EN
3EN
THERMOPOT BR1091
Thermopot is intended for boiling water and
maintaining its temperature at a set level.
DESCRIPTION
1. Water level scale
2. Water Button
3. Spout for pouring water
4. Control panel
5. Detachable lid
6. Lid opening button
7. Hand pump
8. Lid installation place
9. Hand pump mechanical lock
10. Carrying handle
11. Body
12. Power cord connector
Control panel
13. Reboil on button «Reboil»
14. «Boiling» light indicator
15. «Keeping warm» light indicator
16. Water dispense on button «Water dispense»
17. Unlocked water dispensing light indicator
18. Water dispensing unlock button «Lock»
19. Hot water temperature maintenance indication «9585-65-55-45»
20. Water temperature digital symbols
21. Hot water temperature maintenance setting button
«Selection of С°»
22. Power cord
ATTENTION!
For additional protection it is reasonable to install a
residual current device (RCD) with nominal operation
current not exceeding 30 mA into the mains. To install
RCD, contact a specialist.
6 7
5 8
4
3
2
1
9
10
11
12
4 EN
13 14 15
Подача воды
Повторное
кипячение
Поддержание
температуры
Блокировка
55
65
45
Выбор
С°
Кипячение
95 85
21
16
17
20
18
20
19
Рiс. 1 Рiс. 2 Рiс. 3
5
EN
SAFETY MEASURES AND OPERATION
RECOMMENDATIONS
Read the operation instructions carefully before
using the thermopot and keep it for future reference.
• Use the thermopot for its intended purpose only, as it
is stated in this manual.
• Mishandling the thermopot can lead to its breakage
and cause harm to the user or damage to his/her
property and it is not covered by warranty.
• The thermopot is intended for heating and boiling
drinking water only, do not heat or boil any other
liquids.
• Make sure that operating voltage of the thermopot
indicated on the label corresponds to your home mains
voltage.
• The power plug is equipped with a grounding contact,
plug it into the socket with
• reliable grounding contact. In case of short circuit the
grounding reduces the risk of electric shock.
• Contact an electrical technician, if you are not sure
that your sockets are installed properly and grounded.
• To prevent re do not use adapters designed for
connecting the plug to the mains socket without
grounding contact.
• In case of sparking in the mains socket and
occurrence of smell of burning, unplug the unit and
apply to the organization maintaining your home
mains.
• If smoke appears from the body of the thermopot,
unplug the unit and take measures to prevent re
spreading.
• Do not use the thermopot outdoors.
• It is not recommended to use the unit during lightning
storms.
• Protect the unit from impacts, falling, vibrations and
other mechanical stress.
• Do not switch the thermopot on if the water tank is
empty.
• Do not ll the thermopot with water directly from the
faucet; to ll the thermopot use a suitable bowl.
• Do not place the thermopot next to the walls or close
to the kitchen furniture.
• Place the thermopot keeping at least 20 cm gap
between the thermopot body and the wall and at
least 50 cm gap above the thermopot.
• Never leave the plugged-in thermopot unattended.
• Do not use the thermopot in proximity to kitchen
sink, in bathrooms, near swimming pools or other
containers lled with water.
• Do not use the thermopot near heating appliances,
heat sources or open ame.
• Do not use the thermopot in places where aerosols
are used or sprayed, and in proximity to inammable
liquids.
• Place the thermopot on a at stable surface; do not
place it on the edge of a table. Do not let the power
cord hang from the edge of the table and make sure
6
EN
it does not touch hot surfaces or sharp edges of
furniture.
• Do not touch the power cord and the power plug with
wet hands.Do not switch the thermopot on without
water, after the thermopot is lled, close the lid tightly.
• Ensure that the water level is not above the maximal
mark. If the water level exceeds the maximal mark,
boiling water can splash out of the thermopot during
boiling.
• To avoid burns by hot steam, do not bend over the
steam release openings in the thermopot lid. Do not
block the steam release openings with any objects.
• Do not open the thermopot lid while water boiling.
• Be careful while carrying the thermopot lled with
boiling water.
• Be very careful when pouring hot water out of the
thermopot.
• Unplug the thermopot before cleaning or when you
are not using it. When unplugging the thermopot hold
only the power cord plug and carefully remove it from
the mains socket, do not pull the power cord — this
can lead to damage of the power cord or the socket
or cause short circuit.
• To avoid electric shock do not immerse the thermopot
into water or any other liquids.
• Do not wash the thermopot in a dishwashing
machine.
• For children safety reasons do not leave polyethylene
bags, used as a packaging, unattended.
ATTENTION!
Do not allow children to play with polyethylene bags
or packaging lm. Danger of suocation!
• The thermopot is not intended for usage by children.
• Do not leave children unattended to prevent using
the unit as a toy.
• Do not allow children to touch the unit and the power
cord during the thermopot operation.
• Place the unit out of reach of children during the
operation and cooling down.
• This unit is not intended for usage by physically or
mentally disabled persons (including children) or by
persons lacking experience or knowledge if they are
not under supervision of a person who is responsible
for their safety or if they are not instructed by this
person on the usage of the unit.
• Check the integrity of the power cord, the power plug
and the thermopot body periodically.
• If the power cord is damaged, it should be replaced
by the manufacturer, a maintenance service or
similar qualied personnel to avoid danger.
• If the power cord is damaged, it should be replaced
with a power cord received from the manufacture or
service.
• Transport the thermopot in the original package.
• Keep the unit out of reach of children and disabled
persons.
7
EN
THERMOPOT IS INTENDED FOR HOUSEHOLD USE
ONLY, DO NOT USE THE COFFEE MAKER FOR
COMMERCIAL OR LABORATORY PURPOSES.
BEFORE USING THE THERMOPOT
After unit transportation or storage at low
temperature keep it for at least 3 hours at room
temperature before switching on.
• Unpack the thermopot and remove all the packaging
materials.
• Keep the original package.
• Read the safety measures and operating
recommendations.
• Check the delivery set.
• Examine the thermopot for damages, in case of
damage do not plug it into the mains.
• Make sure that the specications of power supply
voltage specied on the label correspond to the
specications of your mains. When using the
thermopot in the mains with 60 Hz frequency, the unit
does not need any additional measures.
• Wipe the outer surface of the unit body (10) with a
clean, slightly damp cloth to remove dust.
• Open the lid (5) by pressing the button (6) and
holding it (pic. 1).
• Wipe the inner surface of the thermopot ask with a
clean, slightly damp cloth to remove dust. Close the
lid (5).
SWITCHING THE THERMOPOT FOR THE FIRST
TIME AND USING THE UNIT
• Place the thermopot on a dry at surface keeping at
least 20 cm gap between the thermopot body and
the wall or furniture and at least 50 cm gap above the
thermopot.
• Open the lid (5) by pressing the button (6) and
holding it (pic. 1).
• Fill the thermopot with water using a suitable bowl,
do not exceed the maximal water level mark. Do not
ll the thermopot with water directly from the faucet;
to ll the thermopot use a suitable bowl.
Notes: to reduce the mineral deposit (scale), we
recommend using the water cleaned with domestic
lters.
• Close the lid (5) until the lock clicking, make sure that
the lid (5) is closed.
Notes: when using the thermopot, always check the
sealing gasket. If you nd any cracks on the sealing
gasket, stop using the thermopot and apply to the
service center to replace the gasket.
• Insert the power cord (22) jack into the connector
(11) on the thermopot body, and the
• power cord (22) plug into the mains socket.
• The boiling mode indicator «Boiling» (14) will light up
on the control panel (4). The digital symbols (20) will
show the water temperature in the thermopot.
• After long water boiling, you will hear a sound signal
8
EN
and the thermopot will be switched to the keep warm
mode, the keep warm indicator (19) «85» will light up.
The water temperature 85°С is set by default.
Notes: the thermopot uses a long boiling technology
which signicantly reduces the chlorine level in water.
• To avoid burns by hot steam, do not bend over the
steam release openings (7) in the thermopot lid (5).
Do not block the steam release openings (7) with any
objects.
• Drain the water after the rst boiling. Hot water
resulting from the rst boiling is not recommended to
consume, you may use it for domestic needs.
ATTENTION!
Be careful when pouring out water to avoid burns
by hot water.
• Unlock the activation of the water pump by pressing
and holding the «Lock» button (18) within 5 seconds,
the indicator (17) will light up.
• To drain the water you can do the following:
First option: place a suitable bowl, for instance, a cup
under the spout for pouring water (3) and press the
water (2) dispense button with a rim of the cup (pic. 3).
Second option: place a suitable bowl under the spout
for pouring water (3) and press and hold the water
dispense button (16) «Water dispense», after the cup is
lled release the button (16).
Notes:
- the water is dispensed only when the indicator (17) is
switched on; if you pressed the button (18) «Lock» and
didn’t do anything, in this case the indicator (17) will go
out in 10 seconds;
- if you haven’t used the thermopot for a long time,
the water dispense may malfunction. In this case it
is recommended to open and close the lid (5) and to
switch the water dispense on again.
• To switch the thermopot o disconnect the power
cord (22) plug from the mains socket.
• Open the thermopot lid (5) and wait until it cools
down completely.
• Always drain the remaining water from the thermopot
ask, to do this remove the lid (5).
• Before removing the lid (5) slightly open it at the
angle of approximately 45°, and pull the lid (5)
towards the control panel (4) (pic. 2).
• Carefully tilt the thermopot to drain the remaining
water (pic. 3).
• Install the lid (5) to its place; to do this, set the lid
(5) at the angle of approximately 45° and insert
the lid (5) to its installation place; before using the
thermopot make sure that the lid (5) is xed properly.
Additional information
• The thermopot is equipped with rotating base (12).
You can turn the thermopot body (10) in the required
direction.
9
EN
• Check the water level in the thermopot using the
scale (1).
• Timely rell the thermopot.
HOT WATER MAINTENANCE TEMPERATURE
SELECTION
• You can select one of ve presets of hot water
temperature maintenance.
• To select the hot water maintenance temperature
press the button (21) «Selection of С°», you can
select the hot water maintenance temperature of
«95-85-65-55-45» degrees.
• Recommended water temperature for brewing tea
and making other beverages:
• - «45» - water temperature for making powdered
baby milk
• - «55» - brewing white tea
• - «65» - red or herbal tea
• - «85» - green or yellow tea, brewing coee
• - «95» - black tea
• The preset keep warm temperature is shown by the
corresponding indicators (19).
• If the water temperature goes signicantly below
the preset temperature (for example, if you added
cold water), the boiling mode will switch on and the
indicator (14) «Boiling» will light up.
• You can switch the reboiling mode on by pressing the
button (13) «Reboiling», the indicator (14) «Boiling»
will light up. After water boiling you will hear a sound
signal and the keep warm mode will switch on, the
keep warm indicator (19) «85» will light up. The water
temperature 85°С is set by default.
• To switch the thermopot o disconnect the power
cord (22) plug from the mains socket.
CLEANING AND MAINTENANCE
• Before cleaning the thermopot unplug it (22), open
the lid (5) and wait until the thermopot cools down
completely.
• Always drain the remaining water from the thermopot
ask, to do this remove the lid (5).
• Before removing the lid (5) slightly open it at the
angle of approximately 45°, and pull the lid (5)
towards the control panel (4) (pic. 2).
• Carefully tilt the thermopot to drain the remaining
water (pic. 7).
• Install the lid (5) to its place; to do this, set the lid
(5) at the angle of approximately 45° and insert
the lid (5) to its installation place; before using the
thermopot make sure that the lid (5) is xed properly.
• Clean the outer surface of the thermopot body (10)
with a slightly damp cloth and then wipe it dry.
• Use neutral detergents to remove dirt, do not use
metal brushes, abrasives and solvents.
• Do not immerse the thermopot and the power cord
(22) into water or other liquids.
• Do not put the thermopot in a dishwashing machine.
10
EN
Stains on the inner surface of the thermopot ask
• Water contains various minerals that can cause
stains on the inner surface of the thermopot ask, the
stains do not aect the operation of the thermopot,
stains are not covered by the warranty.
• You can remove the stains from the inner surface of
the thermopot ask with citric acid solution or table
vinegar.
• To remove the avour of citric acid or vinegar, boil
water and pour it out.
• Repeat this procedure until the smell and foreign
taste vanish completely.
Removing the mineral deposits (descaling)
• Scale, appearing inside the thermopot ask,
inuences the water taste and disturbs the heat
exchange between water and the heating element.
It also risks damaging the heating element. Burning
of the heating element caused by the large amount
of scale in the thermopot ask is not covered by
warranty.
• To remove the scale ll the thermopot with a mixture
of one part ordinary vinegar and two parts water up
to the maximal level mark (15).
• Insert the power cord (22) jack into the connector
(11) on the thermopot body, and the power cord (22)
plug into the mains socket.
• The thermopot will be switched on in the boiling
mode. After the water boiling disconnect the power
cord (22) plug from the socket and leave the
thermopot lled with the vinegar solution overnight.
• In the morning pour out the vinegar solution, ll the
thermopot with water up to the maximal level, boil it
and pour out the water.
• You can use special descaling agents for electric
kettles, strictly following the instruction.
• Clean the thermopot from scale regularly.
STORAGE
• Before taking the thermopot away for long storage,
disconnect it from the mains, let the unit cool down
and pour out the water.
• Clean the thermopot.
• Keep the thermopot out of reach of children and
disabled persons.
DELIVERY SET
1. Thermopot – 1 pc.
2. Power cord - 1 pc.
3. Manual – 1 pc.
ECHNICAL SPECIFICATIONS
• Power supply 220-240 V, ~ 50-60 Hz
• Rated input power: 1450 W
• Max capacity: 5,5 l
11
EN
RECYCLING
To prevent possible damage to the
environment or harm to the health of
people by uncontrolled waste disposal,
after expiration of the service life of the
unit or the batteries (if included), do not
discard them with usual household waste,
take the unit and the batteries to specialized stations for
further recycling.
The waste generated during the disposal of products
is subject to mandatory collection and consequent
disposal in the prescribed manner.
For further information about recycling of this product
apply to a local municipal administration, a household
waste disposal service or to the shop where you
purchased this product.
The manufacturer reserves the right to change the
design, structure and specications not aecting
general operation principles of the unit, without prior
notice.
The unit operating life is 3 years
The manufacturing date is specied in the serial
number.
In case of any malfunctions, it is necessary to apply
promptly to the authorized service center.
DE
12 DE
THERMOPOT BR1091
Mit dem Thermopot können Sie Wasser kochen und
seine Temperatur eingestellt zu halten.
BESCHREIBUNG
1. Wasserstandsskala
2. Wasserknopf
3. Wasserablauftülle
4. Bedienungsplatte
5. Abnehmbarer Deckel
6. Handpumpe
7. Dampfablasslöcher
8. Deckelaufstellplatz
9. Tragegri
10. Gehäuse
11. Netzkabelanschluss
12. Drehuntersatz
Bedienungsplatte
13. Wiederkochtaste «Wiederkochen»
14. Lichtanzeige «Kochen»
15. Lichtanzeige «Temperaturhaltung»
16. Wasserzufuhrtaste «Wasserzufuhr»
17. Lichtanzeige der Wasserzufuhrentriegelung
18. Wasserzufuhrentriegelungstaste «Verriegelung»
19. Heißwassertemperaturhaltungsanzeige «95-85-
65-55-45»
20. Wassertemperaturzahlensymbole
21. 21. Einstelltaste der Heißwassertemperaturhaltung
«С°-Wahl»
22. 22. Netzkabel
ACHTUNG!
Als zusätzlicher Schutz ist es zweckmäßig, den
FI-Schalter mit Nennstrom maximal bis 30 mA im
Stromversorgungskreis aufzustellen; wenden Sie sich
dafür an einen Spezialisten.
6 7
5 8
4
3
2
1
9
10
11
12
13 14 15
Подача воды
Повторное
кипячение
Поддержание
температуры
Блокировка
55
65
45
Выбор
С°
Кипячение
95 85
21
16
17
20
18
13DE
20
19
Abb. 1 Abb. 2 Abb. 3
14
DE
SICHERHEITSHINWEISE UND
GEBRAUCHSANLEITUNG
Bevor Sie den Thermopot benutzen, lesen Sie
die Bedienungsanleitung aufmerksam durch und
bewahren Sie sie zum späteren Gebrauch auf.
• Verwenden Sie den Thermopot nur
bestimmungsgemäß, wie es in dieser
Gebrauchsanleitung beschrieben ist.
• Nicht ordnungsgemäße Nutzung des Thermopots
kann zu seiner Störung führen, einen
gesundheitlichen oder materiellen Schaden beim
Nutzer hervorrufen, und ist kein Garantiefall.
• Benutzen Sie den Thermopot nur fürs
Wasserkochen, es ist nicht gestattet, andere
Flüssigkeiten darin aufzuwärmen oder aufzukochen.
• Vergewissern Sie sich, dass die auf dem
Bezeichnungszettel angegebene Betriebsspannung
und die Netzspannung übereinstimmen.
• Der Netzstecker hat einen Erdungskontakt; stecken
Sie ihn nur in eine Steckdose
• mit dem zuverlässigen Erdungskontakt. Bei
einem Kurzschluss verringert die Erdung das
Stromschlagrisiko.
• Wenden Sie sich an einen Elektriker, wenn Sie sich
nicht sicher sind, ob Ihre Steckdosen richtig installiert
und geerdet sind.
• Verwenden Sie keine Adapterstecker, die zum
Anschließen des Netzsteckers an eine Steckdose
ohne Erdungskontakt bestimmt sind, um das
Brandrisiko zu vermeiden.
• Bei Brandgeruch und Funken in der Steckdose
ziehen Sie den Netzstecker aus der Steckdose
heraus und wenden Sie sich an den Ihr
Hausstromnetz leistenden Dienst.
• Wenn Rauch aus dem Thermopot austritt, ziehen Sie
das Netzkabel aus der Steckdose heraus und treen
Sie die Feuerverhinderungsmaßnahmen.
• Es ist nicht gestattet, den Thermopot draußen zu
benutzen.
• Es ist nicht empfohlen, das Gerät bei Gewitter zu
benutzen.
• Schützen Sie das Gerät vor Stößen, Stürzen,
Vibrationen und anderen mechanischen
Einwirkungen.
• Schalten Sie das Thermopot ohne Wasser nicht ein.
• Es ist nicht gestattet, das Thermopot direkt aus dem
Wasserhahn anzufüllen, benutzen Sie dafür ein
passendes Geschirr.
• Stellen Sie das Thermopot in keiner Nähe von
Wänden oder Küchenmöbeln auf.
• Stellen Sie das Thermopot so auf, dass ein Abstand
zwischen ihm und einer Wand oder den Möbeln
mindestens 20 cm und der Freiraum darüber nicht
weniger als 50 cm beträgt.
• Lassen Sie den ans Stromnetz angeschlossenen
Thermopot nie unbeaufsichtigt.
Loading...
