Bpt MTMRFID Programming Manual

FB00435-EN

PROGRAMMING MANUAL

MTMRFID

ON

1 2 3 4

SW4

A

SW2

MASTER

VAS/101

ON

1 2 3 4

SW4

ON

1 2 3 4

SW4

ON

1 2 3 4

SW4

ON

1 2 3 4

SW4

A

B

+

+

❶

❶

❷

❸

❷

❸

beep

beep

Page 2 - Manual FB00435-EN - vers. 1

- 10/2016- © Came S.p.A . - The contents of the manual are to be considered as subject to change at any time and without the need for any advance warning.

General warnings

• Read the instructions carefully before starting installation and proceed as specified by the manufacturer.

• Installation, programming, commissioning and maintenance of the product must only be performed by qualified technicians who

have been properly trained in compliance with current standards, including health and safety and packaging disposal regulations.

• Before performing any cleaning or maintenance operation, disconnect the power supply to the device.

• The unit must only be used for the purpose for which it was explicitly designed.

• The manufacturer declines all liability for any damage as a result of improper, incorrect or unreasonable use.

Default factory reset

Stand-alone programming in MASTER mode

Adding a badge

This procedure allows you to associate a badge to one of the two
relays present in the following way:

- DIP3 set to ON badges associated with relay 1 (terminal NC,
NO, C1);

- DIP3 set to OFF badges associated with relay 2 (terminal NO,
C2).
Set DIP1 on SWITCH SW4 to ON A❶. The red LED will flash
slowly A❷. Swipe the badges to be associated with the se­lected relay according to the procedure described above A❸.
A tone will confirm that the association has taken place; 3 quick
tones will indicate an error condition.
At the end, set DIP1 back to OFF: the red LED will go o.

Removing badges

Set DIP2 to ON B❶. The red LED will flash quickly B❷. Pass
all the badges to be removed close to the reader B❸.
A tone will confirm that the removal has taken place; 3 quick
tones will indicate an error condition.
At the end, set DIP2 back to OFF: the red LED will go o.

In order to return the MTMRFID module to its factory settings,
disconnect the power supply, set DIP1 and DIP2 on SWITCH SW4
to ON A and power the module again.
After 5 seconds, the module restarts and a tone will confirm that
the reset has taken place.

SW2

MASTER

SW2

SLAVE

VA/08

ETI/XIP

ETI/XIP APP

DVC/IP

PROG

RFID

PROG

+

Ð

ON

1 2 3 4

SW4

❷

❶

❶

PROG

RFID

PROG

+

Ð

B

A

❸

beep

PROG

RFID

PROG

+

Ð

ON

1 2 3 4

SW4

❷

❸

beep

C

ON

1 2 3 4

SW4

ON

1 2 3 4

SW4

ON

1 2 3 4

SW4

ON

1 2 3 4

SW4

C

D

+

+

❶

❶

❸

❷

❷

beep

beep

Page 3 - Manual FB00435-EN - vers. 1

- 10/2016- © Came S.p.A . - The contents of the manual are to be considered as subject to change at any time and without the need for any advance warning.

To remove lost badges, set DIP4 to ON C❶, The red LED will
remain on and steady C❷.
Pass all the badges previously acquired close to the reader C❸.
At the end, set DIP4 back to OFF: the red LED will go o D.

A tone will confirm the removal of the badges programmed previ­ously but not acquired in the phase, otherwise 3 quick tones will
indicate an error condition.

N.B.

- In order for the procedure to be valid, you must pass at
least one previously acquired badge.

Stand-alone programming in SLAVE mode

Adding badges with VA/08

Set the RFID PROG jumper on the power supply to “+” A❶.
The red LED on the RFID will flash quickly A❷.

Swipe the badges to be associated. A tone will confirm that the association has taken
place A❸; 3 quick tones will indicate an error condition.

At the end, reposition the RFID PROG jumper in the rest position. The PROG LED on the
power supply and the red LED on the reader go o B.

Removing badges with VA/08

Set the RFID PROG jumper on the power supply to “-” C❶. The
red LED on the RFID will flash slowly C❷.

Swipe the badges to be removed twice. A tone will confirm that
the removal has taken place C❸; 3 quick tones will indicate
an error condition.
At the end, reposition the RFID PROG jumper in the rest position.
The PROG LED on the power supply and the red LED on the
reader go o B.

ON

1 2 3 4

SW4

❸

❷

beep

ON

1 2 3 4

SW4

C

❶

SW2

MASTER

SW2

SLAVE

SW2

SLAVE

VA/01

M1

PROGPROG

>3’’

A

PROG

B

M1

PROGPROG

<1’’

D

Page 4 - Manual FB00435-EN - vers. 1

- 10/2016- © Came S.p.A . - The contents of the manual are to be considered as subject to change at any time and without the need for any advance warning.

Programming with MTMA/01 MTMV/01 modules in SLAVE mode

Programming relay codes with badges

Door release code programming associates badges with the relays present on the MTMA/01 MTMV/01 module. Control is local and if
you have multiple MTMA/01 MTMV/01 modules, you need to program the door release codes on each entry panel.

N.B. The procedure for programming the door release and relay codes erases all previously programmed codes.

Accessing programming
With VA/01: press PROG A until the

PROG LED lights up.
Without VA/01: press PROG B on the
entry panel for at least 3 seconds and re­lease within 6 seconds.

Use the dip switches on SWITCH SW4 to set the relay with which
to associate the badge C❶:

associate the badge with the first VLS/2 relay

associate the badge with the second VLS/2 relay

associate the badge with the auxiliary contact on the
MTMA/01 MTMV/01 module

associate the badge with the door release control on
the MTMA/01 MTMV/01 module

Swipe the badge on the entry panel you wish to program C❷.
A tone will confirm that the association has taken place C❸; 3
quick tones will indicate an error condition.

Exiting programming
Briefly press the PROG key D: the entry panel indicator LEDS go o.

RFID

PROG

+

Ð

M1

PROG

A

B

ON

1 2 3 4

SW4

C

D

beep

RFID

PROG

+

Ð

M1

PROG

E

RFID

PROG

+

Ð

M1

PROG

F

G

ON

1 2 3 4

SW4

H

ON

1 2 3 4

SW4

I

beep

Page 5 - Manual FB00435-EN - vers. 1

- 10/2016- © Came S.p.A . - The contents of the manual are to be considered as subject to change at any time and without the need for any advance warning.

Programming access control with badges

This procedure allows you to associate/remove badges with video entry system users (group) to control door release present in the
MTMA/01 MTMV/01 module.

Adding a badge

Set the RFID PROG jumper on the power
supply to “+” A. The PROG LED on the
power supply and the and indicator
LEDs will flash quickly B.

Swipe the badge to be programmed.
If the badge is valid, the indicator LED remains on and steady
and you move on to the next stage of programming C.

Press the group call button with which to associate the badge. A long tone will confirm
the correct procedure D.

N.B.

- In each of the two stages of programming, any error condition will be indicated
by three quick beeps. Repeat the stage correctly.

-You can associate up to 5 badges per group.

At the end, reposition the RFID PROG jumper in the rest position E.

Deleting a badge

Set the RFID PROG jumper on the power
supply to “–” F. The PROG LED on the
power supply flashes and the and
indicator LEDs will flash slowly G.

Move a badge relative to a group close to the reader or swipe the
badge. If the badge is valid, the indicator LED remains on and
steady and you move on to the next stage of programming H.

Swipe the badge again to confirm the operation. A long tone will
confirm the correct procedure I.

N.B. In each of the two stages of programming, any error
condition will be indicated by three quick beeps.
Repeat the stage correctly.

L

RFID

PROG

+

Ð

M1

PROG

J

K

beep

Page 6 - Manual FB00435-EN - vers. 1

- 10/2016- © Came S.p.A . - The contents of the manual are to be considered as subject to change at any time and without the need for any advance warning.

To delete all the badges relative to a group, press the call button relative to the GROUP
whose badges you wish to delete. If the group is valid, the indicator LED remains on
and steady and you move on to the next stage of programming J.

Press the call button again. A long tone will confirm the correct procedure K.

N.B. In each of the two stages of programming, any error condition will be indi­cated by three quick beeps. Repeat the stage correctly.

At the end, reposition the RFID PROG jumper in the rest position L.

The product complies with the applicable reference directives.
Dismantling and disposal. Dispose of the packaging and the device properly at the end of its life cycle, according to the regulations in force in the country where
the product is used. The recyclable components bear the symbol and code for the material.

THE DATA AND INFORMATION PROVIDED IN THIS MANUAL ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT PRIOR NOTICE.
MEASUREMENTS, UNLESS OTHERWISE INDICATED, ARE IN MILLIMETRES.
