GX2000
Instruction Manual
13
Congratulations on your purchase of this high-quality BRAX amplier.
With the amplier BRAX GX2000 you have chosen a product which combines ultimate perfection in sound and technical
maturity with a maximum of individuality. Only hand selected components and nest materials are used in the amplier‘s
production process and thus guarantee a top-class high-end music experience.
For more than 30 years we have been working on the development and manufacturing of top-notch audio components.
The brand BRAX has worldwide an excellent reputation for superior quality. Various honours by the world‘s major car audio
magazines and, last but not least, numerous innovation awards are the proof of our excellent work.
We have provided the amplier BRAX GX2000 with everything it requires in order to set new standards concerning sound
quality, manufacturing, and longevity. We are very proud to offer you this high-end product MADE IN GERMANY.
We wish you many hours of enjoyment with your BRAX GX2000.
AUDIOTEC FISCHER GMBH
Heinz Fischer
Founder and Managing Director
DEAR CUSTOMER
Your amplier BRAX GX2000 has the serial number:
14
Based on our basic principles “handmade” and “made in Germany” we have designed the amplier BRAX GX2000 according to the latest technical knowledge. The result is both a top-class amplier and a true high-end statement: A long lasting
period of research and development, innovative technologies and an extremely fastidious manufacturing combined with
the love for music as the driving force for our work make the BRAX GX2000 doubtlessly to one of the most powerful and
best sounding 2-channel ampliers.
Concerning the straight design of the GX2000 amplier and the sophisticated layout of the circuit board, we have deliberately set crossovers and lter functions aside. Short signal paths combined with selected components “made in Germany”
ensure pristine listening pleasure and underline the puristical high-end philosophy of BRAX ampliers.
In order to completely eliminate power differences and manufacturing tolerances, we only use hand-selected transistors
for the production of each GX2000 amplier. Concerning power-, voltage- and resistance data we select them in more
than 300 categories. Thus, all transistors harmonize perfectly in terms of technical specications. In doing so, our BRAX
ampliers obtain a worldwide reference status. Striving for ultimate perfection, Audiotec Fischer is the only manufacturer
of audiophile products on the globe that conducts this extensive and time-consuming hand-selection. Of course, all mea-
surement devices which are necessary for this procedure are in-house developments.
In order to control voltage uctuations, an external power stabilizer can directly be connected to the power supply. Moreover, the solid and gold-plated terminals for cables up to 50 mm² make another contribution to an ideal power supply of
the BRAX GX2000.
At the end of the day, the BRAX GX2000 can be described as an amplier with a sound rendition that is highly dynamic,
powerful in an awsome way and swift as an arrow. The underlying philosophy is topped-off by a packaging in a precious
wooden box. Furthermore, each single amplier is manufactured individually and its respective serial number is recorded in
our data-base. The amplier BRAX GX2000 is only produced on demand and of course we can respond to our customer’s
requirements. In this way, each amplier is a valuable individual item that rightly deserves the title “high-end made in
Germany”.
THE BRAX PHILOSOPHY
15
CONNECTION AND CONTROL ELEMENTS
7 78
Loudspeaker terminals
7
Signal inputs
8
1 2 3 5 6
Connection remote lead
1
Connection +12 V battery cable
2
Connection ground cable
3
CPS LED
4
5
Connection BRAX Power Stabilizer (plus)
4
6
Connection BRAX Power Stabilizer (minus)
