To Adjust Angle of Hand Shower
Rotate holder in vertical direction to set desired hand
shower angle.
WARNINGS:
●To avoid hot water dangers and conserve even more
energy, make sure your water heater is set at 120°F
(48.9°C) or below.
●Test the shower water with your hand before bathing.
●As with all combination showers,using both shower
together always cause water pressure to drop in each
shower head.
Use shower head or hand shower individually to maximize
water pressure for high-power performance. Use combined
dual-shower application for gentle pampering, wide flow
coverage and targeting of different body areas.
●Always ensure the hand-held shower head is properly
placed in the bracket, so as to prevent the shower head
from falling.
●Do not pull on or tug the flexible hose. This may result in
the shower head coming loose and falling.
Instruction Manual
To begin your shower experience we want to give you all of
the proper tools to make installation easy and quick. This
way you are that much closer to enjoying an invigorating
shower with your new shower head.
●Gather the tools to install the shower head.
Adjustable Wrench (not included)
●Remove old shower head and remove all pipe tape as well.
●Insure that the washer from the old shower is not
connected to the pipe. Use a thin utensil to check inside the
pipe for washers, such as a pencil or screw driver. Do not
use your fingers.
INSTALLATION
Dual Shower Heads
3 in 1 Fixed
Mount Shower
Head
3-way Diverter
Control Handle
Hose Outlet
Washer
Short Hose Nut
Shower Arm
Washer
Rotatable Holder
Washer
Long Hose Nut
Hose
Hand-held
Shower Head
② Locate the hose end with short hose nut and hand
tighten to shower head. IMPORTANT! If hose is not
installed in this manner unit will not operate properly.
Note: Several U.S. state and local municipal plumbing
codes require the use of a backflow prevention device when
installing a hand shower. This device is termed a vacuum
breaker. If your hand shower includes a vacuum breaker it
will be located in the plug of hand-held shower.
OPERATION:
Spray Selector
Spray Selector allows you to
select from various spray
patterns. Spray pattern is
controlled by the small lever that
rotates left and right.
To Save Water while Lathering or Shampooing
To save water, turn dial lever to pause mode. For your
safety (to prevent pressure buildup), pause mode has
water dripping instead of complete shut-off. After use, do
not leave dial set to pause mode.
① Attach 3 in 1 fixed mount
shower head by threading
clockwise onto shower arm
with rotatable holder to the
right and 3-way diverter
control handle to the left. Use
a wrench to tighten shower
head nut to a snug fit. Do not
over tighten. Wrap shower
head nut with a cloth if you
are using pliers.
To Use 3-way Diverter
To change between the
hand-held or fixed mount spray
or combination of both, turn the
handle on the 3 in 1 fixed mount
shower head clockwise or
counter clockwise.
③ Place hand-held shower head in rotatable holder. Point
all shower heads away from you and turn on the water full
force. Check for leaks. Re-tighten all connectors if
necessary.
