Page 1
Leporello, 85x165 mm, 12 pages, 2/2c = black + PMS541u
cruZer
2
Z40
Page 2
1
2
3
4
5
7
4a
4b
6
a
2
1
2
Page 3
b
90°
90°
c
d
2
1
180°
e
f
g
3
Page 4
45678
Page 5
Page 6
Page 7
Page 8
Page 9
English
Our products are designed to meet the highest standards of
quality, functionality and design. We hope you entirely enjoy
your new Gillette shaver.
Please read the use instruction carefully and thoroughly
before using the appliance.
Warning
Your shaver is provided with a special cord set with an
integrated Safety Extra Low Voltage power supply. Do not
exchange or manipulate any part of it. Otherwise there is risk
of electric shock.
This appliance is not intended for use by children or persons
with reduced physical, sensory or mental capabilities, unless
they are given supervision by a person responsible for their
safety. In general, we recommend that you keep the
appliance out of reach of children. Children should be
supervised to ensure that they do not play with the
appliance.
Oil bottle
Keep out of reach of children. Do not swallow. Dispose of
properly when empty.
Description
1 Foil protection cap
2 Shaver foil
3 Cutter block
4 Rotating styler
4a Wide shaper (28 mm)
4b Narrow shaper (14 mm)
5 Charging light
6 On/off switch
7 Special cord set
Charging
The best environmental temperature for charging is between
15 °C and 35 °C. Do not expose the shaver to temperatures
higher than 50 °C for extended periods of time.
Using the special cord set, connect the shaver to an
•
electrical outlet with the motor switched off.
When charging for the first time or when the appliance is
•
not used for a few months, leave the appliance to charge
continuously for 4 hours.
The charging light (5) shows that the appliance is being
•
charged. When the battery is fully charged, the charging
9
Page 10
light turns off. Intermittent blinking after a while indicates
that the battery maintains its full capacity. This can also
happen short term when charging after the battery was
completely discharged.
•
A full charge provides 30 minutes of cordless shaving time
depending on your beard growth.
•
Once the shaver is completely charged, discharge the
shaver through normal use. Then recharge to full capacity.
Subsequent charges will take about 1 hour.
•
Maximum battery capacity will only be reached after
several charging/discharging cycles.
•
If the rechargeable batteries are discharged, you may also
shave by connecting the shaver to an electrical outlet via
the special cord set.
Shaving
Remove the foil protection cap (1). Activate the on/off switch
(6). The floating foil frame automatically adapts to your skin
surface for a close, smooth shave.
For best results:
•
Always shave before washing your face.
•
At all times, hold the shaver at right angles (90°) to the
skin (b).
•
Stretch the skin and shave against the direction of hair
growth.
•
For pre-shaving after a few days of not having shaved, use
the wide shaper (4a) to pre-cut long hairs. For a close,
smooth shave, finish with the foil.
•
To maintain 100% shaving performance, replace your foil
and cutter block at least every 18 months or when worn.
Using the rotating styler (4)
The wide shaper (4a) evenly cuts and trims large areas (c).
It is ideal for shaping sideburns, moustaches and partial
short beards. The wide shaper is provided with safety rips
and a gliding strip for less irritation and easy gliding. Press
the green stripes to push up the rotating styler (4).
While stretching the skin, guide the wide shaper against the
direction of hair growth.
The narrow shaper (4b) precisely defines lines and edges (d),
being ideal for precise contouring.
To use the narrow shaper, push up the styler and turn it 180°.
Frequent use of the styler (4) will reduce the battery capacity.
10
Page 11
Cleaning
This appliance is suitable for cleaning under an open
water tap.
Warning: Detach the hand-held part from the power
supply before cleaning it in water.
Regular cleaning ensures better shaving performance.
Rinsing the shaving head after each shave under running
water is an easy and fast way to keep it clean:
Switch the shaver on (cordless) and rinse the shaving head
•
under hot running water (e). A natural based soap may
also be used provided it contains no particles or abrasive
substances. Rinse off all foam and let the shaver run for a
few more seconds.
Next, switch off the shaver, remove the shaver foil and the
•
cutter block. Then leave the disassembled shaving parts
to dry.
If you regularly clean the shaver under water, then once a
•
week apply a drop of light machine oil onto the long hair
trimmer and shaver foil (g).
Alternatively, you may clean the shaver using the brush
provided (f):
Switch off the shaver. Remove the shaver foil.
•
Using the brush, clean the cutter block and the inner area
•
of the shaver head. However, do not clean the shaver foil
with the brush as this may damage the foil.
Keeping your shaver in top shape
Replacing the shaving parts
To maintain 100% shaving performance, replace your foil
and cutter block at least every 18 months or when worn.
Change both parts at the same time for a closer shave with
less skin irritation.
(Shaver foil and cutter block: 20 R)
Preserving the batteries
In order to maintain the optimum capacity of the
rechargeable batteries, the shaver has to be fully discharged
(by shaving) every 6 months approximately. Then recharge
the shaver to full capacity.
11
Page 12
Environmental notice
This product contains rechargeable batteries. In the
interest of protecting the environment, please do not
dispose of the product in the household waste at the
end of its useful life. Disposal can take place at a
Braun Service Centre or at appropriate collection
points provided in your country.
Subject to change without notice.
For electric specifications, see printing on the
special cord set.
99507861/III-10
China/GB
12
