Page 1
DPX-620III 6 Channel
Dimmer S
dimmer pack
User manual
Page 2
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: info@thomann.de
Internet: www.thomann.de
26.04.2018, ID: 186689
Page 3
Table of contents
1 General notes............................................................................................................................................... 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions.................................................................................................................................. 10
3 Features....................................................................................................................................................... 14
4 Installation and starting up................................................................................................................ 15
5 Connections and controls................................................................................................................... 18
6 Operating.................................................................................................................................................... 22
7 Technical specifications....................................................................................................................... 32
8 Plug and connection assignments.................................................................................................. 33
9 Protecting the environment.............................................................................................................. 34
Table of contents
DPX-620III 6 Channel Dimmer S
3
dimmer pack
Page 4
4
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 5
1 General notes
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General notes
DPX-620III 6 Channel Dimmer S
5
dimmer pack
Page 6
1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search
Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides
Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service
If you have any problems with the device the customer service will
gladly assist you.
General notes
6
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 7
1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’.
Letterings
Displays
General notes
DPX-620III 6 Channel Dimmer S
7
dimmer pack
Page 8
The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ð
Automatic operation is started.
3. Switch off the device.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Instructions
General notes
8
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 9
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – danger zone.
General notes
DPX-620III 6 Channel Dimmer S
9
dimmer pack
Page 10
2 Safety instructions
This appliance is designed for professional use only and is intended to be used to control the
brightness of connected spotlights. Use the device only as described in this user manual. Any
other use or use under other operating conditions is considered to be improper and may result
in personal injury or property damage. No liability will be assumed for damages resulting from
improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
10
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 11
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
Safety
Safety instructions
DPX-620III 6 Channel Dimmer S
11
dimmer pack
Page 12
DANGER!
Electric shock caused by short-circuit
Do not modify the mains cable or the plug. Failure to do so could result in electric
shock/death or fire. If in doubt, seek advice from a registered electrician.
NOTICE!
Risk of fire
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked flames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
12
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 13
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
DPX-620III 6 Channel Dimmer S
13
dimmer pack
Page 14
3 Features
n Six dimmer channels
n
Output: 6 shockproof sockets
n
Digital control system
n
Control via DMX 512
n
Single channel fuse (each 16 A)
n
Phase correction for linear dimming
n
Individually adjustable dimmer curve
n
Power supply via 5-pin mains connection cable for CEE plug
Features
14
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 15
4 Installation and starting up
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Create all connections while the device is off. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
Installation and starting up
DPX-620III 6 Channel Dimmer S
15
dimmer pack
Page 16
DANGER!
Hazardous voltage
Hazardous voltage may be present at cable ends and screw terminals.
The connection of screw terminals as well as all maintenance and repair work on
the electrical installation of the device must only be performed by qualified electrical personnel in volt-free condition. Failure to do so may result in electric shock
and risk of fire and loss of life.
By all means you have to observe all electrical safety instructions applicable at the
place of operation.
The device is designed for mounting in 19" racks, it occupies two rack units (RU).
If necessary, install a CEE plug on the power cord of the unit.
First, connect the loads to the terminals on the back of the device. Establish the DMX link to
the controller. Finally, connect the CEE plug of the device to a CEE socket.
Installation and starting up
16
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 17
Connect the DMX input of the device to the DMX output of a DMX controller or other DMX
device. Connect the output of the first DMX device to the input of the second one and so on,
to form a series connection. Make sure that the output of the last DMX device in the chain is
terminated by a resistor (110 Ω, ¼ W).
Connections in ‘DMX’ mode
Installation and starting up
DPX-620III 6 Channel Dimmer S
17
dimmer pack
Page 18
5 Connections and controls
Front panel
Connections and controls
18
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 19
1 Display
2 [1]…[6]
Voltage indicators of channels 1…6.
The LEDs of active channels light solid green during operation.
3 [DMX]
The control LED lights when a DMX signal is received.
4 [CH 1] … [CH 6]
Buttons for direct control of channels 1…6.
5 [MENU]: Opens the main menu.
6 [UP] / [DOWN]: Navigates within a menu, increases or decreases the displayed value.
7 [ESC]: Closes an opened menu.
8 [1]…[6]
Circuit breakers for channels 1…6, arranged in three blocks.
With the circuit breakers, the desired channels are being activated ([I - ON]) or deactivated ([O - OFF]).
Connections and controls
DPX-620III 6 Channel Dimmer S
19
dimmer pack
Page 20
Rear panel
Connections and controls
20
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 21
9 Power cord for 5-pin CEE plug (40 A / phase, 3 × 230 V)
10 Dimmer outlets, designed as shockproof sockets.
11 [DMX OUT]
DMX output
12 [DMX IN]
DMX input.
13 [ANALOG]
Connections to control the device by a voltage in the range 0 V … 10 V.
Connections and controls
DPX-620III 6 Channel Dimmer S
21
dimmer pack
Page 22
6 Operating
As soon as you connect the device to the voltage supply, the display shows the current software version, then a bar graph with the brightness set for each channel.
Turn on the required channels via the associated circuit breakers (LEDs of active channels light
up green).
Disconnect the device from the power supply to turn it off.
DANGER!
Hazardous voltage
Hazardous voltage may be present at cable ends and screw terminals.
The connection of screw terminals as well as all maintenance and repair work on
the electrical installation of the device must only be performed by qualified electrical personnel in volt-free condition. Failure to do so may result in electric shock
and risk of fire and loss of life.
By all means you have to observe all electrical safety instructions applicable at the
place of operation.
Turning on and off
Operating
22
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 23
Press one of the channel buttons [CH 1] … [CH 6] to change the brightness. Pressing briefly
results in changes with small increments, press longer for changes with larger increments.
Press [ESC] to reverse the direction of change.
Press one of the channel buttons [UP] or [DOWN] to increase or decrease the brightness of all
channels together. Pressing briefly results in changes with small increments, press longer for
changes with larger increments.
Adjusting the brightness of an
individual channel
Setting the brightness for all
channels
Operating
DPX-620III 6 Channel Dimmer S
23
dimmer pack
Page 24
Proceed as follows to assign DMX addresses to the dimmer channels:
1. Press [MENU] to open the main menu. Press [UP] or [DOWN] to select the ‘Patching’
menu.
2. Confirm with [MENU].
ð
The display shows ‘Patching Start’ .
3. Use [UP] or [DOWN] to select between assignment mode ‘Start’ (channels are automati-
cally addressed consecutively) and ‘Independent’ (DMX addresses are independent of
each other).
Confirm with [MENU].
4. In ‘Start’ mode: Use [UP] or [DOWN] to select the DMX address of channel 1 in a rage 1 …
512.
Confirm with [MENU].
5. In ‘Independent’ mode: Use [UP] or [DOWN] to select between ‘All’ (all channels get the
same DMX address) and ‘Single’ (each channel can get an individual DMX address).
In ‘Independent – All’ mode: Use [UP] or [DOWN] to select the DMX address for all chan-
nels in a rage 1 … 512. Confirm with [MENU].
Assigning a DMX address
(patching)
Operating
24
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 25
In ‘Independent – Single’ mode: Use [UP] or [DOWN] to first select the channel whose
DMX address is to be set. Confirm with ‘MENU’ . Then select the DMX address for this
channel from a range 1 … 512. Confirm with [MENU] and repeat the procedure for all
channels.
6. Press [ESC] to return to the main menu.
Operating
DPX-620III 6 Channel Dimmer S
25
dimmer pack
Page 26
Proceed as follows to specify how the unit behaves when the DMX signal is missing.
1. Press [MENU] to open the main menu. Press [UP] or [DOWN] to select the ‘DMX Fail’
menu.
2. Confirm with [MENU].
ð
The display shows ‘Dmx fail’ .
3. Use [UP] or [DOWN] to select between options
n ‘LastHold’ : Last setting is retained
n
‘Analog’ : The analogue control signal (input [ANALOG]) is analysed
n
‘Progr:01-12’ : The built-in automatic programmes are executed
Confirm with [MENU].
4. In ‘Progr:01-12’ mode: Use [UP] or [DOWN] to select the duration of each step (and thus
the programme speed) in the range 0.005 s … 30.0 s.
5. Press [ESC] to return to the main menu.
Device behaviour on missing
DMX signal.
Operating
26
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 27
Proceed as follows to set the maximum brightness for the dimmer channels:
1. Press [MENU] to open the main menu. Press [UP] or [DOWN] to select the ‘MaxLevel’
menu.
2. Confirm with [MENU].
ð
The display shows ‘MaxLevel’ .
3. Use [UP] or [DOWN] to select between ‘All’ (all channels get the same maximum bright-
ness) and ‘Single’ (each channel can get an individual maximum brightness).
Confirm with [MENU].
4. In ‘All’ mode: Use [UP] or [DOWN] to select the maximum brightness for all channels in a
rage 70 % … 100 %. Confirm with [MENU].
In ‘Independent – Single’ mode: Use [UP] or [DOWN] to first select the channel whose
maximum brightness is to be set. Confirm with ‘MENU’ . Then select the maximum
brightness for this channel from a range 70 % … 100 %. Confirm with [MENU] and repeat
the procedure for all channels.
5. Press [ESC] to return to the main menu.
Setting maximum brightness
Operating
DPX-620III 6 Channel Dimmer S
27
dimmer pack
Page 28
Proceed as follows to set the minimum brightness for the dimmer channels:
1. Press [MENU] to open the main menu. Press [UP] or [DOWN] to select the ‘MinLevel’
menu.
2. Confirm with [MENU].
ð
The display shows ‘MinLevel’ .
3. Use [UP] or [DOWN] to select between ‘All’ (all channels get the same minimum bright-
ness) and ‘Single’ (each channel can get an individual minimum brightness).
Confirm with [MENU].
4. In ‘All’ mode: Use [UP] or [DOWN] to select the minimum brightness for all channels in a
rage 0 % … 30 %. Confirm with [MENU].
In ‘Single’ mode: Use [UP] or [DOWN] to first select the channel whose minimum bright-
ness is to be set. Confirm with ‘MENU’ . Then select the minimum brightness for this
channel from a range 0 % … 30 %. Confirm with [MENU] and repeat the procedure for all
channels.
5. Press [ESC] to return to the main menu.
Setting minimum brightness
Operating
28
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 29
Proceed as follows to adjust the dimmer curve of the dimmer channels:
1. Press [MENU] to open the main menu. Press [UP] or [DOWN] to select the ‘Curve’ menu.
2. Confirm with [MENU].
ð
The display shows ‘Curve’ .
3. Use [UP] or [DOWN] to select between ‘All’ (all channels get the same dimmer curve) and
‘Single’ (each channel can get an individual dimmer curve).
Confirm with [MENU].
4. In ‘All’ mode: Use [UP] or [DOWN] to select the dimmer curve from the options:
n ‘Linear’
n
‘S Curve’
n
‘Non Dim’
n
‘Square’
Confirm with [MENU].
In ‘Single’ mode: Use [UP] or [DOWN] to first select the channel whose dimmer curve is to
be set. Confirm with ‘MENU’ . Then select the dimmer curve for this channel from the
options:
n ‘Linear’
Setting the dimmer curve
Operating
DPX-620III 6 Channel Dimmer S
29
dimmer pack
Page 30
n ‘S Curve’
n
‘Non Dim’
n
‘Square’
Confirm with [MENU] and repeat the procedure for all channels.
5. Press [ESC] to return to the main menu.
Operating
30
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 31
Menu overview
Operating
DPX-620III 6 Channel Dimmer S
31
dimmer pack
Page 32
7 Technical specifications
Operating supply voltage
One-phase: 230 V 50 Hz
Three-phase: 400 V 50 Hz
Output current One-phase: max. 16 A / channel, 96 A (total)
Three-phase: max. 16 A / channel, 32 A (per phase)
Channel fuse 1 × circuit breaker per channel, each 16 A
Signal input DMX 512 via 3-pin XLR socket
Outputs 6 outlets
Dimensions (W × H × D) 483 mm × 90 mm × 390 mm
Weight 8.6 kg
Technical specifications
32
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 33
8 Plug and connection assignments
This chapter will help you select the right cables and plugs to connect your valuable equipment so that a perfect light experience is guaranteed.
Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug
fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a
short circuit or ‘just’ a not working light show!
The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please
refer to the drawing and table below for the pin assignment of a suitable XLR plug.
Pin Configuration
1 Ground, shielding
2 Signal inverted (DMX–, ‘cold signal’)
3 Signal (DMX+, ‘hot signal’)
Introduction
DMX connections
Plug and connection assignments
DPX-620III 6 Channel Dimmer S
33
dimmer pack
Page 34
9 Protecting the environment
For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that
they are collected for recycling. Please follow the notes and markings on the packaging.
This product is subject to the European Waste Electrical and Electronic Equipment Directive
(WEEE) in its currently valid version. Do not dispose with your normal household waste.
Dispose of this device through an approved waste disposal firm or through your local waste
facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
Disposal of the packaging material
Disposal of your old device
Protecting the environment
34
DPX-620III 6 Channel Dimmer S
dimmer pack
Page 35
Page 36
Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de
Loading...
