MC D601 UI – Voyager 3 Use Instructions NA
English Master Copy UI – D601 UI (Voyager 3) – NA Region
-> Use images as reference only; will be updated.
|
Resp |
Global English Master Copy – D601 UI |
|
Comments |
|
Translations LC |
|
onsib |
(generic for all D601 handles/ |
|
|
|
(French, Spanish) |
|
ility |
all modes/accessories/Teens and adult) |
|
|
|
|
|
|
|
|
|
|
|
|
MC |
IPMS#: 91267217 |
|
Project |
|
n/a |
|
Creat |
|
|
Informatio |
|
n/a |
|
or |
|
|
n |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
|
Cover pages information:
R&D |
Braun GmbH |
LE |
n/a |
|
Frankfurter Strasse 145 |
|
|
|
61476 Kronberg |
|
|
|
Germany/Allemagne/Alemania |
|
|
MKT |
www.oralb.com |
Provide |
n/a |
|
www.oralb.ca |
customer |
|
|
www.braun.com |
service |
|
|
www.service.braun.com |
contact |
|
|
|
information |
|
|
|
if needed |
|
MKT |
GB – 0 800 731 1792 |
Provide |
|
|
IE - 1 800 509 448 |
customer |
|
|
|
service |
|
|
|
contact |
|
|
|
information |
|
MKT |
PRO |
Use as |
n/a |
|
DEEP SWEEP™ |
reference |
|
|
powered by BRAUN |
only |
|
|
SMARTSERIES |
|
|
|
3000–6000 |
|
|
|
with Bluetooth® |
|
|
R&D |
Charger Type 3757 |
Type Info |
n/a |
|
Handle Type 3767 |
|
|
Copy elements: INTRODUCTION + WARNING STATEMENTS |
|
|
|
GPS |
IMPORTANT SAFEGUARDS |
No |
|
|
|
translation |
|
|
Your Oral-B® toothbrush has been carefully designed to offer you |
required |
|
|
and your family a unique brushing experience that is both safe |
|
|
|
and effective. |
|
|
|
|
|
|
2
When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following:
|
Read all instructions before using. |
|
|
GPS |
DANGER |
No |
|
|
In order to reduce the risk of electrocution: |
translation |
|
|
1. |
Do not place or store the charger where it can fall or be pulled |
required |
|
into a tub or sink. |
|
|
|
2. |
Do not place the charger in water or other liquid. |
|
|
3. |
Do not reach for a charger that has fallen into water. Unplug |
|
|
immediately. |
|
|
|
4. |
Do not use while bathing. |
|
GPS |
WARNING |
|
|
|
To reduce the risk of burns, electrocution, fire or injury: |
update |
|
|
1. |
Close supervision is necessary when this product is used by, |
|
|
on, or near children or persons with disabilities. |
|
|
|
2. |
Use this product only for its intended use as described in this |
|
|
manual. Do not use attachments not recommended by the |
|
|
|
manufacturer. |
|
|
|
3. Keep cord away from heated surfaces. |
|
|
|
4. |
Never drop the appliance or insert any object into any opening |
|
|
of the appliance. |
|
|
|
5. |
Never operate this product if it has a damaged cord or plug, if |
|
|
it is not working properly, if it has been dropped or damaged or if |
|
|
|
it has been dropped into water. If any of these occur, please |
|
|
|
contact a service center and return the product for examination |
|
|
|
and repair. |
|
|
|
6. Do not use on self when drowsy or on another who is drowsy |
|
|
|
or sleeping. |
|
|
|
7. |
Do not use outdoors or operate where aerosol (spray) |
|
|
products are being used or where oxygen is being administered. |
|
|
GPS |
IMPORTANT |
update |
|
|
1. |
Periodically check the entire product/cord for damage. A |
|
|
damaged or non-functioning unit should no longer be used. If |
|
|
|
product/cord is damaged, take it to an Oral-B Service Center. |
|
|
|
|
|
3 |
|
2. If the toothbrush handle is dropped, the brush head should be |
|
|
|
replaced before the next use even if no damage is visible. |
|
|
|
3. Do not touch the power plug with wet hands. This can cause an |
|
|
|
electric shock. |
|
|
|
4. When unplugging, always hold the power plug instead of the |
|
|
|
cord. |
|
|
|
5. Do not modify or repair the product. This may cause fire, |
|
|
|
electric shock or injury. Consult your dealer for repairs or contact |
|
|
|
an Oral-B Service Center. |
|
|
|
6. The appliance has no user serviceable parts. Do not open and |
|
|
|
dissemble device except when disposing of the battery. Follow |
|
|
|
handling and disposal instructions of the battery/device |
|
|
|
described in this manual. |
|
|
|
7. This product is not intended for children 3 years and under. |
|
|
|
8. This toothbrush is a personal care device and is not intended |
|
|
|
for use on multiple patients in a dental practice or institution. |
|
|
|
9. Replace brush (head) every 3 months or sooner if brush head |
|
|
|
becomes worn. |
|
|
GPS |
CAUTION |
|
|
|
If you are undergoing treatment for any oral care condition, |
|
|
|
consult your dental professional prior to use. |
|
|
|
SAVE THESE INSTRUCTIONS |
|
|
GPS |
Important Information |
|
|
+ |
• Your Oral-B toothbrush can be used with your smartphone |
|
|
R&D |
(find details under Connecting your toothbrush to your |
|
|
|
Smartphone ). |
|
|
|
• To avoid electromagnetic interference and/or compatibility |
|
|
|
conflicts, deactivate the radio transmission before using it in |
|
|
|
restricted surroundings, such as aircrafts or specially marked |
|
|
|
areas in hospitals. Deactivate radio transmission when your |
|
|
|
toothbrush is turned off by pressing the on/off button (c) for |
|
|
|
3 seconds. All indicator lights (b, e & f) will flash simultaneously. |
|
|
|
Follow the same procedure to reactivate transmission again. |
|
|
|
Note: Every time you turn your toothbrush off, when using it |
|
|
|
without radio transmission, the indicator lights will flash |
|
|
|
simultaneously. |
|
|
4
• Persons with pacemakers should always keep the toothbrush more than six inches (15 centimeters) from the pacemaker while turned on. Anytime you suspect interference is taking place, deactivate the radio transmission of your toothbrush.
Copy elements: INTRODUCTION + TECHNICAL DATA
R&D |
Description |
update |
+ |
a Brush head |
|
MKT |
b Pressure sensor light |
. |
|
c On/off button (mode selection) |
|
|
d Handle (with Bluetooth® wireless technology) |
|
|
e Charge indicator light |
|
|
f Low charge indicator light |
|
|
g Charger |
|
|
Accessories (depending on model): |
|
|
||
|
h Brush head compartment with protective cover |
|
|
||
|
i Brush head holder |
|
|
||
|
j Smartphone holder |
|
|
||
|
k Travel case |
|
|
||
|
Note: Content may vary based on the model purchased. |
|
|
||
|
|
|
|
|
|
R&D |
Specifications |
update |
|
||
|
For voltage specifications refer to the bottom of the charging |
|
|
||
|
unit. |
|
|
||
|
Noise level: 68 dB (A) |
|
|
||
R&D |
220-240 V ac~ |
Reference |
n/a |
||
|
50-60 Hz |
only - Use if |
|
||
|
0,9 W |
needed in |
|
||
|
IP 67 |
local |
|
||
|
|
|
|
language |
|
|
|
|
|
|
|
R&D |
This rechargeable toothbrush contains a Bluetooth radio which |
|
|
|
|
+ |
operates in the 2.4 to 2.48 GHz band with a maximum power of |
Update |
|
||
GPS |
1mW. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5 |
|
|
|
Hereby, Braun GmbH declares that the radio equipment types |
|
|
|
||||||
|
|
3765, 3754, 3764, 3762 and 3767 are in compliance with |
|
|
|
|
|
||||
|
|
Directive 2014/53/EU. The full text of the EU declaration of |
|
|
|
|
|||||
|
|
conformity is available at the following internet address: |
|
|
|
|
|||||
|
|
www.oralb.com/ce |
|
|
|
|
|||||
R&D |
|
Charger Type 3757 |
|
Reference |
n/a |
||||||
+ |
|
Handle Type |
3767 |
|
|
only - Use if |
|
||||
GPS |
|
|
|
|
|
|
|
|
|
needed in |
|
|
|
|
|
|
|
|
|
|
|
local |
|
|
|
|
|
|
|
|
|
|
|
language |
|
|
|
|
|
|
|||||||
Copy elements: INSTRUCTIONS |
|
|
|
||||||||
R&D |
Charging and Operating |
|
|
|
+Your toothbrush has a waterproof handle, is electrically safe and
MKT designed for use in the bathroom. |
Update |
•You may use your toothbrush right away or charge it briefly by placing it on the plugged-in charger (g).
Note: In case the battery is empty (no charging light illuminated
(e) while charging or no reaction when pressing the on/off button (c)), charge at least for 30 minutes.
•The green charge indicator light (e) flashes while the handle is being charged. Once it is fully charged, the light turns off. A full charge takes typically 12 hours and enables at least 2 weeks of regular brushing (twice a day, 2 minutes) (picture 1).
Note: After deep discharge, the charge indicator light might not flash immediately; it can take up to 30 minutes.
•If the battery is running low, the red charge indicator
light (f) is flashing for a few seconds when turning your toothbrush on/off and the motor is reducing its speed. Once the battery is empty, the motor will stop; it will need at least a 30minute charge for one usage.
• You can always store the handle on the plugged-in charging unit to maintain it at full power; a battery overcharge is prevented by device.
Note: Store handle at room temperature for optimal battery maintenance.
6
|
Caution: Do not expose handle to temperatures higher than 50 |
|
|
|
|
°C. |
|
|
|
|
|
|
|
|
R&D |
Using your toothbrush |
|
|
|
+ |
Brushing technique |
|
|
|
MKT |
Wet brush head and apply any kind of toothpaste. To avoid |
|
|
|
|
splashing, guide the brush head to your teeth before switching |
|
|
|
|
on the appliance (picture 2). When brushing your teeth with one |
|
|
|
|
of the Oral-B oscillating-rotating brush heads guide the brush |
|
|
|
|
head slowly from tooth to tooth, spending a few seconds on each |
|
|
|
|
tooth surface (picture 5). |
|
|
|
|
When using the Oral-B «DeepSweep» brush head place the |
|
|
|
|
toothbrush bristles against the teeth at a slight angle towards the |
|
|
|
|
gumline. Apply light pressure and start brushing in back and forth |
Delete: |
|
|
|
motions, just like you would do with a manual toothbrush. |
|
(picture 6) |
|
|
With any brush head start brushing the outsides, then the insides |
|
|
|
|
and finally the chewing surfaces. Brush all four quadrants of your |
|
|
|
|
mouth equally. |
|
|
|
|
You may also consult your dentist or dental hygienist about the |
|
|
|
|
right technique for you. |
|
|
|
|
In the first days of using any electric toothbrush, your gums may |
|
|
|
|
bleed slightly. In general, bleeding should stop after a few days. |
|
|
|
|
Should it persist after 2 weeks, please consult your dentist or |
|
|
|
|
dental hygienist. If you have sensitive teeth and/or gums, Oral-B |
|
|
|
|
recommends using the «Sensitive» mode (depending on model) |
|
|
|
|
(optional in combination with an Oral-B «Sensitive» brush head). |
|
|
7
