TIME
YM52
Instruction book pag. 1 • Mode d’emploi pag. 8 Gebrauchsanleitung pag. 14 • Manuale di funzionamento pag. 20 Manual de instrucciones pag. 26
Thank you very much for purchasing a BREIL WATCH.To ensure its correct use, please read these instructions carefully.
In order to be able to make full use of the guarantee service (subject to the guarantee terms), please ensure that the Breil international guarantee card is supplied with the watch at the time of purchase.
Nous vous remercions de la préférence que vous nous avez accordée en achetant une montre BREIL. En vue d'une utilisation correcte de celle-ci, lire attentivement les instructions contenues dans ce livret.
Lors de l'achat, contrôlez que la montre soit accompagnée de la garantie qui devra être présentée pour obtenir les prestations qui y sont décrites.
Wir danken Ihnen für das Vertrauen, daß Sie uns mit dem Kauf einer BREIL QUARTZ-Uhr erwiesen haben. Damit Sie Ihre Uhr immer einwandfrei gebrauchen können, möchten wir Sie bitten, die in dieser Gebrauchsanleitung enthaltenen Anweisungen gewissenhaft zu lesen.
Beim Kauf sollten Sie kontrollieren, ob Ihnen zusammen mit der Uhr auch die Garantiekarte ausgehändigt wurde, denn diese Karte müssen Sie vorlegen, um die darin genannten Leistungen in Anspruch nehmen zu können.
Vi ringraziamo per la preferenza accordataci con l’acquisto di un orologio BREIL. Per un corretto uso dello stesso,Vi preghiamo leggere attentamente le istruzioni contenute in questo libretto.
Al momento dell’acquisto controllate che insieme all’orologio Vi venga fornita anche la garanzia, da presentare per ottenere le prestazioni in essa descritte.
Le agradecemos su preferencia por un reloj BREIL. Para poder utilizar correctamente el reloj, le rogamos leer atentamente las instrucciones contenidas en este folleto.
Al comprarlo, controle que junto al reloj le sea entregada la garantía que debe ser presentada para obtener los servicios que en la misma se describen.
When reading this instruction booklet, keep the watch diagram on the left unfolded and in full view.The symbols (A, B, etc.) on the diagram are those referred to in the section describing the operating instructions.
Pendant la lecture de ce mode d'emploi, gardez le schéma d'illustration de la montre ci-contre ouvert et bien en vue. Les symboles (A, B, etc.) utilisés dans les différents chapitres du mode d'emploi correspondent à ceux indiqués sur ce schéma.
Zur Lektüre dieser Gebrauchsanleitung sollten Sie die nebenstehend gezeigte Übersichtsdarstellung der Uhr ausklappen und im Blick behalten. Die in den einzelnen Abschnitten der Gebrauchsanleitung verwendeten Zeichen (A, B, usw.) entsprechen den Kennzeichnungen in dieser Übersicht.
Durante la lettura di questo manuale di istruzioni, tenere lo schema illustrativo dell’orologio a sinistra aperto e in vista. I simboli (A, B, ecc.) usati nelle sezioni delle istruzioni sul funzionamento corrispondono a quelli indicati in questo schema.
Mientras lee este manual de instrucciones, mantenga el esquema ilustrativo del reloj aquí presentado al lado izquierdo, abierto y bien visible. Los símbolos (A, B, etc.) utilizados en las secciones de instrucciones sobre el funcionamiento, corresponden a los que se utilizan en este esquema.
1 2 4
(0) (1) (2)
7 |
C |
3
|
|
GB |
|
CONTENTS |
|
|
|
|
A |
MAIN COMPONENTS |
3 |
|
|
|
B |
SETTINGTHETIME |
3 |
|
|
|
C |
SETTINGTHE DATE |
3 |
|
4 |
|
D |
PRECAUTIONS AND USEFUL INFORMATION |
|
|
|
|
2
A |
MAIN COMPONENTS |
|
|
1 |
Hour hand |
6 Date |
|
2 |
Minute hand |
(some models only) |
|
C Crown |
|||
3 |
Second hand |
||
|
(some models only)
B SETTINGTHETIME
If your watch has a locking screw-type crown, first unscrew the crown.
1.Stop the second hand at "0" by pulling out the crown to position (1) (position (2) if the model has a date display).
2.Turn the crown to adjust the hands to the correct time.
3.Restart the watch by pushing the crown back to position (0).
CSETTINGTHE DATE (some models only)
1.Pull out the crown to position (1)
2.Rotate the crown until the required date appears.
3.Put the crown back to position (0)
3
D PRECAUTIONS AND USEFUL INFORMATION
|
Indication |
|
|
Use in |
|
|
|
|
|
|
|
water |
|
|
|
Spray, sweat, |
Swimming, |
Degreeof resistance |
Dial |
Case |
|
light rain, |
|
|
etc. |
||||
|
|
||||
|
|
|
|
washing, etc. |
|
|
|
|
|
|
|
|
|
|
|
|
|
A |
— |
— |
|
NO |
NO |
B |
— |
WATER RESISTANT |
|
YES |
NO |
|
|
|
|
|
|
C |
WATER RESISTANT |
WATER RESISTANT |
|
YES |
YES |
50M (5bar) |
|
||||
|
|
|
|
|
|
D |
WATER RESISTANT |
WATER RESISTANT |
|
YES |
YES |
100M (10bar) |
|
||||
|
|
|
|
|
|
E |
WATER RESISTANT |
WATER RESISTANT |
|
YES |
YES |
200M (20bar) or more |
|
||||
|
|
|
|
|
|
The words “WATER RESISTANT” may sometimes be abbreviated to “WATER RESIST”.
–In order to prevent water coming into contact with the internal mechanism, never pull the crown out when the watch is wet.
–If any watches designed for sportswear or use in water come into contact with salt water or heavy sweating, they should be rinsed in fresh water and dried thoroughly.
–Contact with water may cause a deterioration in the quality of some leather straps.
4
Water |
|
|
|
Skin-diving |
Scuba diving |
Water-resistance |
|
characteristics |
|||
|
|
||
NO |
NO |
Not water resistant. Must be kept away from water and moisture |
|
NO |
NO |
Average water resistance. Can withstand spray, sweat, |
|
light rain, washing, etc. during daily use |
|||
|
|
||
NO |
NO |
Can be worn while swimming but not diving |
|
YES |
NO |
Suitable for skin-diving |
|
YES |
YES |
Suitable for scuba diving |
|
|
|
|
|
*Always keep the crown in its normal position. |
*Fully tighten crown screw lock. |
||
–As the internal parts of the watch can retain moisture, when the outside temperature is lower than the inside, the watch glass may mist-up.This phenomenon is purely temporary and should not create any problems. However, if it persists for any length of time, the watch should be checked by the shop where it was purchased or by the nearest Authorised Service Centre.
5
Impact
This watch can withstand normal everyday impacts and shocks and those normally imparted by non-contact sports such as golf and baseball. Serious damage, however, may result if the watch is dropped or subjected to severe shock.
Magnetic fields
This watch is antimagnetic up to 60 gauss, and is therefore not affected by magnetic fields produced by normal domestic appliances. If used near strong magnetic fields, its operation may be temporarily affected.
Chemicals and gases
Avoid wearing the watch in the presence of strong gases or chemical substances. Parts of the watch may discolour, dissolve or even break if brought into contact with benzol or petroleum based products such as solvents, thinners, detergents, adhesives etc.
Pay special attention to avoiding contact with chemicals.
The watch case and strap may discolour if they come into contact with mercury from a broken thermometer or other equipment.
Keeping the watch clean
Use an absorbent soft cloth to clean off any dirt or damp from the watch glass. Wearing the watch when the strap or back of the case is dirty can cause skin irritation. Keeping the watch clean also keeps shirt cuffs clean.
6
Cleaning the watch strap.
•Metal bands: use a toothbrush and soapy warm water to wash the dirt off.
•Plastic or rubber straps: wash with water. Do not use solvents.
•Leather straps: gently rub the face of the strap using a soft dry cloth. Clean the opposite side with a cloth and alcohol.
Periodic inspection
In order to guarantee long trouble-free operation, it is advisable to have the watch checked by an authorised assistance centre once every 12 months or two years.
If your watch is fitted with a quartz movement
Temperature
Do not leave the watch exposed to direct sunlight or temperature extremes for long periods of time.
Long exposure, in fact, may adversely affect the operation of the watch and actually shorten battery life, causing it to gain or lose time and affect its other functions.
Static electricity
The integrated circuits present inside the watch are sensitive to static electricity. If the watch is exposed to intense electrical fields, the time display may temporarily lose some of its accuracy.
Keep batteries out of the reach of children
In order to improve the product, the technical specifications may be modified without prior notice.
