Label Picture Description QTY
A
Hind Leg(With pre-
installed levellers)
2
B
Front Leg(With pre-
installed levellers)
2
C Chair Body 1
Caution : You must read this before you proceed
Dining Chair
Page 1 OF 5
Label Picture Description QTY
① Allen Key 1
②
Bolt
(M6*16mm)
15
③
Washer
(12mm)
15
④
Spring Washer
(12mm)
15
Before
Beginning
Assembly:
Overview
FRONT FACING
Chair Body (C)
Front Leg (B)
Hind Leg (A)
Page 2 OF 5
Step 1
Place the Chair Seat(C) facedown on the edge of a clean Table Top.
Attach Right Leg(B) to Chair Seat(C) using Bolts(②), Washers(③), and Spring Washers(④), with
Allen Key(①) as pictured above.
Repeat this same process to attach the other Front Leg(B) to Chair Seat(C).
Do not fully tighten the Bolts.
Step 2
This Dining Chair has multiple parts and may require up to 30 minutes to assemble.
To give you an overview of the Dining Chair parts, the above picture is to help you
put the various parts into perspective. Please read through the instructions below to
familiarise yourself with the parts and steps before assembly.
Page 3 OF 5
Step 3
Stand the Chair up and place on flat, level surface.
Carefully and gently sit onto the Chair.
This will help properly align all parts at all joints and remove any gaps.
Carefully get off the Chair and gently turn it over.
Then proceed to tighten all Bolts at all joints.
When tightening the Bolts, tighten sequentially.
Do not tighten any Bolt fully and then move on towards the next one, this could cause the
frame to warp.
If the Chair is not Stable adjust the Pre-installed Levellers at the bottom of the legs until the
chair is level.
Your Dining Chair is ready for use.
This Dining Chair can only be used on a flat, level surface.
Attach Hind Leg(A) to Chair Seat(C) using Bolts(②), Washers(③), and Spring Washers(④), with
Allen Key(①) as pictured above.
Repeat this same process to attach the other Hind Leg(A) to Chair Seat(C).
Do not fully tighten the Bolts.
Page 4 OF 5
Questions & Answers about Proposition 65
• What is Proposition 65?
Proposition 65 requires businesses to provide warnings to Californians about significant
exposures to chemicals that cause cancer, birth defects or other reproductive harm. These
chemicals can be in the products that Californians purchase, in their homes or workplaces, or that
are released into the environment. By requiring that this information be provided, Proposition 65
enables Californians to make informed decisions about their exposures to these chemicals.
Proposition 65 also prohibits California businesses from knowingly discharging significant
amounts of listed chemicals into sources of drinking water.
Proposition 65 requires California to publish a list of chemicals known to cause cancer, birth
defects or other reproductive harm. This list, which must be updated at least once a year, has
grown to include approximately 900 chemicals since it was first published in 1987.
• What types of chemicals are on the Proposition 65 list?
The list contains a wide range of naturally occurring and synthetic chemicals that include additives
or ingredients in pesticides, common household products, food, drugs, dyes, or solvents. Listed
chemicals may also be used in manufacturing and construction, or they may be byproducts of
chemical processes, such as motor vehicle exhaust.
• What does a warning mean?
If a warning is placed on a product label or posted or distributed at a workplace, a business, or in
rental housing, the business issuing the warning is aware or believes that it is exposing individuals
to one or more listed chemicals.
By law, a warning must be given for listed chemicals unless the exposure is low enough to pose
no significant risk of cancer or is significantly below levels observed to cause birth defects or other
reproductive harm.
• Where can I get more information on Proposition 65?
If you have specific questions on the administration or implementation of Proposition 65, you can
contact OEHHA's Proposition 65 program at P65.Questions@oehha.ca.gov, or by phone at (916)
445-6900.
Page 5 OF 5
