Congratulations!
You have chosen Oral-B’s most technologically
advanced rechargeable toothbrush. Oral-B
will provide you with the superior* oral care results you
have been striving to achieve.
Oral-B Triumph has an innovative new brushing
technology that is proven to help deliver cleaner and
whiter teeth. Its advanced Oral-B
®
FlossAction™
brush head features MicroPulse™ bristles that gently
penetrate deep between teeth for an extraordinary
interdental clean. It provides such an exceptional clean,
you won't believe how great you feel about your teeth.
Oral-B Triumph is a significant advancement in
brushing technology featuring the following:
• Smart Technology, an interactive feature that
gives you feedback to enhance your brushing
performance.
• Innovative Brush heads with new brushing
technology provide comprehensive cleaning for your
teeth and as a result, help to improve gum health.
• Four Brushing Modes let you customize your
brushing routine to address your specific needs.
• An innovative SmartPlug charger makes Oral-B
Triumph convenient for traveling.
®
Triumph™
Oral-B
Oral-B Triumph is brought to you by Oral-B, the
worldwide leader in toothbrushes and the brand more
dentists use themselves.
If you have any questions about using the new Oral-B
Triumph toothbrush, please visit our web site at
www.oralb.com or contact our helpline.
Thank you for choosing
Oral-B Triumph.
Sincerely,
Bruce Cleverly
President, Oral-B
Smart Technology ... Brilliant Results.
* vs. brushing with FlexiSoft
brush head in the world
®
brush head, the #1 selling power toothbrush
Oral-B Triumph has been carefully designed to offer you and
Oral-B
your family a new and unique brushing experience that is both
safe and effective. However, when using electrical products,
basic safety precautions should always be followed. Please
read carefully before use.
Important
• The Oral-B Triumph is provided with a SmartPlug with
integrated Safety Extra Low Voltage power supply. Do not
exchange or manipulate any part of it. Otherwise there is
the risk of electric shock. Periodically check the SmartPlug
for damage. A damaged or non-functioning appliance
shall no longer be used. Take it to an Oral-B Braun
Service Centre.
• This product is not intended for use by children under age
three.
• If the product is dropped, the brush head should be
replaced before the next use even if no damage is visible.
Description of Oral-B T
Description of Oral-B T
a Oral-B FlossAction brush head
b On/off button
c Brushing mode button
d Handle
e SmartDisplay
f SmartPlug charger (includes charging ring and SmartPlug)
g Base plate
h Base station
i Protective cover
j ProBright
A convenient travel case holds the Oral-B Triumph handle
and two Oral-B brush heads (except for Oral-B CrossAction
Power and Oral-B Sonic Complete brush heads).
Connecting and char
Connecting and char
Oral-B Triumph has a waterproof handle, is electrically safe
and is designed for use in the bathroom.
To assemble the base station (h) as a charging unit, detach
the base plate (g) first (1, page 3). Place the charging ring
into the base station and attach the base plate as shown
(2 and 3, page 3). Then insert the protective cover (i) on the
back of your base station (see diagram 4, page 3).
12 h
• Plug the SmartPlug into an electrical outlet and place the
toothbrush handle (d) on the charging unit. Alternatively,
Oral-B Triumph can be charged by placing the handle
directly into the charging ring while the SmartPlug is
plugged in.
®
brush head
riumph
riumph
ging
ging
12
• A battery symbol should appear in the SmartDisplay. The
Full Charge
battery symbol will fill up while the handle is being charged
and «Charging» will be displayed. When the handle is fully
charged, the SmartDisplay shows «Full Charge». A full
charge takes at least 12 hours and enables approximately
two weeks of regular brushing.
Please note: If the battery symbol is not displayed
immediately, continue charging. It will appear in 10 – 15
minutes.
• When the rechargeable battery is low, the bars of the
battery symbol will disappear and «Low» will be displayed.
Your toothbrush will slow down and then stop. It is time
to recharge Oral-B Triumph. When the battery is fully
discharged, «Empty» is displayed. It will then need a
15-minute charge before you can use it for a 2-minute
brushing.
• For everyday use, the toothbrush handle can be stored on
the charging unit to maintain it at full power. There is no
risk of overcharging the battery.
• To maintain the maximum capacity of the rechargeable
battery, unplug the charging unit and fully discharge the
handle by regular use at least every 6 months.
Oral-B Triumph is convenient for traveling because you only
need the compact SmartPlug charger and an appropriate
travel adapter for recharging in foreign countries. The
SmartPlug automatically adapts to any voltage worldwide.
For electric specifications, see printing on the SmartPlug.
Personalizing Oral-B T
Personalizing Oral-B T
Before getting started, you can program your toothbrush so
that it meets your specific needs. Oral-B Triumph has
innovative Smart Technology that lets you choose the
language and the timer that works best for you.
Select your language
Oral-B Triumph comes with the English language activated. If
you wish to switch to another language, proceed as follows:
Press and hold the brushing mode button (c) until «English» is
displayed. By briefly pressing the on/off button (b) you can
scroll through 13 different languages. To confirm your desired
language, briefly press the brushing mode button again. This
will also lead you directly to the timer choice menu.
riumph
riumph
13
Select your timer
3
0
s
e
c
3
0
s
e
c
3
0
s
e
c
3
0
s
e
c
The «2-Minute Timer» indicates by a long stuttering sound
when the dentist recommended 2-minute brushing time has
been reached. The «Professional Timer» helps you brush all
four quadrants of your mouth equally. It signals with a short
stuttering sound at 30-second intervals that it is time to move
to the next quadrant of your mouth, followed by a long
stuttering sound when you reach the recommended two
minute mark.
Oral-B Triumph comes with the «Professional Timer»
activated. If you wish to switch to the «2-Minute Timer» after
you have confirmed the language, simply press the on/off
button to change the setting. Then press the brushing mode
button to confirm your choice.
Using Oral-B T
Using Oral-B T
Attach an Oral-B brush head to the handle. You can use any
Oral-B
Oral-B
kind of toothpaste. To avoid splashing, guide the brush head
to your teeth before switching the appliance on.
Brushing technique
• Guide the brush head slowly from tooth to tooth.
• Hold the brush head in place for a few seconds before
moving on to the next tooth.
• Brush the gums as well as the teeth, first the outsides, then
the insides, finally the chewing surfaces.
• Do not press too hard or scrub, simply let the brush do all
the work.
To help you get optimum brushing results, Oral-B Triumph
has a pressure control feature to ensure that the right degree
of pressure is applied. This helps protect your gums from
excessive brushing and makes your toothbrush easy to
operate. If too much pressure is applied, the oscillating
movement of the brush head will continue but the pulsation
will stop. In addition to feeling the change, you can also hear
a different sound.
riumph
riumph
14
Brushing modes
Oral-B Triumph offers four different brushing modes for
varying oral care needs:
«Clean» – Exceptional mouth cleaning.
«Soft» – Gentle, yet thorough cleaning for sensitive
areas.
«Massage» – Gentle stimulation of gums.
«Polish» – Exceptional polishing for naturally whiter
teeth for occasional or everyday use.
How to switch between brushing modes:
• Oral-B Triumph automatically starts in the «Clean» mode
when pressing the on/off button.
• To shift from the «Clean» to the «Soft» mode, press the
brushing mode button once.
• If you wish to switch to the «Massage» mode, press the
brushing mode button again and let the brush head pulse
against your gum line.
• The «Polish» mode is best used with a ProBright
brush head. Once the ProBright is attached, press the
on/off button and your toothbrush automatically starts in
the «Polish» mode (please see «Brush heads»).
• To return from any other mode to the «Clean» mode, press
and hold the brushing mode button.
• To turn your brush off, press the on/off button.
During brushing, the SmartDisplay shows the brushing mode
you have selected, followed by your actual brushing time.
When you finish brushing, the total brushing time will be
displayed for 30 seconds before the display switches back
to the battery charge level. To directly get to the battery
charge level display, you can clear the brushing time display
by pushing the brushing mode button.
In the first few days of using Oral-B Triumph, your gums may
bleed slightly. In general, bleeding should stop after a few
days. Should it persist after 2 weeks, please consult your
dentist or hygienist. If you have sensitive teeth and gums,
Oral-B recommends using the «Soft» mode.
Oral-B
15
Brush heads
The Oral-B FlossAction and ProBright brush heads contain a
«smart chip» to communicate with the electronics inside the
Oral-B Triumph handle. The «smart chip» works for you,
automatically switching to the appropriate brushing mode for
the attached brush head. Nevertheless, you can select other
brushing modes to customize your routine.
Oral-B FlossAction br
The Oral-B FlossAction brush head is recommended for
everyday deep cleaning. It features MicroPulse bristles that
get deep in hard-to-reach areas between your teeth, gently
removing hidden plaque. The brush head’s outer bristles
surround each tooth, providing exceptional overall plaque
removal.
Pr
oBright brush head
The ProBright brush head is for occasional or everyday
polishing. It features a dentist-inspired polishing cup to help
remove stains from coffee, tea and tobacco for effective
brightening.
We do not recommend using the ProBright or Oral-B
FlossAction brush head with braces. The Oral-B Ortho
brush head is specifically designed to clean around
braces and wires and can be used with Oral-B Triumph.
Oral-B Triumph has Smart Technology that helps you
remember when to replace your brush head to get optimum
results. Dentists recommend that you change your brush head
every three months. As soon as your Oral-B FlossAction or
ProBright brush head has surpassed the recommended
usage, the SmartDisplay shows «Replace Brush head».
Replace with a new brush head to get optimum brushing
results. If you notice unusual wear before receiving the
«Replace Brush head» message, replace your brush head
immediately.
ush head
16
Cleaning r
Cleaning r
• After brushing, rinse your brush head thoroughly under
running water.
• Remove the brush head from the handle and clean both
parts separately under running water. Then wipe them dry
before you put the handle on the charging unit.
ecommendations
ecommendations
• Before cleaning your charging unit, make sure you
disassemble it first. The charging ring and the SmartPlug
should never
other parts (base station, base plate and protective cover)
are dishwasher-safe.
• From time to time, you can also clean the charging ring and
the SmartPlug with a damp cloth. The SmartPlug charger
should never be placed in water.
Subject to change without notice.
This product conforms to the European Directives
EMC 2004/108/EC and Low Voltage 2006/95/EC.
This product contains rechargeable batteries. In the
interest of protecting the environment, please do not
dispose of the product in the household waste at the
end of its useful life. Disposal can take place at an
Oral-B Braun Service Centre or at appropriate collection
points provided in your country.
Guarantee
We grant 1 year guarantee on the product commencing on
the date of purchase. Within the guarantee period we will
eliminate, free of charge, any defects in the appliance
resulting from faults in materials or workmanship, either by
repairing or replacing the complete appliance as we may
choose.
be placed in the dishwasher. However, all
This guarantee extends to every country where this appliance
is supplied by Braun or its appointed distributor.
This guarantee does not cover: damage due to improper use,
normal wear or use, especially regarding the brush heads, as
well as defects that have a negligible effect on the value or
operation of the appliance. The guarantee becomes void if
repairs are undertaken by unauthorised persons and if original
Braun parts are not used.
To obtain service within the guarantee period, hand in or
send the complete appliance with your sales receipt to an
authorised Oral-B Braun Customer Service Centre.
17
Loading...
