Label Picture Description QTY
A Left Armrest 1
B Right Armrest 1
C Seat 1
Assembly Instructions
Caution: You must read this before you proceed
Dining Chair
Parts List
Page 1 OF 6
D Backrest 1
E Seat Cushion 1
Label Picture Description QTY
① Bolt (M6*30MM) 9
② Washer 9
③ Allen Key 1
Before Beginning
Assembly:
Hardware
Assembly Preparation
Page 2 OF 6
Step 1
Assembly Steps
Overview
This Dining Chair has multiple parts and may require up to 30 minutes to assemble. To
give you an overview of the Dining Chair parts, the above picture is to help you put the
various parts into perspective. Please read through the instructions below to familiarise
yourself with the parts and steps before assembly.
①
②
Page 3 OF 6
If the Dowel does not match the mounting position, please loosen the Dowel by 3-5MM.
Step 2
Step 3
Open the carton and place all the parts onto a clean, non-marring surface.
1.1 Insert the Dowel on the Backrest(D) into the mounting position of the Left
Armrest(A).
1.2 Atach Backrest(D) to Left Armrest(A) using Bolts(①) and Washers(②) with Allen
Key(③) as shown in the picture.
Do not fully tighten the Bolts.
Occasionally some of the PE Wicker shifts and covers the mounting positions
preventing easy assembly. The PE Wicker should never be cut, but moved away
from the mounting positions.
2.1 Align Seat(C) with Left Armrest(A) and Backrest(D).
2.2 Attach Seat(C) to Left Armrest(A) and Backrest(D) using Bolts(①) and
Washers(②) with Allen Key(③) as pictured.
Do not fully tighten the Bolts.
①
②
①
②
①
②
Step 3.1
Step 3.2
Page 4 OF 6
Step 4
Align Right Armrest(B) to Backrest(D) and Seat(C).
3.1 Insert the Dowel on the Backrest(D) into the mounting position of the Right
Armrest(B).
3.2 Attach Right Armrest(B) to Backrest(D) and Seat(C) using Bolts(①) and
Washers(②) with Allen Key(③) as shown in the picture.
Stand the Chair up.
Exert pressure floorwards, onto the Chair with both your hands.
This pressure will help the Chair reach full alignments status.
Check for wobbles on a LEVEL surface.
If no wobbles are found proceed to tighten the Bolts and Screws in a sequential
manner, until evenly secured.
When tightening the Bolts and Screws sequentially.
DO NOT tighten any Bolt or Screw fully and then move on towards the next one.
If there are still wobbles, loosen the Bolts and Screws and excute the same
above process.
If the Chair is not stable it could lead to damage to the product.
Put the Seat Cushion(E) on the Chair.
Your Dining Chair is ready for use.
This Dining Chair can only be used on the flat, level surface.
Page 5 OF 6
Questions & Answers about Proposition 65
• What is Proposition 65?
Proposition 65 requires businesses to provide warnings to Californians about significant exposures to
chemicals that cause cancer, birth defects or other reproductive harm. These chemicals can be in the
products that Californians purchase, in their homes or workplaces, or that are released into the
environment. By requiring that this information be provided, Proposition 65 enables Californians to
make informed decisions about their exposures to these chemicals.
Proposition 65 also prohibits California businesses from knowingly discharging significant amounts of
listed chemicals into sources of drinking water.
Proposition 65 requires California to publish a list of chemicals known to cause cancer, birth defects
or other reproductive harm. This list, which must be updated at least once a year, has grown to
include approximately 900 chemicals since it was first published in 1987.
• What types of chemicals are on the Proposition 65 list?
The list contains a wide range of naturally occurring and synthetic chemicals that include additives or
ingredients in pesticides, common household products, food, drugs, dyes, or solvents. Listed
chemicals may also be used in manufacturing and construction, or they may be byproducts of
chemical processes, such as motor vehicle exhaust.
• What does a warning mean?
If a warning is placed on a product label or posted or distributed at a workplace, a business, or in
rental housing, the business issuing the warning is aware or believes that it is exposing individuals to
one or more listed chemicals.
By law, a warning must be given for listed chemicals unless the exposure is low enough to pose no
significant risk of cancer or is significantly below levels observed to cause birth defects or other
reproductive harm.
• Where can I get more information on Proposition 65?
If you have specific questions on the administration or implementation of Proposition 65, you can
contact OEHHA's Proposition 65 program at P65.Questions@oehha.ca.gov, or by phone at (916)
445-6900.
Page 6 OF 6
