BRAGI B1000 Users Manual
How to charge
How to apply the Case - XL
copyright 2015 by BRAGI
Content may change without prior warning
v1. 07-25 -2015
7
How to connect
The Dash & BT Device
Go to your smartphone settings to turn on
bluetooth. Insert the Dash into your ear and activate pairing mode by touching the touch area with
a finger until the pairing feedback sound is heard.
Phone & media connection (Bluetooth Classic)
Select “The Dash Audio“ in your list of available
bluetooth devices.
Data connection (Bluetooth LE)
Open the Bragi App and select “The Dash Smart“.
8
How to charge
The Dash
9
How to charge
The Charger
Please plug the Charger
with the Dash into a
USB-Port or Wallcharger.
10
Guess what ...
The Charger & Slide
11
How to update
The Software
Download the latest Software
1
from developer.bragi.com
Place the Dash in the Charger
2
Connect the Charger to your computer
3
Copy the software file onto
4
your Dash
Safely eject the Dash mass storage
5
The Dash will start to blink blue and
6
run the update
The update is complete when the Dash
7
LED starts breathing again
Enjoy the new version!
8
Take a paper cl ip
or something
else poi nty
12
How to reset
The Dash
If you need to reset the
Dash Plug it into
the charger and press
a paper clip into the
hole on the right side
of the Charger for
until it blinks 3 times.
13
How to interact
Basic gestures
Left
Tra ck
Start / Stop activity
Activity feedback
Audio Transparency Up/Down Volume Up/Down
Activity Menu Enter/Exit
Select activity
Next activity
–
Right
Listen & Communicate
Play / Pause music
Tap
Next song
2x Tap
Swipe
Playlist Menu Enter/Exit
Hold
Select playlist
Tap
Next playlist
2x Tap
BT Pairing mode
5 sec.
14
More
Treasures
developer.bragi.com
We created a platform
for you to ask questions,
discuss with us on
different topics, share
your experience with
other developers & get
additional and always
up-to-date information
on the Dash.
Bragi Developer App
To get the Developer
App please visit
developer.bragi.com for
further instructions
The Dash Developer Kit
Quick Start Guide
How to check battery status of The Case
Before you get started –
Activate The Dash.
!
To activate the Dash connect
1
the Charger including Dash
to a USB power source.
Disconnect the USB Power and
your Dash is active.
2
Download the Bragi Developer App
on developer.bragi.com
Register your Dash through the
3
developer app to get full support.
Here we go.
1
What’s inside?
Introducing the Dash
FitSleeves
(XS/S/M/L)
Optical Touch Surfac e
LED Lightring
Passive Noise
Cancellation
Pulse Oximitre &
Health Sensors
... and a lot mo re.
2
What’s inside the box?
The Developers Kit
Ambient Microphone
4GB Flash storage
InEar Microphone
Balanced
Armature Drivers
Accelerometer
The Dash
the Charger &
the Slide
FitSleeves
XS / S / M / L
USB t o
Micro-USB Cable
3
How to insert
The Dash
2
&
1
Position the „R“ Dash with LED lightring in a
vertical position as shown in diagram „Insert the
Dash“. Insert the tip of the Dash
firmly into your ear canal and rotate backwards.
3
To finish installing the Dash, gently pull the top
portion of your ear upwards, while using your
free hand to adjust the Dash for a comfortable
fit within your ear canal and outer ear cartilage.
6
How to check the battery
4
How to wear
The Perfect Fit
2
1
3
4
4
To achieve a good seal, you should
feel the tip of the sleeve close
off your ear canal. Check that
The Dash is firmly seated within
the portion of your ear.
Experiment with the Perfect Fit
by trying the different sizes: large
sleeve to the extra small tip.
FitSleeves
L / M / S / XS
5
How to change size
The FitSleeves
Try different sleeve sizes until
it feels comfortable and secure.
You will need the Perfect Fit to maximise
performance and accuracy of the device.
The Dash & the Charger
Shake the Dash
to get the batter y status
Shake the
Charger
with the Dash
plugged in
100%
< 40%
< 20%
The Dash
Attention!
EN ATTENTION!
Headphone listening at high volume levels
– particularly over extended periods of time –
may damage your hearing.
INFORMATION ON DISPOSAL FOR
USERS OF WASTE ELECTRICAL &
ELECTRONIC EQUIPMENT
(PRIVATE HOUSHOLDS)
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
› To guarantee your personal safety, please ensure that
these headphones are not worn or kept in the
immediate vicinity (closer than 10 cm) of a pacemaker.
› Do not insert jack plug into electric sockets.
› Supervise children when using the equipment.
The product is not a toy.
This symbol on the products and/or accompanying documents means that used electrical and electronic products
should not be mixed with general household waste. For
proper treatment, recovery and recycling, pleas take these
products to designated collection points, where they will
be accepted on a free of charge basis. Alternatively, in
some countries you may be able to return your products to
your local retailer upon the purchase of an equivalent new
product. Disposing of this product correctly will help to save
valuable resources and prevent any potential negative effects
on human health and the environment which could otherwise
arise from inappropriate waste handling. Please contact your
local authority for further details of your nearest designated
collection point. Penalties may be applicable for incorrect
disposal of this waste, in accordance with national legislation.
INFORMATION ON DISPOSAL IN OTHER COUNTRIES
OUTSIDE THE EUROPEAN UNION
This symbol is only valid in the European Union. If you wish to
discard this product, please contact your local authorities or
dealer and ask for the correct method of disposal.
