Page 1
Residential Flue Damper
Gas Water Heaters
SERVICE
MANUAL
Troubleshooting Guide
and Instructions for Service
(To be performed ONLY by
qualified service providers)
Models Covered
by This Manual:
D4403S*F(BN,SX)
D4504S*F(BN,SX)
(*) Denotes Warranty Years
Manual 238-48385-00A
Save this manual for future reference
Page 2
Page 2
Table of Contents
Section Page
Introduction ______________________________________________5
How to Use this Manual _____________________________________6
Tools Required for Service ___________________________________6
Specifications _____________________________________________7
Sequence of Operation______________________________________9
Power Up Sequence
Normal Heating Sequence
Abnormal Operation
Troubleshooting __________________________________________ 13
Burner Maintenance _______________________________________ 15
Burner Inspection
Burner Cleaning Procedure
Pilot Maintenance _________________________________________ 17
Pilot Inspection, Testing and Replacement
Damper Replacement______________________________________ 19
Thermal Well Testing ______________________________________ 21
Determine Water Temperature Inside Tank_____________________ 22
Component Disassembly ___________________________________ 23
Gas Control Removal ______________________________________ 24
Gas Control Assembly _____________________________________ 25
Flammable Vapor Sensor Testing_____________________________ 27
120 VAC Circuit Trace _____________________________________ 27
Diptube Inspection ________________________________________ 28
Anode Inspection _________________________________________ 29
Damper Removal _________________________________________ 31
Inner Door Removal_______________________________________ 32
Inner Door Gasket Replacement _____________________________ 33
Inner Door Installation_____________________________________ 34
Arrestor Cleaning _________________________________________ 35
Damper Relay Installation __________________________________ 35
Common Terms __________________________________________ 38
Notes __________________________________________________ 38
Parts List _______________________________________________ 39
2
Page 3
WARNING
If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury, or death.
What to do if you smell gas:
x Do not try to light any appliance
x Do not touch any electrical switch; do not use any phone in your building
x
Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
x If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency, or the
gas supplier.
CAUTION
Incorrect operation of this water heater may create a hazard to life and property and will
nullify the warranty.
If sweat fittings are to be used, DO NOT apply heat to the nipples on top of the water
heater. Sweat the tubing to the adapter before fitting the adapter to the water connections. It is imperative that heat is not applied to the nipples containing a plastic liner.
Turn off or disconnect the electrical power supply to the water heater before servicing.
Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.
DANGER
Do not store or use gasoline or other flammable, combustible, or corrosive vapors and liquids in the vicinity of this or any other appliance.
NOTICE
Before proceeding, please inspect the water heater and its components for possible damage. DO NOT install any water heater with damaged components. If damage is evident,
then please contact the supplier where the water heater was purchased or the manufac-
Page 3
3
Page 4
Page 4
WARNING
Water heaters are heat producing appliances. To avoid damage or injury, do not store
materials against the water heater or any of its components. Use proper care to avoid unnecessary contact, especially by children, with the water heater and its components. Under no circumstances must flammable materials, such as gasoline or paint thinner be used
o
r stored in the vicinity of this water heater or in any location in which the fumes could
reach the water heater.
Hydrogen gas can be produced in an operating water heater that has not had water drawn
from the tank for a long period of time (generally two weeks or more). Hydrogen gas is
extremely flammable. To prevent the possibility of injury under these conditions, we recommend a hot water faucet to be open for several minutes at the kitchen sink before you
use any electrical appliance which is connected to the hot water system. If hydrogen is
present, there will be an unusual sound such as air escaping through the pipes as hot water begins to flow. Do not smoke or have open flame near the faucet at the time it is open.
DO NOT ATTEMPT TO LIGHT ANY GAS APPLIANCE IF YOU ARE NOT CERTAIN OF THE FOLLOWING:
Liquefied petroleum gases/propane gas and natural gas have an odorant added by the gas
supplier that aids in the detection of the gas. Most people recognize this odor as a “sulfur”
or “rotten egg” smell. Other conditions, such as “odorant fade” can cause the odorant to
diminish in intensity, or ”fade,” and not be as readily detectable. If you have a diminished
sense of smell, or are in any way unsure of the presence of gas, immediately contact your
gas supplier from a neighbor's telephone. Gas detectors are available. Contact your gas
supplier, or plumbing professional for more information.
FAILURE TO INSTALL AND MAINTAIN A NEW, LISTED 3/4” X 3/4” TEMPERATURE AND
PRESSURE RELIEF VALVE WILL RELEASE THE MANUFACTURER FROM ANY CLAIM THAT
MIGHT RESULT FROM EXCESSIVE TEMPERATURE AND PRESSURES.
4
Page 5
Page 5
The Bradford White DEFENDER Safety System
®
The Bradford White DEFENDER Safety System was designed to resist the ignition of flammable vapors that can occur outside of the water heater. Use and installation are nearly identical to
previous versions of atmospherically fired and vented water heaters. A number of exclusive design features are incorporated in the system that will require additional knowledge on the part of
the qualified service provider. The following information will instruct service professionals on
the function, proper diagnosis, and repair of water heaters employing the Bradford White DEFENDER Safety System.
Introduction
The new Bradford White Residential Flue Damper water heaters are designed to provide reliable performance with enhanced standard features. New design features include reliable sparkto-pilot ignition system, enhanced diagnostics, simplified servicing, significantly quiet operation, and the Bradford White Defender Safety System.
Spark-to-Pilot Ignition System - employing the spark-to-pilot ignition system promotes reliable and consistent pilot and main burner ignitions to provide hot water on demand.
Integrated Immersion Thermal Well/Gas Control with LED - was developed for ease of
troubleshooting by providing simple diagnostic codes to pinpoint an installation or component
performance issue.
Rugged Wiring Connections - receptacle type connections promote error free wiring.
The gas control maintains water temperature, ignition sequence, and regulates gas flow. If a
situation outside of normal operating parameters exists, the gas control diagnostic LED will
flash a code to positively identify an operational issue.
This service manual is designed to facilitate problem diagnosis and enhance service efficiency.
To further promote quicker service times, the gas control can be removed and replaced without
draining the water heater. A special tool is required and will be provided with each gas control
kit shipped from your Bradford White wholesale distributor.
Please read the service manual completely before attempting service on this new series of
damper models.
How the Safety System Works
During normal operation, air for combustion is drawn into the water heater through the openings in the jacket. This air travels down and around the combustion chamber and enters through
holes in the very bottom of the corrosion resistant combustion chamber. The air then travels up
through the flame arrestor louvers, where the velocity of the air is increased and its direction
altered. The air then mixes in a normal manner with supplied gas and is efficiently combusted,
producing very low NO
x
emissions.
In the unlikely event trace amounts of flammable vapors are present in the air flowing into the
Introduction
5
Page 6
Page 6
combustion chamber, the vapors are harmlessly ignited by the burner. If flammable vapors are
in sufficient quantity to prevent normal combustion, the flammable vapor sensor recognizes this
and shuts down the pilot and main burner. Should the flammable vapors continue to burn, the
flame arrestor prevents the flames from traveling backwards and igniting vapors outside of the
combustion chamber. And, the resettable thermal switch will open and shut down the pilot and
main burner.
How to Use this Manual
It is intended for this manual to be used by qualified service personnel for the primary purpose
of troubleshooting and repair of the Bradford White Residential Flue Damper water heaters.
Understanding the sequence of operation section of this manual will contribute greatly to troubleshooting the water heater.
The Honeywell WV4460E Electronic Gas Control will display error codes in the event of abnormal operation. Error codes are listed in the troubleshooting chart beginning on page 13 of
this service manual. The troubleshooting chart will also indicate the probable cause for the error
code and direct the service professional to a service procedure to properly diagnose the abnormal operation.
Contact the Bradford White technical support group immediately if diagnosis cannot be made
using the methods described in this service manual.
Tools Required for Service
Manometer: A liquid “U” tube type or a digital (magna-helic) type can be used. This device is
used to measure gas and/or air pressure and vacuum.
Multi-Meter: A digital type is strongly recommended. This device is used to measure electrical
values. The meter you select must have the capability to measure volts AC, volts DC, amps,
micro-amps and ohms.
Electronic Probes: In some cases, standard multi-meter probes will damage or simply not be
effective to obtain certain voltage and ohm reading. It will be necessary to have special electronic “pin” type multi-meter probes. These probes are available at most electronic wholesale
outlets.
Thermometer: Used to measure water temperature. An accurate thermometer is recommended.
Water Pressure Gage: Used to measure water supply pressure. Also used to determine tank
pressure by adapting to the drain valve of the heater.
Gas Control Service Tool: BWC part number 239-45991-00. A specialized tool designed to
remove the gas control from gas control thermal well. Available from your Bradford White
parts supplier.
Various Hand Tools: Pipe wrench, channel locks, open end wrenches (3/8", 7/16", 1/2"), 12"
crescent wrench, Allen wrench set, screw drivers (common & Phillips), 1/4" nut driver, pliers
(common & needle nose), socket set, side cutters, wire cutters, wire strippers, wire crimpers,
torpedo level, small shop vac, step ladder, flashlight, and 5 gallon pail.
How to Use this Manual
6
Page 7
Page 7
Power Supply
Dedicated 120VAC, 60 Hz, 15A
Gas Supply Pipe
Minimum 1/2” NPT (Schedule 40 black iron pipe
recommended)
Approved Gas Type
Natural or Propane; unit must match gas type supplied
Gas Pressure
5” w.c. minimum for Natural Gas; 11” w.c. for Propane;
14” w.c. maximum for Natural Gas / Propane
Approved Vent Materials
Single or Double Wall Metal Vent Pipe
Minimum Clearance for
Servicing
18” from top; 24” from front; 4” from sides and rear
Water Supply Pressure
150 psi maximum allowable working pressure; check local
codes for supply pressure
ECO Limit
188°F (87°C)
Temperature Setpoint Range
60°F (16°C) to 160°F (71°C); approximate temperatures
Specifications
7
Page 8
Page 8
Ignition State Timing
Adjust Damper Position and Verify (Open Position)
1
5 seconds
Trial for Ignition 90 seconds
Flame Stabilization Period 3 seconds
Re-adjust Damper Position and Verify 15 seconds
Flame Failure Response Time
1.5 seconds (2 second maximum; 1 second minim
um)
A
djust Damper Position and Verify (Closed Po-
sition)
15 seconds
Damper Blade Position Fault (failed open/close) Retry after 2 minutes
Soft Lockout Retry after 5 minutes
ECO Limit Lockout Indefinite (See page 11 to reset)
Verify Resistive Delay Retry after 2 minutes (repeats 5 times)
Simulated Resistive Load Lockout Indefinite (cycle power to reset)
Hardware Error Lockout
Indefinite (self clears if fault clears for at least 15
seconds)
Specifications
Wiring Diagram
Control Timings
8
Page 9
Page 9
Power Up Sequence
1. Start-up: Upon power up, the gas control runs a safe start check with a typical delay of 5 seconds.
2. Flammable Vapor Verification: The gas control verifies that the Flammable Vapor
Sensor is in the proper operating range prior to energizing any components. If the
sensor is within the proper range, the gas control resumes normal operation. If the
Flammable Vapor Sensor is out of range, the gas control LED immediately flashes
7 times with a 3 second pause.
Normal Heating Sequence
When the phrase “Damper Open” is used, this means that the damper blade is in the
vertical position (open). Alternatively, “Damper Closed” means that the damper blade
is in the horizontal position (closed). This must not be confused with the phrase
“Damper Circuit Open,” as this means that the damper blade is in the horizontal position. “Damper Circuit Closed” means that the damper blade is in the vertical position,
and the water heater can proceed to an ignition trial.
1. Thermostat Calls for Heat: Prior to energizing the damper, the gas control verifies
the damper safety circuit to see if it is in the correct state. If the safety circuit is
closed, the gas control LED flashes 2 times with a 3 second pause. The gas control waits 2 minutes. Then, the damper is powered closed. This cycle repeats until
the safety circuit opens.
2. Damper Powered Open
3. Damper Safety Circuit Check: If the damper safety circuit does not close within 30
seconds, the gas control LED flashes 3 times with a 3 second pause. The damper
is powered open for a maximum of 30 seconds every 2 minutes trying to close the
damper safety circuit. This cycle repeats as long as there is a call for heat.
4. Damper Hold Period (15 seconds)
5. Trial for Pilot Ignition (90 seconds): The gas control lights the pilot by activating
the spark igniter and gas flow to the pilot burner. If flame is not sensed within 90
seconds, the spark igniter and gas flow are deactivated. The damper will remain
open, and the gas control LED flashes 6 times with a 3 second pause.
6. Main Burner Ignition: After pilot flame is sensed, the gas control activates the
main valve for main burner ignition. The gas control will ignore flame signals for 3
seconds to allow for the main burner to stabilize.
Sequence of Operation
9
Page 10
Page 10
Normal Heating Sequence (cont’d)
7. Steady State Operation: During steady state operation, the gas control monitors:
Thermostat Temperature Sensor: When the setpoint temperature is satisfied, the
gas control is shutdown, and the damper is powered closed. The gas control LED
flashes a short flash once every 4 seconds (Idle status code).
Damper Position: If the damper position is altered during a call for heat, the pilot
and main valves are shutdown. The damper is powered open attempting to close
the damper safety circuit. The gas control LED flashes 3 times with a 3 second
pause.
Flame Sensor: If flame is lost, the pilot and main valves are shutdown. The damper
is powered open. The gas control attempts to re-light the pilot 4 times. If unsuccessful, the damper is closed, and the gas control proceeds to a 5 minute lockout.
The gas control re-attempts to light the pilot starting at Normal Heating Sequence
#2.
8. Thermostat Satisfies: Gas control LED flashes once every 4 seconds.
9. Burner Off
10.Damper Powered Closed (15 seconds)
Abnormal Operation
1. Flammable Vapor Sensor Fault:
A) If the resistance is greater than 70,000 ohms: The gas control immediately turns
off all outputs. The gas control waits and monitors resistance for 30 seconds. If the
resistance is greater than 65,000 ohms after 30 seconds, the gas control proceeds
to verify resistive delay for 2 minutes and flashes 7 times then 1 time with a three
second pause. This process is repeated 5 times until the control either returns to
normal operation or proceeds to flammable vapor lockout.
B) If the resistance is below 3000 ohms: The gas control immediately turns off all
outputs and proceeds to flash 8 times then 1 time with a three second pause. The
error self clears if the resistance returns to normal range for at least 15 seconds.
Sequence of Operation
10
Page 11
Page 11
Abnormal Operation (cont’d)
2. Temperature Sensor Fault:
A) Temperature Sensor Open Circuit: The gas control immediately turns off all outputs and proceeds to flash 8 times then 3 times with a three second pause. The
error self clears if the fault clears for at least 15 seconds.
B) Thermal well sensors not reading the same temperature within ±5.5°F: The gas
control immediately turns off all outputs and proceeds to flash 8 times then 3 times
with three second pause. The error self clears if the fault clears for at least 15 seconds.
C) Water Temperature in excess of ECO (Energy Cut Off) Limit: The gas control
immediately turns off the pilot and main valves. The gas control LED proceeds to
flash 4 times with a 3 second pause.
To reset the gas control, rotate the setpoint knob to the minimum setting for at least
6 seconds before returning to desired temperature setting.
3. Damper Safety Circuit Fault:
A) Damper Failed to Open: The gas control proceeds to flash 3 times with a three
second pause. The gas control waits 5 minutes, and then tries to open the
damper again.
B) Damper Failed to Close: The gas control proceeds to flash 2 times with a three
second pause. The gas control waits 5 minutes, and then tries to open the
damper again.
4. Trial for Ignition Fault:
A) Damper Jostled During Trial: The gas control stops the trial for ignition. The gas
control proceeds to flash 3 times with a three second pause. The gas control
waits 5 minutes, and then tries to open the damper again.
B) Flame Not Sensed: The gas control energizes the spark igniter attempting to
light the pilot and prove flame. If flame is not sensed within 90 seconds, the
spark igniter turns off, the pilot valve is closed. The gas control LED flashes 6
times then 1 time with 3 second pause. The control waits 5 minutes before repeating the ignition sequence.
Sequence of Operation
11
Page 12
Page 12
Abnormal Operation (cont’d)
5. Flame Sensing Fault:
A) Flame Lost During Run: The gas control turns off pilot and main valves. The gas
control increments the recycle count, if the recycle count has not reached its limit
(4), another trial for ignition begins. If the recycle count has been reached, the gas
control LED flashes 6 times then 3 times with a 3 second pause. The gas control
waits 5 minutes before repeating the ignition sequence.
B) Flame Sensed Out of Sequence: The gas control only looks for pilot flame when
the damper is in the open position. If flame is present when the pilot valve is not
open, the gas control proceeds to wait for flame loss and flashes 5 times with 3
second pause. This continues until flame is lost. Once the flame signal is lost, the
control flashes 6 times then 4 times with a 3 second pause. The control waits 5
minutes before repeating the ignition sequence.
Sequence of Operation
12
Page 13
Page 13
LED Status Control Status Probable C ause Service P rocedure
None (LED
not on or
f
lashin
g
)
Ele ctrica l p o w er n o t
present
Control power switch in "OFF"
position.
Su
p
p
lyv
olta
g
e
inte rru
p
t
ed.
Turn P ow er O n
One short
flash every
four seconds
Sta nd-by mode,
Thermostat is
satis fie d
(
no faults
)
Temperature demand is satisfied
(no call for heat)
Normal operation
Alternates
bright and
dim
(
heartbeat
)
The rmos tat ca lling
for he a t (no fault)
Tank temperature below
setpoint of thermostat
Normal operation
Short flash
once every
second
Weak pilot signal
on la s t ca ll for hea t
1. Uns ta ble pilo t
2. P ilo t tu be blocke d o r restricte d
3. Oxid a tion b uild-up o n pilot
electrode
4. W ire d a mage to pilo t
assembly or bad connection at
gas control
1. See Burner Inspection on
page 15
2-4. See P ilo t Inspection ,
Testing a n d Re p la ceme nt o n
page 17
Tw o fla she s ,
three second
pause
Dampe r test circuit
not working
1. Damper not in proper position
or malfunctionin g - stu ck in open
position
2. Obstructed venting
3. Faulty damper
1. Ve rify cord sets a re fully
plu gged in
2. Ve rify sw itch o n da mper is
in " Automatic" position
3. Ve rify tha t da mper and
ventin
g
is not obstructed
Three
flashe s,
three second
pause
Dampe r test circuit
not working
1. Damper not in proper position
or malfunctioning - not reaching
full o p e n position
2. Obstructed venting
3. Faulty damper
1. Ve rify cord sets a re fully
plu gged in
2. Ve rify sw itch o n da mper is
in " Automatic" position
3. Ve rify tha t da mper and
ventin
g
is not obstructed
Four flashes,
three second
pause
Excessive ta nk
temperature,
system must be
reset
1. Thermal w e ll sensor o ut o f
calibratio n
2. Faulty gas control
1. Te s t Ga s C o ntrol & Thermal
Well
2. Re p la ce g a s co ntro l if
necessar
y
Five fla shes,
three second
pause
Fa ls e p ilo t fla me
present
Pilot va lve stu ck in open p o s ition Replace gas co ntrol
Six flas hes,
one flash,
three second
pause (Soft
Lockout)
Fa ile d to light p ilo t,
system resets after
(5) minu te s
1. Uns ta ble pilo t
2. P ilo t tu be block o r restricte d
3. Oxid a tion b uild-up o n pilot
electrode
4. W ire d a mage to pilo t
assembly or bad connection at
g
as va lve
1. See Burner Inspection on
page 15
2-4. See P ilo t Inspection ,
Testing a n d Re p la ceme nt o n
page 17
O
bserve the green LED on the water heater gas
control. Error codes are displayed with a 3 second
pause before repeating. Once the error code is known,
check and repair the water heater, as recommended in
the table below.
Troubleshooting
Green LED
13
Page 14
Page 14
LED Status Control Status Probable Cause Service Procedure
Six flas hes,
t
wo flashes,
three second
p
ause (Soft
Lockout)
Damper test circuit
not working
pro perly during
burner operation,
system auto resets
after (5) minute s
1. Damper not in proper position
or malfunctioning - damper
m
oved from full o p e n p o s ition
d
uring run cycle
2. Obstructed venting
3. Faulty damper
4. Damper jostled during run
c
y
cle
1. Se e Bu rner Inspectio n
on page 15
2-4. See Pilot Inspection,
T
esting and Replacement
on pate 17
S
ix flashes,
t
hree
flashes,
three second
pause (Soft
Lockout)
Pilot fla me
extinguished,
system auto resets
after (5) minute s
1. Unstable pilot
2. P ilo t tu be block o r re stricte d
3. Oxid a tion b uild-up o n pilot
electrode
4
. Wire damage to pilot
assembly or bad connection at
gas control
5. Insufficient combustion air
6. Insufficient
gasp
res s ure
1. Se e Bu rner Inspectio n
on page 15
2-4. See Pilot Inspection,
Testing and Replacement
on page 17
5. Refer to Installation &
Operation Manual
Six flas hes,
fou r flashes,
three second
pause
Undesired false
pilo t flame s ense d,
system auto resets
Pilot valve s tuck in open po s ition Replace g a s co n trol
Seven
flashes,
three second
pause
Flammable vapor
sensor or
resettable thermal
switch fault
detected, see
warning label
1. Flammable va p o r p re s e nt
2. Flammable vapor sensor
exposed to e xcessive moisture
3. Flammable vapor sensor
exposed to extreme ambient
tempe ra ture
4. Resettable thermal switch
o
p
en
See Flammable Vapor
Sensor Testing on page 27
Eight
flashes, one
flas h, three
second
pause
Flammable vapor
sensor out of
spe cification,
possible short
1. Flammable vapor sensor out
of specification; ve rify Fla mmable
Vapor Sensor (FVS) resistance is
not below 25 k.
2. Possible short in flammable
vapor sensor or resettable
the rmal sw itch w irin
g
See Flammable Vapor
Sensor Testing on page 27
Eight
flashes,
three
flashes,
three second
pause
Thermal well sensor
damaged or
unplugged or gas
control ele ctronics
fault detected
1. Damage to thermal well wires
2. Thermal w e ll s ensor
resistance out of range
3. Re p la ce thermal w e ll
4. Ve rify contro l is n o t w e t o r
ph ys ica lly da ma ge d
5. Reset control on/off switch
6. Replace gas control if 8-3 error
persists
See Thermal W e ll Te s ting
on page 21
Eight
flas hes, four
flashes,
three second
pause
Gas control fault
detected
1. Ve rify contro l is n o t w e t o r
ph ys ica lly da ma ge d
2. Reset control on/off switch
3. Replace gas control if 8-4 error
persists
1. Re p la ce g a s co n trol if
wet or physically damaged
2. Cycle power
3. Replace gas control
Troubleshooting
14
Page 15
Page 15
Burner Inspection
At periodic intervals (every 6 months), a visual inspection should be made of the pilot
and main burner for proper operation and to assure no debris is accumulating. The
pilot flame should be stable. Some causes for an unstable pilot flame are:
a) Gas pressure is out of specification.
b) Pilot flame not fully engulfing spark/flame sensor.
The main burner should light smoothly from the pilot and burn with a blue flame with a
minimum of yellow tips.
Steel burner models self adjust air to gas ratio mixture and do not have an adjustable
air shutter. The main burner must be free from any debris accumulation that may
effect burner operation (See Burner Cleaning Procedure on page 15).
Burner Cleaning Procedure
Step 1. Move the gas control power switch to the “OFF”
position.
Step 2. Unplug the water heater from the wall outlet.
Step 3. Turn off the gas supply to the water heater.
Step 4. Remove the outer door.
Burner Maintenance
Gas control power
switch
Damper (water
heater) power cord
Outer door
15
Page 16
Page 16
Burner Cleaning Procedure (cont’d)
Step 5. Remove the (4) 1/4” hex drive screws holding the
right side inner door in place.
Step 6. Disconnect the pilot tube
using a 7/16” wrench and the main burner
feedline with a 3/4” wrench from the gas
control.
Step 7. Disconnect the spark igniter/flame sensor wire from
gas control.
Step 8. Remove the burner assembly from the combustion
chamber.
Step 9. Thoroughly inspect the burner surface area and
burner port area and remove any loose debris.
Step 10. Unscrew the burner from the main burner orifice.
Step 11. Remove the main burner orifice from the main
feedline using a 1/2” wrench. Inspect the orifice and clean or
replace, if necessary.
Burner Maintenance
(
4) 1/4” hex drive
s
crews
R
ight side
i
nner door
Pilot and main
feedlines
Spark igniter/flame
sensor wire
Gas control
Burner assembly
Burner surface area
and burner ports
1/2” wrench
Main burner
orifice
Main feedline
16
Page 17
Page 17
Burner Cleaning Procedure (cont’d)
Step 12. Reassemble the burner assembly and reinstall into the water heater.
Restore gas supply and check for gas leaks.
Step 13. To resume operation, follow the instructions located on the water heater
lighting instruction label. Or, use the lighting instructions located in the water heater
installation and operating manual.
Pilot Inspection, Testing and Replacement
Step 1. Move the gas control power switch to the “OFF”
position
Step 2. Unplug the water heater from the wall outlet.
Step 3. Turn off the gas supply to the water heater.
Step 4. Remove the outer door.
Step 5. Remove the (4) 1/4” hex drive screws holding the
right side inner door in place.
Step 6. Disconnect the pilot tube
using a 7/16” wrench and the main burner
feedline with a 3/4” wrench from the gas
control.
Pilot Maintenance
Gas control power
switch
Outer door
(4) 1/4” hex drive
screws
Right side
inner door
Pilot and main
feedlines
Damper (water
heater) power cord
17
Page 18
Page 18
Pilot Inspection, Testing and Replacement (cont’d)
Step 7. Disconnect the spark igniter/flame sensor wire from
gas control.
Step 8. Remove the burner assembly from the combustion
chamber.
Step 9. Remove the pilot assembly from the main feedline
using a 1/4" nut driver.
Step 10. Visually inspect the spark igniter/flame sense wire for damage. Replace
the pilot assembly, if damage is found.
Step 11. With a multi-meter set to the ohms setting, check
continuity through the spark igniter/flame sense wire. Replace
the pilot, if there is no continuity.
Step 12. Visually inspect the spark igniter/flame sense electrode for deterioration.
Replace the pilot assembly, if necessary. The electrode should not be in contact with
pilot hood. If it is in contact with the pilot hood, carefully adjust electrode to a gap
distance of 3/32" from the pilot hood.
Step 13. Visually inspect the spark igniter/flame sense electrode for oxidation build
up. Carefully clean any oxidation using very fine emery cloth.
Pilot Maintenance
S
park igniter/flame
s
ensor wire
G
as control
Burner assembly
Pilot assembly
1/4” nut driver
Multi-meter
18
Page 19
Page 19
Pilot Inspection, Testing and Replacement (cont’d)
Step 14. Visually inspect the pilot tubing for kinks or cracks. If damage is found,
replace the pilot assembly.
Step 15. Inspect the pilot tubing and pilot orifice for blockages:
a) Remove ferrule nut from the bottom of the pilot
assembly using a 7/16" wrench.
b) Remove the pilot tube and pilot orifice.
c) Inspect the pilot tubing and pilot orifice for
blockages. Clean or replace, as necessary.
Step 16. Reassemble the pilot assembly and install it on the main feedline.
Reinstall the burner assembly into the combustion chamber. Restore the gas supply
and check for gas leaks.
Step 17. To resume operation, follow the instructions located on the water heater
lighting instruction label. Or, use the lighting instructions located in the water heater
installation and operating manual.
Damper Removal & Installation
Step 1. Move the gas control power switch to the “OFF”
position.
Step 2. Unplug the water heater from the wall outlet.
Damper Replacement
Gas control power
switch
Damper (water
heater) power cord
19
Page 20
Page 20
Damper Removal & Installation (cont’d)
Step 3. Disconnect the vent system from the draft hood
that is mounted on top of the damper.
Step 4. Remove the draft hood from the damper and retain
it for use on the new damper.
Step 5. Unplug the cord sets from the damper.
Step 6. Remove the two damper mounting screws using a
1/4” nut driver and retain for later use.
Step 7. Remove the damper from the top of the water
heater.
Step 8. Clean any debris from the jacket head of the water heater.
Step 9. Set the new damper with in place using the water heater tank flue and
the screw holes in the jacket head.
Step 10 Secure the damper in place using the screws from Step 6.
Step 11. Re-install the draft hood from Step 4.
Step 12. Reconnect the vent system to the draft hood.
Damper Replacement
V
ent system
D
raft hood
Damper
Cord sets
1/4” nut driver
Damper
Top of water
heater
Water heater tank flue
20
Page 21
Page 21
Damper Removal & Installation (cont’d)
Step 13. Reconnect the cord sets from Step 5.
Step 14. Plug the water heater into the wall outlet.
Step 15. Move the gas control power switch to the “ON” position.
Step 16. Verify proper damper operation.
Thermal Well Testing
Follow the procedure, below, if the water heater gas control has gone into a ECO
lockout (4 flash, 3 second pause). Reset the gas control by rotating the setpoint knob
to the minimum setting for at least 6 seconds before returning to the desired water
temperature setting.
Step 1. Unplug the thermal well connector from the gas
control.
Step 2. With a multi-meter set to the ohms setting,
measure the resistance between the middle and right side wires.
Step 3. With a multi-meter set to the ohms setting,
measure the resistance between the middle and left side wires.
Thermal Well Testing
CAUTION
Do not use standard multi-meter probes for this testing. Doing so will damage the connector. Use special pin type electronic probes or small diameter wire pins inserted into
connector.
Thermal well connector
21
Page 22
Page 22
Thermal Well Testing (cont’d)
Determine the correct resistance values using the Determine the Water Temperature
Inside the Tank procedure on page 23. If the values are correct, replace the gas
control, otherwise replace the thermal well.
Determine Water Temperature Inside Tank
Note: It is important to understand once the resistance for the thermal well is
determined using the Thermal Well Testing Procedure on page 21, water flow through
the water heater should not occur. Prior to performing the steps below, turn off the
cold water supply to the water heater. This will prevent cold water flow into the tank
affecting the resistance value of thermal well.
Step 1. Move the gas control power switch to the “OFF”
position.
Step 2. Draw approximately 4 gallons of water from the drain valve into a
container and discard. Draw an additional gallon and immediately measure the water
temperature using an accurate thermometer. It may be necessary to open a hot water
faucet to allow heater to drain.
Step 3. Using the chart on page 23, determine the correct resistance value for
the water temperature from Step 2.
Example: If temperature of water is 84°F, then the resistance through the sensor
would be 8449 (see shaded area). NOTE: Sensor resistance increases as the
temperature falls.
WARNING
Stored water may be HOT when performing the following steps in this procedure. Take
necessary precaution to prevent personal injury.
Determine Tank Temperature
Gas control power
switch
22
Page 23
Page 23
Sensor Resistance at Various Temperatures
Gas Control & Thermal Well Removal From Water Heater
Step 1. Move the gas control power switch to the “OFF”
position.
Step 2. Unplug the water heater from the wall outlet.
Step 3. Drain the water heater to a point below the gas control level.
Step 4. Turn off the gas supply to the water heater and disconnect the gas piping
from the gas control.
°F012345678 9
40 26109 25400 24712 24045 23399 22771 22163 21573 21000 20445
5
0 19906 19383 18876 18383 17905 17440 16990 16553 16128 15715
60 15314 14925 14548 14180 13823 13477 13140 12812 12494 12185
70 11884 11592 11308 11032 10763 10502 10248 10000 9760 9526
80 9299 9078 8862 8653 8449 8250 8057 7869 7685 7507
9
0 7333 7165 7000 6839 6683 6531 6383 6238 6098 5961
100 5827 5697 5570 5446 5326 5208 5094 4982 4873 4767
110 4663 4562 4464 4368 4274 4183 4094 4006 3922 3839
120 3758 3679 3602 3527 3453 3382 3312 3244 3177 3112
130 3048 2986 2925 2866 2808 2752 2697 2643 2590 2538
140 2488 2439 2391 2344 2298 2253 2209 2166 2124 2083
150 2043 2004 1966 1928 1891 1856 1820 1786 1753 1720
160 1688 1656 1625 1595 1566 1537 1509 1481 1454 1427
170 1402 1376 1351 1327 1303 1280 1257 1235 1213 1191
180 1170 1150 1129 1110 1090 1071 1053 1035 1017 999
190 982 965 949 933 917 901 886 871 857 842
200 828 814 801 788 775 762 749 737 725 713
In Degrees F
Component Disassembly
Gas control power
switch
Damper (water
heater) power cord
23
Page 24
Page 24
Gas Control & Thermal Well Removal From Water Heater (cont’d)
Step 4. Disconnect the pilot tube
using a 7/16” wrench and the main burner
feedline with a 3/4” wrench from the gas
control.
Step 5. Disconnect the wire harnesses and spark igniter/
flame sense wire from the gas control.
Step 6. Remove the gas control &
thermal well by rotating the flats of the Thermal Well counter
clockwise using a 1-5/16” wrench.
Gas Control Removal From Thermal Well
Following the steps below allows for the removal of the gas control from the thermal
well without removing the thermal well from the tank.
Step 1. Move the gas control power switch to the “OFF”
position.
Step 2. Unplug the water heater from the wall outlet.
Gas Control Removal
Pilot and main
feedlines
Spark igniter/flame
sensor wire
Gas control
Flats of thermal
well
Gas control power
switch
Damper (water
heater) power cord
24
Page 25
Page 25
Gas Control Removal From Thermal Well (cont’d)
Step 3. Turn off the gas supply to the water heater and disconnect the gas piping
from the gas control.
Step 4. Disconnect the pilot tube
using a 7/16” wrench and the main burner
feedline with a 3/4” wrench from the gas
control.
Step 5. Disconnect the wire harnesses and spark igniter/
flame sense wire from the gas control.
Step 6. Using the gas control service tool, p/n 239-4599100, available from your BWC parts supplier, insert the tool into
the back of the gas control.
Step 7. Pivot the tool towards the water heater, as far as possible. Lift straight up
on the gas control. The gas control should move about 1/8". Hold the gas control in
position and remove the tool. Lift straight up on the gas control to remove it completely
from the thermal well.
Gas Control Assembly to the Thermal Well
Step 1. Install the threaded end of the thermal well into the tank. Be sure the
thermal well flange is positioned properly to allow for proper gas control installation.
Tighten the thermal well using a 1-5/16” wrench.
Gas Control Assembly
Pilot and main
feedlines
Spark igniter/flame
sensor wire
Gas control
Gas control service
tool
25
Page 26
Page 26
Gas Control Assembly to the Thermal Well (cont’d)
Step 2. Route the wire leads back into relief opening.
Step 3. Align the slots located on the thermal well flange
with the tabs located on the back of the gas control.
Step 4. Carefully push the gas control back onto the thermal well flange as far as
possible towards the water heater. Then, slide the gas control down to lock into
position.
Step 5. Install the burner assembly
and connect the pilot and main feedlines
to the gas control using a 7/16” and 3/4”
wrench, respectively.
Step 6. Reconnect the wire harnesses to the gas control.
Step 7. Reconnect the gas piping to the gas control. Restore the gas supply and
check for gas leaks.
Gas Control Assembly
W
ire leads on
t
hermal well
Relief opening
S
lots in thermal well
Tabs on back of gas
control
Pilot and main
feedlines
Wire harnesses
26
Page 27
Page 27
Gas Control Assembly to the Thermal Well (cont’d)
Step 8. To resume operation, follow the instructions located on the water heater
lighting instruction label. Or, use the lighting instructions located in the water heater
installation and operating manual.
Flammable Vapor Sensor Testing
Step 1. Move the gas control power switch to the “OFF”
position.
Step 2. Disconnect the flammable vapor sensor harness from
the gas control.
Step 3. Using a multi-meter set to the ohms setting, measure
the resistance of the flammable vapor sensor and resettable
thermal switch. The resistance must be between 3,000 and 48,000
ohms. If the resistance is out of this range, verify that the
resettable thermal switch has not been tripped. If it hasn’t, replace
the thermal switch.
120 VAC Circuit Trace
Step 1. Verify 120VAC and proper polarity are at the wall outlet.
Step 2. With the water heater plugged in and the gas control power switch in the
“ON” position verify LED status.
Flammable Vapor Sensor Testing
CAUTION
Do not use standard multi-meter probes for this testing. Doing so will damage the connector. Use special pin type electronic probes or small diameter wire pins inserted into
connector.
Gas control power
switch
Flammable vapor
sensor harness
27
Page 28
Page 28
Dip Tube Inspection and Replacement
Step 1. Move the gas control power switch to the “OFF” position
Step 2. Unplug the water heater from the wall outlet.
Step 3. Turn off the cold water supply to the water heater. Connect a hose to the
drain valve of the water heater and route to an open drain. Open a nearby hot water
faucet to vent the water heater for draining. Open the drain valve of water heater and
allow the water heater to drain to a point below the inlet connection nipple.
Step 4. Disconnect the inlet nipple from the plumbing system.
Step 5. With an appropriate tool, such as a pipe wrench, remove the inlet nipple/
diptube from the water heater. Use caution not to damage pipe threads.
Step 6. Visually inspect the inlet nipple/diptube. The inlet nipple/diptube should
be free of cracks and any blockage. Hydro-jet slots should be open and free of any
blockage. Any damage, such as cracks, restriction due to deformation, or
unintentional holes are not field repairable and the inlet nipple/diptube must be
replaced.
Step 7. Upon completion of the inspection or subsequent replacement, reinstall
the inlet nipple/diptube into the water heater. Connect the nipple to the plumbing
system, resume water supply to the water heater, and refill the water heater.
Step 8. To resume operation, follow the instructions located on the water heater
lighting instruction label. Or, use the lighting instructions located in the water heater
installation and operating manual.
WARNING
Water heater components and stored water may be HOT when performing the following
s
teps in this procedure. Take necessary precaution to prevent personal injury.
Dip Tube Inspection
28
Page 29
Page 29
Anode Inspection and Replacement
Step 1. Move the gas control power switch to the “OFF” position
Step 2. Unplug the water heater from the wall outlet.
Step 3. Turn off the cold water supply to the water heater. Connect a hose to the
drain valve of the water heater and route to an open drain. Open a nearby hot water
faucet to vent the water heater for draining. Open the drain valve of water heater and
allow the water heater to drain to a point below the outlet connection nipple.
Step 4. Disconnect the outlet nipple from the plumbing system.
Step 5. With an appropriate tool, such as a pipe wrench, remove the outlet
nipple/anode from the water heater. Use caution not to damage the pipe threads.
Step 6. Visually inspect the outlet nipple/anode. The outlet nipple/anode should
show signs of depletion, which is normal. If depletion is one-half the original anode
diameter (approximately 3/4” diameter), replacement is recommended. If any of the
steel core of the anode is exposed, replacement is recommended.
Step 7. Upon completion of the inspection or subsequent replacement, reinstall
the outlet nipple/anode into the water heater. Connect the nipple to the plumbing
system, resume water supply to the water heater, and refill the water heater.
Step 8. To resume operation, follow the instructions located on the water heater
lighting instruction label. Or, use the lighting instructions located in the water heater
installation and operating manual.
WARNING
Water heater components and stored water may be HOT when performing the following
steps in this procedure. Take necessary precaution to prevent personal injury.
Anode Inspection
29
Page 30
Page 30
Remove the Damper to Gain Access to the Flue Baffle
Step 1. Move the gas control power switch to the “OFF”
position.
Step 2. Unplug the water heater from the wall outlet.
Step 3. Disconnect the vent system from the draft hood that is mounted on top of
the damper.
Step 4. Unplug the cord sets from the damper.
Step 5. Remove the two damper mounting screws using a
1/4” nut driver and retain for later use.
Damper Removal
Gas control power
switch
Vent system
Draft hood
Damper
Cord sets
1/4” nut driver
Damper (water
heater) power cord
30
Page 31
Page 31
Remove the Damper to Gain Access to the Flue Baffle (cont’d)
Step 6. Remove the damper from the top of the water
heater.
Step 7. Remove the flue baffle from the water heater.
Step 8. Inspect the baffle for deterioration and missing
restrictors. Clean any scale or debris build-up. Replace with a
new baffle, as necessary.
Step 9. Reinstall the baffle into the flue. Be sure the baffle
hanger tab is inserted into the notch locations at the top of the
flue.
Step 10. Check the burner to ensure no scale has accumulated during operation.
See the Burner Cleaning Procedure on page 15, if accumulation has occurred.
Step 11. Secure the damper in place using the screws from Step 5.
Step 12. Reconnect the vent system to the draft hood.
Step 13. Reconnect the cord sets from Step 4.
Step 14. Plug the water heater into the wall outlet.
Step 15. To resume operation, follow the instructions located on the water heater
lighting instruction label. Or, use the lighting instructions located in the water heater
installation and operating manual.
Damper Removal
D
amper
Top of water
heater
Water heater tank flue
Flue baffle
31
Page 32
Page 32
Inner Door Removal Procedure
Step 1. Move the gas control power switch to the “OFF”
position.
Step 2. Unplug the water heater from the wall outlet.
Step 3. Remove the outer door.
Step 4. Remove (4) 1/4” hex drive screws from the right
side inner door.
Step 5. Remove (2) 1/4” drive screws from the left side inner door.
Step 6. Remove the connectors attached to the resettable
thermal switch on the right side inner door.
Inner Door Removal
Gas control power
switch
Outer door
(4) 1/4” hex drive
screws
Right side
inner door
Connectors attached to re-
settable thermal switch
Damper (water
heater) power cord
32
Page 33
Page 33
Inner Door Removal Procedure (cont’d)
Step 7. Inspect both inner doors for any of the following imperfections: tears,
missing material, cracks, dirt or debris, lack of adhesion to the inner door, material left
on combustion chamber, or any other imperfections that will inhibit a proper seal.
If any of the imperfections above are present, replace the inner door gasket following
the Inner Door Gasket Replacement Procedure. If not, replacement of the inner door
gaskets is not necessary.
Inner Door Gasket Replacement Procedure
Step 1. Completely remove all gasket and adhesive residue from the right and
left side inner doors, as needed.
Step 2. Using RTV sealant, apply a 1/8” bead to secure
the inner door gasket to the inner door sections. Refer to the
illustration for proper application. Note the overlap
configuration in the flange area of the inner door. Set the
flange section first, and this will help to achieve the proper
overlap position.
Inner Door Gasket Replacement
WARNING
If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury, or death.
Gasket Overlap must be as
shown +
1/32
Enlarged
view of
flange area
Expanded view
Gasket Overlap must be as
shown +
1/32
Recommended pattern for RTV sealant
33
Page 34
Page 34
Inner Door Installation with Gasket
Step 1. Clean any residual gasket residue or other debris from the combustion
chamber surface before installing the inner door/gasket assembly.
Step 2. Place the left side inner door into position first, being sure to firmly
position the concave channel of the inner door around the feedline.
Step 3. Using the 1/4” hex drive screws removed in Step 5 of the Inner Door
Removal Procedure on page 32, secure the left side inner door in place. Do not overtighten the screws.
Step 3. Position the pilot tube and spark igniter wire against the left side inner
door flange gasket. Do not route these through the concave channel with the feedline.
Step 4. Firmly place the right side inner door flange against the left side inner
door flange.
Step 5. Using the 1/4” hex drive screws removed in Step 4 of the Inner Door
Removal Procedure on page 32, secure the two flanges together. Do not over-tighten
the screws.
Step 6. Align the right side inner door to the combustion chamber and verify the
fastener holes of the combustion chamber are aligned with the right side inner door
slotted openings. Verify seal integrity around the combustion chamber opening.
Step 7. Using the 1/4” hex drive screws removed in Step 3 of the Inner Door
Removal Procedure on page 32, secure the right side inner door. Do not over-tighten
the screws. Verify that both the left and right side inner doors are properly positioned
and sealed against the combustion chamber.
Step 8. Re-install the outer door.
Step 9. To resume operation, follow the instructions located on the water heater
lighting instruction label. Or, use the lighting instructions located in the water heater
installation and operating manual.
Inner Door Installation
WARNING
Stripped fastener connections may allow for an inner door seal breach. A seal breach may
result in a fire or explosion, causing property damage, personal injury, or death. Do not
over tighten screws. If a fastener connection is stripped, contact the manufacturer listed
34
Page 35
Page 35
ScreenLok®Flame Arrestor Cleaning Procedure
Step 1. Move the gas control power switch to the “OFF” position and unplug the
water heater from the wall outlet.
Step 2. Remove the outer door.
Step 3. Remove the right side inner door per the Inner Door Removal Procedure
on page 32.
Step 4. Disconnect the pilot tube using a 7/16” wrench and the main burner
feedline with a 3/4” wrench from the gas control.
Step 5. Disconnect the spark igniter/flame sensor wire from gas control.
Step 6. Remove the burner assembly from the combustion chamber.
Step 7. Clean the ScreenLok
®
flame arrestor using a stiff brush, compressed air,
and/or a shop vacuum to remove any scale or other debris accumulation. Using a soft
brush, clear jacket openings from any dirt, dust, restrictions, or other obstructions.
Step 8. Remove any debris from the burner assembly following the Burner
Cleaning Procedure on page 15.
Step 9. Re-install the burner assembly.
Step 10. Reconnect the main and pilot tubing and spark igniter wire to the gas
control.
Step 11. Re-install the inner door per the Inner Door Installation with Gasket
Procedure on page 34.
Step 12. To resume operation, follow the instructions located on the water heater
lighting instruction label. Or, use the lighting instructions located in the water heater
installation and operating manual.
Damper Relay Installation
If the damper fails and water heater operation is necessary temporarily, a relay, p/n
233-47642-00, and harness, p/n 239-48471-00, can be ordered from the Bradford
White Service Parts Department.
Step 1. Move the gas control power switch to the “OFF”
position.
Arrestor Cleaning
Gas control power
switch
35
Page 36
Page 36
Damper Relay Installation (cont’d)
Step 2. Unplug the water heater from the wall outlet.
Step 3. Disconnect the vent system from the draft hood
that is mounted on top of the damper.
Step 4. Remove the draft hood from the damper and retain it for use on the new
damper.
Step 5. Unplug the cord sets from the damper.
Step 6. Remove the two damper mounting screws using a
1/4” nut driver and retain for later use.
Step 7. Move the damper blade to the vertical position.
Step 8. Move the switch on the back to the damper to the
“Service” position (towards the front of the water heater).
Damper Relay Installation
D
amper (water
heater) power cord
Vent system
Draft hood
Damper
Cord sets
1/4” nut driver
Damper Blade
Service Switch
36
Page 37
Page 37
Damper Relay Installation (cont’d)
Step 9. Turn the damper on its side and lay it on top of the water heater.
Step 10. Remove the Red wire in the damper housing
from its location. Connect the 1/4” Red female connector on
the relay harness in its place.
Step 11. Remove the Yellow wire in the damper housing
from its location. Connect the 1/4” Yellow female connector on
the relay harness in its place.
Step 12. Remove the Blue wire in the damper housing from its location. Connect
the 1/4” Blue female connector on the relay harness in its place.
Step 13. Remove the White wire in the damper housing from its location. Connect
the 1/4” White female connector on the relay harness in its place.
Step 14. Using the White wire that was removed in Step
13, connect it to the piggyback spade connector that was
installed in Step 13.
Step 15. Connect the other ends of the relay harness, as
shown.
Step 16. Place the relay and its harness fully inside
the damper housing.
Damper Relay Installation
Relay and
harness
Damper Housing
Leave this Terminal
Open
Blue Wire
Relay
White Wire
Red Wire
Yellow Wire
Blue Wire
W
hite Wire
Red Wire
Yellow Wire
37
Page 38
Page 38
Common Terms
BTU British Thermal Units
ECO Energy Cut Off
GPM Gallons per Minute
Hz Hertz
KWh Kilowatts per hour
LED Light Emitting Diode
NPT National Pipe Thread
Ohms Ohms of resistance
PSI Pounds per Square Inch
RPM Revolutions per Minute
VAC Volts Alternating Current
W.C. Inches of Water Column
°C Degrees Centigrade
°F Degrees Fahrenheit
NOTES
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
Common Terms
38
Page 39
Page 39
1
2
3
4
5
6
7
8
9
10
12
13
14
15
16
15A
17
18
19
20
21
22
23
24
26
27
11
25
PART NAME AND DESCRIPTION
1. Draft Hood 15. Inner Door (Right)
2. Damper 15A. Resettable Thermal Switch
3. Jacket Head Pan 16. Inner Door (Left)
4. Jacket 17. Damper Wire Harness
5. Heat Trap—Cold Water Inlet 18. Thermal Well
6. Magnesium Anode–Hot Water Outlet 19. Gas Control Valve
7. Heat Trap—Cold Water 20. Wire Harness (FVS / RTS)
8. Flue Baffle Assembly 21. FVS Sensor Clip
9. Dip Tube–Cold Water Inlet 22. Flammable Vapor Sensor (FVS)
10. Temperature and Pressure Relief Valve 23. Outer Door
11. Glass Lined Tank 24. Steel Burner
12. Combustion Chamber Assembly 25. Orifice
13. Jacket Base Pan 26. Pilot Assembly
14. Drain Valve
27. Feedline
Parts List
39
Page 40
Email
parts@bradfordwhite.com
techserv@bradfordwhite.com
www.bradfordwhite.com
Loading...
