COLD PLANER
For Skid Steer Loaders
The Bradco Cold Planer, by Paladin, is an
effective tool for small milling jobs, as well as
asphalt and concrete pothole and frost heave
repair, curb cutting, pavement texturing and
removal of traffic lane stripes and roadway
around manholes.
• Independent self-leveling depth adjustment plates
• Planetary drive delivers high torque
• High rear spoil clearance to prevent recirculation of
material
• Protective shields for hydraulic & electrical
components
Page 2
• Fully adjustable with electrohydraulic controls
• Manual depth and tilt option
available on standard flow Cold
Planer ONLY
• Convenient for milling frost
heaves, expansion joints, railroad
approaches, etc.
COLD PLANER
Specifications SP300 HP400 HP450 HP600 HP750 HP1000
Hydraulic flow requirements standard high high high high high
Hydraulic flow range (gpm) 12-22 22-40 22-40 22-40 22-40 22-40
Width (overall) 52” 65” 65” 65” 65” 65”
Height (overall) 32” 35” 35” 35” 35” 35”
Length (overall) 44” 50” 50” 50” 50” 50”
Planning width 12” 16” 18” 24” 30” 40”
• Water nozzle kit standard with
integral water nozzle ports
• Optional in-cab control harness for
most skid-steer loader models
• Pick maintenance tool included and
stowed with the Cold Planer
• Convenient ergonomic electrohydraulic control joystick for depth,
tilt and side shift standard
• Independent self-leveling depth
adjustment plates which allow for
precise lapping cuts and taper cuts
• Replaceable steel bushings at pivot
locations
• Efficient piston drive motor
Planning depth 0 ”- 5” 0” - 5” 0” - 5” 0” - 5” 0” - 5” 0” - 5”
Tilt ±11º ±8º ±8º ±8º ±8º ±8º
Drum diameter 19” 22” 22” 22” 22” 22”
Number of carbide picks 37 43 45 57 69 89
Weight (lbs) 1500 1500 2200 2400 2600 3100
Sideshift - center to right 0” - 19” -3” - 22” -3” - 22” -3 ”- 22” -3” - 22” -3” - 22”
Operating pressure psi 2500-3000 2500-3000 2500-3000 2500-3000 2500-3000 2500-3000
A
• Solid hardened steel wheels with
greasable manifold pins and
secluded greased zerks
• Exclusive angled spoil guard wheel
design prevents wheels from riding
up and over millings, this feature
provides more force to the cutting
action by significantly reducing
rolling resistance and allow for
maintained control over depth of cut
|| PH: 800.456.7100 || www.paladinattachments.com || Connect with Paladin:
D
B
E
C
Bradc o Cold Plan er 0114-1 © 2014 Paladin Pow erful Atta chment Tools
