IMPORTANT!

Read this entire installation manual to ensure
proper installation. When finished with the
installation, file this manual with the owner
or maintenance department.

Separate parts from packaging and make
sure all parts are accounted for before
discarding any packaging material. If any
parts are missing, do not begin installation
until you obtain the missing parts.

Make sure that all water supply lines have
been flushed and then completely turned off
before beginning installation. Debris in
supply lines can cause valves to
malfunction.

Hardware supplied by installer must be
appropriate for wall construction. Wall
anchors used must have a minimum pull-out
rating of 1,000 lbs.

The Adaptive® Infrared control must be
connected with a 24 VAC Class II
transformer. Connections to 110 VAC can
cause personal injury and will result in
damage to the electronics.

Product warranties may be found under
“Product Information” on our web site at
www.bradleycorp.com.

IMPORTANT !

Lire ce manuel d’installation dans son
intégralité pour garantir une installation
appropriée. Une fois celle-ci terminée,
classer ce manuel auprès du service à la
clientèle ou d’entretien.

Séparer les pièces de l’emballage et veiller à
bien avoir toutes les pièces avant de jeter le
matériau d’emballage. Le cas échéant, ne
pas commencer l’installation avant d’avoir
obtenu les pièces manquantes.

Veiller à bien vidanger et fermer toutes les
conduites d’eau avant de commencer
l’installation. Tout débris dans les conduites
d’alimentation risque de provoquer un
mauvais fonctionnement des soupapes.

La quincaillerie fournie par l’installateur doit
être appropriée pour la construction des
murs. Les dispositifs d’ancrage muraux
doivent avoir un indice d’arrachement
minimum de 454 kg (1 000 lbs.).

La commande à infrarouge Adaptive® doit
être connectée avec un transformateur
24 V c.a. Classe II. Des connexions à du
110 V c.a. peuvent provoquer des blessures
personnelles et endommager les
composants électroniques.

Les garanties du produit figurent sous la
rubrique « Informations techniques » sur
notre site Internet à www.bradleycorp.com.

¡IMPORTANTE!

Lea todo este manual para garantizar su
instalación adecuada. Cuando haya
terminado la instalación, preséntelo al dueño
o al Departamento de Mantenimiento.

Separe las piezas del empaque y asegúrese
de que no falte ninguna antes de desechar el
material del empaque. Si falta alguna pieza,
no comience con la instalación hasta que
obtenga las faltantes.

Asegúrese de que todas las tuberías de
suministro de agua hayan sido lavadas y
cerradas completamente antes de comenzar
la instalación. Los desechos en las tuberías
de suministro pueden causar averías en las
válvulas.

Las piezas metálicas proporcionadas por el
instalador deben ser adecuadas para la
construcción en la pared. Las sujeciones de
pared usadas deben tener una capacidad
mínima de extracción de 454 kg (1.000
libras).

El control infrarrojo Adaptive® debe
conectarse con un transformador clase II de
24 V CA. Las conexiones a 110 V CApueden
causar lesiones personales y producirán
daños a los componentes electrónicos.

Se pueden encontrar garantías de los
productos en Product Information
(Información sobre productos) en nuestro
sitio Web en www.bradleycorp.com.

Installation
Installation
Instalación

TDB3103

Terreon®36" Semi-circular Deep Bowl Washfountain
with Infrared Control

Terreon®Lavabo fontaine 914 mm (36") à cuvette
profonde semi-circulaire avec commande à infrarouge

Fuente de lavado semicircular con palangana
profunda Terreon®de 914 mm (36") con control
infrarrojo

WF3203

Terreon®Extra Height 36" Semi-Circular Classic
Washfountain with 9" Deep Bowl and Infrared Control

Terreon®Lavabo fontaine 914 mm (36") à hauteur
supplémentaire classique semi-circulaire à cuvette
profonde de 229 mm (9") et commande à infrarouge

Fuente de lavado clásica semicircular Terreon®de
altura adicional de 914 mm (36") con palangana
profunda de 229 mm (9") y control infrarrojo

P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1-800-BRADLEY Fax: [phone]
http:\\www.bradleycorp.com

215-1332 Rev T; EN 08-009
© 2008 Bradley Corporation
Page 1 of 70 3-5-08

A

D

A

C

O

M

P

L

I

A

N

T

TDB3103 with

Infrared Control

TDB3103 avec

commande à infrarouge

Modelo TDB3103 con

control infrarrojo

WF3203 with

Infrared Control

WF3203 avec

commande à infrarouge

Modelo WF3203 con

control infrarrojo

TDB3103, WF3203 Installation

2 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

Table of Contents

Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Model TDB3103 Washfountain Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Model WF3203 Washfountain Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Washfountain Rough-Ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-12

Vernatherm Adjustment Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Terreon® Cleaning/Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Gel-Coated Fiberglass Cleaning/Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Stainless Steel Cleaning/Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Soap Dispensing Valve Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-17

Soap Recommendations and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Sprayhead Troubleshooting/Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

I.R. Module Assembly Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Infrared Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Solenoid Valve Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21-22

Vernatherm™ Mixing Valve Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23-24

Cleaning the Strainer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23-24

Supplies Required by Installer

• (4) 1/2" lag bolts, screws or other fasteners to anchor washfountain pedestal

• 1/2" hot and cold water supply lines and fittings (refer to rough-ins on page 6)

• Reducing fittings and 1/2" nom. copper tubing supply lines for types with supplies from above

• Standard P-trap (refer to rough-ins on pages 5-7)

• 1-1/2" drain lines and fittings (refer to rough-ins on pages 5-7)

• Teflon tape or pipe dope

• 110 VAC GFI power source for 110/24 VAC UL Class II transformer supplied

• OPTIONAL: Bradley recommends installing an electrical cut-off switch to the unit. This feature
allows no accidental water delivery during regular maintenance and service.

Pre-Installation Information

Terreon® Material

The Washfountain is constructed of Terreon®, a densified solid surface material composed of
polyester resin. Terreon®is resistant to chemicals, stains, burns and impact. Surface damage can be
easily repaired with everyday cleaners or fine-grit abrasives. Terreon® is NAHB certified to meet
ANSI Z124.3, Z124.6 and ANSI/ICPA SS-1-2001.

Adaptive Infrared

The sprayhead is controlled by a solenoid valve, allowing the user to activate a flow of water. The
Infrared sensor will take a few minutes to adapt to its environment when the unit is powered up.

Installation TDB3103, WF3203

3Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

Semi-Circular Washfountain Dimensions

14-1/16"
(357)

22-3/4"
(577)

*24-1/2"
(622)

*30-3/8"
(772)

5-1/2"

(140)

4-3/4"
(121)

13-1/2"
(343)

*34"
(864)

*38"
(965)

*41-1/4"

(1048)

*44-7/8"

(1140)

*53-1/4"

6"

(152)

(1353)

8"

(203)

14"

(356)

9"

(229)

7"

(178)

10"

(254)

5-1/2"

(140)

12"

(305)

10"

(254)

36"

(914)

14"

(356)

*

*

Optional equipment may not comply
with all ADA dimensional guidelines

Model TDB3103

36" Semi-circular - side view

Model TDB3103

ADA Compliant

Back view

Bottom View

Top view

* ADJUSTMENTS TO VERTICAL DIMENSIONS

FOR VARIOUS RIM HEIGHTS

Rim Height Application Adjustment

34" Adult Height ADA, None, as shown

TAS Adult Height

32" TAS Ages 11 thru Subtract 2"

14 or 15, Grades 6
thru 8 or 9

30" TAS Ages 4 thru Subtract 4"

10 or 11, Grades 6
thru 8 or 9 &
Proposed Juvenile
Height ADA

Figure 1a

TDB3103, WF3203 Installation

4 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

Semi-Circular Washfountain Dimensions

6"

(152)

Model WF3203

36" Semi-circular - side view

Back view

Bottom View

Top view

Figure 1b

Installation TDB3103, WF3203

5Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

Semi-Circular Washfountain Rough-Ins

2" (51mm)

1" (25mm)

1-1/2" NPT DRAIN
FROM THE WALL

PEDESTAL
OPENING
AT WALL

LOCATION OF ELECTRICAL OUTLET

(CHECK LOCAL CODES - OUTLET

MAY BE REQUIRED TO BE IN A

REMOTE LOCATION)

7"

(178mm)

2"

(51mm)

4"

(102mm)

9"

(229mm)

12"

(305mm)*

SEE TABLE

BELOW

34"

(864mm)

RIM

HEIGHT*

SEE TABLE

BELOW

MALE 1" NPT SUPPLY LINES

STUB OUT 1" FROM WALL

FINISHED FLOOR

HOT COLD

Figure 1c

* ADJUSTMENTS TO VERTICAL DIMENSIONS

FOR VARIOUS RIM HEIGHTS

Rim Height Application Adjustment

34" Adult Height ADA, TAS Adult Height None, as shown
35" (WF3203)

32" TAS Ages 11 thru 14 or 15, Subtract 2"

Grades 6 thru 8 or 9

30" TAS Ages 4 thru 10 or 11, Subtract 4"

Grades Pre-K thru 5 or 6 &
Proposed Juvenile Height ADA

TDB3103, WF3203 Installation

6 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

Rough-In Specifications

CLEARANCE

TRAP FOR WALL OUTLET ONLY

1/2" NPT COLD SUPPLY THROU GH WALL

1/2" NPT HOT SUPPLY THROUGH WALL

1-1/2" NPT DRAIN

5" R. BOTTOM ACCESS

36" BOWL
(914)

HOLE

4"

(102)

2"

(51)

2"

(51)

1"

(25)

*12"

(305)

*17 - 21"

(432 - 533)

DRAIN THROUGH WALL

SUPPLIES THROUGH WALL

4-3/4"
(121)

NOTE: Supply lines for one to two
washfountains should be 1"; for three
washfountains, 1-1/4". For more than
three washfountains, pipe sizes should
be increased proportionately.

Figure 2

NOTE:

DRAIN P-TRAP &
SUPPLIES BY OTHERS

NOTE: Supply lines for one to two
washfountains should be 1"; for three
washfountains, 1-1/4". For more than
three washfountains, pipe sizes should
be increased proportionately.

*ADJUSTMENTS TO VERTICAL DIMENSIONS

FOR VARIOUS RIM HEIGHTS

Rim Height Application Adjustment

34" Adult Height ADA, None, as shown
(35" WF3203) TAS Adult Height

32" TAS Ages 11 thru Subtract 2"

14 or 15, Grades 6
thru 8 or 9

30" TAS Ages 4 thru Subtract 4"

10 or 11, Grades
Pre-K thru 5 or 6 &
Proposed Juvenile
Height ADA

Figure 3

Type A Drain

- Supplies through wall

- Vent through wall off-drain

Type O Drain

- Supplies from above

- |Vented through wall off drain

(mm)

(mm)

1-1/2" NPT DRAIN

THROUGH WALL
(STUB OUT TO SUIT
TRAP DIMENSIONS)

1" NPT SUPPLIES FROM ABOVE

MUST REDUCE TO 1/2" NOM.

COPPER TUBE ON THESE

CENTERS TO PASS THROUGH

13" R. TOP ACCESS

1"

(25)

WASHFOUNTAIN

4"

(102)

TRAP FOR WALL OUTLET ONLY

TRAP

1-1/2" NPT DRAIN

COLD

7/8"
(22)

7/8"
(22)

OT

H

7-3/8" R. BOTTOM ACCESS

36" BOWL
(914)

4"

(102)

CLEARANCE
HOLE

4-3/4"
(121)

*17 - 21"

(432 - 533)

DRAIN THROUGH WALL

WALL

Installation TDB3103, WF3203

7Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

1

2

Rough-in drain & supplies

Bowl/pedestal mounting and assembly

NOTE:

A location to plug in the 24
VAC transformer is required.
Refer to Figure 1c on page 5
for outlet rough-in.

NOTE:

Before attaching 1/4" wing nuts
and washers to threaded rod,
remove red protective caps from
threaded rods. Discard sleeve
caps after removal.

CAUTION:

Bowl surface is smooth.
Aprroximate weight of bowl is 75
pounds. Handle with Care!

ROUGH IN SUPPLYAND DRAIN
PIPING AS REQUIRED FOR YOUR
INSTALLATION (SEE PAGES 5-6
FOR ROUGH-INS OF OPTIONAL
INSTALLATIONS)

A

ATTACH THE STAINLESS STEEL PEDESTAL BASE TO THE PEDESTAL
USING SUPPLIED SCREWS AND FINISHING WASHERS. FOR WALL­MOUNTED MODELS, SEE PAGES 3-4 FOR PEDESTAL HEIGHT.

A

POSITION THE PEDESTALAT THE DESIRED LOCATION AND MARK THE
POSITION OF THE (4) PEDESTAL WALL MOUNTING LOCATIONS.

B

SECURE THE PEDESTAL TO THE WALL WITH SUITABLE FASTENERS, 1/2"
ANCHORS AND 1/2" BOLTS (SUPPLIED BY INSTALLER) (SEE FIGURE 1B
FOR WALL MOUNTING LOCATIONS).

C

USING TWO PEOPLE, CAREFULLYLIFT THE BOWL ONTO THE PEDESTAL
(SEE FIGURE 4).

D

POSITION THE BOWL SO THAT THE THREADED RODS IN THE BOWL MATE
WITH THE SLOTTED HOLES IN THE PEDESTAL (SEE FIGURE 4).

E

USING 1/4" WING NUTS AND WASHERS, SECURE THE BOWLTO THE
PEDESTAL, THREE PLACES (SEE FIGURE 4).

F

Figure 4

TDB3103, WF3203 Installation

8 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

Figure 5

3

4

Installing drain spud in bowl

Supply Stop Valve connection,
and P-trap installation

NOTE!

Seal between drain spud and drain hole with
plumber’s putty (supplied by installer).

NOTE!

Fush supply lines before making
connections. Do not use pipe sealant
on compression fittings.

SECURE DRAIN SPUD WITH LOCK NUT AND WASHERS AS
SHOWN IN FIGURE 5.

A

USING PIPE THREAD SEALANT, THREAD SUPPLIED 1/2" STREET ELBOWS
INTO THE 1/2" ANGLE SUPPLY STOPS (SEE FIGURE 9A, PAGE 12)

A

AGAIN USING PIPE THREAD SEALANT, THREAD
SUPPLYSTOPS ONTO STUB-OUTS.

B

FOLLOW THE PROCEDURES BELOW AND REFER TO
FIGURE 6 WHEN INSTALLING 3/8" TUBING INTO
SPRAYHEAD TO ENSURE THAT YOU ACHIEVE A
LEAKPROOF SEAL.

C

USING A SHARP KNIFE, CUT TUBING SQUARELY AND
REMOVE ANY BURRS. DO NOT PINCH OR CRUSH END
OF TUBING.

D

LOOSEN NUT ON FITTING. MOISTEN END OF TUBE AND PUSH INTO
FITTING UNTIL IT IS FIRMLY SEATED. TIGHTEN NUT TO SECURE TUBE
TO FITTING (MAKE SURE NUT IS SECURELY TIGHTENED).

E

IF CONNECTOR LEAKS, RESEAT TUBING ACCORDING TO ABOVE
PROCEDURE. IF LEAKING PERSISTS, REPLACE MALE CONNECTOR,
OR CALL YOUR BRADLEY REPRESENTATIVE FOR ASSISTANCE.

F

CONNECT P-TRAP (SUPPLIED BY INSTALLER) TO TAILPIECE AND
DRAIN OUTLET.

G

NUT

TUBING

MALE
3/8" TUBE
CONNECTOR
145-105

SPRAYHEAD

Figure 6

TUBING

Installation TDB3103, WF3203

9Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

Adaptive infrared assembly for A drain and O drain units

Electrical connections for Adaptive Infrared

6

5

INSTALL HEMMED END (NOT SHARP END) OF SUPPORT TUBE WITH GASKET ONTO BOWL (SEE FIGURE 7 ON PAGE 10).

A

SECURE INFRARED MODULE COVER AND TOP COVER WITH ACORN NUT AND SOCKET HEAD SET SCREW.

E

ATTACH INFRARED FEMALE CONNECT WIRE FROM INFRARED MODULE TO SOLENOID AS SHOWN IN FIGURE 9B ON PAGE 12.

A

ATTACH THE INFRARED MALE CONNECT WIRE FROM THE INFRARED MODULE TO THE TRANSFORMER LEAD WIRE.

B

ATTACH THE REMAINING TRANSFORMER LEAD WIRE TO THE SOLENOID.

C

CONNECT 24 VAC TRANSFORMER PROVIDED TO POWER SOURCE.

D

TURN SUPPLIES ON. OPEN CHECK/STOP VALVES COMPLETELY.

E

OPEN VOLUME CONTROL VALVE COMPLETELY AND CHECK PIPING INSTALLATION FOR LEAKS.

F

PASS YOUR HAND IN FRONT OF EACH SENSOR UNTILAIR IS PURGED FROM THE LINES.

G

HOLDING THE VALVE ASSEMBLY OUTSIDE OF PEDESTAL, CONNECT 3/8" TUBING FROM SPRAYHEAD TO VALVE ASSEMBLY TUBE
CONNECTOR (SEE FIGURE 9A ON PAGE 12).

F

THREAD ONE SUPPLIED 3/8" NUT ONTO THE TIE ROD. SLIDE VALVE ASSEMBLY ON NEXT AND SECURE WITH ANOTHER 3/8" NUT.
SEE FIGURE 9A.

FOR A UNIT: CONNECT SUPPLY LINES TO STOPS USING SUITABLE FITTINGS.
FOR O UNIT: INSTALL 1/2" NOMINAL COPPER TUBING SUPPLY LINES (PASS THEM THROUGH HOLES IN COVER DOWN THROUGH

SUPPORT COLUMN) AND CONNECT TO SUPPLY STOP VALVES USING SUITABLE FITTINGS.

G

PLACE SPRAYHEAD WITH 3/8" TUBING ONTO SUPPORT TUBE AS SHOWN IN FIGURE 7 ON PAGE 10. RUN TUBING DOWN THROUGH
SUPPORT TUBE. MAKE SURE SPRAY HOLES POINT AWAY FROM THE WALL.

B

PLACE INFRARED MODULE ASSEMBLY ON TOP OF SPRAYHEAD. ROTATE UNTIL INFRARED MODULE LOCKS IN WITH TIE BAR.
DROP TWO INFRARED MODULE WIRES DOWN TO VALVE ASSEMBLY. MAKE SURE INFRARED MODULE WINDOWS ARE FACING

TOWARD THE FRONT OF THE UNIT.

D

PLACE UPPER TIE BAR (NOTCHED AT CORNERS OF BOTH ENDS) ON TOP OF SPRAYHEAD PARALLEL TO WALL. CONNECT THE
TWO THREADED TIE RODS TOGETHER USING THE COUPLING NUT WITH HEX HEAD SET SCREWS. RUN THE TIE ROD DOWN
THROUGH UPPER TIE BAR (SEE FIGURE 7) AND SECURE FROM UNDERNEATH THE BOWL USING THE LOWER TIE BAR (NO
NOTCHES) AND HEX NUT WITH SOCKET HEAD SET SCREW. A MINIMUM OF 1-1/2" OF THREADED TIE ROD SHOULD PROTRUDE
BELOW THE LOWER TIE BAR; THIS WILL BE REQUIRED TO ATTACH THE VALVING.

C

FOR UNITS WITH SOAP OPTION, INSTALL THE SPACER, SOAP DISPENSER AND COVER USING THE COUPLING NUT, THIRD TIE ROD
(8-5/8" LONG) AND SECOND COUPLING NUT AS SHOWN (SEE FIGURE 8 ON PAGE 11). SECURE WITH SPRAYHEAD RESTRAINING
BRACKET, ACORN NUT AND SOCKET HEAD SCREW.

NOTE! Skip to step E for units without soap.

•

START-UP NOTE: Do not use for two minutes after making power connection. The sensors will
take up to eight minutes (without being used) to adapt to the bowl if another object is detected
during the two-minute start-up period.

TDB3103, WF3203 Installation

10 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

PEDESTALASSY.

S17-287

DRAIN
269-1597

TIE BAR

MODULE COVER

S04-083

TIE ROD

176-008

SUPPORT TUBE

S57-006

SUPPORT TUBE

GASKET

125-011

TIE ROD PRE-PACK

S45-1336

TOP COVER

107-099 (A)
107-179 (O)

I.R. MODULE
ASSEMBLY
S50-367

TERREON™ SEMI-CIRCULAR DEEP BOWL
(ADA bowl shown, classic bowl is optional)

Part no. varies with color of bowl. Contact your
local Bradley Representative for assistance.

VALVE ASSY .
SEE FIGURE 8A FOR PART NUMBER

SPRAYHEAD
S05-054B

A/O UNITS

(A shown)

Figure 7

3/8" FLEXIBLE

SUPPLY TUBE

R68-600014

COVER

TIE ROD

PRE-PACK

TIE
ROD

COUPLING NUT

AND SET SCREW

SECTION VIEW OF

A/O UNIT ASSEMBLY

SPRAYHEAD

INFRARED
MODULE ASSY.

TIE
BAR

SUPPLY TUBE

ACCESS PANEL
186-1260

Installation Instructions continued . . .

Installation TDB3103, WF3203

11Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

TOP COVER

Figure 8

I.R. MODULE
ASSEMBLY

SPRAYHEAD

SUPPORT

TUBE

COUPLING

NUT AND

SET SCREW

COUPLING

NUT AND

SET SCREW

SPACER

SOAP

DISPENSER

18-1/8"

TIE ROD

176-008

UNIT WITH “A” DRAIN AND I.R. MODULE
SHOWN, ALSO AVAILABLE WITH “O” DRAIN

4-1/4" TIE
ROD
176-118

8-5/8"
TIE ROD
176-010

MODULE
COVER

TIE BAR

RESTRAINING

BRACKET

140-128

Optional Soap Installation Instructions

Installation Instructions continued . . .

TDB3103, WF3203 Installation

12 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

Figure 9a

Installation Instructions continued . . .

Figure 9b

S50-367

TIE ROD

MIXING VALVE (SHOWN) S45-2233

3/8" TUBING FROM SPRAYHEAD

I.R. VALVE WITH THERMOSTATIC

VOLUME CONTROL

I.R. VALVE WITH TEMPERED LINE

NOT SHOWN

(S45-2234)

CHECK STOP

ELBOW
169-639

S27-102

HOT

TIE ROD NUT 110-064

(DO NOT APPLY PIPE SEALANT
TO COMPRESSION FITTINGS)

FLEXIBLE HOSE 269-1735

CHECK STOP
S27-102

ELBOW
169-639

COLD

3/8" TUBING FROM SPRAYHEAD

INFRARED MODULE

FEMALE CONNECT WIRE

I.R. VALVE WITH

THERMOSTATIC MIXING VALVE

(SHOWN) S45-2233

I.R. VALVE WITH TEMPERED LINE

(NOT SHOWN) S45-2234

24 VAC

TRANSFORMER

S83-134

(DO NOT APPLY PIPE SEALANT
TO COMPRESSION FITTINGS)

INFRARED MODULE
S50-403 (36" BOWL)
S50-367 (54" BOWL)

MALE CONNECT

FEMALE CONNECT

SOLENOID VALVE

Installation TDB3103, WF3203

13Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

Figure 10

Vernatherm Ajustment Instructions

NOTE: The Vernatherm TMA valve is NOT factory preset. Upon installation, the temperature
of this valve must be checked and adjusted to ensure delivery of a safe water temperature.

Water in excess of 110°F (43°C) may cause scalding.

CHECK THE TEMPERATURE AND ADJUST IF NECESSARY (THE RANGE OF THE VALVE IS 95°F–115°F (35°C–43°C). TO ADJUST THE
TEMPERATURE, FOLLOW THE PROCEDURE BELOW:

A

CLEAN SPRAYHEAD IF NECESSARY. SEE PAGE 19 FOR SPRAYHEAD MAINTENANCE AND REPAIR PARTS. ADJUST THE VOLUME
CONTROL VALVE, IF NECESSARY, TO CONTROL THE FLOW OF WATER.

B

ATTACH PEDESTAL ACCESS PANEL WITH HARDWARE PROVIDED.

C

LOOSEN TEMPERATURE LOCKING NUT WITH WRENCH.

•

ONCE DESIRED TEMPERATURE IS REACHED, TIGHTEN NUT TO PREVENT TEMPERATURE CHANGE.

•

USING A BLADE SCREWDRIVER, TURN THE ADJUSTMENT STEM COUNTERCLOCKWISE TO INCREASE THE TEMPERATURE OR
CLOCKWISE TO DECREASE THE TEMPERATURE (FIGURE 10).

•

TEMPERATURE

ADJUSTMENT

STEM

TEMPERATURE

LOCKING

NUT

TDB3103, WF3203 Installation

14 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

Cleaning/Maintenance Instructions for Terreon®

Material Description: Terreon® is a NAHB Certified densified solid surface material composed of polyester
resin and is resistant to chemicals, stains, burns and impact. Surface damage can be easily repaired with
everyday cleansers or fine grit abrasives.

Routine Cleaning: Clean daily or as often as conditions require using a standard commercial or household
cleaner such as Formula 409

®

or Windex®.

Stubborn Stains: Remove tough stains with Ajax

®

, Comet®, or Soft-Scrub®and a green Scotch-Brite®pad or
lightly sand in a circular motion with 240 grit wet/dry sandpaper. The finish can be renewed with a maroon
Scotch-Brite pad.

Special Situations for Material

Scratches: Remove scratches with a green Scotch-Brite®pad. The finish can then be renewed with a maroon
Scotch-Brite

®

pad.

Hard Water Deposits: Remove hard water deposits with a mild solution of vinegar and water. Always rinse
the unit thoroughly after cleaning.
Restoring the Surface: Use Hope’s

®

Solid Surface cleaner and polish to refresh and protect the Terreon
Solid Surface material. Bradley recommends additional care and maintenance for the darker colored Terreon,
for complete instructions on this additional maintenance see Bradley document #1505.

IMPORTANT:

DO NOT USE STRONG ACID OR ALKALINE CHEMICALS AND CLEANSERS TO
CLEAN TERREON. IF THESES CHEMICALS COME IN CONTACT WITH THE TERREON
SURFACE WIPE THEM OFF IMMEDIATELY AND RINSE WITH SOAPY WATER. AVOID CONTACT
WITH HARSH CHEMICALS SUCH AS PAINT REMOVER, BLEACH, ACETONE, ETC. AVOID
CONTACT WITH HOT PANS AND OBJECTS.

Repair Kits: Terreon®repair kits are available. Contact your Bradley representative or distributor for part
numbers and pricing.

NOTE: Repair kits are made to order and have a shelf life of 30 days.

Brand Names: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an
endorsement, nor does the omission of any brand name cleaner imply its inadequacy. Many products named
are regional in distribution, and can be found in local supermarkets, department and hardware stores, or
through your cleaning service. It is emphasized that all products should be used in strict accordance with
package instructions.

Cleaning/Maintenance Instructions for Gel-coated Fiberglass

Material Description: The Terreon®Washfountains referenced in this installation manual use a gel-coated
fiberglass pedestal.

Routine Cleaning: The gel-coated pedestal should be cleaned daily or as often as needed with a mild solution
of detergent and water. Always use a soft cloth to avoid damage to the finish.

Repair Kits: There are no repair kits available for fiberglass materials. However, replacement parts are
available, contact your Bradley representative for pricing and part numbers.

IMPORTANT: DO NOT EXPOSE GEL-COATED FIBERGLASS TO SOLVENTS AS THEY
WILL DAMAGE THE MATERIALAND MAY CREATE HARMFUL FUMES.

Brand Names: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an
endorsement, nor does the omission of any brand name cleaner imply its inadequacy. Many products named are
regional in distribution, and can be found in local supermarkets, department and hardware stores, or through your
cleaning service. It is emphasized that all products should be used in strict accordance with package instructions.

Installation TDB3103, WF3203

15Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

Cleaning and Maintenance Instructions for Stainless Steel

Material Description: Stainless steel is extremely durable, and maintenance is simple and inexpensive.
Proper care, particularly under corrosive conditions, is essential. Always start with the simplest solution and
work your way toward the more complicated.

Routine Cleaning: Daily or as often as needed use a solution of warm water and soap, detergent, or
ammonia. Apply the cleaning solution per the manufacture’s instructions and always use a soft cloth or
sponge to avoid damaging the finish.

Stubborn Stains: To remove stains from stainless steel use a stainless steel cleaner and polish such as Ball

®

stainless steel cleaner or a soft abrasive. Always follow the manufacture’s instructions and apply in the same
direction as the polish lines.

IMPORTANT: NEVER USE ORDINARY STEEL WOOL OR STEEL BRUSHES ON STAINLESS
STEEL. ALWAYS USE STAINLESS STEEL WOOL OR STAINLESS STEEL BRUSHES.

Special Situations for Material

Finger Prints and Smears: To remove fingerprints or smears use a high quality stainless steel cleaner and
polish in accordance with the manufacture’s instructions. Many of these products leave a protective coating
the helps prevent future smears and fingerprints.

Grease and Oil: To remove grease and oil use a quality commercial detergent or caustic cleaner. Apply in
accordance to the manufacture’s instructions and in the direction of the polish lines.

Precautions: Avoid prolonged contact with chlorides (bleaches, salts), bromides (sanitizing agents),
thiocyanates (pesticides, photography chemicals, and some foods), and iodides on stainless steel equipment,
especially if acid conditions exist.

IMPORTANT: DO NOT PERMIT SALTY SOLUTIONS TO EVAPORATE AND DRY ON
STAINLESS STEEL.

The appearance of rust streaks on stainless steel leads to the belief that the stainless steel is rusting. Look for the
actual source of the rust in some iron or steel particles which may be touching, but not actually a part of the
stainless steel structure.

NOTE: Strongly acidic or caustic cleaners may attack the steel causing a reddish film to appear. The use of
these cleaners should be avoided.

Brand Names: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an
endorsement, nor does the omission of any brand name cleaner imply its inadequacy. Many products named are
regional in distribution, and can be found in local supermarkets, department and hardware stores, or through your
cleaning service. It is emphasized that all products should be used in strict accordance with package instructions.

TDB3103, WF3203 Installation

16 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

1 118-025 Valve Body 1
2 110-007 Packing Nut 1
3 135-001L Spring 1
4 125-001BU Washer 1
5 119-028 Plunger 1

* 161-014 Nut 1
* 124-001D Washer 2
* 142-002AH Washer - Stainless Steel 1

Attaching

Parts

S09-007S

Item Part No. Description Qty

Parts List

Soap Valve — Liquid — S09-007S

* Not Illustrated

3

1

5

4

2

This valve delivers a measured amount of soap with each upward stroke. The soap dispenser has
been standard on washfountains since 1983 and is not well-suited for very thick lotion soaps.

NOTE: Lotion soap will clog liquid soap valves. Use only lotion soap valves with lotion soap.

Soap Valve — Lotion — S09-057S

1 124-001D Washer — 1
2 110-057 Nut — 1
3 125-001AN Stopper — 1
4 159-114 Reinforcing Plate — 1
5 124-001AT Washer — 1
6 160-176 Screw — 1
7 S09-040 Valve 1 1
8 S53-045 Adaptor 1 1

Valve Attaching

Assembly Parts

S09-057 S09-057S

Item Part No. Description Qty

Parts List

3

2

1

4

5

7

6

8

Installation TDB3103, WF3203

17Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

Soap Valve — Powdered — S09-010A

3

2

1

4

1 160-069 1 Screw, 1/4-20 RD
2 142-002X 1 Washer, 1/4 Split-Lock
3 S62-002 1 Agitator / Slide Assy.
4 192-004 1 Lever - Powdered Soap

Item Part No. Qty Description

Parts List

NOTE: Reducer plugs are available for use with fine granulated
soap to reduce the flow.

NOTE: Valves can be changed from powdered to liquid by plugging
the innermost, or “bearing” hole with rubber plug, part number
125-001AK. To change from liquid to powdered, the plug must be
removed. If none is present, it will be necessary to drill out the
bearing hole with a 1/2" or 5/8" drill. The plastic container
configuration forms a natural template for locating the bearing
hole.

TDB3103, WF3203 Installation

18 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

SOAP

RECOMMENDA

TIONS

Quality soap dispensers require good quality soap and periodic maintenance to properly operate. Bradley soap
dispensers will provide dependable, consistent operation over the long term when soap with reasonable
viscosity and pH levels are used and when a minimal amount of periodic maintenance is performed on the
valves.

Soap thickness is determined by a measurement called viscosity. Soap viscosity should be between 100 cps
(centerpoise) and 2500 cps for all Bradley soap dispensers. Thinner soaps are perceived by the users as being
“watered down” so users tend to take more than they need, resulting in waste. Thick soaps flow slower and
inhibit the “flushing” action of the valves, which allows the soap to congeal in the valve and cause clogs.

The pH (acid) level of the soap should be in the range of 6.5 to 8.5. More acidic soaps (pH levels lower than

6.5) will corrode metal parts (even stainless steel!!) and degrade rubber and plastic components. They will also
cause skin irritation. Most inexpensive soaps (typically the pink lotion type) fall into this acidic category and
will eventually cause valve failure and metal corrosion.

Base soaps (pH levels higher than 8.5) will cause

swelling or degradation of rubber and plastic parts and skin irritation.
Generally, any quality soap meeting the viscosity and pH guidelines above will work well with Bradley soap

dispensers. PCMX or Isapropanol based antibacterial soaps (within viscosity and pH limits) will also work
with Bradley dispensers. Soaps satisfying these basic guidelines will provide consistent flow and reduce clogs.

Most soap dispenser problems are caused by soap that is too thick or corrosive, or by a lack of maintenance.
Many soaps come in concentrate form which must be diluted with water. Often, the soap is improperly diluted
or used straight out of the bottle, which causes clogging and valve failure. If proper soap is being used, valves
that have never been cleaned are usually the source of dispensing problems. Bradley has entered into an
agreement with Champion Brand Products to provide additional customer service for purchasers of our
dispensers regarding soap issues. They are very helpful and can get to the bottom of almost any soap dispenser
related problem. They also sell an excellent “Bradley approved” soap. Please see Soap Instruction Sheet 215-
1286 for details about soap valve cleaning or how to contact Champion. With proper maintenance and soap,
Bradley dispensers will provide long term, trouble free operation.

SOAP DISPENSER MAINTENANCE INSTRUCTIONS

Bradley soap dispensers will provide dependable, consistent operation over the long term when the proper
soap is used and when a minimal amount of periodic maintenance is performed on the valves. Valves must be
maintained (cleaned) to function properly.

To ensure proper operation of your soap dispenser, follow these instructions:

• Once per month, unscrew valve from reservoir and soak it for 30 minutes in hot water.

• Push valve at least 20 times while it is soaking.

• Flush soap reservoir with hot water while valve is soaking.
In cases of extreme clogging, the valve should be disassembled and the parts should be soaked in hot water or

cleaning solution to restore proper functioning. Soap dispensers that will not be used for extended periods of
time (schools during summer break, etc.) should be drained, cleaned and left empty until put back into service.
Soap left on the outside of dispensers can cause discoloration and corrosion of the reservoir (even on stainless
steel units). All soap should be wiped or scrubbed off daily, then the outside of the dispenser should be rinsed
with clear water and dried with a soft cloth.

Soap Maintenance Tips

Installation TDB3103, WF3203

19Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

Sprayheads — Standard w/Neoprene Spray Ring Grommet

3

2

1

10

4

5

7

6

8

9

1 125-001DE Neoprene Washer-Top 1 1
2 139-031 Sprayhead Manifold 1 —
3 124-001AL Washer 3 4
4 160-211 Carriage Bolt 3 4
5 115-061 Sprayhead Top 1 —
6 116-008 Sprayhead Bottom 1 —
7 124-001AT Washer 3 4
8 161-025 Nut 3 4
9 124-020D Sprayhead Grommet - Semi-circle 1 —

10 125-001DF Neoprene Washer-Bottom 1 1

Sprayhead Repair Kit

Assembly S05-054B S45-051

Item Part No. Description Qty

Parts List

NOTE: Repair kit does not include sprayhead

grommet. Order as a separate item.

Sprayhead Service Suggestions

Problem: Water splashes over the rim of the bowl.

Cause: Foreign matter has reduced the size of the sprayhead slots, causing greater pressure at the open slots.

Solution: Clean the sprayhead:

1. Disassemble the sprayhead and dislodge any dirt, lime build-up and foreign debris with a wire brush.

2. Sprayheads with rubber grommet spray rings may be cleaned by rubbing a coin over the grommet.

3. Throttle down the volume control (water spray should strike the bowl without splashing outside of the bowl).

Problem: Water flow diminishes from the sprayhead.

Cause: Strainer portion of the stop-strainer-check valve is plugged.

Solution: Remove and clean the strainer screen from the stop-strainer-check valve.

NOTE: The sprayhead shown above includes a perforated neopreme spray ring gr ommet that is self-cleaning. The water pressure flexes
the spray holes which slows accumulation of foreign matter and tends to “br eak loose” any such deposits that may have accumulated.

TDB3103, WF3203 Installation

20 3-5-08 Bradley Corporation • 215-1332 Rev. T; EN 08-009

I.R. Module Assembly Components S50-367

IR Actuator

WINDOW

269-1351

Troubleshooting Adaptive IR

There is a LED diagnostic light built into the small black box housing the circuitry for the sensor.
Below is a list of what the signals from the LED mean. Use this list to troubleshoot the sensor.

1. LED not illuminated — no power is getting to the sensor. Check for power at the 110 VAC wall
outlet and from the wires from the 24 VAC transformer. If there is 110 VAC power at the wall
outlet, but no power from the transformer, touching the leads from the transformer while plugged
in or a power surge may have burned out the transformer. Add surge protection at the outlet if a
power surge is suspected and replace the transformer. If 24 VAC power is being supplied from
the transformer, check for loose wire connections and check connections against the wiring
diagram (see Figure 9b).

2. Fast Blink — Sensor is detecting something in its view and water should be on (power is being
sent to the solenoid). If the sensor is blinking fast, the water is turning on and there is nothing in
the detection area, disconnect the power for at least 30 seconds. This will allow the sensor to
loose it’s memory and be reset. Reconnect the power and wait 2 full minutes to allow the sensor
to relearn the environment before attempting to activate. The sensor may take up to 8 minutes to
readjust if it activated during those 2 minutes. If the condition persists, make sure the LEDs at
the ends of the sensor cables are pushed all the way in to the backs of the lenses. If the sensor is
blinking fast and the water is not turning on, go through the troubleshooting guide for the
solenoid.

3. Slow Blink — Sensor is detecting something in its view and the water is off (power is not being
sent to the solenoid). The sensor has detected a stationary object in its view for more than 30
seconds and shut off power to the solenoid valve. Remove the object, if it is still in the bowl, and
repeat the part of Step 2 for resetting the sensor.

4. Blinking SOS (3 short, 3 long, 3 short) — The sensor has detected an overload condition and
shut down to protect it's circuits. Check connections against the wiring diagram. This condition
usually means the solenoid valve is not properly wired. After correcting any wiring error, it will
be necessary to restart the sensor by repeating the part of Step 2 for resetting the sensor.

If you need further assistance, please call your local Bradley Representative. Please call us at
1-800-Bradley if you need the name and telephone number of your local Bradley Representative.

Installation TDB3103, WF3203

21Bradley Corporation • 215-1332 Rev. T; EN 08-009 3-5-08

Solenoid Valve Troubleshooting

CAUTION: Turn off water supplies to unit before troubleshooting.

Problem: An individual operating station fails to shut off and drips.
Cause: There is debris trapped between the diaphragm and the valve seat.
Solution: Remove debris between diaphragm and the valve seat.

1. Remove the three #8 Phillips-head screws that hold the solenoid valve assembly together. Be
careful not to lose the armature or spring (see Figure 11 on page 22).

2. Remove the diaphragm. Remove any particles that have been trapped between the diaphragm
and the valve seat. Rinse off the diaphragm and inspect for damage. Make sure the center orifice
and both small side orifices are open.

3. Reassemble in reverse order, being careful not to overtighten the Phillips-head screws or you
may crack the plastic valve body. Tighten until the armature plate makes contact with the plastic
body.

4. Reconnect the wiring per diagram on page 12.

Problem: An individual operating station fails to turn on.
Cause: Afailed coil for the valve or loose electrical connection to the terminal.
Solution: Test the station to determine cause.

1. Disconnect the wires from the coil of an adjacent valve. Disconnect the wires from the problem
valve and reconnect to the adjacent valve.

2. Turn on electrical and water supplies to the unit. Pass your hand in front of the sensor of the
problem station, and the adjacent station should turn on.

If the adjacent station turns on and cycles normally, replace the coil on the problem valve.
If the adjacent valve fails to turn on, inspect the wires from the sensor cable and do the following:

• make sure there are no breaks and that the fully insulated disconnect terminals are firmly
crimped in place;

• turn off the electrical and water supplies;

• reconnect to the adjacent valve and turn on the water supplies to the unit;

• pass your hand in front of the sensor. If the station still fails to turn on, replace the sensor.
