DPX-620OPERATIONMANUAL
GENERAL
TECHNICALSPECIFICATIONS
Thismodelisa6channeldimmerpack,hasavarietyoffunctions,includingDMX,
ANALOGandMANUALcontrolmodes,Dimming,Preheatcontrol,overheatandoverloadprotection,andDMX512addressallowingtosimultaneouslycontrol6channeloutput.
1.Powerinput:
AC230V~50-60Hz()
AC220V~50-60Hz()
2.Poweroutput:10Aperchannelmax.Total60Amax.()
20Aperchannelmax.,Total120Amax.()
3.Fuse:20Acircuitbreaker
4.Dimensions:482x370x85mm
5.Weight:7.1Kg
3-phaseorsinglephaseinput
CE
CHINA
CE
CHINA
1.Channelindicator(x6)
Theseindicatorsareturnedonwithoutconnectingload,theyareturnedoffwhenloadiscon-
nected.
2.Circuitbreaker(x6)
Thiscircuitbreakerwillcutoffpowersupplyautomaticallywhenloadcurrentexceeds20A
3.Dipswitch
Theseswitchesaresettoselectinitialchannelsettingmode.
4.PREHEATcontrol
Thiscontroladjusttheinitiallightingpoint.
5.DMXindicator
6.Channeldimmerindicator(x6)
7.Channeldimmercontrol(x6)
Thesecontrolsadjustappropriatechanneldimmerlevel.
8.Powerswitch
9.Powerindicator
PRECAUTIONSBEFOREINSTALLING
1.Fittingconstructionofthisunitisasfollows:
2.Removewiringcover,connectwiresinaccordancewiththismanualorscreenprint
onthetopcover.
CONTROLSANDFUNCTIONS
FRONTPANEL
REARPANEL
Enclosure
Wiringenclosure
Wiringcover
CH2
CH3 CH4
CH5 CH6
OFF
ON
CH1
POWER
PREHEAT
CH1 CH2 CH3 CH4 CH5 CH6
10
0
8
2
6
4
10
0
8
2
6
4
10
0
8
2
6
4
10
0
8
2
6
4
10
0
8
2
6
4
10
0
8
2
6
4
10
0
8
2
6
4
STARTADDRESS
DMXSIGNAL
25%
0
50%
INPARALLEL
1 2 3 45 87 1096
1
2
3
4 5 6
7 8
9
1 2
3 54
24-004-0028
R
Page 2
1.DMXoutputsocket
UsetoconnecttoDMXinputsocketofnextunitforparallelcontrol.
2.DMXinputsocket
UsetoconnecttoDMXinputsignals.
3.ANALOGoutput(8-pindinsocket)
4.ANALOGinput(8-pindinsocket)
5.Outputwiringport(x5)
Usetoconnectto6channeloutput,10Aperchannelmax.,Total60Amax.()
20Aperchannelmax.,Total120Amax.()CECHINA
OPERATION
1.Pleaseconfirmpowerrequirementismatchedwiththatspecifiedonthisunit
2.Setupcorrectwireconnections.(seeconnectionsdiagram).
3.Applytorequiredcontrolsignals.
4.Checkforproperwireconnections,turnpowerswitchon.
5.Allowthesystemtoconnectavailablecontrolsignalsatatime,theprevailingoneshould
controlchanneloutput.IfPREHEATcontrolissettomaximum,channeldimmerlevelshould
be50percentofsettingmaximumdimmer.
6.ReceiveDMXsignals
Primarily,selectinitialchanneltoapplytoDMXsignals.
Setdipswitch10toON,thesystemshouldreceiveonlythefirstchannelDMXsignals
whichsynchronouslycontrol6channeloutput.
Setdipswitch10toOFF,thesystemshouldreceive6channelD MXsignalsandcontrol6
channeloutputinsequence,howDMXindicatorshouldturnon.
7.AppropriateinitialchannelDMXsettingmodeisreferedtofollowingtable:
.
.
.
8.Turnthepowerswitchoff,adjustchannelprogramsetting,andthenturnthepoweron.
9.Receive0-10Vpowerlevelsignals.
ThisunittransmitreceivedlevelsignalstoANALOGoutput,outputsupplyis+20VDC
600mAmax.
WARNING:
1.Thisapparatusmustbeearthed
2.Topreventfireorelectricshockhazard,donotexposethisapparatustorain
ormoisture.
3.Incasecircuitbreakeriscutoffautomatically,checkcorrespondingchannel
tofindwhetherthereisanymalfunction.
4.Toassureventilation,donotblockorstackgoodsneartoopenings.
5.Waitforatleast3secondstoturnonyourunitafteryouhaveturnedoffyourunit.
1 2 3 4 5 6 7 8 9 Initialchannel
0 0 0 0 0 0 0 0 0
0
1 0 0 0 0 0 0 0 0 1
0 1 0 0 0 0 0 0 0 2
1 1 0 0 0 0 0 0 0 3
0 0 1 0 0 0 0 0 0 4
1 1 1 1 1 1 1 1 0 255
0 0 0 0 0 0 0 0 1 256
1 0 0 0 0 0 0 0 1 257
1 1 1 1 1 1 1 1 1 511
LOADING
NNNLNN
CH6 CH4 CH2CH5 CH3 CH1
E
LOADING
SINGLEPHASECONNECTION
CHINA
POWERINPUT:AC230V~50-60Hz
OUTPUT:10Aperchannel,Total60A
POWERINPUT:AC220V~50-60Hz
OUTPUT:20Aperchannel,Total120A
LOADING
N N
N
L1L1L2L2L3
L3
NN
CH6 CH4 CH2CH5 CH3 CH1
E
LOADING
CHINA
POWERINPUT:AC230V~50-60Hz
OUTPUT:10Aperchannel,Total20Aperphase
POWERINPUT:AC220V~50-60Hz
OUTPUT:20Aperchannel,Total40Aperphase
THREE-PHASECONNECTION
