the Smart Rice Box
Instruction Book - LRC480
TM
Contents
IMPORTANT
SAFEGUARDS
2 Important Safeguards
8 Components
10 Functions
14 Rice Cooking Guide
18 Care & Cleaning
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition we ask
that you exercise a degree of
care when using any electrical
appliance and adhere to the
following precautions.
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
• Remove and safely
discard any packaging
material and promotional
labels before using the
rice cooker for the
first time.
• To eliminate a choking
hazard for young children,
remove and safely discard
the protective cover fitted
to the power plug of this
rice cooker.
• Do not place the rice
cooker near the edge of
a bench or table during
operation. Ensure that
the surface is level, clean
and free of water and
other substances.
2
• Position the lid so that
the steam vent is directed
away from you. Lift and
open the lid carefully
to avoid scalding from
escaping steam.
• Always ensure the
rice cooker is properly
assembled before use.
Follow the instructions
provided in this book.
• Always operate the rice
cooker on a stable and
heat resistant surface.
• Use the removable
cooking bowl supplied
with the rice cooker.
Do not use any other
bowl inside the rice
cooker housing.
• Do not use a damaged
or dented removable
cooking bowl. If damaged
or dented, replace bowl
before using.
• Do not operate the
rice cooker on a sink
drain board.
• Do not place anything
on top of the lid when
assembled, when in use
and when stored.
• Do not touch hot surfaces.
Use the handle for lifting
and carrying the
rice cooker.
• Do not use chemicals,
steel wool, metal scouring
pad or abrasive cleaners
to clean the outside of the
rice cooker housing or
cooking bowl as these
can damage the housing
or the coating of the
cooking bowl.
• Keep the rice cooker
clean. Follow the cleaning
instructions provided in
this book.
• Never plug in or switch
on the rice cooker without
having the removable
cooking bowl placed
inside the rice cooker
housing.
3
• Do not place food or
liquid in the rice cooker
housing. Only the
removable cooking bowl
is designed to contain
food or liquid.
• Never operate the rice
cooker without food and
liquid in the removable
cooking bowl.
• Do not touch hot surfaces,
use oven mitts to remove
the lid and or removable
cooking bowl. Lift the lid
carefully to avoid scalding
from escaping steam.
• Do not allow water from
the lid to drip into the rice
cooker housing, only into
the removable cooking
bowl.
• Do not leave the rice
cooker unattended when
in use.
• Extreme caution must be
used when the rice cooker
contains hot food and
liquids. Do not move the
appliance during cooking.
• The temperature of
accessible surfaces will be
high when the rice cooker
is operating and for some
time after use.
• Always insert the
connector end of the
power cord into the
appliance inlet before
inserting power plug
into the power outlet and
switching on appliance.
Ensure the appliance inlet
is completely dry before
inserting the connector
end of the power cord.
• To prevent scratching the
non-stick surface of the
removable cooking bowl,
always use wooded or
plastic utensils.
• Always position the steam
vent on lid away from
yourself to avoid scalding
from escaping steam.
• Ensure the removable
cooking bowl is correctly
positioned in the rice
cooker base before you
commence cooking.
4
• The appliance connector
and power cord must be
removed before the rice
cooker is cleaned and the
inlet must be dry before
use.
• To prevent damage to the
rice cooker do not use
alkaline cleaning agents
when cleaning, use a soft
cloth and mild detergent.
IMPORTANT
SAFEGUARDS
FOR ALL
ELECTRICAL
APPLIANCES
• Fully unwind the power
cord before use.
• Connect only to a 230V
or 240V power outlet.
• Do not let the power cord
hang over the edge of a
bench or table, touch
hot surfaces or
become knotted.
• To protect against electric
shock, do not immerse
the power cord, power
plug or appliance in water
or any other liquid or
allow moisture to come
in contact with the part,
unless it is recommended
in the cleaning
instructions.
• The appliance is not
intended for use by
persons (including
children) with reduced
physical, sensory or
mental capabilities,
or lack of experience
and knowledge, unless
they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their
safety.
• Children should be
supervised to ensure that
they do not play with the
appliance.
5
• It is recommended to
regularly inspect the
appliance. To avoid a
hazard, do not use the
appliance if power cord,
power plug or appliance
becomes damaged in
any way. Return the
entire appliance to
the nearest authorised
Breville Service Centre
for examination and/or
repair.
• Any maintenance other
than cleaning should
be performed at an
authorised Breville
Service Centre.
• This appliance is for
household use only.
Do not use this appliance
for anything other than
its intended use. Do not
use in moving vehicles
or boats. Do not use
outdoors. Misuse may
cause injury.
• The installation of
a residual current
device (safety switch)
is recommended to
provide additional safety
protection when using
electrical appliances.
It is advisable that a
safety switch with a rated
residual operating current
not exceeding 30mA be
installed in the electrical
circuit supplying the
appliance. See your
electrician for professional
advice.
• Always turn the appliance
to the OFF position,
switch off at the power
outlet and unplug at the
power outlet when the
appliance is not in use.
• Before cleaning, always
turn the appliance to the
OFF position, switch off at
the power outlet, unplug
at the power outlet and
remove the power cord,
if detachable, from the
appliance and allow all
parts to cool.
6
• Do not place this
appliance on or near
a heat source, such as hot
plate, oven or heaters.
• Position the appliance at
a minimum distance of
20cm away from walls,
curtains and other heat or
steam sensitive materials
and provide adequate
space above and on all
sides for air circulation.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
7
Components
A
B
C
D
E
8
F
G
H
L
I
J
K
A. Removable steam vent
B. Lid release button
C. Fuzzy Logic technology
D. 10 cup rice capacity
Makes up to 25 cups of cooked rice
E. Control panel with 8 pre-set cooking functions
- White rice - Steam
- Brown rice - Soup
- Sticky / Sushi - Porridge
- Fast cook - Cake
M
F. Detachable lid seal assembly
G. Carry handle
H. Anodized ceramic coated cooking bowl
I. Steaming basket
J. Removable power cord
K. Serving spoon
L. Serving ladle
M. Measuring cup
9
Functions
BEFORE FIRST USE
Remove all promotional labels and any
packaging materials from the rice cooker.
Ensure that you have all parts and accessories
listed before discarding the packaging.
Wash the cooking bowl, lid seal assembly,
steaming basket, measuring cup, serving
spoon and serving ladle in hot, soapy water,
rinse and dry thoroughly.
USING THE RICE COOKER
Ensure that the rice cooker housing and the
exterior of the cooking bowl are clean and clear
of any debris before placing the cooking bowl
into the bowl cavity. This will ensure proper
contact with the inner cooking surface.
Always ensure the lid seal assembly is properly
attached to the lid before cooking (instructions
to install and remove lid seal assembly on
page 18).
Insert the power cord into the power plug inlet
on the right hand side of the rice cooker. Plug
the power plug into a 230V or 240V power
outlet and switch on. The rice cooker will beep
once and the screen will illuminate, showing
the current internal temperature of the cooking
bowl.
The removable cooking bowl has cup and
liquid levels marked on the inside of the bowl.
Use these markings when cooking brown rice
or porridge only. For other rice types, follow the
ratios outlined on page 14 and 15.
When using the cup markings, place 2 cups
of rice in the bowl, then fill with liquid to
the 2 CUP marking. When using the liquid
markings, place 0.5kg of rice in the bowl, then
fill to the 0.5L marking with liquid.
COOKING FUNCTIONS
The Smart Rice Box has 8 pre-set cooking
functions; use the MENU button to navigate
between functions. The arrow next to the
function on the control panel will illuminate
and flash when a function is pending.
For all rice cooking functions, the LED screen
will display the current bowl temperature. The
cooking time cannot be adjusted on the rice
cooking and cake functions as the timing is
determined by the Fuzzy Logic technology.
For the steam, soup and porridge functions the
LED screen will display the default cooking
time. The cooking time can be adjusted for
these functions.
To adjust the cooking time, select the TIMER
button followed by the HOUR and MIN
buttons until the desired time is displayed on
the LED screen.
To confirm the function, select START. The
function arrow and START button will remain
illuminated to indicate that the cooking
function has commenced.
FUNCTION
White rice n/a n/a
Brown rice n/a n/a
Sushi / Sticky rice n/a n/a
Fast cook n /a n/a
Steam 40 minutes 30 – 60 minutes
Soup 60 minutes 30 – 180 minutes
Porridge 15 minutes 5 - 45 minutes
Cake n/a n/a n/a
DEFAULT
TIME
VARIABLE
TIME
PRE-SET
AVAILABLE
10
AUTOMATIC
KEEP WARM
MAX
CAPACITY
10 cups
10 cups
10 cups
10 cups
6 cups liquid
10 CUP marking
10 cups
2 CUP marking
COOKING RICE (USING THE WHITE
RICE - BROWN RICE - STICKY/SUSHI
RICE - FAST COOK FUNCTIONS)
1. Use the measuring cup, provided to
measure the required quantities of rice.
When using the cup always ensure to
measure a level cup, not heaped (Fig 1.).
Fig. 1
2. Wash the rice by placing it in a sieve under
cold running water. This will remove any
excess starch. The rice is ready when the
water runs clear from the sieve. Drain the
rice well before cooking.
3. Place the rice into the removable cooking
bowl, ensuring that it is evenly spread
across the bottom of the cooking bowl
(Fig 2.).
Fig. 2
4. Add the required quantity of water to the
cooking bowl, following the below ratios:
White rice = 1 measuring cup rice :
1 measuring cup water
Brown rice = 1 measuring cup rice :
Cup level marked on cooking bowl
(Refer to cooking tables on page 15 for more
information.)
NOTE
Always ensure that the lid seal assembly is
properly attached to the lid before cooking.
5. Close the lid, pressing down firmly to
ensure the lid securely clicks into place.
6. Press the MENU button until the arrow on the
LED screen illuminates next to the required
rice setting. Select the START button to
confirm the function and the rice cooker will
commence cooking.
7. Whist cooking, the arrow and START lights
will remain illuminated. The LED screen
will display a flashing rectangle (Fig 3.).
This indicates the fuzzy logic technology is
evaluating the contents of the cooking bowl
and determining the required cooking time.
Fig. 3
8. Once the rice cooker reaches the final stages
of cooking, it will beep and the LED screen
will display a countdown timer showing
the remaining cooking time. When this
countdown commences, it is recommended to
open the rice cooker lid and fluff up the rice,
using the rice serving spoon. The lid should
then be closed and the rice cooker left for the
duration of the timer.
9. Once the rice has been rested and the timer
has completed its countdown, the rice cooker
will beep before automatically switching
into KEEP WARM mode. The KEEP WARM
light will illuminate and the LED display will
commence counting upwards. If desired, the
rice can be rested for an additional 10 minutes
on KEEP WARM mode for extra fluffy rice.
10. Press the lid release button and use the rice
serving spoon to fluff up the rice before serving.
NOTE
The FAST COOK function is best suited to
cooking white rice quickly. When using brown,
rice it is recommended to rest the rice on KEEP
WARM for an additional 10 minutes after
cooking is complete.
CAUTION
Use caution when opening the lid after cooking
to avoid scalding from escaping steam.
11
11. Any remaining rice can remain in the rice
cooker on KEEP WARM, or alternatively,
turn the rice cooker off by pressing the
CANCEL button. Turn the rice cooker off at
the power outlet and remove the plug.
NOTE
The rice cooker can be left on KEEP WARM
for up to 24 hours, but for optimal quality, it
should only be left for 5 – 8 hours.
USING THE STEAM FUNCTION
Steamed foods retain most of their nutritional
value. Food may be steamed by placing it in
the steaming basket over stock or water in
the cooking bowl and closing the lid. When
steaming, it is important to keep the lid closed
as opening it will allow the steam to escape,
resulting in prolonged cooking times.
1. Place 4 measuring cups of water or stock
into the removable cooking bowl (use a
maximum of 6 measuring cups). Place
the removable cooking bowl into the rice
cooker housing.
2. Place the food being steamed directly into
the steaming basket, place the basket into
the cooking bowl and close the lid.
3. Press the MENU button until the arrow
to the left of STEAM illuminates and the
default time is displayed. Set the desired
steaming time by pressing the TIMER
and the MIN buttons. Select START to
commence cooking.
4. Once the timer displayed on the LED screen
reaches zero, the rice cooker will beep and
automatically change to KEEP WARM
mode.
5. Press the lid release button and carefully
allow the lid to open. Check to see if the
steamed food is ready.
6. If further cooking is required, check the
liquid levels in the removable cooking bowl
and if required, top up with hot liquid before
restarting the STEAM function. If no further
cooking is required, press the CANCEL
button, turn the rice cooker off at the power
outlet and unplug the power cord.
7. For further information on steaming, refer to
the Steaming Guide on page 18.
CAUTION
Use caution when opening the lid after cooking
to avoid scalding from escaping steam.
NOTE
The lid should be kept closed during the
cooking process to ensure that the steam
doesn’t escape, resulting in a prolonged
cooking time.
USING THE SOUP / PORRIDGE
FUNCTIONS
1. Place all ingredients in the removable
cooking bowl ensuring an even spread
across the bottom of the cooking bowl.
2. Close the lid, pressing down firmly until the
lid locks into place.
3. Press the MENU button until the arrow next
to the desired function is illuminated. The
default cooking time will be displayed on
the LED screen. To adjust the time, press
the TIMER button and the HOUR and MIN
buttons until the desired time is displayed.
To start cooking, press the START button.
4. Once the timer reaches zero, the rice cooker
will beep and automatically change to
KEEP WARM mode.
Soup
• The maximum capacity when using the
SOUP function is 3.2 litres. This is marked on
the cooking bowl as the 10 CUP or 1.8L line.
Porridge
• Ensure ratios are correct, before commencing
cooking. Refer to the Porridge cooking guide
on page 15.
• The maximum capacity is 10 cups of oats.
Exceeding the maximum will affect the
cooking results and may cause overflow.
• Once cooking is complete, stir well before
serving.
12
USING THE CAKE FUNCTION
The cake function is similar to the rice cooking
functions. The fuzzy logic technology will
determine the required cooking for the cake
based on the temperature of the mixture in the
bowl.
1. Place all combined ingredients into the
removable cooking bowl, ensuring an even
distribution over the base of the bowl and
select the CAKE function.
2. Once complete, use heat-proof mitts to
remove the cooking bowl. Turn the bowl
upside down to remove the cake. Place the
cake on a cooling rack to cool.
• The cooking bowl will make 1 x 21cm round
cake.
• Cake batter should not exceed the 2 CUP level
marking on the inside of the cooking bowl.
• Lightly spray the inside of the removable
cooking bowl with cooking spray, then wipe
with paper towel before adding cake batter.
USING THE REHEAT FUNCTION
The reheat function is programmed to reheat
cold cooked rice to serving temperature. This
setting is best suited to reheating smaller
quantities of cooked rice. It is recommended to
not exceed the 4 cup marking on the cooking
bowl.
The timer cannot be adjusted when using this
function, as the rice cooker is programmed to
heat the rice contents to the correct serving
temperature before switching to the KEEP
WARM mode.
1. Place the rice to be reheated into the
cooking bowl. Loosen the rice with a fork
and add a small amount of water to avoid
sticking or burning.
2. Select the REHEAT button. The light
will remain illuminated for the reheating
process. Once the rice has reached serving
temperature, the rice cooker will beep
before automatically changing to KEEP
WARM mode.
USING THE KEEP WARM FUNCTION
All functions on this rice cooker will
automatically switch into KEEP WARM mode
once the cooking process is complete. When
the rice cooker is on KEEP WARM mode the
KEEP WARM light will remain illuminated
and the LED display will count up.
The maximum amount of time that the rice
cooker will remain on KEEP WARM mode is
24 hours. To ensure the quality of the cooked
food, it should not be held on KEEP WARM for
longer than 8 hours. For optimum quality rice,
it should only be left on KEEP WARM for 5-8
hours.
USING THE PRE-SET TIMER
FUNCTION
The pre-set timer can be used on all functions,
except for CAKE. The pre-set timer allows you
to set the rice cooker to commence cooking
and finish by a specified timer.
To set the timer, select the desired cooking
function then press PRESET. Use the HOUR
and MIN buttons to adjust the timing as
shown on the screen (the time being set is the
finishing time). Select START and the rice
cooker will start counting down.
For example: On the PORRIDGE function,
setting 2 hour and 30 minutes, means that the
rice cooker will complete the cooking cycle and
the porridge will be ready to serve in 2 hour
and 30 minutes.
CANCEL BUTTON
The CANCEL button can be pressed at any
time to stop and cancel a cooking function.
The rice cooker will return to standby mode
once the cooking function has been cancelled.
Pressing the CANCEL button again will place
the rice cooker into KEEP WARM mode. The
light will remain illuminated and the LED
display will commence counting up.
Food should not be place into KEEP WARM
mode unless the cooking cycle has completed.
13
Rice Cooking Guide
The measuring cup provided with the Smart Rice Box is used in the following cooking tables.
The measuring cup is approximately 150g of rice or 180ml of water.
White Rice
CUPS UNCOOKED
WHITE RICE
2 cups 2 cups 5 cups 34 minutes 29 minutes
4 cups 4 cups 10 cups 37 minutes 33 minutes
6 cups 6 cups 15 cups 39 minutes 35 minutes
8 cups 8 cups 20 cups 41 minutes 37 minutes
10 cups 10 cups 25 cups 45 minutes 40 minutes
Brown Rice
CUPS UNCOOKED
BROWN RICE
2 cups 2 level marking 4 cups 65 minutes 35 minutes
4 cups 4 level marking 8 cups 68 minutes 37 minutes
6 cups 6 level marking 14 cups 70 minutes 40 minutes
8 cups 8 level marking 20 cups 72 minutes 43 minutes
10 cups 10 level marking 24 cups 74 minutes 45 minutes
CUPS COLD TAP
WATER
COLD TAP WATER
(FILL TO)
CUPS COOKED
RICE (APPROX)
CUPS COOKED
RICE (APPROX)
COOKING TIME ON
WHITE FUNCTION
(APPROX)
COOKING TIME ON
WHITE FUNCTION
(APPROX)
COOKING TIME
ON FAST COOK
(APPROX)
COOKING TIME
ON FAST COOK
(APPROX)
Porridge
OATS MILK / WATER SERVES
2 cups 3 cups 2 serves 9 minutes
4 cups 6 cups 6 serves 15 minutes
6 cups 9 cups 9 serves 20 minutes
8 cups 12 cups 12 serves 25 minutes
10 cups 15 cups 15 serves 30 minutes
SUGGESTED COOKING
TIME
The above ratios are a guide, liquid levels should be increased or decreased based on your
personal preference.
14
SUSHI RICE
INGREDIENTS
4 cups medium grain white rice
6 cups water
4 tablespoons rice vinegar
4 tsp caster sugar
¾ tsp salt
METHOD
1. Rinse the rice and place into the removable
cooking bowl with the water. Close the lid,
select the SUSHI / STICKY function and
press the START button.
2. Place the rice vinegar, sugar and salt into a
small bowl and stir until the sugar and salt
is dissolved.
3. Once the cooking process has finished,
open the lid and stir the rice vinegar
mixture through the rice.
4. Transfer the rice to a large, shallow dish and
spread to cool.
5. Use immediately as required in sushi
recipes.
STICKY RICE
INGREDIENTS
2 cups glutinous rice
1 litre water (for soaking)
2½ cups water (for cooking)
METHOD
1. Soak rice in water overnight.
2. Drain and rinse the rice. Place the rice and
water into the removable cooking bowl and
close the lid.
3. Select the SUSHI / STICKY function then
press the START button.
4. Once the cooking process has finished,
allow the rice to rest on KEEP WARM for 5
minutes before serving.
TIPS
• Add a little bit extra water for fluffier rice or
a little bit less water for firmer rice, this will
depend on personal preference.
• Washed rice will have some extra water
after rinsing, this extra water may lead to an
increased cooking time. Reduce the measured
amount of water added, if necessary.
• Some rice varieties may require more water
for cooking, such as wild rice blends, Arborio
rice or short grain rice. Follow the directions
on the pack or use the brown rice cooking
table as a guide.
• Do not fill the removable cooking bowl above
the MAX level marking indicated.
RICE VARIATIONS
• Savoury rice: prepare rice in the rice cooker
as specified, but substitute water with
the same volume of chicken, beef, fish or
vegetable stock.
• Sweet rice: prepare rice in the rice cooker
as specified, substituting half the water with
apple, orange or pineapple juice.
• Saffron rice: Add ½ teaspoon of threads to
every 2 cups of water. Follow the white rice
cooking table and mix well when cooking is
complete.
• Arborio rice: follow the brown rice
cooking tables.
• Jasmine rice: follow the white rice cooking
tables.
• Basmati rice: follow the white rice cooking
tables.
• Wild rice: It is not recommended to cook
wild rice alone in the rice cooker as it requires
substantial amounts of water. Blend wild rice
with white or brown rice for best results.
15
Steaming Guide
Steaming Vegetables:
• Smaller pieces will steam faster than larger pieces.
• Vegetables should be a uniform size to ensure a more consistent cooking result.
• Fresh or frozen vegetables can be steamed, though frozen will take longer to cook.
• If steaming frozen vegetables, do not thaw before cooking.
• Size and shape of vegetables and personal preference may call for adjustments to the advised
cooking times. For softer vegetables, allow extra cooking time.
• Do not allow the water or stock in the removable cooking bowl to reach the steaming tray.
VEGETABLES PREPARATION & TIPS QUANTITY COOKING TIME
Asparagus trim, leave as spears 2 bunches 12 - 16 minutes
Beans top and tail, leave whole 250g 15 - 20 minutes
Broccoli cut into florets 250g 13 - 16 minutes
Brussel Sprouts cut a cross in the base 350g 27 – 29 minutes
Carrots cut into batons 3 medium 20 - 25 minutes
Cauliflower cut into florets 350g 25 - 30 minutes
Corn whole corn cobs 2 small cobs 20 - 25 minutes
Snow peas topped and tailed 250g 12 - 15 minutes
Peas fresh, peeled 250g 15 - 18 minutes
Peas frozen 250g 12 - 15 minutes
Potatoes new, chat whole 8 (80g each) 40 - 50 minutes
Sweet Potato cut into pieces 400g 25 - 30 minutes
Pumpkin cut into 3 cm pieces 400g 24 - 29 minutes
Spinach (English) leaves and stems cleaned 1 bunch 12 - 15 minutes
Squash (baby) topped and tailed 350g 20 - 25 minutes
Turnips peeled and cut into 3cm pieces 350g 30 - 35 minutes
Zucchini cut into 3cm pieces 330g 17 - 20 minutes
(APPROX)
16
Steaming fish and seafood
• Season fish with fresh herbs, onions, lemon etc. before cooking.
• Ensure fish fillets are in a single layer in the basket and do not overlap.
• Fish is cooked when it flakes easily with a fork and is opaque in colour.
TYPE SUGGESTIONS AND TIPS COOKING TIME (APPROX)
Fish – fillets
– whole
– cutlets
Mussels – in shell Clean and remove beard, steam until just opened 15 - 18 minutes
Clams and Pipis Clean, steam until just opened 18–20 minutes
Prawns – in shell Steam until pink 17 - 22 minutes
Scallops Steam until opaque 18 - 22 minutes
Steam until opaque and easy to flake. A cutlet is cooked
when the centre bone is able to be easily removed.
18 – 20 minutes
25 - 30 minutes
20 - 22 minutes
Steaming poultry
• Select similar sized pieces of poultry to ensure even cooking.
• For even cooking results arrange poultry in a single layer in the basket.
• Remove visible fat and skin.
• To obtain a browned appearance, sear the chicken before steaming.
• Check poultry is cooked by piercing the thickest part. It is cooked when the juices run clear.
TYPE SUGGESTIONS AND TIPS COOKING TIME (APPROX)
Breast fillet Place the thickest part of the chicken fillet to outside of
Drumstick Place thickest part to outside of the steaming tray 35 - 40 minutes
Thigh fillet Place thickest part to outside of the steaming tray 28–32 minutes
the steaming tray. (200g)
22 - 25 minutes
Steaming dumplings
• Fresh or frozen dumplings and savoury buns can be steamed.
• Place small pieces of baking paper, or cabbage or lettuce leaves, under the dumplings to avoid
sticking to the steaming tray.
TYPE SUGGESTIONS AND TIPS COOKING TIME (APPROX)
BBQ pork or chicken buns Cook from frozen 22 - 27 minutes
Dumplings – frozen Separate before cooking 20 - 25 minutes
Dumplings – fresh 25 - 29 minutes
17
Care & Cleaning
Switch the rice cooker off at the power outlet
and unplug the cord.
WARNING
Allow all parts of the rice cooker to cool before
disassembling and cleaning.
1. Ensure that all parts of the rice cooker have
completely cooled before attempting to
disassemble or clean the rice cooker.
2. Open the rice cooker lid and detach the
lid seal assembly. Use both hands to
simultaneously press on the clips at the top
left and right of the lid housing until the lid
seal assembly is detached from the lid
(Fig. 4).
Press Press
Fig. 4
3. Use an absorbent sponge or paper towel
to wipe the moat around the cooking bowl
cavity for any liquid that may have collected
during the cooking process.
4. Close the lid of the rice cooker and remove
the steam vent from the lid. Place your
fingers under the back edge of the vent and
lever upwards, until the vent pops out
(Fig 5.).
Fig. 5
5. On the underside of the vent, the locking
graphic indicates how to separate the two
parts of the vent for cleaning.
6. Open the lid of the rice cooker and remove
the removable cooking bowl from the bowl
cavity. Wash the removable cooking bowl,
lid seal assembly, steam vent, steaming tray,
serving spoon, serving ladle and measuring
cup in hot, soapy water, rinse and dry
thoroughly.
7. Once fully dried, place the removable
cooking bowl into the bowl cavity in the rice
cooker housing then reattach the lid seal
assembly, and steam vent.
8. Slide the base of the lid seal assembly into
the grooves at the base of the lid, then lift
and press the clips on the lid seal assembly
into the lid until they click into place.
9. Reassemble the steam vent, ensuring the
parts are locked into place. Place the steam
vent into the hole on the lid of the rice
cooker, with the steam hole at the back.
Press down on the front and then the back
of the steam vent until it clips securely into
place.
18
WARNING
Do not wash any parts of the Smart Rice
Box in the dishwasher. Dishwashers use
harsher cleaning detergents and high water
temperatures that could damage or distort
parts of the rice cooker.
WARNING
Do not use abrasive cleaners, steel wool or
metal scouring pads to clean the removable
cooking bowl, as they will damage the cooking
surface. If rice or other food has cooked onto
the removable cooking bowl, fill the bowl with
hot, soapy water and leave to stand for 10
minutes before cleaning.
10. Use a soft, damp cloth to wipe over the
outer housing of the rice cooker then dry
thoroughly.
11. Once all parts are clean and dry, store the
accessories, steaming tray and power cord
in the rice cooker and close the lid. Rice
cooker is ready to be stored away.
WARNING
The detachable power cord must be removed
from both the power outlet and rice cooker
before the rice cooker is cleaned.
WARNING
Do not immerse the rice cooker housing or
power cord in water or any other liquid as this
may cause electrocution.
WARNING
Do not use chemicals, steel wool, metal
scouring pads or abrasive cleaners to clean the
rice cooker as these can damage the housing or
the coating on the removable cooking bowl.
19
Breville Customer Service Centre
Australian Customers
Mail: Locked Bag 2000
Botany NSW 1455
AUSTRALIA
Phone: 1300 139 798
Fax: (02) 9700 1342
Customer Service:
Email:
askus@breville.com.au
New Zealand Customers
Mail: Private Bag 94411
Botany Manukau 2163
Auckland NEW ZEALAND
0800 273 845
Phone:
Fax: 0800 288 513
Customer Service:
Email:
askus@breville.co.nz
Web: www.breville.co.nzWeb: www.breville.com.au
Breville is a registered trademark of Breville Pty. Ltd. A.B.N. 98 000 092 928.
Due to continued product improvement, the products illustrated/photographed
in this brochure may vary slightly from the actual product.
Copyright Breville Pty. Ltd. 2017.
LRC480 ANZ–A17
Loading...
