Label Picture Description QTY
A Chair Back 1
B Chair Seat 1
C Side Plate 2
D Foot 4
E Seat Cushion 1
F Back Cushion 1
Caution: You must read this before you proceed
CHAIR
1 OF 7
Label Picture Description QTY
①
Allen Key (M6) 1
②
Bolt (M6*45mm) 13
③
Washer 13
④
Allen Key (M4) 1
⑤
Bolt (M6*45mm) 9
⑥
Washer Ring 9
Before Beginning Assembly:
2 OF 7
Step 1
This Chair has multiple parts and may require up to some 30 minutes to assemble. To give you an
overview of the Chair parts, the above picture is to help you put the various parts into perspective.
Please read through the instructions here below to familiarise the parts and steps before assembly.
Chair Back(A)
Back Cushion(F)
Seat Cushion(E)
Chair Seat(B)
Side Plate(C)
FRONT FACING
Foot(D)
3 OF 7
Step 3
Attach Side Plate(C) between the Chair Back(A) and Chair Seat(B) using Bolt(②) and
Washer(③) with Allen Key(①) as shown above.
Only loosely tighten Bolts.
Step 2
Open the carton and place all the parts onto a clean, non-marring surface.
Attach Chair Back(A) to Chair Seat(B) using Bolt(②) and Washer(③) with Allen Key(①) as shown
above.
Only loosely tighten Bolts.
ATTENTION: There may be some PE wicker that may have covered the Mounting Points. To
ease assembly, guide and slide the PE wicker away from these Mounting Points.
DO NOT CUT AWAY ANY PE WICKER as this would cause the wicker to unravel!
4 OF 7
Place the Chair as shown in the picture above.
Attach Side Plate(C) between the Chair Back(A) and Chair Seat(B) using Bolt(②) and
Washer(③) with Allen Key(①) as shown above.
Only loosely tighten Bolts.
Step 4
Step 5
Attach the Feet(D) to the Chair using Bolt(⑤) and Washer(⑥) with Allen Key(④) as shown
above.
Only loosely tighten Bolts.
5 OF 7
Step 6
Place the Back Cushion(F) and Seat Cushion(E) onto the Chair.
Your Chair is ready for use.
Caution:This Chair can only be used on a flat, level surface.
Turn the Chair right side up.
Place the Chair on a LEVEL SURFACE.
Inspect it and make sure all parts are adequately connected.
Gently and gracefully, sit into to the Chair.
This would help to align all the parts at all the joint areas.
Then get off the Chair, and in a sequential manner, proceed to tighten all bolts.
When tightening the Bolts, tighten sequentially.
DO NOT tighten any Bolt fully and then move on to the next one.
This may cause the frame to warp.
If there is still wobbles, loosen the bolts and execute this same process.
If the Chair is not stable it could lead to damage to the product.
Note: This step is done better with the assistance of a second adult.
6 OF 7
Questions & Answers about Proposition 65
• What is Proposition 65?
Proposition 65 requires businesses to provide warnings to Californians about significant exposures
to chemicals that cause cancer, birth defects or other reproductive harm. These chemicals can be
in the products that Californians purchase, in their homes or workplaces, or that are released into
the environment. By requiring that this information be provided, Proposition 65 enables Californians
to make informed decisions about their exposures to these chemicals.
Proposition 65 also prohibits California businesses from knowingly discharging significant amounts
of listed chemicals into sources of drinking water.
Proposition 65 requires California to publish a list of chemicals known to cause cancer, birth
defects or other reproductive harm. This list, which must be updated at least once a year, has
grown to include approximately 900 chemicals since it was first published in 1987.
• What types of chemicals are on the Proposition 65 list?
The list contains a wide range of naturally occurring and synthetic chemicals that include additives
or ingredients in pesticides, common household products, food, drugs, dyes, or solvents. Listed
chemicals may also be used in manufacturing and construction, or they may be byproducts of
chemical processes, such as motor vehicle exhaust.
• What does a warning mean?
If a warning is placed on a product label or posted or distributed at a workplace, a business, or in
rental housing, the business issuing the warning is aware or believes that it is exposing individuals
to one or more listed chemicals.
By law, a warning must be given for listed chemicals unless the exposure is low enough to pose no
significant risk of cancer or is significantly below levels observed to cause birth defects or other
reproductive harm.
• Where can I get more information on Proposition 65?
If you have specific questions on the administration or implementation of Proposition 65, you can
contact OEHHA's Proposition 65 program at P65.Questions@oehha.ca.gov, or by phone at (916)
445-6900.
7 OF 7
