5775
start
• stop
washable
5775
5770
www.braun.com/register
Type 5 724
5-724-350/00/IV-05/M
Korea/GB
5000
100%
1
2
5000
6000
Series
100%
6000
Series
2
start • stop
1
3
4
start • stop
5775
5
washable
Flex Integral / Flex XP
8
6
9
7
stop
•
rt
oil
2
345
English
Our products are designed to meet the
highest standards of quality, functionality and
design. We hope you enjoy your new Braun
shaver.
Warning
Your shaver is provided with a special cord set
with integrated Safety Extra Low Voltage
power supply. Do not exchange or manipulate
any part of it. Otherwise there is a risk of
electric shock.
Description
1 Shaver foil
2 Cutter block
3 Release button
4 On/off switch («start/stop»)
5 Long hair trimmer
6 Charging light (green)
7 Model 5775 only: Low charge light (red)
8 Model 5775 only: Charging stand
9 Special cord set
Indicator lights
The green charging light shows that the
shaver is being charged. When the rechargeable battery is fully charged, the charging light
goes off. If later on, the charging light comes
on again, this indicates that the shaver is
being recharged to maintain its full capacity.
Model 5775 only:
The red low-charge light glows when the
battery capacity has dropped below 20%
provided the shaver is switched on. The
remaining capacity will then be sufficient for
2 to 3 shaves.
Shaving
Turn on the shaver («start»):
The pivoting cutting system automatically
adjusts to every contour of your face.
Trimmer: When the long hair trimmer is
activated, it allows the controlled trimming of
moustache or sideburns.
Charging the shaver
• When charging for the first time: Using the
special cord set, connect the shaver/the
charging stand with an electrical outlet. The
shaver must be switched off. Charge it for at
least 4 hours (low voltage adapter and
shaver might get warm). Once the shaver
is completely charged, shave until fully discharged. Then recharge to full capacity
again (1 hour).
•A full charge will give up to 50 minutes of
cordless shaving time depending on your
beard growth. However, the maximum battery capacity will only be reached after
several charging/discharging cycles.
• Best environmental temperature range for
charging is 15 °C to 35 °C.
• When fully discharged, you may also shave
with the shaver connected to an electrical
outlet via the special cord set.
6
Tips for the perfect shave
• We recommend that you shave before
washing, as the skin tends to be slightly
swollen after washing.
• Hold the shaver at right angles (90°) to the
skin. Stretch your skin and shave against
the direction of beard growth.
• To maintain 100% shaving performance
replace your foil and cutterblock every
18 month or when worn.
Cleaning
This appliance is suitable for cleaning
under an open water tap.
Warning: Detach the hand-held part
from the power supply before cleaning it in
water.
Regular cleaning ensures better shaving
performance. Rinsing the shaving head after
each shave under hot running water is an easy
and fast way to keep it clean:
• Switch the shaver on (cordless) and rinse
the shaving head under hot running water.
A natural based soap may also be used
provided it contains no particles or abrasive
substances. Rinse off all foam and let the
shaver run for a few more seconds.
• Next switch the shaver off and press the
release buttons. Lift the shaver foil off and
pull the cutter block out. Then leave the
disassembled shaving parts to dry.
Alternatively, you may clean the shaver using
the brush provided:
• Switch the shaver off. Press the release
buttons and lift shaver foil off.
• Using the brush, clean the cutter block and
the inner area of the shaver head. However,
do not clean the shaver foil with the brush as
this may damage the foil.
• Clean the charging stand with a damp cloth.
Unplug first.
Keeping your shaver in top
shape
About every four weeks, clean the cutter block
with Braun cleaning agents. Put a drop of light
machine oil onto the long hair trimmer and the
shaver foil.
Preserving the batteries
In order to maintain the optimum capacity of
the rechargeable batteries, the shaver has to
be fully discharged (through normal use) every
6 months approximately. Then recharge the
shaver to full capacity. Do not expose the
shaver to temperatures higher than 50 °C for
extended periods of time.
Replacing the shaving parts
To maintain 100% shaving performance,
replace your foil and cutter block every 18
months or when worn. Change both parts at
the same time for a closer shave with less skin
irritation.
(Shaver foil and cutter block:
part no. 5000/6000)
Environmental notice
This appliance is provided with nickel-hydride
rechargeable batteries. To protect the
environment, do not dispose of the appliance
in the household waste at the end of its useful
life. Open the housing as shown on page 31,
remove and dispose of the batteries at your
retail store or at appropriate collection sites
according to national or local regulations.
Subject to change without notice.
This product conforms to the European
Directives EMC 89/336/EEC and Low
Voltage 73/23/EEC.
Electric specifications see printing on the
special cord set.
At the end of the product's useful life,
please dispose of it at appropriate
collection points provided in your
country.
Guarantee
We grant 1 year guarantee on the product
commencing on the date of purchase. Within
the guarantee period we will eliminate, free of
charge, any defects in the appliance resulting
from faults in materials or workmanship, either
by repairing or replacing the complete
appliance as we may choose.
This guarantee extends to every country
where this appliance is supplied by Braun or
its appointed distributor.
This guarantee does not cover: damage
due to improper use, normal wear or use as
well as defects that have a negligible effect
on the value or operation of the appliance.
The guarantee becomes void if repairs are
undertaken by unauthorised persons and if
original Braun parts are not used.
To obtain service within the guarantee period,
hand in or send the complete appliance with
your sales receipt to an authorised Braun
Customer Service Centre.
7
Battery removal at the end of the product’s
useful life
Caution: Opening the handle will destroy
the appliance and invalidate the guarantee.
