the AirRounder Plus

Instruction Book - LPH708

Connect

SPECIFICATIONS

Contents

2 Breville Recommends Safety First 8

Components

Remote Control Panel 9 Control Panel 9 Display Screen 10 Features 11 Assembly 12 Functions 17 Wi-Fi Connectivity

& Voice Assistants 20 Care, Cleaning & Storage 21 Replacing the Filter 22 Troubleshooting

BREVILLE RECOMMENDS SAFETY FIRST

At Breville we are very safety conscious. We design and manufacture consumer products with the safety of you, our valued customer, foremost in mind. In addition, we ask that you exercise a degree of care and adhere to the following precautions.

Filter Life Approx. 9 months Product

Dimensions (HxWxL mm) For room size 30 to 40m² Noise level (Max) 60dBA Power Consumption 2100W Weight Approx. 5.4kg OS Compatibility Android

591.5 x 253.8 x 253.8

5.0 or later and

iOS 9.0 or later

IMPORTANT SAFEGUARDS

READ ALL INSTRUCTIONS BEFORE USE AND SAVE FOR FUTURE REFERENCE

• Carefully read all instructions before operating the puriﬁer fan heater for the ﬁrst time and save for future reference.

• Always ensure the puriﬁer fan heater is properly assembled before use. Follow the instructions provide in this instruction book.

• Remove and safely discard any packaging material and promotional labels before using the puriﬁer fan heater for the ﬁrst time.

• To eliminate a choking hazard for young children, remove and safely discard the protective cover ﬁtted to the power plug of this puriﬁer fan heater.

• Avoid touching the puriﬁer fan heater body while it is on as some parts of the puriﬁer fan heater are hot. When moving the puriﬁer fan heater, switch OFF and let the puriﬁer fan heater cool down before attempting to move it.

• When moving the puriﬁer fan heater, always carry the puriﬁer fan heater by the base. Do not attempt to move the puriﬁer fan heater by the power cord.

• Keep combustible materials such as drapes and other furnishings at least 1.7 meters from the front, sides and rear of the puriﬁer fan heater.

• Extreme caution and supervision are necessary when this puriﬁer fan heater is used by or near children, invalids or animals.

• Children should be supervised to ensure that they do not play with the puriﬁer fan heater.

• Do not use this puriﬁer fan heater in the immediate surroundings of a bath, a shower or a swimming pool. Do not immerse or allow liquids to be spilt on the puriﬁer fan heater.

• Do not use the puriﬁer fan heater to dry your laundry.

• This puriﬁer fan heater has hot and arcing or sparking parts inside. Do not use in areas where petrol, paints, aerosols or other ﬂammable substances are used or stored.

• Do not allow materials that have been in contact with oil, petroleum-based products or drying ﬂuids to come in contact with the puriﬁer fan heater.

• Do not operate the puriﬁer fan heater on an incline plane.

• Only use the puriﬁer fan heater on a horizontal and stable surface.

• Do not leave the puriﬁer fan heater unattended. Always switch the puriﬁer fan heater OFF at the controls and at the power outlet then unplug the puriﬁer fan heater from the power outlet when not in use.

• Do not operate puriﬁer fan heater whilst asleep.

• Do not operate the puriﬁer fan heater with a damaged cord or plug, or if the puriﬁer fan heater has been dropped or damaged in any matter, return the puriﬁer fan heater to your nearest Breville service centre for examination, electrical or mechanical adjustment or repair.

• Do not operate the puriﬁer fan heater with the power cord damaged, frayed or split, wound around any part of the puriﬁer fan heater, or in contact with heated surfaces of the heater.

• Do not run the cord under carpeting or cover the cord with rugs, runner of the like. Arrange the cord away from trafﬁc areas and where it will not be tripped over.

• Do no locate the puriﬁer fan heater immediately below socket outlet when in use.

• Do not use this puriﬁer fan heater with a programmer, timer or any other device that switches the puriﬁer fan heater on automatically since a ﬁre risk may exist if the puriﬁer fan heater is covered or positioned incorrectly.

• This puriﬁer fan heater is not intended for use in wet or moist locations.

• To disconnect the puriﬁer fan heater, switch the power switch to OFF, then switch off at the power outlet then remove plug from the outlet.

• Do not insert or allow foreign objects to pass through the inlet or outlet openings. This may cause an electric shock, ﬁre or damage the puriﬁer fan heater.

• To prevent a possible ﬁre or heat damage, allow ample space around the puriﬁer fan heater (at least 1.7m at the front, 0.5m at the rear, top and sides) and do not totally or partially block the air inlet or outlets in any manner. Check the openings from time to time for accumulated dust. Ensure long shag carpet does not obstruct airﬂow under the unit.

• Do not touch hot surfaces or the front grill when in operation or for some time after, as these surfaces may be hot.

• Switch the puriﬁer fan heater to OFF, then turn off at the power outlet and unplug. Allow the puriﬁer fan heater to cool down before cleaning or storing.

• Do not operate the puriﬁer fan heater on a sink or drain board.

• To avoid an electrical overload, it is recommended that no other appliances are plugged into the same circuit as your puriﬁer fan heater when it is in use.

• Do not move the puriﬁer fan heater when it is switched on.

• Do not use outdoors. This puriﬁer fan heater is not intended for commercial use such as construction sites.

• Use this puriﬁer fan heater only as described in this instruction manual. Any other use not recommended by the manufacturer may cause ﬁre, electric shock or injury and void all warranties.

• Regularly inspect the supply cord, plug, control settings, air inlets and outlets and main housing for any damage. If found damaged in any way, immediately cease use of the puriﬁer fan heater and return to Breville or an authorized service agent for inspection or repair.

• Do not unplug the puriﬁer fan heater by pulling on the power cord. Always unplug using the power plug.

• To disconnect the puriﬁer fan heater, switch the heater to OFF, then switch off at the power outlet and remove the plug from the power outlet. Allow the puriﬁer fan heater to cool down before cleaning and storing.

• Keep the puriﬁer fan heater and ﬁlter clean. Follow the cleaning instructions provided in this book.

• To prevent a possible ﬁre or heat damage in heating mode in heating mode, do not operate the unit remotely using the Breville Home Connect™ app when the unit is unattended.

IMPORTANT SAFEGUARDS FOR ALL ELECTRICAL APPLIANCES

• Fully unwind the power cord before use.

• Connect only to a 230V or 240V power outlet.

• Do not let the power cord hang over the edge of a bench or table, touch hot surfaces or become knotted.

• To protect against electric shock, do not immerse the power cord, power plug or appliance in water or any other liquid or allow moisture to come in contact with the part, unless it is recommended in the cleaning instructions.

• The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• It is recommended to regularly inspect the appliance. To avoid a hazard, do not use the appliance if power cord, power plug or appliance becomes damaged in any way. Return the entire appliance to the nearest authorized Breville service centre for examination and / or repair.

• Any maintenance other than cleaning should be performed at an authorised Breville Service Centre

• This appliance is for household use only. Do not use this appliance for anything other than its intended use. Do not use in moving vehicles or boats. Do not use outdoors. Misuse may

cause injury.

• The installation of a residual current device (safety switch) is recommended to provide additional safety protection when using electrical appliances. It is advisable that a safety switch with a rated residual operating current not exceeding 30mA be installed in the electrical circuit supplying the appliance. See your electrician for professional advice.

• During electrical storms, the appliance should be disconnected from the power source at the wall socked to prevent any electrical surges that may arise during the storm and which may inadvertently cause damage to the appliance and its electronic componentry.

• Always turn the appliance to the OFF position, switch off at the power outlet and unplug at the power outlet when the appliance is not in use.

• Before cleaning, always turn the appliance to the OFF position, switch off at the power outlet, unplug at the power outlet and remove the power cord, if detachable, from the appliance and allow all parts to cool.

• Do not place this appliance on or near a heat source, such as hot plate, oven or heaters.

• Position the appliance at a minimum distance of 1m away from walls, curtains and other heat or steam sensitive materials and provide adequate space above and on all sides for air circulation.

FOR HOUSEHOLD USE ONLY SAVE THESE INSTRUCTIONS

Components

A G I

A. Touch Control Panel B. Light Ring C. Front Grille D. LED Display E. Front Vent F. Oscillating Base (up to 360 degrees) G. Remote Control H. 3- Layer Filter I. Removable Back Vent (rear cover)

NOT PICTURED

• Power Cord and Plug

• Remote Control Storage

• Non-Slip/Non-Marking Rubber Feet

60° 120° 360°

C E

1H-7H

LO MED HI

SET TEMP

LO MED HI

REMOTE CONTROL PANEL

A. Power ON/OFF & Wi-Fi button B. Oscillation 60°C, 120°C & 360°C C. Timer (up to 7 hours) button D. Heating LOW/MEDIUM/HIGH,

Temp Increase & Set Temp button

E. Cooling LOW/MEDIUM/

HIGH & Temp decrease button

Control Panel

TOUCH CONTROL PANEL

A. Timer (up to 7 hours) &

light ring button

B. Oscillation 60°C, 120°C,

360°C & Filter Reset button

C. Cooling LOW/MEDIUM/

HIGH, Temp decrease & Child Lock button

D. Heating LOW/MEDIUM/

HIGH, Temp increase & Set Temp button

E. Power ON/OFF &

Wi-Fi button

DISPLAY SCREEN

A. Ambient/Set

Temperature display B. Wi-Fi C. Air Quality Index display D. Child Lock E. Air Quality Index lights F. Replace Filter

1H 2H 4H 60° 120°360° LO MED HI LO MED HI

LIGHT RING

A B C D E

TEMP

FILTER RESET

A B

SET

TEMP

C D

PM2.5 AQI

REPLACE

FILTER

E F

Features

WHAT IS THE AIRROUNDER PLUS™ CONNECT PURIFIER FAN HEATER?

The Breville AirRounder Plus™ Connect puriﬁer fan heater features an air puriﬁer, heater and cooling fan in one.

The Puriﬁer improves your indoor air quality using 3 distinct levels of protection.

1. A Pre-Filter

Captures larger airborne particles such as human hair, pet dander and dust particles.

2. A True HEPA Filter

Traps up to 99.97% of ﬁne particles, allergens and airborne contaminants down to

0.3 microns in size. These include bacteria, viruses, mould spores, plant spores, and pollen.

3. An Activated Carbon Membrane

Along with assisting in the capture of dust, smoke, pollen and other airborne allergens, the activated carbon membrane helps to neutralise odours in the home and to eliminate fumes emitted by household products as well as other volatile organic compounds (VOC’s) that might be found in the air.

SAFETY FEATURES

Safety Tip-Over Cut-Out Switch

There is a tip-over switch inside the puriﬁer fan heater.

If the puriﬁer fan heater is accidentally tipped over, the puriﬁer fan heater will stop operating. Once placed back into the upright position, press the power button to switch the puriﬁer fan heater on again.

THERMOSECURE™ Protection

Your puriﬁer fan heater is ﬁtted with a safety device that switches off the puriﬁer fan heater in the event of overheating. Should this puriﬁer fan heater stop working, turn off the puriﬁer fan heater and inspect the air inlet and outlet for blockages. Wait until the puriﬁer fan heater is fully cooled for the protection system to reset before attempting to restart the puriﬁer fan heater. If the puriﬁer fan heater fails to operate or the safety device switches off again, take the puriﬁer fan heater to an authorised Breville Service Centre for examination or repair.

Heating/Cooling Light Ring

Your puriﬁer fan heater is ﬁtted with a light ring that surrounds the head of the puriﬁer fan heater that illuminates a blue colour when in cooling mode and a red colour when in heating mode.

The light ring can be switched off at any time. Touch and hold the panel for 3 seconds to turn off the light ring in any mode.

button on the control

NOTE

The heating/cooling light ring should not be confused with the air quality light indicators on the control panel.

Assembly

BEFORE FIRST USE

• Remove and safely discard any packaging

material or promotional labels attached to your puriﬁer fan heater and ﬁlter. Check for any missing or damaged parts as per the components list.

• Remove the ﬁlter from the puriﬁer fan heater

(see REPLACING THE FILTER on page 19) and take it out of the plastic bag. Then reinsert the ﬁlter into the puriﬁer fan heater.

• Select a ﬂat and level location for the

puriﬁer fan heater

• For proper air ﬂow, locate the unit at least

20cm from any wall or furniture.

• Ensure the air inlet and outlets are not

blocked before use.

• Ensure the ﬁlter has been ﬁtted correctly as

per the instructions in this book.

• Plug the power plug into a 230V or 240V

power outlet and turn on the power outlet.

WARNING

Remove the ﬁlter packaging before ﬁrst use.

IMPORTANT

When moving the puriﬁer fan heater, always lift the unit using two hands and set down gently on a ﬂat and level surface.

Functions

OPERATING YOUR PURIFIER FAN HEATER

NOTE

The puriﬁer automatically operates when either Heating or Cooling is turned on. It is recommended to use the Low Fan setting to purify the surrounding area when a room temperature adjustment is not required.

Place the puriﬁer fan heater on a ﬂat surface. Insert the power plug into a 230V or 240V power outlet and switch on at the outlet. When switched on, a chime will sound to conﬁrm the unit is switched on and it is in standby mode.

1. Touch the

or press the button on the remote control

to turn the puriﬁer fan heater on. When

switched on for the ﬁrst time, the puriﬁer

fan heater will start automatically in heating

mode, at medium heat level and 25°C as the

default set temperature.

2. The LED display screen will illuminate,

and the light ring will illuminate with a red

colour light.

3. To turn the puriﬁer fan heater off at any

time, touch the

panel or press the button on the remote

control. When switched off, a chime

will sound to conﬁrm the unit has been

switched off, the light ring will no longer

illuminate, and the unit will go into

standby mode.

4. To adjust how the puriﬁer fan heater

operates, follow the directions below.

button on the control panel

button on the control

NOTE

When the puriﬁer fan heater is on and correctly setup to the Wi-Fi network, Wi-Fi will attempt to connect automatically. If a connection has been made, the Wi-Fi symbol will ﬂash for 60 seconds, after 60 seconds, the Wi-Fi symbol will illuminate on the LED display. If a connection is not made, the Wi-Fi symbol will stop illuminating. See Wi-Fi Connectivity in this book for more details.

SENSAIR SYSTEM

LIVE PURITY MONITOR

• Your Breville AirRounder Plus™ Connect

Puriﬁer Fan Heater has a built-in air quality monitor to detect changes to air quality in the surrounding area.

• The SensAir System

on the LED display panel will change colours according to the quality of the surrounding air.

• The LED screen provides real-time indication

of ﬁne particles PM2.5 concentration.

Grade

* Air Quality Index Based on the Australian Air National

Environment Protection Measure (NEPM) standard.

Air

Quality

1 Very Good 0-33 Blue

2 Good 34–66 Bright Purple

3 Fair 67–99 Orange

4 Poor > 100 Red

air quality pattern

AQI*

Measured in

PM2.5

pattern Light

Colour of

air quality

ROOM AMBIENT TEMPERATURE

To help maintain a comfortable environment, your Breville AirRounder Plus™ Connect puriﬁer fan heater is ﬁtted with a temperature sensor that detects the room temperature (in °C) which will display on the LED display screen. The number displayed is only an indication of the room temperature and will vary depending on the location of the puriﬁer fan heater in the room.

NOTE

The room temperature display is an indicative temperature only based on the temperature sensor within the puriﬁer fan heater. Temperatures further away from the unit itself may be different to this reading.

MEMORY

The puriﬁer fan heater has a memory function and will return to the last setting it was set to when it was turned off. This will only occur if the puriﬁer fan heater is not unplugged and/or switched off at the power point.

FUNCTIONS

Cooling + Purifying Mode

Your puriﬁer fan heater has 3 cooling fan settings: LOW, MEDIUM and HIGH.

5. To choose between these cooling fan

settings, press the

control panel or

remote control, until the desired setting

illuminates on the LED display screen.

The LED display screen will display the

room ambient temperature and current

fan setting.

6. To cancel a cooling setting, press the

button to stop operation. If the operation is stopped, the unit will enter

standby mode and the LED display screen will be dimmed and display the ambient room temperature.

button found on the

Heating + Purifying Mode

Your puriﬁer fan heater has 3 heat settings: LOW, MEDIUM and HIGH and allows you to set your desired temperature.

1. To choose between these heat settings, press the panel or press the remote control repeatedly, until the desired setting illuminates on the control panel LED lights. The LED display screen will illuminate the room ambient temperature and the light ring will illuminate red.

2. To cancel a heat setting, touch/press the

button on the control panel or remote control to stop operation. If the operation is stopped, the unit will enter standby mode and the LED display screen will illuminate ‘OFF’ whilst the unit is cooling down. Once cooled, the ambient room temperature will be displayed.

button found on the control

button found on the

WARNING

To avoid overheating, do not cover the heater.

Set Temp

Take control of your room temperature. Everyone's comfort levels are different, so you can set your own preferred temperature or even heat the room before you go to bed.

1. To set the desired temperature, touch and hold for 3 seconds the on the control panel or press and hold for 3 seconds the remote-control.

2. To increase the temperature tap the button on the control panel repeatedly or press the remote control.

3. To decrease the temperature, tap the button on the control panel repeatedly or press the remote control.

4. Once the temperature has been set, the LED display screen will illuminate the room ambient temperature. The puriﬁer fan heater will maintain the room ambient temperature to the temperature setting automatically.

button repeatedly on the

button found

button found on the

NOTE

Choose the heat setting to determine how quickly the puriﬁer fan heater will maintain the set temperature setting.

NOTE

When the puriﬁer fan heater is turned on from standby, the memory function will start heating based on the previously set temperature and heating setting.

NOTE

When operating the puriﬁer fan heater remotely in heat mode, the puriﬁer fan heater will automatically switch off after 7hrs by default.

SET TEMP & SENSAIR

1. The puriﬁer fan heater will stop heating and purifying when the ambient temperature is greater than the set temperature (e.g. >25˚C) and the air quality is very good (AQI Measured 0-33).

2. Ambient temperature will ﬂash, the light ring will no longer illuminate, and oscillation will stop. The unit will start heating and purifying again when the ambient temperature is less than the set temperature (e.g. ambient temperature < set temperature 25˚C). Ambient temperature will stop ﬂashing, the light ring will turn on and oscillation will resume at the same angle as previously set, only if the oscillation button is touched on the control panel or pressed on the remote control.

3. If the ambient temperature is greater than the set temperature, but the AQI is over 33, the unit will stop heating but continue to purify using low fan.

NOTE

If the AQI measured is over 33, the unit will stop heating and fan setting will automatically change to low.

Night Mode

Your puriﬁer fan heater is ﬁtted with a lightsensitive sensor that will intelligently stop the LED display screen and light ring from illuminating at night or when in a dark place.

The Night mode will automatically turn off the light ring and all lights on the LED display panel and will operate in the last setting.

Touch any button on the control panel or press any button on the remote control to re-engage the LED display panel.

TIMER

AUTO-OFF TIMER

The puriﬁer fan heater comes with a 7-hour auto-off timer to turn off after a set number of hours.

The puriﬁer fan heater can be set in 1 hour increments up to 7 hours. After the selected number of hours have elapsed, the puriﬁer fan heater will switch to standby mode. If no timer is set, the puriﬁer fan heater will continuously operate until it is manually switched off.

AUTO-OFF TIMER Example: Set the auto-off timer to 3 hours, and the puriﬁer fan heater will stop operating after 3 hours. 1h and 2h will illuminate on the control panel LED lights.

The auto-off timer can be set in any MODE. To set the timer, tap the

on the control panel or press on the remote control until the desired number of hours displays on the control panel LED lights. The timer will start on the selected mode, and will stop automatically once the timer has expired.

The control panel LED lights will illuminate the remaining auto-off time.

REMAINING TIME Example: Set the auto-off timer to 3 hours, once 1 hour has elapsed, the remaining time will be displayed in a decremental way, whereby 2h will only illuminate on the control panel LED lights, after another hour has elapsed 1h will illuminate on the control panel LED lights until the set time has completely elapsed.

button repeatedly

To cancel the pre-set auto-off time, once the timer is set, tap the on the control panel or press on the remote control until the number of hours no longer illuminates on the control panel LED lights.

button repeatedly

NOTE

The timer can be set on all modes and all modes can be adjusted at any time once the timer is set.

The puriﬁer fan heater will switch to standby mode once the set time has elapsed.

OSCILLATION

The puriﬁer fan heater has horizontal oscillation. The oscillation can be set on all modes.

To activate oscillation, press the repeatedly on the control panel or press on the remote control to select between 60, 120 and 360 degrees, until the desired degree of oscillation displays on the control panel LED lights. The puriﬁer fan heater will move left to right continuously.

To stop and direct the orientation of your puriﬁer fan heater during oscillation, when the airﬂow has reached your preferred position, press the panel or press on the remote control until 60, 120 or 360 degrees is no longer illuminating on the control panel LED lights.

When the puriﬁer fan heater is turned off, the unit will stop oscillating and return to centre position. When turned on from standby, the puriﬁer fan heater will start oscillating at the same angle as previously set.

If no oscillation angle was set, the unit will stay at the same position as it was when it stopped.

button repeatedly on the control

button

2. To cancel, repeat step 1 until the child lock icon no longer illuminates on the LED display panel.

FILTER RESET

• The REPLACE FILTER icon will illuminate on

the LED display panel indicating that the ﬁlter needs to be replaced.

• Replace the ﬁlter according to the directions

found under Replacing the Filter in this book.

• Once the ﬁlter is replaced, press and hold

button on the control panel for 10

the seconds to reset. The REPLACE FILTER icon will no longer illuminate on the control panel display.

• The built-in timer for the ﬁlter reset

is 292 days.

NOTE

For best performance, the ﬁlter should be cleaned at least monthly as per the instructions found in the Care, Cleaning & Storage section of this book.

REMOTE CONTROL

The puriﬁer fan heater comes with a remote control. This remote control features the same controls as the control panel on the puriﬁer fan heater and can be used the same way.

The control panel has an additional control not found on the remote control. The FILTER RESET function can be set using the control panel only. Refer to the FILTER RESET section of this book for more details.

To avoid misplacing your remote control, place the remote control in the remote holder at the back of the unit (Fig 1).

CHILD LOCK

When the Child Lock is engaged, the buttons on the control panel are locked from use.

1. To turn on, touch and hold the the control panel or press and hold the on the remote control until a beep sounds and the child lock icon illuminates on the LED display panel.

button on

Fig. 1

USING THE REMOTE CONTROL

The remote control includes 1 x CR2032 3V Lithium battery. This Lithium battery is protected by an isolating slip. Before ﬁrst using the remote control, remove the battery isolating slip by pulling the slip outwards away from the remote control.

To check and/or to replace the battery, open up the battery compartment at the back of the remote by forming a good grip of the remote, pushing the small arched groove to the right and simultaneously pushing out the battery compartment cover by pushing the rectangular groove outwards. Insert the battery paying attention to the polarity (+ and -) (Fig 2).

BACK OF REMOTE

NOTE

To use the remote control, it must be pointed at the control panel and must be used within ﬁve meters of the unit

WARNING

KEEP BATTERIES OUT OF REACH OF CHILDREN

Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical burns

and potential perforation of the oesophagus. If you suspect your child has swallowed or inserted a button battery immediately call the 24-hour Poisons Information Centre on 13 11 26 for fast, expert advice. Examine devices and make sure the battery compartment is correctly secured, e.g. that the screw or other mechanical fastener is tightened. Do not use if compartment is not secure. Dispose of used button batteries immediately

and safely. Flat batteries can still be dangerous. Tell others about the risk associated with button batteries and how to keep their children safe.

Fig. 2

Reinsert the battery compartment into the remote control ensuring that the + symbol is facing downwards when inserted. Make sure the battery compartment is correctly secured (Fig 3).

360°

Fig. 3

Wi-Fi Connectivity

The Breville AirRounder Plus™ Connect puriﬁer fan heater can offer remote operation by using a home Wi-Fi connection and the Breville Home Connect™ app downloaded to a compatible mobile phone. through the Google Play store or Apple App store.

To go straight to the appropriate app store, scan the QR code below.

For instructions on how to use the app, scan the QR code below, refer to the Quick Start Guide that can be found in the box or go to tinyurl.com/HomeConnectQuickStart.

CONNECT YOUR PURIFIER FAN HEATER TO WI-FI

1. Ensure the mobile device is connected to a home Wi-Fi network.

2. The puriﬁer fan heater can either be on standby mode or turned on when setting up. The symbol panel. The puriﬁer fan heater is now ready to connect. The symbol stops ﬂashing after 60 seconds but pairing remains possible.

3. Log into your Breville Home Connect™ app account and stay on the “Home” page. To add the puriﬁer fan heater to the list. Touch ‘Add Device’ or the top right-hand corner of the screen. Follow the prompts in the app.

will ﬂash fast on the display

symbol found in the

NOTE

The Breville Home Connect™ app is compatible with mobile phones running

Android or later.

5.0 or later and iOS devices 9.0

NOTE

To control the puriﬁer fan heater using the app, the puriﬁer fan heater must be plugged in to an active power outlet.

4. If the connection is successful, the puriﬁer fan heater will appear in the main page of the app and the Insert the puriﬁer fan heater will illuminate.

5. If unsuccessful, touch and hold the button

for 3 seconds until the symbol is ﬂashing slowly. Follow the prompts in the app to connect in a different mode.

symbol light on

Voice Assistants

The Breville AirRounder Plus™ Connect puriﬁer fan heater comes with the added feature of voice assistance, allowing you to control your puriﬁer fan heater using your voice by linking your Breville Home Connect™ app with Amazon Alexa and Google Home/Assistant.

To link your Breville Home Connect app account with either Amazon Alexa or Google Home/ Assistant, refer to the instructions on www.Breville.com or follow instructions found in the Breville Home Connect™ app under Me > Third-Party Voice Services > View more ways to link.

NOTE

To control the puriﬁer fan heater using the Amazon Alexa and Google Home/Assistant app, the puriﬁer fan heater must be plugged in to an active power outlet and turned on.

IMPORTANT NOTE

The recommended voice commands to operate the appliance's functions differ between Amazon Alexa and Google Home/Assistant as listed below. Variations of these commands may also be recognised, however, if a command fails, check against the recommended voice command.

VOICE CONTROL WITH AMAZON ALEXA

Before you can voice control your Breville AirRounder Plus™ Connect with Amazon Alexa, you need to link the Breville Home Connect™ account to the Amazon Alexa app as per the instructions.

Recommended Amazon Alexa Voice Commands for the Breville AirRounder Plus™ Connect

Supported Settings Amazon Alexa Voice Commands

Power

Cooling Mode Heating Level

Oscillation (Default 60 degrees)

Activate/Deactivate Child Lock

Set Temperature * Ambient Temperature * Light Ring

Turn ON DEVICENAME Turn OFF DEVICENAME Set DEVICENAME fan speed to Low/Mid/High Set DEVICENAME to heater low/heater medium/heater high

Turn Horizontal Swing ON on DEVICENAME

Turn Horizontal Swing OFF on DEVICENAME Turn child lock ON on DEVICENAME Turn child lock OFF on DEVICENAME Set DEVICENAME to XX degrees What is the temperature of DEVICENAME Turn ON the light on DEVICENAME Turn OFF the light on DEVICENAME

NOTE

Currently, Amazon Alexa does not support the following settings:

• Oscillation mode (120 & 360 degree), timer, air quality, ﬁlter lifetime and reset ﬁlter.

VOICE CONTROL WITH GOOGLE HOME/ASSISTANT:

Before you can voice control your Breville AirRounder Plus™ Connect with Google Home/ Assistant, you need to link the Breville Home Connect™ account to the Google Home/Assistant app as per the instructions.

Download the Google Home/Assistant app and create an account before starting on the below steps.

Recommended Google Home/Assistant Voice Commands for the Breville AirRounder Plus™ Connect

Supported Settings Google Home/Assistant Voice Commands

Power

Cooling Mode Heating Level Oscillation (Default 60 degrees)

Activate/Deactivate Child Lock

Set Temperature * Ambient Temperature * Light Ring

Turn on DEVICENAME Turn off DEVICENAME Set fan speed to Low/Mid/High on DEVICENAME

Set DEVICENAME to heater low/heater medium/heater high

Turn swing ON on DEVICENAME Turn swing OFF on DEVICENAME Turn child lock ON on DEVICENAME Turn child lock OFF on DEVICENAME Set DEVICENAME to XX degrees What’s the temperature of DEVICENAME? Turn ON light for DEVICENAME Turn OFF light for DEVICENAME

NOTE

Currently, Google Home/Assistant does not support the following settings:

• Oscillation mode (120 & 360 degree), timer, air quality, ﬁlter lifetime and reset ﬁlter.

TIPS for Amazon Alexa and Google Home/Assistant

• Conﬁgure your Amazon Alexa or Google Home/Assistant compatible devices with the "Amazon

Alexa" or “Google Home/Assistant” app if using, or simply download onto your phone.

• Renaming your device - You will ﬁnd your device listed as the Breville product name in your

Breville Home Connect™ smart home devices. Tap on it to rename your device for more convenient voice commands, e.g. “Puriﬁer Living Room” or give it a name, e.g. "Kenny".

• Training your voice assistant - Voice Match - Teach your assistant to recognise your voice. This

isn’t training it to understand English, but rather to recognise your voice as belonging to you. You can do this by going to the Settings menu in the voice assistant app on your phone.

• Routines - Amazon Alexa and Google Home/Assistant allow you to combine multiple actions

in one voice command, to create a Routine, tap on the ‘Routines’ option via settings and follow the steps.

• Ensure the primary language is set to English (United States) for all apps. * Ensure measurement units in Amazon Alexa and Google Home/Assistant are set to Celsius.

Care, Cleaning & Storage

The puriﬁer fan heater and ﬁlter should be cleaned at least once every month. Ensure the puriﬁer fan heater is switched off and disconnected from the power outlet and allow all parts to cool before cleaning or storing.

• Use a clean, dry cloth to clean all external

surfaces of the puriﬁer fan heater.

NOTE

More frequent cleaning may be required depending on environmental conditions.

BREVILLE RECOMMENDS

• Always ensure the puriﬁer fan heater is

turned off, switched off at the power outlet and unplugged and allow the unit to cool before performing any cleaning or ﬁlter replacement.

DO NOT stick any foreign objects or your

8

ﬁngers inside the air inlet/outlet of this unit. DO NOT use gasoline, benzine, thinner,

8

harsh cleaners, etc. on and/or in the unit while cleaning as they will damage the unit.

NEVER use alcohol or other solvents

8

on this unit.

AIR QUALITY SENSOR CARE AND CLEANING

• It is important to keep the air quality sensor

clean for best performance.

• The air quality sensor is situated above the

back vent (air outlet) at the rear of the unit.

• Gently vacuum over the openings on the air

quality sensor cover using a small hand brush tool. Cleaning should occur regularly, at least once a month (Fig 4).

Fig. 4

• For more thorough cleaning, remove the air

quality sensor cover by using and Philips head screwdriver.

• Gently vacuum the mesh ﬁlter of the

air quality sensor using the hand brush tool (Fig 5).

Fig. 5

Thorough cleaning should occur at least once every six months.

• Replace the mesh ﬁlter and cover when clean,

ensuring it is screwed securely back into place.

WARNING

The air quality sensor is fragile and can be damaged if excessive force is used during cleaning. Use extra care when cleaning.

FILTER CARE & CLEANING

WARNING

The ﬁlter is not washable. Do not immerse any part of the air puriﬁer in water as it will cause damage.

• The Pre-ﬁlter should be cleaned at least once

every month using a vacuum cleaner. Gently vacuum using a hand-tool attachment such as a brush or upholstery tool. Clean more often if required (Fig 6).

Fig. 6

• Do not attempt to clean the carbon ﬁlter with

a vacuum as this can cause damage.

• Do not use any solutions, hard bristle

brushes or sharp objects to clean as this can cause damage.

• Replace the ﬁlter as indicated using the

following instructions.

1. Remove the rear housing cover (Fig 7).

Fig. 7

2. Remove the used ﬁlter using the pull tabs on the ﬁlter (Fig 8).

Fig. 8

REPLACING THE FILTER

Your AirRounder Plus™ Connect puriﬁer fan heater ﬁlter should be replaced in the time frames indicated below. The ﬁlter life is approximately 9 months if used 24 hours daily, or 12 months if used 12 hours daily.

• The ﬁlter life may vary to this timing

depending on environmental conditions.

• Remove all packaging from the replacement

ﬁlter and place the ﬁlter into the unit as described below.

3. Remove all packaging from the replacement ﬁlter then place into the puriﬁer fan heater with pull tabs facing the opening (Fig 9).

Fig. 9

NOTE

There is no top or bottom on the ﬁlter. The ﬁlter can be placed into the unit either way.

NOTE

If the ﬁlter is not in place or not ﬁtted correctly, the puriﬁer fan heater will not operate.

REPLACEMENT FILTERS

Replacement ﬁlters must be purchased from the Breville website^ or at participating retail

outlets. See the table below for the replacement

product code to suit this Breville Puriﬁer Fan Heater.

4. Ensure the ﬁlter is correctly ﬁtted.

5. Replace the rear housing cover (Fig 10).

Fig. 10

6. Press and hold the

button on the

control panel for 10 seconds to reset the ﬁlter. REPLACE FILTER icon will no longer illuminate on the LED display panel.

Breville Puriﬁer Fan Heater Model No.

the AirRounder™ Connect

LPH408WHT

the AirRounder Plus™ Connect

LPH708WHT

^Delivery charges may apply.

Filter Replacement Product Code

LPH040WHT

LPH070WHT

Please contact Breville Customer Service Centre for further support.

Only use the original Breville ﬁlter specially intended for this appliance. Do not use any other ﬁlters.

STORAGE

When not in use, store the puriﬁer fan heater upright in a cool, clean and dry location.

Troubleshooting

MINI TROUBLESHOOTING GUIDE

Before carrying out any of the following service checks, unplug the unit from the mains.

PROBLEM WHAT TO DO

Unit will not start

Insufﬁcient air ﬂow

Excessive noise

Light ring not illuminating Not heating in the heating mode

Poor air puriﬁcation quality Filter Indicator is still

illuminated after replacing the air ﬁlter

PM2.5 value of the display is seriously high or it does not drop from a higher value

If the problem is not listed, please contact Breville Customer Service Centre (see back cover for contact details).

Check that the power plug is connected to a power outlet and the

•

outlet is turned on. Check that puriﬁer fan heater is assembled correctly.

•

Check that the ﬁlter is ﬁtted correctly in place.

•

Make sure the ﬁlter is removed from the packaging.

•

Check that the ﬁlters are clean.

•

Check for any obstructions in the air inlet and/or outlet.

•

Check if the ﬁlter is clogged and ready for replacement.

•

Check that the rear housing cover is closed properly.

•

Check that the unit is on a level surface.

•

Contact Breville service centre for replacement.

•

Check for any obstructions in the air inlet and/or outlet.

•

Surface temperature of the heating plate rises, and the thermostat

•

has stopped working.

Clean the air quality sensor (see page 18).

•

Reset the REPLACE FILTER indicator (see page 19).

•

Air quality sensor mesh ﬁlter needs to be cleaned.

•

BREVILLE HOME CONNECT™ APP TROUBLESHOOTING

PROBLEM WHAT TO DO

Why can’t I connect my puriﬁer fan heater to Wi-Fi network?

How do I change my Wi-Fi network to a 2.4GHz Wi-Fi network?

I already have another appliance connected to the Breville Home Connect™ app, but my puriﬁer fan heater won’t connect?

My puriﬁer fan heater is ofﬂine

Check that your puriﬁer is within range of the Wi-Fi router

•

During the setup process you must be on a secure 2.4GHz

•

Wi-Fi network. Make sure the Wi-Fi password you entered is correct.

•

Check that the ﬁlter is ﬁtted correctly in place.

•

Unplug the puriﬁer for 10 seconds and plug it back in.

•

Most dual-band routers support both 2.4Ghz and 5Ghz networks.

•

Select the Wi-Fi name that does not end in “-5G” If your phone is attempting to connect to the 5Ghz network, try

•

“forgetting” or temporarily disabling the 5Ghz network. If you are unsure, or if the 2.4Ghz and 5Ghz networks do not have

•

separate names, please contact your internet service provider.

Close and relaunch the Breville Home Connect™ app

•

Reset the puriﬁer fan heater by pressing and holding the power

•

button for 15 seconds. The Wi-Fi indicator will rapidly blink 10 times and turn off.

Re-pair the puriﬁer to the Breville Home Connect™ app by

•

following the instructions in this booklet

Make sure your router is connected to the internet and your

•

phone’s network connection is working properly. Check that your puriﬁer is within range of the Wi-Fi router

•

Delete the ofﬂine puriﬁer fan heater for the Breville Home

•

Connect™ app. Swipe left (iOS) or tap and hold (Android), and tap Delete.

Reset the Wi-Fi on the puriﬁer fan heater by touching and holding

•

the power button for 3 seconds when in standby mode. The Wi-Fi indicator will rapidly blink and turn off.

Reconﬁgure your puriﬁer fan heater with the Breville Home

•

Connect™ app.

NOTE: Power outages, internet outages, or changing Wi-Fi

•

routers may cause your air puriﬁer to go ofﬂine.

If the problem is not listed, please contact Breville Customer Service Centre (see back cover for contact details).

TROUBLESHOOTING GUIDE FOR AMAZON ALEXA AND GOOGLE HOME/ASSISTANT

PROBLEM WHAT TO DO

Why is Amazon Alexa or Google Home/Assistant not responding to my voice commands.

If the problem is not listed, please contact Breville Customer Service Centre (see back cover for contact details)

Check the internet connection.

•

Restart your device & mobile phone.

•

Restart your modem and router.

•

Make sure your Amazon Alexa or Google-enabled device or mobile phone is in

•

Wi-Fi range. When you are giving a command to Amazon Alexa or Google Home/Assistant

•

make sure you are clear and there is no unwanted noise in the background. While the voice assistant is always on in the background, only an activation

•

phrase will allow for the voice assistant to start. registering the commands being relayed. The activation phrase depends on the application being used; For Amazon Alexa, use “Alexa”, while “OK Google” is for Google Home/Assistant.

Ensure your voice is clear and distinct to allow the assistant to accurately record

•

and process the command. Ask direct questions. Refer to the commands list for recommended commands.

•

Note

Breville Customer Service Centre

Australian Customers Phone: 1300 139 798 Web: www.breville.com

New Zealand Customers

0800 273 845

Phone: Web: www.breville.com

Breville, the Breville logo, Master Every Moment, AirRounder Plus, ThermoSecure, SensAir System

and Breville Home Connect are trademarks of Breville Pty. Ltd. A.B.N. 98 000 092 928.

All other brands may be trademarks of their respective owners.

Due to continued product improvement, the products illustrated/photographed in this booklet

may vary slightly from the actual product.

LPH708 ANZ C21

Breville LPH708 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
