ElectriFLEX HD™ (Heavy Duty) Commercial
Electric Water Heater
Bradford White ElectriFLEX HD™ Electric Models Feature:
■ Immersion Thermostats —Designed to provide outlet water at a
thermostatically controlled temperature greater than 180°F (82°C).
■ Conversion Kits—Design certified by ETL for field conversion. Conversion
kits are available to convert any one model to a variety of voltages and kW
inputs (Kit part numbers on reverse side). All models are shipped from the
factory standard Three Phase, and can be field converted to Single Phase
without a conversion kit.
■ Insulation System—3" (76mm) Non-CFC foam covers the sides and top
of the tank, reducing heat loss. This results in less energy consumption,
improved efficiencies, and jacket rigidity.
®
Sediment Reduction System—Sediment
1
⁄2" (38mm) NPT factory-installed true dielectric fittings
Photo is of
CEHD50(kW)3*CF
■ Factory Installed Hydrojet
reducing device that also increases first hour delivery of hot water while
minimizing temperature build-up in tank.
■ Vitraglas
®
Lining—An exclusively engineered enamel formula that provides
superior tank protection from the highly corrosive effects of hot water. This
formula (Vitraglas
®
) is fused to the steel surface by firing at a temperature of
over 1600°F (871°C).
■ Water Connections—1
extend water heater life and simplify water line connections.
■ Elements—Screw in style low watt density incoloy sheathed elements
standard. These elements resist burnout caused by dry fire or lime buildup.
■ Two Protective Magnesium Anode Rods—Provide added protection
against corrosion for long-term, trouble-free service.
■ Hand Hole Cleanout—Allows inspection of tank interior and facilitates the
removal of sediment deposits.
■ ASME Construction Available.
■ NSF Construction Available.
■ Low Restrictive Brass Drain Valve—Durable tamper proof design.
■ T&P Relief Valve—Installed.
■ Completely Pre-wired—With pressure lug terminal block eliminating need for
splicing or taping of wires.
■ Voltages Available—208v, 240v, 277v, 380v, 415v, 480v and 600v.
■ Internal Fusing—Standard on all models.
3 or 5-Year Limited Tank Warranties / 1-Year Limited Warranty on Component Parts.
For more information on warranty, please visit www.bradfordwhite.com
For products installed in USA, Canada, and Puerto Rico. Some states do not allow limitations on warranties.
See complete copy of the warranty included with the heater.
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 5,682,666; 7,634,976; 5,660,165; 5,954,492; 6,056,542; 6,935,280; 5,372,185; 5,485,879; 5,574,822; 7,971,560; 7,992,526;
6,684,821; 7,334,419; 7,866,168; 7,270,087; 7,007,748; 5,596,952; 6,142,216; 7,699,026; 5,341,770; 7,337,517; 7,665,211; 7,665,210; 7,063,132; 7,063,133; 7,559,293; 7,900,589; 5,943,984; 8,082,888;
5,988,117; 7,621,238; 7,650,859; 5,761,379; 7,409,925; 5,277,171; 8,146,772; 7,458,341; 2,262,174. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS: 2,314,845;
2,504,824; 2,108,186; 2,143,031; 2,409,271; 2,548,958; 2,112,515; 2,476,685; 2,239,007; 2,092,105; 2,107,012. Vitraglas
®
and Hydrojet® are registered trademarks of Bradford White® Corporation.
C1401-A-0419
ElectriFLEX HD™ Electric Models
525/8
651/2
663/4
Liters
1337
1664
1695
J
C/L of
Hot Water
Conn.
in.
J
C/L of
Hot Water
Conn.
mm.
Commercial Electric Water Heater
B
Model
Number
CEHD50(A)(kW)3*CF
CEHD80(A)(kW)3*CF
CEHD120(A)(kW)3*CF
Model
Number
CEHD50(A)(kW)3*CF
CEHD80(A)(kW)3*CF
CEHD120(A)(kW)3*CF
Nominal
Gal.
Capacity
U.S.
Gal.
50
80
119
Nominal
Liter
Capacity
189
303
450
Imp.
Gal.
42
67
100
A
Floor to
Top of
Heater
in.
7
50
/16
611/4
6411/16
A
Floor to
Top of
Heater
mm.
1281
1556
1643
B
Jacket
Dia.
in.
24
26
1
30
B
Jacket
Dia.
mm.
610
660
768
C
Floor to
Hot Water
Conn.
in.
5
52
/8
651/2
/4
663/4
C
Floor to
Hot Water
Conn.
mm.
1337
1664
1695
E
Floor to
C/L of
Cold Water
Conn.
in.
15
/16
6
7
15
6
/16
E
Floor to
C/L of
Cold Water
Conn.
mm.
176
178
176
F
Floor to
T&P
Conn.
in.
4011/16
523/16
543/4
F
Floor to
T&P
Conn.
mm.
1033
1326
1391
G
Floor to
Top of
Control
Box
in.
1
/8
49
491/8
505/8
G
Floor to
Top of
Control
Box
mm.
1248
1248
1337
J
C/L of
Hot Water
Conn.
in.
12
13
1
15
/8
J
C/L of
Hot Water
Conn.
mm.
308
330
384
Water
Conn.
NPT
in.
1
1
/2
11/2
11/2
Water
Conn.
NPT
mm.
38
38
38
Approx
Shipping
Weight
lbs.
Std. ASME
270
335
430
Approx
Shipping
Weight
kg.
Std. ASME
122
152
195
* = voltage and phase designator. Voltage and phase must be specified when ordering. Example: CEHD50123*CF, 240 Volt, 3 phase.
(A) ASME Construction available. For ASME construction add “A” to the model number. Example: CEHD50A123*CF.
(mm)
COLD
58°
J
HOT
12"
(305)
J
18 1/2"
(470)
63°
COLD
J J
13"
HOT
(330)
J
19 1/2"
(495)
52°
56°
COLD
45°
15 1/8"
HOT
(384)
J
22 1/8"
(562)
47°
302
378
485
137
171
220
C
A
G
E
F
Commercial Electric Water Heater
Number of Elements
Full Load Current Amperes
Model Conversion Kit Part Numbers***Desired Input
Total
kW
CEHD with
3 Elements
CEHD with
6 Elements
CEHD with
9 Elements
12
13.5
15
18
24
27
30
36
45
54
3 element models may convert 6 kW
thru 18 kW ONLY
6 element models may convert 24 kW
thru 36 kW ONLY
9 element models may convert 45 kW
thru 54 kW ONLY
* Only kW conversion is allowed for models rated 600V. Models rated 480V and below must not be converted to 600V.
** Only available as a three phase conversion kit.
Element
6
9
kW
4.5
4.5
2
3
4
5
6
4
5
6
5
6
208 Volts
415-51043-73
415-51043-74
415-51043-75
415-51043-76
415-51043-77
415-51043-78
415-51043-79
415-51043-80
415-51043-81
415-51043-82
415-51043-83
415-51043-84**
*** Converting 3 Element Configurations (6-18kW)
From
208/240/480 Volt
277/380/415 Volt
208/240/480 Volt
277/380/415 Volt
240 Volts 277 Volts 380 Volts 415 Volts 480 Volts 600 Volts*
415-51043-61
415-51043-62
415-51043-63
415-51043-64
415-51043-65
415-51043-66
415-51043-67
415-51043-68
415-51043-69
415-51043-70
415-51043-71
415-51043-72
277/380/415 Volt
208/240/480 Volt
208/240/480 Volt
277/380/415 Volt
415-51043-49
415-51043-50
415-51043-51
415-51043-52
415-51043-53
415-51043-54
415-51043-55
415-51043-56
415-51043-57
415-51043-58
415-51043-59
415-51043-60
To
415-51043-37
415-51043-38
415-51043-39
415-51043-40
415-51043-41
415-51043-42
415-51043-43
415-51043-44
415-51043-45
415-51043-46
415-51043-47
415-51043-48
Transformer Required
264-41994-02
264-41994-01
No Transformer Change Required
No Transformer Change Required
415-51043-25
415-51043-26
415-51043-27
415-51043-28
415-51043-29
415-51043-30
415-51043-31
415-51043-32
415-51043-33
415-51043-34
415-51043-35
415-51043-36
*** Converting 6 or 9 element configurations (24-54kW)
From
208/240/480 Volt
277/380/415 Volt
208/240/480 Volt
277/380/415 Volt
415-51043-13
415-51043-14
415-51043-15
415-51043-16
415-51043-17
415-51043-18
415-51043-19
415-51043-20
415-51043-21
415-51043-22
415-51043-23
415-51043-24
To
277/380/415 Volt
208/240/480 Volt
208/240/480 Volt
277/380/415 Volt
415-51043-01
415-51043-02
415-51043-03
415-51043-04
415-51043-05
415-51043-06
415-51043-07
415-51043-08
415-51043-09
415-51043-10
415-51043-11
415-51043-12
Transformer Required
264-41995-02
264-41995-01
No Transformer Change Required
No Transformer Change Required
Input
kW
6
9
12
13.5
15
18
24
27
30
36
45
54
Input
kW
6
9
12
13.5
15
18
24
27
30
36
45
54
3 element models may convert 6 kW thru 18 kW ONLY
6 element models may convert 24 kW thru 36 kW ONLY
9 element models may convert 45 kW thru 54 kW ONLY
40
62
93
124
140
155
186
248
279
310
372
465
558
208V
Phase
13
3
3
3
3
3
3
3
3
3
3
3
3
6
6
6
6
6
6
6
6
9
9
9
9
50
50
74
99
112
124
149
199
223
248
298
372
447
240V
Phase
13
3
3
3
3
3
3
3
3
3
3
3
3
6
6
6
6
6
6
6
6
9
9
9
9
GPH Temperature Rise °F
60
70
41
35
62
53
83
71
93
80
103
89
124
106
164
142
186
160
207
177
248
213
310
266
372
319
380V
277V
Phase
Phase
3
1
3
3
3
3
3
3
3
3
3
3
3
3
6
6
6
6
6
6
6
6
9
9
9
9
Recovery
80
31
47
62
70
78
93
124
140
155
186
233
279
415V
Phase
Recovery
Input
90
100
120
140
28
25
37
50
56
62
74
99
112
124
149
186
223
480V
Phase
3
3
3
3
3
3
6
6
6
6
9
9
21
31
41
47
52
62
83
93
103
124
106
155
133
186
160
600V
Phase
3
3
3
3
3
3
3
3
3
3
3
3
3
6
6
6
6
6
6
6
6
9
9
9
9
42
55
62
69
83
110
124
138
165
207
248
3
13
3
3
3
3
3
3
6
6
6
6
9
9
kW
Input
kW
6
9
12
13.5
15
18
24
27
30
36
45
54
6
9
12
13.5
15
18
24
27
30
36
45
54
18
27
35
40
44
53
71
80
89
23
235
352
469
530
587
704
939
1056
1173
1408
1760
2112
208V
Phase
13
28.8
16.6
43.2
25.0
57.6
33.3
64.9
37.5
72.1
41.6
86.5
50.0
115.4
66.7
129.8
75.0
144.2
83.3
173.0
100.0
216.3
125.0
259.6
150.0
28
189
280
375
424
469
564
753
844
939
1128
1408
1692
Phase
13
25.0
37.2
50.0
56.2
62.5
72.0
100.0
112.5
125.0
150.0
187.5
225.0
LPH Temperature Rise °C
34
155
132
235
201
314
269
352
303
390
337
469
401
621
538
704
606
784
670
939
806
1173
1007
1408
1208
14.4
21.6
28.9
32.5
36.1
43.4
57.8
65.0
72.2
86.7
108.3
130.0
277V
Phase
108.3
129.9
162.4
194.9
240V
40
1
21.6
32.4
43.3
48.7
54.1
64.0
86.6
97.4
45
117
178
235
265
295
352
469
530
587
704
882
1056
380V
Phase
10.0
14.0
19.0
21.0
23.0
28.0
37.0
41.0
46.0
55.0
69.0
83.0
50
56
67
78
106
95
79
159
140
208
189
235
212
261
235
314
280
416
375
469
424
522
469
625
564
784
704
939
844
415V
Phase
3
13.0
17.0
19.0
21.0
25.0
34.0
38.0
42.0
50.0
63.0
75.0
3
9.0
480V
Phase
13
12.5
18.7
25.0
28.1
31.2
37.5
50.0
56.2
62.5
75.0
93.7
112.5
117
155
178
197
235
314
352
390
469
587
704
7.2
10.8
14.4
16.2
18.0
21.6
28.9
32.5
36.1
43.3
54.1
65.0
102
132
151
167
201
269
303
337
401
503
606
600V
Phase
3
5.8
8.7
11.5
13.0
14.4
17.3
23.1
26.0
28.9
34.6
43.3
52.0
68
Sample Specification
The water heater shall be a Bradford White ElectriFLEX HD™ model with a rated storage capacity of not less than_______gallons (_______liters), a minimum
kW input of _______kW (_______ BTU/Hr.), a minimum recovery of _______GPH (_______ LPH). The tank shall be Vitraglas® lined and have a bolted hand hole
cleanout.The tank shall have _______magnesium anode rods installed in separate tank head couplings. The heater shall have 3" Non-CFC foam insulation,
and come equipped with an ASME rated T&P relief valve, a cold water inlet Hydrojet
®
Sediment Reduction System. It shall be design certified by ETL for
180ºF (82ºC) application, either with or without a separate storage tank, and comply with state and local codes and ordinances.
General
All electric water heaters are certified at 300 PSI test pressure (2068 kPa) and 150 PSI working pressure (1034 kPa). All models are design certified by ETL,
to provide outlet water at a thermostatically controlled temperature greater than 180°F (82°C) as an Automatic Storage Heater, and an Automatic Circulating
Tank Heater. As an Automatic Storage Heater, all models are complete, self-contained water heating systems. It needs no separate storage tank, pump,
wiring or elaborate piping network. When equipped with a mixing valve, it will supply 180°F (82°C) sanitizing and lower temperature general purpose hot
water simultaneously. These models can be used either as a single unit or in multiples connected in series or parallel (recommended). Dimensions and
specifications subject to change without notice in accordance with our policy of continuous product improvement.
For field service, contact your professional installer or local Bradford White sales representative.
Sales / Technical Support 1-866-690-0961 / 905-203-0600
Fax 905-636-0666 / Email bwcctech@bradfordwhite.com / www.bradfordwhite.com
©2019, Bradford White Corporation. All rights reserved.
Printed in U.S.A.C1401-A-0419
Loading...
