Label Picture Description QTY
H Left Armrest 1
I Back 1
J Seat 1
D Side Plate 1
E Foot 4
F Seat Cushion 1
G Back Cushion 1
Caution: You must read this before you proceed
LEFT ARMCHAIR
1 OF 6
Label Picture Description QTY
①
Allen Key (M6) 1
②
Bolt (M6*45mm) 13
③
Washer 13
④
Allen Key (M4) 1
⑤
Bolt (M6*45mm) 9
⑥
Washer Ring 9
Before Beginning Assembly:
2 OF 6
Overview
This Left Armchair has multiple parts and may require up to 30 minutes to assemble. To give
you an overview of the Left Armchair parts, the above picture is to help you put the various
parts into perspective. Please read through the instructions below to familiarise yourself with
the parts and steps before assembly.
Open the carton and place all the parts onto a clean, non-marring surface.
Place the Left Armrest(H) with its inside facing up.
Attach Chair Back(I) to the corresponding point in Left Amrest(H) using Bolt(②) and
Washer(③) with Allen Key(①) as shown above.
Do not fully tigthen.
ATTENTION: There may be some PE wicker that may have covered the Mounting
Points. To ease assembly, guide and slide the PE wicker away from these Mounting
Points.
DO NOT CUT AWAY ANY PE WICKER as this would cause the wicker to unravel!
Step 1
Back (I)
Left Armrest (H)
Side plate (D)
Seat Cushion (F)
Seat (J)
Back Cushion (G)
Foot (E)
FRONT FACING
3 OF 6
Step 2
Attach Seat(J) between the Left Armrest(H) and Back(I) using Bolt(②) and Washer(③) with
Allen Key(①) from position # I to # V as shown above.
Do not fully tigthen.
Step 3
Attach Side Plate(D) between the Back(I) and Seat(J) using Bolt(②) and Washer(③) with
Allen Key(①) as shown above.
Do not fully tigthen.
Step 4
Attach the Foot(E) to the Chair using Bolts(⑤) and Washer Rings(⑥) with Allen Key(④).
4 OF 6
Place the Back Cushion(G)and Seat Cushion(F) onto the Left Armchair as shown.
Your Left Armchair is ready for use.
Caution:This Left Armchair can only be used on a flat, level surface.
Turn the Left Armchair right side up.
Place the Left Armchair on a LEVEL SURFACE.
Inspect it and make sure all parts are adequately connected.
Gently and gracefully, sit into to the Left Armchair.
This would help to align all the parts at all the joint areas.
Then get off the Left Armchair, and in a sequential manner, proceed to tighten all bolts.
When tightening the Bolts, tighten sequentially.
DO NOT tighten any Bolt fully and then move on to the next one.
This may cause the frame to warp.
If there is still wobbles, loosen the bolts and execute this same process.
If the Left Armchair is not stable it could lead to damage to the product.
Note: This step is done better with the assistance of a second adult.
Step 6
Step 5
5 OF 6
Questions & Answers about Proposition 65
• What is Proposition 65?
Proposition 65 requires businesses to provide warnings to Californians about significant
exposures to chemicals that cause cancer, birth defects or other reproductive harm. These
chemicals can be in the products that Californians purchase, in their homes or workplaces, or
that are released into the environment. By requiring that this information be provided,
Proposition 65 enables Californians to make informed decisions about their exposures to
these chemicals.
Proposition 65 also prohibits California businesses from knowingly discharging significant
amounts of listed chemicals into sources of drinking water.
Proposition 65 requires California to publish a list of chemicals known to cause cancer, birth
defects or other reproductive harm. This list, which must be updated at least once a year, has
grown to include approximately 900 chemicals since it was first published in 1987.
• What types of chemicals are on the Proposition 65 list?
The list contains a wide range of naturally occurring and synthetic chemicals that include
additives or ingredients in pesticides, common household products, food, drugs, dyes, or
solvents. Listed chemicals may also be used in manufacturing and construction, or they may
be byproducts of chemical processes, such as motor vehicle exhaust.
• What does a warning mean?
If a warning is placed on a product label or posted or distributed at a workplace, a business,
or in rental housing, the business issuing the warning is aware or believes that it is exposing
individuals to one or more listed chemicals.
By law, a warning must be given for listed chemicals unless the exposure is low enough to
pose no significant risk of cancer or is significantly below levels observed to cause birth
defects or other reproductive harm.
• Where can I get more information on Proposition 65?
If you have specific questions on the administration or implementation of Proposition 65, you
can contact OEHHA's Proposition 65 program at P65.Questions@oehha.ca.gov, or by phone
at (916) 445-6900.
