Installation Guide
BL-500 Bluetooth PCMCIA Card in
Windows2000
Version: 1.0
Brain Boxes Limited, Unit 3C, Wavertree Boulevard South, Wavertree Technolog y Par k, Liverpool, L7 9PF, UK
Tel: +44 (0) 151 220 2500 Fax: +44 (0)151 252 0446 Web: www.brainboxes.c om Email: s ales@brai nboxes.c om
Page 2
Declaration of Conformity
Bluetooth PC Card – Rev 5. Product Code: BL-500
We, Brain Boxes Limited, of Unit 3c Wavertree Boulevard South, Wavertree Technology Park, Liverpool L7 9PF,
United Kingdom declare that the Product listed above is in conformance with the essential requirements of the
Eu ropean Council Directi ve:
1999/5/EC (R & TTE) Radio and Telecommunications Terminal Equipment Directive (following Annex III of this
Directive)
The essential requirements being:
Safety of the user (Article 3.1a) Following directive 73/23/EEC; 93/68/EEC
Electromagnetic Compatibility (article 3.1b) Following directive 89/336/EEC
Effective use of the spectrum (article 3.2) Following notified body opinion from ETS Dr Genz,
GmbH, Storkower Strasse 38c, D-15526, Reichenwalde
bei Berlin, Germany
This declaration is based upon compliance with the following standards:
EN 60950: 1992; EN60335-1: 1994 Safety information Technology Equipment, including
Electrical Business Equipment
ETS 300 826; EN 301 489-1/-17: 2000; EN50081 – 1:
1992; EN 50082 – 1: 1997
ETS 300 328-2: 2000 Radio Equipment and Systems (RES); Wideband
This Declaration is made under our sole responsibility.
Electromagnetic compatibility
t ra n sm i ssi o n syst e m s; T e ch ni cal ch a ra cte ri st i cs a nd te st
conditions for data transmission equipment operating in
the 2.4 GHz ISM band and using spread spectrum
modulation techniques.
Authorised Signatory: Da t e : 0 7 June 2002
P M Gray
Brain Boxes Limited
Unit 3c Wavertree Boulevard South
Wavertree Technology Park
Li verp oo l L7 9PF, UK
Issue D ate: 07/06/2002
Revision Numbe r: Rev A
Page 3
Regulatory Information
IMPORTANT SAFETY INFORMATION
·Do not open the case. There are no user serviceable parts inside the unit.
·Do NOT plug in, turn on or attempt to operate an obviously damaged unit.
·Do not alter or modify the cable assembly, or attempt to connect the cable(s)
except as directed in the User Guide.
·Do not expose this product to extremes of heat or cold, or to moisture - ie.
dripping or splashing
Bluetooth product operating in 2.4GHz band for Home and Office use.
Europe – EU Declaration of Conformity
This device complies with the R&TTE Directive 1999/5/EC, and the following standards:
EN 60950: 1992; EN60335-1: 1994 Safety information Technology Equipment,
i n cl udi ng El e ctri c al Bu si ne ss Equi pme nt
ETS 300 826; EN 301 489-1/-17: 2000;
EN50081 – 1: 1992; EN 50082 – 1: 1997
ETS 300 328-2: 2000 Radio Equipment and Systems (RES);
Important Notice for use in France and Italy
Italy: Li cen se required for use. Your reseller will tell you the procedure to follow.
E’necessaria la concessione ministeriale anche per l’uso. Verification con I
rivenditori la procedura da seguire.
France: Low power device (1mW), there is no limitation for indoor or outdoor use.
Dispositif à faible uissance (1mW), pas de limitation pour son usage à
l’intérieur ou a l’extérieur.
Electromagnetic compatibility
Wideband transmission systems; Technical
characteristics and test conditions for data
transmission equipment operating in the 2.4
GHz ISM band and using spread spectrum
modulation techniques.
Page 4
6
BL-500 Bluetooth PC Card Installation
T his sec ti on will give you all t he i n forma ti on t ha t i s ne eded t o in sta ll y ou r Brain Bo xes Bl uet ooth P C Card
Hardware into your computer running the Windows 2000 Operating System.
Insert t he Bluetoo th Pro du c t CD in to your CDROM drive.
Insert the Bluetooth PC Card into a free PC Card slot
Windows 2000 will detect y our ca rd a nd start t he Found New Hardware Wizar d.
Installation Guide BL-500 Bl uetooth
P CMCIA card in Windows2000 .doc
© C opyright Bra in Boxes Lim it ed 20 02 P age 2 of
Page 5
6
Click Next
Select “Search for a suitable driv er for my device”. Cli c k Next
Select CD-RO M drive s. Cli c k Next
Installation Guide BL-500 Bl uetooth
P CMCIA card in Windows2000 .doc
© C opyright Bra in Boxes Lim it ed 20 02 P age 3 of
Page 6
6
The Wi zard has found the required software. Click Next
The software is now installed. Click Finish.
Installation Guide BL-500 Bl uetooth
P CMCIA card in Windows2000 .doc
© C opyright Bra in Boxes Lim it ed 20 02 P age 4 of
Page 7
6
The Found New Hardw are wizard will detect a number of devices on your card and install the drivers for
them.
A My Blu etooth devi c es ic on will now a pp ear in the My Compute r folder on you r desktop. Doub le clic ki ng on
this ic on will ope n the My B luetooth De vi c es user inte rfa ce which will enab le you to configu re you r card and
establish connections with other bluetooth enabed devi ces.
The Brain Boxes Bluetooth icon found in the icon tray on your start bar can also be used to access this user
interface.
Full details of the My Bluetooth Devices user interface can be found in the configuration chapter.
Installation Guide BL-500 Bl uetooth
P CMCIA card in Windows2000 .doc
© C opyright Bra in Boxes Lim it ed 20 02 P age 5 of
Page 8
6
Version Date Author Checked By Comments
