BRANDT MMK51X1E User Manual
Operating instructions
Microwave oven
2
Table of contents
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
General description . . . . . . . . . . . . . . . . . . . . . . . . . .5
The control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Setting the clock / Microwave power settings . . . . . . . . . . . .7
The display & the selector knob . . . . . . . . . . . . . . . . . .8
The folding rack / Programming . . . . . . . . . . . . . . . . . .9
Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
AUTO Programming / The grill function . . . . . . . . . . . .11
Microwave + grill function . . . . . . . . . . . . . . . . . . . . .12
The fan functions . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Programming the fan function . . . . . . . . . . . . . . . . . .14
Programming the fan + microwave function . . . . . . . . .15
Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Care & cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . .18
After-sales service . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Important safety instructions. Read careffully
and keep for future reference
•
Your installation must be protected by a 16 Amp thermal fuse.
•
It is mandatory to use a power point with a ground terminal, connected in accordance with
current safety regulations.
•
In your electrical installation, provide a device that is accessible to the installer, capable of
separating the appliance from the mains power and whose contact opening is at least 3 mm
at all of the poles.
•
Never operate the oven if the supply cord and/ or its plug are damaged. In case of damage,
call in a specialised technician trained by the manufacturer.
3
LOCATION
BEFORE CONNECTION
Installation
•
Check whether your oven has not suffered any damage during transport (deformed door
or door seal, etc.). If you see any signs of damage, contact your dealer before use.
•
Verify the power voltage. If there is a PERMANENT undervoltage (200-210 volts), consult your
electrical installer.
ELECTRICAL CONNECTION
•
Place the oven on a flat and horizontal surface, away from any source of heat or steam.
•
The oven should be set at least 85 cm above floor level.
•
Leave sufficient space around the oven : 5 cm between the sides of the oven and any walls or
objects, 14 cm above the oven and 10 cm behind the oven to ensure that air may circulate freely
around the oven.
•
Make sure that nothing obstructs the ventilation louvres at the back of the appliance and that the
electrical plug will be accessible after installation.
•
Please refer to the installation manual included with your oven for further instructions.
4
Warning
• Your appliance is designed exclusively for the domestic purposes of defrosting, heating or
cooking foods. The manufacturer bears no responsibility in the case of improper usage.
• Only use ustensils that are suitable for use in microwave ovens.
• To avoid deterioration of your microwave oven, never operate it empty or without the
turntable.
• Never tamper with the lock mechanism of your microwave oven; you could cause damage
requiring repair by an authorised technician.
• When heating food in plastic or paper containers, keep an eye on the oven due to the
possibility of ignition.
• It is not advisable to use metal recipients, forks, spoons, knives, metal ties or staples for
deep-freeze bags.
• The contents of feeding bottles are baby food jars shall be stirred or shaken and the
temperature checked before consumption in order to avoid burns.
• Only allow children to use the oven without supervision when adequate instructions
have been given so that the child is able to use the oven in a safe way and understands
the hazards of improper use.
• Liquids and other foods must not be heated in sealed containers they are liable to explode.
• Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens
since they may explode, even after microwave heating has ended.
• Microwave heating of beverages can result in delayed eruptive boiling, therefore care
must be taken when handling the container.
• For small amounts (one sausage, a single croissant, etc.), place a glass of water alongside the food item.
• Time settings that are too long may dry out and burn the food. To avoid such incidents,
never use the same cooking times as those recommended for traditional ovens.
• If smoke is observed, switch off or unplug the appliance and keep the door closed in
order to stifle any flames.
• In order to evacuate moisture, your appliance is fiited with a delayed ventilation function. Depending on the applied cooking mode (solo / grill / combination), the oven ventilation will continue to operate after the cokking end.
5
General description
• THE TURNTABLE :
ensures equal cooking of food throughout with no need to stir or turn the dish.
- It may be used as a cooking platter.
- Rotation is controlled by the drive shaft and the wheel support.
- The turntable revolves in both directions.
- If it does not turn, verify that all components are properly positioned.
- For easy removal, wells are provided on either side.
The turntable may be stopped (STOP TURNTABLE key ) in order to use platters
which require the entire surface of the oven floor. When off, remember to turn the
recipient or stir the contents.
• THE WHEEL SUPPORT :
Do not try to rotate the roller ring manually, as this could damage the drive system. If it
does not turn smoothly, make sure that there is nothing in the well beneath the
turntable.
TurntableDrive shaft Wheel support Identification label Grill
6
The control panel
A
Display window :
to simplify programming, the display indicates : the time of day, the types of food
and functions, the minutes / seconds or
weight programmed.
B
The selector knob :
to choose the food type, function, programme time or weight.
C
FOOD TYPE key :
to choose the food type, with the selector
knob.
D
FUNCTION key :
to choose the appropriate function, with
the selector knob.
E TIME key :
used to set the programme time, with the
selector knob.
F
“AUTO” key :
automatically sets the correct programme
time according to a specified food type and
weight.
G GRILL key :
to select low or high grill.
H FAN key
:
to cook as if with a traditional oven.
I STOP-TURNTABLE key :
to stop the turntable from revolving.
J PAUSE/CANCEL key :
to interrupt (press once) or cancel a programme (press twice). Also used to set the
clock.
K START key :
to start all programmes.
B
G
F
K
D
E
C
H
J
I
4 0 : 0 0
2 2 0 ° C
A
