MODEL 63100 MOBILE EQUIPMENT CART
Important Information ........................................... 2
Safety Information ................................................2
Specifications ....................................................... 2
Assembly.............................................................. 2
Operation .............................................................3
Maintenance ....................................................... 3
Options, Accessories .......................................... 4
Limited Warranty ................................................. 4
7002 © ASU ni detnirP 101470 RevB# tnemucoD
Page 2
MOBILE EQUIPMENT CART
IMPORTANT INFORMATION
General
The Brewer Mobile Equipment Cart is designed to solve your storage shortages. The cart provides additional storage
for medical supplies as a room-to-room supply transport and a solution to a lack of cabinet space.
Service
If you require assistance with the installation or operation of your Brewer Mobile Equipment Cart, call the Brewer Customer
Service Department at 1.888.Brewer.1. Our trained staff will attempt to assist you in correcting the problem directly
over the phone. If service is required, a factory authorized technician will be sent to your location. Please fill in the
following information for use when calling The Brewer Company or your distributor with questions regarding your unit.
Date of Purchase
Model Number
SAFETY INFORMATION
Safety Information
The primary concern of The Brewer Company is that the
equipment is operated and maintained with the safety of
the patient and healthcare staff in mind. To ensure safe and
reliable operation:
• Read and understand all instructions in this manual
before attempting to install or operate the cart.
• Ensure that appropriate personnel are informed with
the manual contents. This is the responsibility of the
purchaser.
• Ensure that this manual is located near the cart, or if
possible permanently affixed to the cart.
SPECIFICATIONS
Please enter your model number, (from your invoice
or box label) for easy reference.
Failure to follow instructions with this symbol
could result in serious personal injury and/or
damage to the unit.
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury.
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in death
or serous injury.
CAUTION indicates an imminently or poten-
tial hazardous situation which, if not avoided, may
result in serious injury and/or equipment damage.
Weight of Cart .................................................... 90 lbs.
(With carton)..................................................... 100 lbs.
Top Weight Capacity ......................................... 100 lbs.
Drawer Weight Capacity ...................................15 lbs.
NO ASSEMBLY REQUIRED
Perform the following sequence when setting up the cart:
1. Carefully upack the cart.
2. Be sure casters are level.
3. Position cart in desired location.
NOTE: Inspect all boxes and contents for damage.
Report any damage to the carrier immediately.
NOTE: Save all packaging in case re-shipment is required.
Height ............................................................. 34.50 in.
Width ............................................................... 22.00 in.
Depth ................................................................ 21.50 in.
ASSEMBLY
CAUTION
• Exceeding the drawer capacity or extending
all drawers may cause the cart to tip.
• The cart weighs approximately 90 lbs. Two or
more people should assist in removing the cart
from the shipping carton.
• To avoid damaging the cart’s top or painted
surfaces, DO NOT use a knife or any other sharp
object to open the packaging.
7002 © ASU ni detnirP2 101470 RevB# tnemucoD
Page 3
OPERATION
MOBILE EQUIPMENT CART
Removing Drawers
1. Pull drawer out to stop.
2. Grab drawer by sides, lift slightly and
pull out.
Leveling the Casters
The casters are leveled at the factory. If an
adjustment is necessary follow the steps
shown in below.
1. Remove bottom drawer.
2. Loosen locknut.
3. Adjust height of caster
using a wrench on this hex.
Locking / Unlocking The Casters
Cleaning
Drawers and Top Surface
The cart drawers and top surface should be cleaned
daily by wiping with a damp cloth or sponge. Clean
periodically with a mild soap and water solution.
Painted Metal Surfaces
Wipe all painted metal surfaces with a damp cloth or
sponge at least once a week.
The top surface material is resistant to most medicinal-type stains, but may be damaged by solvents
and dyes. Remove any fluids which are spilled on the surface immediately. All surfaces should be
CAUTION
cleaned within your facility’s guidelines concerning antimicrobials and blood-borne pathogens.
Lock
Locking
Lever
MAINTENANCE
Preventative Maintenance
• Inspect the drawers by moving in and out to ensure
satisfactory operation.
• Check casters to ensure they are fastened properly
to the cabinet and the wheels spin freely.
Unlock
Note:
The lock prevents
rotation of the caster
wheel. The lock does
not prevent the caster
from swiveling.
3
7002 © ASU ni detnirP 101470 RevB # tnemucoD
Page 4
OPTIONS, ACCESSORIES, AND COMMON SERVICE PARTS
MOBILE EQUIPMENT CART
Drawer Organizer (optional)
100407
(available for small drawers only)
Small Drawer (replacement)
101528 kit
(includes drawer slides)
Large Drawer (replacement)
101529 kit
(includes drawer slides)
Top (replacement)
101526 kit
(includes mounting screws)
Caster (replacement)
101527 kit (set of 4)
LIMITED WARRANTY
The Brewer Company
GENERAL TERMS AND CONDITIONS
Warranty: The Brewer Company warrants its mobile cart to be free from defects in parts and workmanship under normal use
and service for a period of five (5) years from date of shipment. The Brewer Company will not be responsible for any Product failure
due to abuse, misuse, modification or improper use or for any use which exceeds the published capacity of the Product.
Products returned by prepaid freight for inspection and found defective will, at the option of The Brewer Company, be repaired or
replaced at no charge, but no claim for outside labor or other charges will be allowed. Products must not be authorization from
The Brewer Company. Requests for authorization must be in writing and accompanied by the original purchase order, The Brewer
Company invoice number and a copy of the invoice for the Product. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES AND REMEDIES WHATSOEVER, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY
AND/OR FITNESS FOR A PARTICULAR PURPOSE. NO AGENT, EMPLOYEE, OR REPRESENTATIVE OF THE B
HAS ANY AUTHORITY TO MAKE ANY AFFIRMATION, REPRESENTATION, OR WARRANTY NOT SET FORTH IN THESE TERMS
AND CONDITIONS CONCERNING ANY PRODUCTS OF THE BREWER COMPANY. THE BREWER COMPANY SHALL HAVE NO
LIABILITY WHATSOEVER FOR DAMAGES CAUSED BY TRANSPORTATION, ACCIDENTS, FIRE, UNAUTHORIZED ALTERATION,
OR NORMAL WEAR OR ABUSE, NOR SHALL THE BREWER COMPANY HAVE ANY LIABILITY WHATSOEVER FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES, including without limitation, lost profits or any such damages arising from (a) the design, manufacture,
sale, delivery, installation, repair, operation or use of products of The Brewer Company or any part thereof, (b) any actual or alleged
failure or defect in products of The Brewer company or any part thereof, or (c ) any actual or alleged breach or non-performance by
The Brewer Company of this limited warranty.
Freight Claims: Upon receipt, merchandise should be carefully examined to ascertain that proper amount has been received in
good condition. Any claim for shortage or damage must be made with delivering carrier within
We do not assume any responsibility for loss or damage in transit, and compensation for such loss must be obtained from the carrier.
five (5) days from receipt of goo
REWER COMPANY
ds.
