Owner / Operator
and Safety Manual
See
initial start-up
instructions on page one
IIrroonn && OOaakk 2200 TToonn
Tractor Mount
Horizontal Log Splitter
MMooddeell TTMMHH1100
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Personal Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Worksite Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operating Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Log Splitting Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Maintenance and Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Shipping List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Attaching Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Assembly and Initial Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Start-Up Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Inspection and Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Warranty Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Optional Attachments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
800-817-1005 1 Iron & Oak
Serial Number ______________
Date of Purchase ___________
Please enter the serial number and purchase
date of your log splitter in the space provided.
Keep this manual for future reference.
NOTE: Iron and Oak Commercial Products reserves the right to make technical
changes for product improvement. This manual may contain illustrations
and photographs, for demonstration purposes, which slightly deviate from the
actual product design.
Iron & Oak 2 800-817-1005
Accidents can often be avoided by being alert and recognizing potentially hazardous situations. Any individuals operating, maintaining, or repairing products manufactured by Iron & Oak Commercial Products should have the necessary training, skills, and tools required to perform these functions properly
and safely. The safety information in this manual serves as a basic guide in an
attempt to prevent injury or death.
Iron & Oak Commercial Products cannot anticipate every possible circumstance that might involve a potential hazard. The warnings in this manual and
on the product itself are, therefore, not all inclusive. If tools, procedures, work
methods, or operating techniques that are not specifically mentioned by Iron &
Oak Commercial Products are used, you must satisfy yourself that they are safe
for you and for others. Make sure the log splitter will not be damaged or made
unsafe by any operation, lubrication, maintenance, or repair procedures that
you choose.
DO NOT proceed if any doubt arises about the correct or safe method of performing anything found in this or other Iron & Oak Commercial Products’ manuals. Seek out expert assistance from a qualified person before continuing.
WARNING
To avoid personal injury or death, carefully read and understand all
instructions pertaining to the Iron & Oak Commercial Products’ log
splitter.
Do not attempt to assemble, operate, or maintain our product without
fully understanding all our instructions and safety precautions. Do
not operate the log splitter unless you read and understand the
instructions and warnings in this manual. If any doubt or question
arises about the correct or safe method of performing anything found
in this or other Iron & Oak Commercial Products’ manuals, contact
your Iron & Oak Commercial Products’ dealer or call the Sales and
Service representatives at our main headquarters. Proper care is
your responsibility.
WARNING
Introduction
The commercial TMH10 Horizontal Tractor Mount Log Splitter is designed for tough applications elevated or on the ground. With up to 20 tons of splitting force, the TMH10 will
handle most of your commercial log splitting needs. The log splitter attaches to any tractor with a class 1, 2, or 3 three-point hitch.
Power for the TMH10 comes directly from tractor-supplied hydraulic pressure. The maximum splitting force is determined by the pressure output of the tractor’s hydraulic system. For example, 3000 psi of pressure produces 20 tons of splitting force, 2000 psi produces 12.5 tons, and 1500 psi produces 9 tons.
An attractive, powder-coated finish provides the finest protection available and Iron &
Oak’s rigid, quality-control and component testing help ensure years of productive, reliable service. Since 1982, the name Iron & Oak has stood for quality and reliability when
it comes to log splitters and wood processing products.
Iron & Oak Commercial Products offers the finest commercial log splitter on the market
today!
✔ Rugged, heavy-duty construction for years of exceptional service.
✔ Fits category 1, 2, and 3 tractor hitches.
✔ Rigid, quality-control during manufacturing ensures greater reliability.
✔ Factory testing of all major components.
✔ Powder-coated finish for the best appearance and weather protection.
✔ Year-round manufacturing, parts, and support.
For additional information, contact us at:
Iron & Oak Commercial Products
1705 N. Shabbona St.
Streator, Illinois 61364-1301
Phone: (800) 817-1005 (toll free)
(815) 672-8596
Fax: (815) 672-9073
E-mail: sales@logsplitters-ironoak.com
Web Site: www.ironandoak.com
800-817-1005 3 Iron & Oak
Safety
The following is a list of safety rules you must follow in order to use your log splitter safely.
Personal Protection
✔ To avoid personal injury or death, carefully read and understand all instruc-
tions pertaining to the log splitter including the engine manufacturer’s operating and maintenance instruction manual.
✔ Always wear protective gear, such as safety
goggles, tight-fitting gloves without drawstrings or loose cuffs, steel-toed shoes, and a
protective hearing device.
✔ To prevent injury, make sure all decals are attached to the log splitter and
are legible at all times.
Worksite Safety
✔ To avoid tripping, do not leave tools, logs, or other components laying around
in the work area.
✘ NEVER operate your log splitter on slippery, wet, muddy, or icy surfaces. The
location you choose should be flat, dry, and free from any tall grass, brush,
or other interferences.
✘ NEVER operate the tractor in an enclosed area. Exhaust fumes contain car-
bon monoxide which can be deadly when inhaled. Make sure the area is well
ventilated.
✘ NEVER use your log splitter at night.
✔ ALWAYS operate your log splitter on dry, solid, level ground.
✔ ALWAYS engage the parking brake and block the wheels of the tractor to
prevent movement while operating the log splitter.
✔ Sudden movement or accidental starting of the tractor can cause personal
injury or death to persons on or near the tractor. When working on or near
the tractor, park the tractor on a smooth level surface, stop the engine, and
engage the parking brake.
N
I
N
G
AR
Iron & Oak 4 800-817-1005
Operating Safety
✔ ALLOW ONLY ONE (1) PERSON TO LOAD AND OPERATE THE LOG SPLIT-
TER.
✔ Allow only adults to operate the log splitter. No one under the age of 18 should
be allowed to operate the log splitter.
✔ Always keep bystanders, including children and pets, at least twenty-five (25)
feet away from the work area. Only the operator should stand near the equipment, and the operator should stand only within the safe operating zone prescribed in this manual (see the photos on safe and unsafe operating zones in
the “Operation” section).
✔ When the ram of the log splitter is in the return mode, keep your hands off the
machine — the log splitter is designed to automatically stop when the cylinder
is fully retracted.
✔ Personal injury or death can result from not engaging the tractor’s parking
brake while attaching the log splitter. If the parking brake is not engaged, the
tractor may roll while you are on or near the tractor. Always engage the parking brake before leaving the tractor.
✔ Personal injury could result from an improperly coupled log splitter. Be certain
draft links, top link, and hitch pins are fully engaged on both sides before using
the log splitter.
✔ An improperly installed log splitter could become dislodged from the tractor dur-
ing operation. This could cause injury or death. Do not operate the tractor until
you are sure the log splitter attachment is properly connected.
✔ Heavy three-point hitch mounted equipment reduces road stability, regardless
of the amount of front-end counterweight added. Insufficient roading stability
can lead to an accident, causing personal injury and property damage. Reduce
speed when encountering rough terrain or whenever the tractor’s directional
stability is reduced.
✘ Do not allow any person to operate the log splitter until they have read and
understood the safe operating instructions contained in this manual.
✘ Machine instability can result in injury or death. To ensure stability during oper-
ation, do not overload the tractor and follow all the tractor’s manufacturers safety recommendations.
800-817-1005 5 Iron & Oak
✘ Do not, under any circumstances, alter your log splitter. This equipment was
designed and engineered to be used in accordance with the operating
instructions. Altering the equipment, or using the equipment in such a way
as to circumvent its design capabilities and capacities, could result in serious or fatal injury and WILL VOID THE WARRANTY.
✘ Never operate, or allow anyone else to operate, this equipment while
under the influence of medication, drugs, or alcohol.
✘ Never wear loose clothing or jewelry that may get caught or become entan-
gled in the log splitter.
✘ NEVER place hands or feet between log and splitting wedge or between log
and ram during the forward or reverse stroke.
✘ DO NOT STRADDLE OR REACH ACROSS THE SPLITTING AREA WHEN
OPERATING THE LOG SPLITTER.
✘ Do not step over your log splitter when the tractor is running because you may
trip or accidentally engage the ram.
✘ NEVER attempt to load your log splitter while the ram is in motion.
✘ Only use your hand to operate the control lever. NEVER use your foot, knee, a
rope, or any other extension device.
Log Splitting Safety
✔ Always keep your fingers away from any cracks that open in the log during the
splitting operation.
✔ ALWAYS make sure that both ends of the log you are splitting are cut as square
as possible. This will prevent the log from sliding out of position while under
pressure. Logs should be 24 inches or shorter in length.
✘ NEVER try to split two logs on top of each other.
✘ Never pile logs to be split in a manner that will cause you to reach across the
log splitter.
Iron & Oak 6 800-817-1005
Maintenance and Repair
✔ Follow all safety rules, because most accidents involving the operation,
maintenance, or repair of products occur because the assembler/
owner/operator failed to observe basic safety rules or operating instructions.
✔ ALWAYS inspect your log splitter before each use. Make sure all nuts, bolts,
screws, hydraulic fittings, hose clamps, etc. are securely tightened.
✔ ALWAYS check the oil level in the hydraulic oil tank.
✘ NEVER operate your log splitter when it’s in need of repair or is in poor
mechanical condition.
✘ NEVER make alterations to your log splitter in any manner. Such alterations
may cause the log splitter to become unsafe and WILL VOID THE WARRANTY.
✘ NEVER attach a rope or extension to the control lever or add width or height to
the splitting wedge. Such ALTERATIONS may cause the log splitter to become
UNSAFE and WILL VOID THE WARRANTY.
✘ ALWAYS clean the unit after each use. If possible, store the unit inside or cover
it completely, if stored outside.
800-817-1005 7 Iron & Oak
Assembly Instructions
Shipping List
The following charts contain the list of parts shipped with your log splitter.
Attaching Handle
1. Attach the valve control handle to the
valve. First, install clevis pin and hairpin
clip (1) through the bottom hole on the
valve.
Next, insert the forked end of handle (2)
over pin (1).
Finally, align the hole in the handle with the
top hole in the valve and insert clevis pin
and hairpin clip (3).
Iron & Oak 8 800-817-1005
TMVH02/PTO
Qty. Valve Assembly
1 Control Lever (valve)
1 Knob (valve lever)
1 Valve Link
3 Clevis Pins
3 Cotter Pins
Assembly and Initial Installation Procedure
1. Attach the tractor mount log splitter to the
three-point tractor hitch, as shown, and
according to the directions found in your
tractor operating manual.
2. Lower the log splitter to the ground. Mea-
sure the distances from the inlet and outlet port of the valve to the tractor’s supply
and return port.
3. Attach customer supplied 3/4 inch
hydraulic hose from your tractor’s
hydraulic supply port to the inlet port on
the control valve. Connect the second
hose from the tractor’s return port to the
outlet port on the control valve.
800-817-1005 9 Iron & Oak
4. The log splitter is now completely assem-
bled. Follow the “Start-Up Procedure”
in the following section.
Iron & Oak 10 800-817-1005
Start-Up Procedure
Model TMH10
1. Lubricate the surface of the slide rail with grease. This will help to prevent wear
between the slide plates and the slide rail.
2. Push the valve control handle to the forward position (towards the front of the cylinder)
until the cylinder piston moves forward. (Keep everything away from the splitting wedge
during this step).
3. Cycle the log splitter several times.
4. Push the valve control handle to the retract position and retract the cylinder piston.
The cylinder valve will automatically stop the cylinder from retracting when it reaches the
end of its stroke.
5. Your log splitter is now ready to use.
800-817-1005 11 Iron & Oak
Operation
Do not attempt to operate the log splitter without fully understanding
all our instructions, safety precautions, and/or warnings. If any doubt
or question arises about the correct or safe method of performing any-
thing found in this or other Iron & Oak Products’ manuals, contact your
Iron & Oak Products’ dealer or call the Sales and Service representatives at our
main headquarters. Proper care is your responsibility.
When operating the log splitter make sure you
are standing in the safe operating area, as
shown in these pictures. You must stay in the
safe operating area at all times when the
splitting wedge is in motion (whether extending or retracting). Never place any part of
your body into a position which would cause
an unsafe operating condition.
1. Place the tractor and log splitter on flat, dry
ground. Make sure you read all recommendations from the “Safety” section
before using the log splitter.
2. Make sure both ends of the log you are
splitting are cut as square as possible.
This will prevent the log from sliding out of
position while under pressure. All logs
should be 24 inches long or shorter.
Never attempt to split wood across the
grain. The log splitter was not designed for
cross-grain splitting. Doing so will damage the log splitter and may cause personal injury.
WARNING
WARNING
Iron & Oak 12 800-817-1005
Before loading and operating the log splitter,
always wear protective gear, such as safety
goggles, face shield, hearing protection,
tight-fitting gloves without drawstrings or loose cuffs, and steel-toed shoes.
3. Start the tractor. Warm up the PTO pump
and/or hydraulic system by running the
engine at half throttle for three to four minutes, then advance the engine throttle
control to maximum speed.
4. Use the following photos for the correct
and incorrect methods of splitting logs.
Never split a log using an incorrect or
unsafe method.
a. Place the log on the log splitter. Grasp
the log on the sides near the middle of
the block. Center the log, side-to-side,
on the rail of the log splitter, making
sure that the sawed end is against the
splitting wedge.
Do not place your hands on the
ends of the log when loading the
log splitter. This is a very
UNSAFE method and could result in injury
to your hands.
CAUTION
WARNING
800-817-1005 13 Iron & Oak
b. Using only your hand, push the control
lever forward (towards the log). If the
log moves before it is contacted by the
splitting wedge, release the control
lever and then reposition the log.
Operate the log splitter only when
standing in the safe operating area,
as shown in the picture.
If you find you must hold the log
until the wedge touches it and
holds it in place, be very careful
not to put your hand between the log and
the end plate or the log and the wedge. If
you must, hold the log on top and in the
middle. Remove your hand immediately
when the splitting wedge engages the log.
Never use your hip or any extension device
to operate the valve control handle.
Do not operate the log splitter by
reaching across the rail. This is a
very UNSAFE method which
could cause personal injury or even death.
Do not reach or step across the
rail while the log splitter is run-
ning. This is a very UNSAFE
method which could cause personal injury
or even death.
WARNING
WARNING
CAUTION
Iron & Oak 14 800-817-1005
c. Hold the control lever, extending the
splitting wedge, until the log is split or
the cylinder rod stops at its maximum
travel position. As the log is being
split, DO NOT reach forward and
attempt to catch the split wood — let it
fall to the ground.
d. Once the wedge reaches its full for-
ward travel, pull back on the control
lever to the full retract position. The
ram of the cylinder will automatically
retract into the cylinder. It is not necessary to hold the control lever as the
cylinder retracts. Stop the wedge if the
log sticks (see caution below). When
the cylinder is fully retracted, the control valve will automatically shift to a
neutral position.
e. DO NOT load another log or remove
split pieces from the rail until the
wedge has completely stopped and
the control handle automatically
returns to the neutral position.
Depending on the type of wood
being split, a log may not always
break into two pieces and fall to
the ground. If a log sticks to the wedge,
place the valve handle in the neutral position (stop the wedge from retracting) and
carefully remove the log from the wedge.
Allowing the log to remain attached to the
wedge when it is fully retracted could lead
to possible injury and/or damage to the log
splitter.
CAUTION
800-817-1005 15 Iron & Oak
Inspection and Maintenance
General Maintenance Check (before operating)
The hydraulic system (hoses, cylinder, and pump) should be carefully inspected before
each use. Also, inspect the mechanical parts at the same time. Make sure all clamps,
nuts, bolts, fittings, etc. are properly installed and tightened.
Do not check for leaks with your hand. Leaks can be located by passing a piece of cardboard or wood around the suspected leak and looking for discoloration. High-pressure fluid escaping from a very small
hole can be almost invisible. Escaping fluid under pressure can have
sufficient force to penetrate skin, causing serious injury or even death.
If fluid is injected into your skin, it must be treated immediately by a doctor familiar with this type of injury.
Always replace frayed, kinked, or cracked hoses and/or other damaged hydraulic components with Iron & Oak Commercial Products’ authorized parts and components specified in the “Parts” section of this manual. Replacement parts from secondary suppliers
(not original Iron & Oak replacement parts) can lead to product damage and/or personal
injury, and will void the warranty.
Should it become necessary to loosen or remove any hydraulic fitting or line, be sure to
relieve all hydraulic pressure by shutting off the tractor and moving the valve control handle back and forth several times until no cylinder movement is visible.
Storage
Between each use of the log splitter, we recommend applying a rust preventative (WD-40
or equivalent) to any bare metal areas on the top of the rail.
WARNING
Iron & Oak 16 800-817-1005
Inspection and Maintenance
Mechanical Specifications
(Model TMH10)
Three-Point Hitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Category 1, 2, or 3
Slide Rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6” x 6” heavy-duty, formed steel
Wedge . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 inch, high-carbon steel, compound angle
Force/Tonnage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 tons @ 3000 psi
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12.5 tons @ 2000 psi
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 tons @ 1500 psi
Cylinder Stroke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 inches
Log Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 inch maximum
Operating Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Horizontal
Unit Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 343 lbs.
Hydraulic Specifications (Model TMH10)
Cylinder Size . . . . . . . . . . . . . . . . . 4 x 24 inch, clevis type cylinder with 1.75 inch rod
Safety Release Control Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Detent, auto return
800-817-1005 17 Iron & Oak
Troubleshooting
The following section will detail procedures for checking your log splitter should you
encounter a malfunction. Iron & Oak Commercial Products, Inc. recommends that you
do not attempt to make repairs to the log splitter. In the long run, it is better to take your
log splitter to a servicing lawn and garden dealer for repairs.
Problem: When the control handle is pushed forward (extend), the wedge does not
move.
1. Check tractor hydraulic tank to make sure it is properly filled.
2. Make sure the tractor hydraulics are functioning.
4. Disconnect the wedge from the cylinder. Grasp the hydraulic cylinder shaft
and try to pull it out. If the rod comes out easily, you will need to rebuild
or replace the cylinder.
Problem: The wedge moves slowly, but will split wood.
1. Check the output of the tractor’s supply oil.
2. For PTO models check the output of the PTO pump.
Problem: The ram will not automatically retract.
1. Check the slide rail or wedge assembly for damage.
2. Push the valve handle to the retract position. If the handle will not stay in
this position, adjust valve detent, as described below.
Detent Adjustment Procedure
a. Locate adjustment screw on lower side of valve body.
b. Loosen locknuts.
c. Turn adjustment screw clockwise one-half turn and retighten locknuts.
d. Start tractor hydraulics and test for detent operation. If detent does not
work, repeat Steps b and c.
3. If adjustment of detent does not correct the problem, replace the valve
assembly.
Iron & Oak 18 800-817-1005
Decals
Make sure all decals are attached to the log splitter and/or engine and
are legible at all times.
N
I
NG
AR
WARNING
800-817-1005 19 Iron & Oak
(1c)
(1a)
(1b)
CONTROL VALVE
Reverse
Neutral
Forward
Iron & Oak 20 800-817-1005
Item Part No. Description Qty.
1 BR002308 Decal, Operating Safety (set) 1
2 BR002310 Decal, Warning Crush 1
3 BR002521 Decal, Serial Number 1
4 BR002621 Decal, Made in USA 1
(NS) BR002499 Decal, Iron & Oak 2
NS - not shown
(2)
(4)
(3)
WARNING
Only load log splitter
by holding logs by
their sides. Failure to
do so may result in
crush or amputation
Parts
Model TMH10
800-817-1005 21 Iron & Oak
TMH10-016
8
10
7
6
4
3
2
5
Note 1
1
9
12
11
Note 2
Item Part No. Description Qty.
1 BR026014 Weldment, Rail 1
2 BR021258-03 Weldment, Slide 1
3 BR013103 Guide, Slide 5/8” 2
4 BR013104 Retainer, Slide 2
5 BR001259 Bolt, Carriage, 1/2-13 x 2-1/2” 6
6 BR001404 Lockwasher, 1/2” 6
7 BR001304 Nut, 1/2-13 6
8 BR004057 Cylinder - SMC 4”x24”x1 3/4” 1
9 BR001765 Pin, Clevis, 1/2 x 3” long 1
10 BR001761 Clip, Hairpin, 3/32 x 1-3/4” long 1
11 BR008531A Pin, Grooved, 1” dia. 1
12 BR001705 Clip, Hairpin (Cylinder) 2
Note 1: Holes are used to mount optional BR021180 Log Cradle.
Note 2: Holes are used to mount optional BR026003SA
Kit - PTO Tank (TM10)
Iron & Oak 22 800-817-1005
Item Part No. Description Qty.
1 BR026002 Weldment, Hitch Bracket 1
2 BR001703 Pin Assembly, Lift Arm 2
3 BR001282 Lock Washer, 7/8” 2
4 BR001283 Lock Nut, 7/8” 2
5 BR001495 Hitch Pin, 5/8” 2
6 BR001764 Hairpin Clip 2
TMH10-017
1
3
2
5
6
4
800-817-1005 23 Iron & Oak
TMH10-018
1
3
4
6
2
Item Part No. Description Qty.
1 BR004100HK Handle Assembly Kit
(Includes handle, clevis, pins,
and hairpin clips) 1
2 BR004102 Valve 1
3 BR001052 Fitting, Straight 1
4 BR004002K Fitting, 90 Elbow 1
6 BR004119N Hose, high Pressure 1
Warranty
For one year from the date of purchase, Iron & Oak Commercial Products Inc. will
replace for the original purchaser, or repair free of charge, all parts of the Iron & Oak
Commercial Products’ Hydraulic Log Splitter, returned to our factory PREPAID and found
upon inspection by us to be faulty, due to defects in materials or workmanship.
The warranty shall not apply to any unit which has been overloaded or misused or which
has been installed, used, or operated contrary to our instructions, or which has been
repaired or altered by anyone other than our authorized representative.
We shall not be liable for any contingent liabilities arising out of the improper function of
any parts.
We make NO WARRANTY with respect to parts NOT of our manufacture, but we will
carry out the terms of the warranties of their respective manufacturers.
If a service representative cannot be found in your area, call Iron & Oak Commercial
Products at (800) 817-1005. Have your model and serial number on hand before calling.
Iron & Oak 24 800-817-1005
Important Warranty Information
To activate your Iron & Oak log splitter warranty, Iron & Oak Commercial Products, Inc.
please fill out the information in the form below and mail 1705 N. Shabbona St.
in an envelope to the address listed on the right or Streator, IL 61364-1301
go online to www.ironandoak.com
Iron & Oak Log Splitter Warranty Information - Please Print -
Model: TMH10 SERIAL #: _________________________
OWNER’S NAME: _______________________________________________________________
ADDRESS: ____________________________________________________________________
CITY: ___________________________________ STATE: ______ ZIP: ____________________
Purchased From: _______________________________________________________________
Street Address: _________________________________________________________________
City: _______________________________________ State: _______ Zip: _________________
Your Signature: ____________________________________________ Date: _______________
Optional Attachments
Log Cradle (Part No. BR021180)
✔ Catches split logs - no more stooping to pick up the split pieces.
✔ Each shelf is infinitely adjustable up to 45 degrees to accommodate various sizes of
logs.
✔ Mounts easily to H-beam rail - all hardware included, requires no drilling or welding on
current model log splitters.
4-Way Wedge Assembly (Part No. BR021270-KIT)
✔ Quickly splits large logs into pieces.
✔ Mounts easily to H-beam rail - all hardware included, requires no drilling or welding on
current model log splitters.
✔ Easy to remove - quickly slide off the top.
800-817-1005 27 Iron & Oak
PTO Kit (Part No. BR026003SA)
✔ Increases splitting force and cycle time.
✔ Easy to install.
✔ Mounts easily to H-beam rail - all hardware included, requires no drilling or welding on
current model log splitters.
Iron & Oak 28 800-817-1005
Notes
800-817-1005 29 Iron & Oak
Notes
Iron & Oak 30 800-817-1005
Iron & Oak Commercial Products, Inc.
1705 N. Shabbona St.
Streator, Illinois 61364-1301
Phone: 800-350-8739 (Toll Free)
815-672-8596
Fax: 815-672-9073
E-mail: sales@logsplitters-ironoak.com
Web Site: www.ironandoak.com
TMH10
09/12
Loading...
