2675
cruZer
r
e
Z
u
r
c
Type 5732
5-732-422/00/V-07
Japan/GB
34567
1
2
3
4
6
5
7
8
9
2
1
6
4
90°
90°
a
10
b
c
11
d
l
oi
12
1
2
3
4
5
6
13
141516
English
Our products are designed to meet the highest standards of
quality, functionality and design. We hope you entirely enjoy
your new Braun shaver.
Warning
Your shaver is provided with a special cord set with an
integrated Safety Extra Low Voltage power supply. Do not
exchange or manipulate any part of it. Otherwise there is risk
of electric shock.
Description
1 Foil protection cap
2 Shaver foil
3 Cutter block
4 Long hair trimmer
5 Charging light
6 On/off switch
7 Special cord set
Charging
The best environmental temperature for charging is between
15 °C and 35 °C.
• Using the special cord set, connect the shaver to an
electrical outlet with the motor switched off.
• When charging for the first time, leave the shaver to
charge continuously for 4 hours. The green charging
light (5) shows that the shaver is being charged. When
the battery is fully charged, the charging light intermittently blinks on and off. This indicates that the battery
maintains its full capacity.
• A full charge provides 30 minutes of cordless shaving
time depending on your beard growth.
• Once the shaver is completely charged, discharge the
shaver through normal use. Then recharge to full capacity. Subsequent charges will take about 1 hour.
• Maximum battery capacity will only be reached after
several charging/discharging cycles.
• If the rechargeable batteries are discharged, you may
also shave by connecting the shaver to an electrical
outlet via the special cord set.
Shaving
Remove the foil protection cap (1). Activate the on/off switch
(6). The floating foil frame automatically adapts to your skin
surface for a close, smooth shave.
For pre-shaving after a few days of not having shaved, use
the long hair trimmer (4) to pre-cut long hairs. For a close,
smooth shave, finish with the foil.
Trimming
Push out the long hair trimmer (4). It allows controlled
trimming of moustache and sideburns. It evenly cuts and
trims larger areas: Ideal for shaping sideburns, moustaches and partial short beards.
17
Frequent use of the long hair trimmer may reduce the battery
capacity.
Tips for the perfect shave
• We recommend that you shave before washing, as the
skin tends to be slightly swollen after washing.
• Hold the shaver at right angles (90°) to the skin.
Stretch the skin and shave against the direction of
beard growth.
• To maintain 100% shaving performance, replace your
foil and cutter block at least every 18 months or when
worn.
Cleaning
Always unplug the appliance before cleaning!
Regular cleaning ensures better shaving performance.
Rinsing the shaving head after each shave under running
water is an easy and fast way to keep it clean:
• Switch the shaver on (cordless) and rinse the shaving
head under hot running water (b). A natural based soap
may also be used provided it contains no particles or
abrasive substances. Rinse off all foam and let the
shaver run for a few more seconds.
• Next, switch off the shaver, remove the shaver foil and
the cutter block. Then leave the disassembled shaving
parts to dry.
Alternatively, you may clean the shaver using the brush
provided (c):
• Switch off the shaver. Remove the shaver foil.
• Using the brush, clean the cutter block and the inner
area of the shaver head. However, do not clean the
shaver foil with the brush as this may damage the foil.
Keeping your shaver in top shape
About every four weeks, clean the cutter block with Braun
cleaning agents. Put a drop of light machine oil onto the long
hair trimmer and the shaver foil (d).
Replacing the shaving parts
To maintain 100% shaving performance, replace your foil
and cutter block at least every 18 months or when worn.
Change both parts at the same time for a closer shave with
less skin irritation.
(Shaver foil and cutter block: 2000 series)
Preserving the batteries
In order to maintain the optimum capacity of the rechargeable batteries, the shaver has to be fully discharged (by
shaving) every 6 months approximately. Then recharge the
shaver to full capacity. Do not expose the shaver to temperatures higher than 50 °C for extended periods of time.
18
Environmental notice
This appliance is provided with nickel-hydride rechargeable
batteries. To protect the environment, do not dispose of this
appliance in the household waste at the end of its useful life.
Open the housing as shown as below, remove and dispose
of the batteries at your retail store or at appropriate
collection sites according to national or local regulations.
Subject to change without notice.
This product conforms to the European Directives
EMC 89/336/EEC and Low Voltage 2006/95/EC.
Electric specifications see printing on the special cord set.
Battery removal at the end of the product’s useful life
1
2
546
3
19
