Boxis 110-Sheet User Manual

11 0

Microcut

®

Sheets

Microcut Shredder

A REVOLUTION IN PRODUCTIVITY

®

110-Sheet AutoShred

BONUS

12-pack of lubricant

sheets & 1 waste

liner inside

User Manual

Contents

Technical Specifications & Features ............................................................... 3

Warnings ......................................................................................................... 4

Installation / Safety Instructions ..................................................................... 5

Assembly ........................................................................................................ 6

Operation ..................................................................................................... 6-8

Maintenance ................................................................................................... 8

Troubleshooting .............................................................................................. 9

Warranty ....................................................................................................... 10

Return Instructions and Contact Info ........................................................... 10

2

1

year

Limited Product

Warranty

Auto Feeding Tray

Safety Cover

Manual Feed Entry

Reverse/Off/
On/Forward
slide switch

Reverse

Button

Credit Card

Power

Off

Power

On

Forward

Button

Power

OverheatBin Full

Casters

Technical Specifications

Cutting Type ...........................................................................................Micro Cut

Shred Size .................................................................... 0.16 x 0.39 in. (4 x 10mm)

Will Shred ............................................. Paper, standard staples and credit cards

Credit Cards per pass ......................................................................................... 1

Continuous Operation ........................10 minutes manual / 20 minutes auto feed

Cool Down Time ...................................................................................60 minutes

Bin Size ................................................................................ 6.0 gallons (23 liters)

Unit Dimensions ......................13.58 x 9.45 x 21.89 inches (34.5 x 24 x 55.6 cm)

Unit Weight ..................................................................................20.8 lbs (9.43kg)

3

! !

WARNINGS

CAUTION: KEEP THIS DEVICE AWAY FROM CHILDREN AND PETS!
Place the paper shredder in an area less accessible to children.

DO NOT PLACE FINGERS TOO CLOSE TO THE FEED SLOT AS
SERIOUS INJURY MAY OCCUR. Paper shredders can pull children’s
fingers into the shredder mechanism.

AVOID GETTING LOOSE CLOTHING OR JEWELRY NEAR THE
FEED SLOT.

AVOID GETTING HAIR NEAR THE FEED SLOT.

NEVER spray any aerosol-based products in or around the shredder.
NEVER dispose of flammable chemicals, or materials that have come
into contact with flammable chemicals (for example, nail polish,
acetone, gasoline) in the shredder basket. NEVER use any petroleum
based or flammable oils or lubricants in or around the machine, as
some oils can combust causing serious injury. Lubricants specifically
designed for shredders are acceptable.

NEVER place the shredder near water or any heat source.
Avoid direct contact with water.

STOP STOP

STOP USE IMMEDIATELY IF:

1. The shredder blades become jammed with paper.

2. The shredder motor makes loud and/or irregular noises
during operation.

3. The shredder blades or paper guides become bent or
compromised in any way.

Continuing to operate your shredder with any of the above
conditions present could be potentially dangerous.

4

Installation

• Only operate this product from the type of power source indicated on the marking

label. If you are not sure of the type of power available, consult an electrician.

• Make sure the electrical outlet is easily accessible from the shredder.

• Shredder must be operated only in upright position.

• To make sure the shredder has proper ventilation, place it a minimum distance of

2 in. (5 cm) from the wall or furniture.

Safety Instructions

1. Read and follow all instructions before use. Save these instructions for later use.

2. Always turn off and unplug the machine before moving, servicing, cleaning, or
anything other than normal operation. Serious injury may result. Clean shredder
with a damp cloth, using a mild soap and water solution.

3. Do not use abrasives or petroleum-based cleaners.

4. Place this product as close as possible to power source for quick and easy
unplugging.

5. Turn off the power switch before removing waste bin. It is advisable to
disconnect the power cord before opening the shredder.

6. This product should never be placed near a radiator or other heat source.

7. Do not allow anything to rest on the power cord. Do not place the power cord
where people may walk on it.

8. If an extension cord is used with this product, make sure the total ampere (amps)
ratings on the products plugged into the extension cord do not exceed the
extension cord’s ampere rating.

9. The machine contains no serviceable parts. Do not attempt to service this
product yourself, as opening or removing covers may expose you to risk of injury.
The manufacturer disclaims all liability for injuries resulting from opening the
machine. Mechanical damage resulting from opening the machine may void the
warranty.

10. Unplug this product and contact technical support when:

• The power cord or plug is damaged or frayed.

• Liquid has been spilled on the product.

• The product has been exposed to rain.

• The product does not operate normally, even when the operating instructions

are followed.

• The product has been dropped, or the casing has been damaged.

11. This shredder should be operated only with an operator in attendance.

12. Empty the waste bin regularly so that the waste output is not impeded.

13. This machine can shred normal paper and credit cards. However, you should
shred only one type of these items at a time to avoid causing an overload.

5

Assembly

NOTE: This shredder will operate only when used with the supplied basket. The
supplied basket has a built-in safety feature which prevents the shredder from
operating if used with any other basket or if improperly assembled.

This shredder contains sharp edges on the underside of the shredder head.
The plug on the power supply cord is intended to serve as the disconnect

device, so the socket-outlet should be installed near the equipment and should
be easily accessible.

Operation

Please read operating instructions before using shredder. Check machine for
damage or defect; remnants of paper particles found in the waste bin are normal
due to product testing.

Setup

1. Place the machine on level ground and plug the power cord into any easily
reached grounded electrical outlet.

2. Make sure the wastebasket is correctly positioned.

3. To power On, slide the power switch to the Power On position.

4. The machine will be ready to operate when the Power On LED indicator is
illuminated green.

Paper Clips and Staples:

Although our shredders are safe to shred the occasional standard staple, you
should remove staples whenever possible to prolong the life of the unit. For
auto feeding any stapled papers, please put the stapled side showing on top.
Industrial or non-standard, large-size staples MUST be removed. DO NOT shred
paper clips at any time as this will cause damage to the blades.

6

Operation (cont’d)

Manual Feed (see page 3):

1. To shred paper, insert straight into the manual feed entry.

2. To shred credit cards, insert 1 card at a time into the middle of the
manual feed entry.

Auto Feed (see page 3):

1. Open the auto feed tray.

2. Insert paper into the auto feed tray. Once you insert papers into the auto feed
tray, it will start shredding each sheet automatically.

Please Note:

- Only paper should be used in the auto feed tray. Credit cards should be

shred through the manual paper feed slot.

- Do not insert additional paper into the auto feed tray when it is already in

use.

- Staples must be at the top of the paper (furthest away from the shredder

opening).

- Do not insert folded paper as it may cause the unit to jam.

- While shredding in auto feed mode, you can occasionally shred 2-3 sheets

of paper through manual feed entry in front, simultaneously.

For the safety of children and pets, always Power Off the shredder and
unplug the unit when it is unattended or not in use.

7

Operation (cont’d)

BIN FULL:

The Yellow Bin Full LED indicator will illuminate when waste bin is full.

1. Turn the unit OFF by sliding to the Power Off position.

2. Remove the bin and either dispose of the paper shreds or compress the
shreds down.

3. Re-insert the bin into the housing. NOTE: the Yellow Bin Full LED indicator will
be illuminated and the unit will not power on until the bin is properly inserted.

4. Slide the power switch to Auto On to resume normal operation.

OVERHEATING:

This shredder is equipped with a temperature sensor device that protects
the motor from heat damage. If the device senses the motor is too hot, it will
automatically turn off the shredder and the red Overheat LED indicator will
illuminate. This is normal. If this happens, you shredder will need approximately
60 minutes to cool. Once the Overhead LED indicator is no longer illuminated,
you can continue shredding as normal.

OVERLOAD:

If too much paper is inserted into either the manual feed or auto feed the unit
will automatically stop shredding. When this occurs, slide the switch to Manual
Reverse to dislodge the jammed paper. Remove the paper, recount the pages,
and continue with no more than the maximum stated capacity.

To clear a paper jam, see Troubleshooting section.

MAINTENANCE:

Apply lubricant after 30 minutes of shredding or a minimum of twice per month.
Only shredder lubricant sheets or bottled lubricant designed specifically for
shredders should be used. Follow the instructions provided with the shredder
lubricant. NEVER USE AN AEROSOL LUBRICANT, or any lubricant that is
flammable. Refer to the warnings provided in this shredder manual.

Shredder bag will t this model.

8
