Brandt IVK60 User Manual
REF CONSTRUCTEUR 214
9962 9641 05/03
CookingCooking
c o l l e c t i o nc o l l e c t i o n
Instructions for fitting and using
your mixed induction-ceramic
and
Warranty Details
IVK60X - 600mm Induction-ceramic Cooktop
99629641.qxd 12/06/03 13:27 Page 1
2
C
ongratulations on the purchase of your new appliance.
This appliance has been
designed and manufactured to give you years
of reliable performance.
For best results, carefully read the instructions on how to
install your new appliance. Correct installation will avoid
delays and unnecessary service calls.
Once installation is complete, read this booklet
carefully and get to know the controls and the
features of your new appliance.
We reserve the right to alter the specifications
with no influence on the operation of the
appliance. This instruction manual cannot be
reason for a claim.
99629641.qxd 12/06/03 13:27 Page 2
In this Manual,
displays safety
instructions
displays tips and hints
Using your hob in complete safety..........................4
Containers.........................................................6-7
Installing your hob in complete safety...........................8
Using your hob in all simplicity.............................10
Preserving and maintaining your hob....................12
Small problems and solutions...............................13
Cooking ........................................................14-15
List of contents
We have designed this hob for domestic use only.
With a view to constantly improving our products, we reserve the right to make technical and
programming changes or modify the appearance.
This hob is designed solely for cooking food. No asbestos has been used in its manufacture.
We suggest that you should periodically check that there are no objects (glass, paper, etc.) that could
obstruct the air inlet under your induction hob (See fitting).
3
99629641.qxd 12/06/03 13:27 Page 3
If your hob is placed above your oven (see "Choice of Installation") thermal
protectors prevent it being used when the oven is being
pyro-cleaned
.
4
Using your hob in complete safety
We have designed this hob for private use in homes.
With a view to constantly improving our products, we reserve the right to make any changes to their
technical, program or aesthetic features connected with their technical evolution.
These hobs are exclusively designed for cooking foodstuffs and contain no asbestos based
components.
We suggest that you should periodically check that there are no objects (glass, paper, etc.) that could
obstruct the air inlet under your induction hob (See fitting)
HOB safety
•
A sensor continuously monitors the
temperature of the components of your hob.
The power output by the hob will automatically
be reduced if this temperature becomes
excessive.
Induction safety area
•
You only have to remove the pan from the hob to
stop power instantaneously. Touch the "Off" touch
control to turn off the heating zone completely.
•
SAUCEPAN safety
Each unit is equipped with a sensor that continuously monitors the temperature of the bottom
of the pan, so that overheating is impossible
(empty saucepan, etc.).
•
METALLIC OBJECT safety
A small object such as a fork, spoon or a ring
placed on your induction hob by itself is not
detected as a pan. The display flashes and there
is no output power.
Residual heat indicator
The display shows H.
After intensive use, the cooking zone may remain
hot for several minutes.
The letter “
H”
H”
is displayed during this period.
Do not touch the zones concerned
After a prolonged power cut, a light display may
appear. It will turn itself off after pressing any key
for a while. However, the temperature of the
cooking areas may remain high.
WARNING
Do not touch these areas, risk of burns.
Automatic-Stop
Automatic stop is a safety function for your hob. It
starts up automatically if ever you forget to turn off
your cooking.
The letter A is displayed for the heating zone
concerned and the hob will beep for about 2 minutes. The A will continue to be displayed until any
control of the zone in question is touched. The hob
will then beep twice to confirm your action.
Power consumed The heating zone
goes out automatically
after
Between 1....4 8 hours
Between 5....7 2 hours
Between 8....9 1 hour
WARNING!
The appliance is not intended for use by young
children or infirm persons without supervision.
99629641.qxd 12/06/03 13:27 Page 4
Induced currents
Electronic circuit
Induction coil
5
For the attention of wearers of pacemakers or other active
implants:
The hob complies with all current standards on electromagnetic interference.
Your induction hob is manufactured perfectly in keeping with legal requirements (89/336/CEE
directives). It is designed not to create interference on any other electrical apparatus being used on
condition that the apparatus in question also complies with this legislation.
Your induction hob generates short-range magnetic fields.
To avoid any interference between your induction hob and a pacemaker, the latter must be designed to
comply with relevant regulations.
In this respect, we can only guarantee our own product conformity. Please consult the pacemaker
manufacturer or your doctor concerning its conformity or any possible incompatibility.
L
Your induction hob in complete safety
The principles of induction
When your induction hob is switched on and a
heating power has been selected, the electronic
circuits produce induced currents that
instantaneously heat the bottom of the pan that
transfers this heat to the food.
Thus cooking takes place with practically no ener-
gy loss between the induction hob and the food.
If a crack appears in the glass surface, disconnect the appliance immediately to avoid any risk
of electric shock. For disconnecting, remove the fuses or use the cutout switch.
Do not re-use your hob until the glass surface has been changed.
Your hob must never be used as a storage space or cutting surface for any products whatsoever.
When cooking never use aluminium foil and never place products wrapped in aluminium foil or
products deep-frozen in aluminium packs on the hob.
The aluminium will melt and damage your appliance irreparably.
Do not leave empty pans on your hob in case of residual heat or if the hob is turned on by mistake.
Do not connect electrical appliances on plugs close to the hob. Make sure that the power cable is
not in contact with any heating zones.
99629641.qxd 12/06/03 13:27 Page 5
+
-
