system from shorts and other over-current conditions. Must be ON to supply power to the Automatic Transfer Switch.

Diagnostic LED — Used for troubleshooting operational problems with the Home Standby Generator.All fault conditions are described in the section “Fault Detection System”.

Hour Meter — The hour meter records the total number of hours the generator has been running and is used to schedule maintenance tasks.

Set Exercise Switch — Used to set the exercise cycle start time and day-of-the-week. Exercise cycle only occurs in AUTO mode.

Briggs & Stratton Power Products Home Generator

Operator’s Manual

Access Doors

The Home Standby Generator is equipped with an enclosure that has four access doors (Figure 3).The doors are named for a significant component located behind them. Starting with the side that has the fuel connection and proceeding clockwise, the doors are named:

• Oil Service door

• Air Intake door

• Control Panel door

• Battery door Each Home Standby Generator is equipped with three

identical keys.These keys fit the locks that secure the Oil Service and Control Panel doors.

To Remove an Access Door:

1. Insert key into lock of access door you wish to remove and turn one quarter turn clockwise.

NOTE:The key is retained in the lock when the locks are open.

2. Grasp door’s lift handle and pull door upwards until security pins are free of lower base.

3. With security pins free, pull lift handle outward (away) from unit while pulling door down and out of upper

door channel.The door will come free of generator enclosure.

The Battery door does not have a lock and the Air Intake door does not have a lock or lift handle.The Air Intake door is opened by lifting on the louvers instead of a lift handle. However, you must remove the door lock screws, found directly above the center of the doors.

To Install an Access Door:

1. Support door by grasping lift handle or louver. Guide top of door into generator enclosure.

2. Lift door up into its upper channel until security pins clear sill of enclosure.

3. Push lower half of door into door recess until it is flush with sides.

4. Seat door by pushing it down until rubber coated security pins engage and door rests on mounting sill.

5. If installing a lockable door, turn key one quarter turn counterclockwise. Remove key.

6. If installing air intake or battery door, replace the door lock screw.

Oil Service Door

Fuel Inlet

Exhaust

Port

Air Intake Door

Door Lock

Screw

Door

Lock

Screw

Battery Door

Control Panel Door

Figure 3 — Enclosure Access Doors

CAUTION

• Failure to install Oil Service and/or Control Panel doors while operating the Home Standby Generator will cause overheating.

DO NOT operate the Home Standby Generator unless the Oil Service and/or Control Panel doors are installed.

• DO NOT touch hot surfaces.

• Allow equipment to cool before touching.

Running engines produce heat.Temperature of exhaust port and nearby areas can reach or exceed 600°F (316°C).

Severe burns can occur on contact.

WARNING

Briggs & Stratton Power Products Home Generator

Operator’s Manual

BEFORE INITIAL START-UP

Engine Oil

This engine is shipped from the factory filled with the recommended oil. Before starting the engine, check oil level and ensure that engine is serviced as described in the engine operator’s manual.

Oil Considerations

Your Home Standby Generator is equipped with an engine that has been pre-run at the factory and does not require the traditional “break-in” procedure.

The system is filled with synthetic oil (API SJ/CF 5W-30W). This allows for system operation in the widest range of temperature and climate conditions.

NOTE:The use of synthetic oil DOES NOT alter the required oil change intervals described in the engine operator’s manual.

Battery Connection

The Home Standby Generator is supplied with a 12Volt DC 33 Amp-Hour, valve regulated battery.It is a sealed, lead-acid rechargeable battery. It is installed in the unit and the battery cables are connected at the factory.The generator’s 15 Amp fuse has been removed to prevent the unit from starting during shipping.

NOTE:With the battery installed, all wiring to transfer switch and Home Standby Generator completed, utility power supplied to the Automatic Transfer Switch, and the unit in AUTO mode, the battery receives a trickle charge while the engine is not running.The trickle charger cannot be used to recharge a battery that is completely discharged.

Gaseous Fuel System

• Ensure that all fuel connections are tight, secure and without leaks.

• Ensure that all shutoff valves are OPEN and that adequate pressure is available (see installation manual).

CAUTION

• Refer to engine manual for oil fill information.

• Damage to equipment resulting from failure to follow this instruction will void warranty.

Any attempt to crank or start the engine before it has been properly serviced with the recommended oil will result in equipment failure.

• DO NOT install the 15 Amp fuse until all plumbing and wiring has been completed and inspected.

Installing the 15A fuse could cause the engine to start.

CAUTION

• DO NOT operate engine if smell of fuel is present or other explosive conditions exist.

• If you smell ‘raw’ gaseous fuel (natural or LP) near the unit, immediately turn off the gas supply to the Home Standby Generator.

• Contact your gas utility or the system installer for assistance in determining the source of the smell.

Propane and Natural Gas is extremely flammable and explosive.

Fire or explosion can cause severe burns or death.

WARNING

Briggs & Stratton Power Products Home Generator

Operator’s Manual

AUTOMATIC OPERATION

To select automatic operation, do the following:

1. Set the service disconnect or main distribution panel circuit breaker that sends utility voltage to the transfer switch to ON.

2. Set the generator’s main circuit breaker to its ON position.

3. Set the AUTO/OFF/MANUAL switch to AUTO.

Checking Automatic Operation

To check the system for proper automatic operation, proceed as follows:

1. Turn OFF the service disconnect or main distribution panel circuit breaker sending power to the automatic transfer switch.

The engine will crank and start once the utility voltage drops out and the sensor has timed out. Let the system go through its entire automatic operation sequence.

2. With the generator output supplying its loads, turn ON the service disconnect or main distribution panel circuit breaker that supplies utility power to the Automatic Transfer Switch.

3. The automatic transfer switch will transfer loads back to the utility power after 5 minute minimum run time and utility is restored.

4. The generator will run for an additional one minute for engine cool down, then shut down.

NOTE: If generator does not shut down after 10 minutes, put AUTO/OFF/MANUAL switch to OFF and contact your installer or local service center.

This completes the test procedures for automatic operation.The Home Standby Generator will now start automatically when utility power is lost and will supply power to the transfer switch.

Servicing the System

To service system:

1. Set the AUTO/OFF/MANUAL switch to OFF.

2. Set the generator’s main circuit breaker to its OFF

position.

3. Utility voltage is present. Disconnect power before servicing by removing the two 2 Amp fuses from the transfer switch.

Setting Exercise Timer

The Home Standby Generator is equipped with an exercise timer that will start and exercise the system once every seven days. During this exercise period, the unit runs for approximately 20 minutes and then shuts down. Electrical load transfer DOES NOT occur during the exercise cycle (unless an utility power outage occurs).

A switch on the control panel is labeled “Set Exercise” (depicted on page 10).The specific day and the specific time of day this switch is pressed is programmed into the control board memory.This date and time is then used to automatically initiate the system exercise cycle.

To perform the Set Exercise procedure:

1. Choose the day and time you want your Home Standby Generator to exercise.

2. On that da

y and time, set the AUTO/OFF/MANUAL

switch to OFF.

3. Press and hold down the “Set Exercise” switch for two seconds.

4. Set the AUTO/OFF/MANUAL switch to AUTO.“Set Exercise” is complete.

For example, if you press the “Set Exercise” switch on Sunday morning at 10:00 AM, the unit will run an exercise cycle the following Sunday at 10:00 AM (+/- 1/2 hour).

NOTE:“Set Exercise” will only work if the unit is in the Automatic mode and this exact procedure is followed.The exerciser does not need to be re-set if the 15 Amp fuse is removed or changed.The exerciser will need to be re-set if the 12 Volt DC battery is disconnected.

If you want to change the day and time the unit exercises, simply perform the “Set Exercise” procedure at the exact weekday and time you want it to take place.

• To prevent possible injury that might be caused by such sudden starts, always set the AUTO/OFF/MANUAL switch to OFF.

• Remove the 15 Amp fuse before working on or around the generator or transfer switch.

With the switch set to AUTO, the engine may crank and start at any time without warning. Such automatic starting normally occurs when utility source voltage drops below a preset level or during the normal exercise cycle.

CAUTION

Briggs & Stratton Power Products Home Generator

Operator’s Manual

FAULT DETECTION

SYSTEM

The generator may have to run for long periods of time with no operator present. For that reason, the system is equipped with sensors that automatically shut down the generator in the event of potentially damaging conditions, such as low oil pressure, high oil temperature, over speed, and other conditions.

A light on the generator's control panel is called the Diagnostic LED.A similar LED indicator is installed at a convenient inside location. Both LED's will turn on and off in the same series of blinks if certain problems are detected in your HSG.The blink pattern is repeated with a brief pause between each series.The number of blinks in the series indicates the detected fault, as listed near the control panel, on the mounting plate and as follows:

Number of LED Flashes Fault Description

1 Low battery voltage 2 Low oil pressure 3 Low voltage 4 Engine fail to start 5 Low frequency 6 Engine overspeed 7 Oil temperature high

Reset Fault Detection System

The operator must reset the fault detection system each time it activates.To do so, place the AUTO/OFF/MANUAL switch in the OFF position for 30 seconds or more. Return the Home Standby Generator to service after correcting the problem by placing the AUTO/OFF/MANUAL switch in the AUTO position.

A description of each fault and suggested remedies are as follows:

No LED - Discharged Battery

This condition is caused by a completely discharged battery.To remedy the problem, remove the 15 Amp fuse and disconnect the battery from the generator.Take the battery to a local battery store for analysis.

Replace the battery after it has been fully recharged, connecting the NEGATIVE cable last. Install the 15 Amp fuse.

Low Battery Voltage

This fault is indicated by one blink.This condition occurs if the generator cannot start because the starting battery output power is below that needed to crank the engine. Causes for this problem may be a faulty battery or trickle charger circuit.

To remedy the problem, contact your local service center to check the battery trickle charge output. Remove the 15 Amp fuse and disconnect the battery from the generator. Take the battery to a local battery store for analysis.

Replace the battery after it has been fully recharged, connecting the NEGATIVE cable last. Install the 15 Amp fuse.

Low Oil Pressure

This fault is indicated by two blinks.The unit is equipped with an oil pressure switch (Figure 4) using normally closed contacts that are held open by engine oil pressure during operation. Should oil pressure drop below the 8 psi range, switch contacts close and the engine is shut down.

To remedy the low oil pressure condition, add the recommended oil to the FULL mark on the dipstick.

If low oil pressure condition still exists, engine will start, then shut down after about 10 seconds and diagnostic LED will flash. In this case, contact an authorized service facility.

Figure 4 — Low Oil Pressure & High Temp. Switches

High

Temperature

Switch

Oil Drain

Fitting

Oil

Pressure

Switch

Briggs & Stratton Power Products Home Generator

Operator’s Manual

Low Voltage (Generator)

This fault is indicated by three blinks.This condition is caused by a restriction in the fuel flow, a broken or disconnected signal lead, a failed alternator winding, the control panel circuit breaker is open, or Home Standby Generator is overloaded.

To remedy the problem, contact your local service center.

Engine Fail To Start

This fault is indicated by four blinks.This feature prevents the generator from damaging itself if it continually attempts to start in spite of another problem, such as no fuel supply. Each time the system is directed to start, the unit will crank for 15 seconds, pause for 15 seconds, crank for 15 seconds, pause for 15 seconds, and repeat. If the system does not begin producing electricity after approximately 90 seconds, the unit will stop cranking and the LED will blink.

The most likely cause of this problem is no fuel supply. Check the inside and outside fuel shut off valves to ensure they are fully open. Other causes could be failed spark plug(s), failed engine ignition, or the engine air filter is clogged.You may need to contact your installer for assistance if you can’t remedy these problems.

Low Frequency

This fault is indicated by 5 blinks.This feature protects devices connected to the transfer switch by shutting the generator down if the engine runs slower than the preset limit.

This condition is caused by a failed engine governor or by excessive loads on the generator.To remedy the problem, you may need to contact your installer or local service center for assistance.

Engine Overspeed

This fault is indicated by 6 blinks.This feature protects devices connected to the transfer switch by shutting the generator down if the engine happens to run faster than the preset limit.The overspeed fault is detected as follows:

• If the generator output frequency runs at 72 Hz for five seconds, the generator will shut down.

• If the generator output frequency reaches 75 Hz, the generator will shut down instantly.

This condition is caused by a failed engine governor.To remedy the problem, you should contact your installer or local service center for assistance.

Oil Temperature High

This fault is indicated by seven blinks.The contacts of the temperature switch (Figure 4) are normally open. If the engine oil temperature exceeds approximately 140°C (284°F), the fault is detected and the engine shuts down.

Common causes for this condition include running the unit with all access doors removed, obstructed air inlet or exhaust port, low oil level, or debris in the engine cylinder cooling fins.

To resolve the problem, remove any accumulated debris and obstructions and let the engine cool down. Ensure that the Oil Service door and/or the Control Panel door is installed whenever the unit is running.

Briggs & Stratton Power Products Home Generator

Operator’s Manual

GENERATOR

MAINTENANCE

The generator warranty does not cover items that have been subjected to operator abuse or neglect.To receive full value from the warranty, the operator must maintain the system as instructed in the engine operator’s manual.

All adjustments should be made at least once each season. Follow the requirements in the engine operator’s manual.

Generator maintenance consists of keeping the unit clean. Operate the unit in an environment where it will not be exposed to excessive dust, dirt, moisture or any corrosive vapors. Cooling air louvers on the enclosure must not become clogged with snow, leaves, or any other foreign material.

Check the cleanliness of the unit frequently and clean when dust, dirt, oil, moisture or other foreign substances are visible on its exterior/interior surface.

NOTE: DO NOT use direct spray from a garden hose to clean generator.Water can enter the engine and generator and cause problems.

Changing Engine Oil

• Place the oil drain tube into an approved container.

• Push in and rotate the oil drain fitting 1/4 turn counterclockwise. Slowly pull outward until oil starts draining (Figure 5). DO NOT pull the oil drain fitting off the engine.

• When the oil has drained, push the oil drain fitting in and rotate 1/4 turn clockwise until it locks in place.

• Slide the oil drain tube up into the clamp on the generator.

To fill your engine with oil:

• Follow the synthetic oil grade recommendation and oil fill instructions given in the engine operator’s manual.

To Clean the Generator

• Use a damp cloth to wipe exterior surfaces clean.

• Use a soft, bristle brush to loosen caked on dirt, oil, etc.

• Use a vacuum cleaner to pick up loose dirt and debris.

• Use low pressure air (not to exceed 25 psi) to blow away

dirt. Inspect cooling air slots and openings on the generator. These openings must be kept clean and unobstructed.

When Calling the Factory

You must have the following information at hand if it is necessary to contact a local service center regarding service or repair of this unit:

1. Obtain the unit Model Number and Serial Number

from the unit data decal. See “Know Your Backup Generator” diagram for location.

2. Obtain the engine Model/Type/Code numbers from the

engine label. See “Know Your Backup Generator” diagram for location. Please note that the model number may vary slightly from that presented herein.

STORAGE

The Briggs & Stratton Home Standby Generator is designed for continuous backup operational duty.As such, there is no need to take any storage precautions. However, if it becomes necessary to take the system out of service for an extended period, call Briggs and Stratton Technical Services at 1-800-743-4115, between 8:00 AM and 5:00 PM CT for specific recommendations.

Figure 5 — Oil Drain Fitting

CAUTION

• Refer to engine operator’s manual for oil fill information.

• Damage to equipment resulting from failure to follow this instruction will void warranty.

Any attempt to crank or start the engine before it has been properly filled with the recommended oil will result in equipment failure.

• DO NOT expose generator to excessive moisture, dust,dirt, or corrosive vapors.

• DO NOT insert any objects through cooling slots.

Improper treatment of generator can damage it and shorten its life.

CAUTION

Briggs & Stratton Power Products Home Generator

Operator’s Manual

TROUBLESHOOTING

Problem Cause Correction

Engine is running, but no AC output is available.

1. Circuit breaker open or defective.

2. Fault in generator.

3. Poor wiring connections or defective transfer switch.

1. Reset or replace circuit breaker.

2. Contact local service facility.

3. Check and repair.

Engine runs good at no-load but "bogs down" when loads are connected.

1. Short circuit in a connected load.

2. Generator is overloaded.

3. Shorted generator circuit.

4. Fuel Pressure is incorrect.

5. Natural gas fuel mixture is incorrect.

1. Disconnect shorted electrical load.

2. See "Essential Circuits".

3. Contact local service facility.

4. See "The Gaseous Fuel System" in the Installation Manual.

5. See "The Gaseous Fuel System" in the Installation Manual.

Engine will not start; or starts and runs rough.

1. 15 Amp fuse missing or blown.

2. Out of fuel.

3. Failed battery.

1. Install (new) 15 Amp fuse. See “Know Your System Control Panel”.

2. Open fuel valve(s); check propane tank.

3. Replace battery.

Engine shuts down during operation.

1. Out of fuel.

2. Fault indicator blinking.

1. Check fuel valves, fill propane tank.

2. Count blinks and refer to "Fault Detection System".

Loss of power on essential circuits.

1. Generator circuit breaker is open.

2. Transfer switch problems.

1. Reset circuit breaker.

2. See the transfer switch manual.

+ 39 hidden pages
