Thank you for purchasing our product. To enjoy the features of this device
and to ensure years of trouble-free operation, please read this manual
carefully and follow the instructions.
SYMPTOM
No picture
or sound.
No picture.
Remote
control
does not
function
properly.
CAUSE
Power cord is not
properly connected.
A/V input cables not
properly connected.
A/V input source is
not properly connected.
A/V signal not present.
Contrast and/or
brightness is set
improperly.
Battery is dead.
Remote is not being used
in direct line of sight with
the player or remote IR
sensor. Transmission is
best within 6/feet/35°
angle of IR sensor on the
monitor.
REMEDY
Check that power
connections are
properly made and all
fuses are in functioning
condition.
Check all cables.
Replace or repair A/V
source(DVD player,
video game, etc.)
Check all cables. If
necessary, replace
A/V source.
Adjust contrast and
brightness levels to
see if picture appears.
Replace battery.
Be sure when being
used, the remote is
being pointed directly
toward the player or
remote IR sensor
(if installed).
1 10
SPECIFICATIONS
Power Requirements
DC 12V
PRECAUTIONS
Please read and observe all warning and instructions in this owner’s manual
and those marked on the unit. Retain this booklet for future reference.
There are two kinds of alarm symbols as follows:
Power Consumption
Screen Size
Screen Format
Resolution Pixel
A/V Inputs
Dimensions
IR Power Requirements
IR Power Consumption
IR Transmitter Frequency A
IR Transmitter Frequency B
LCD Panel Type
Compatible video standard
6W
7 inch LED Backlit TFT LCD
16:9 Wide
800xRGBx480
Two video & one audio inputs
(W)13.5x(D)10.59x(H)5.5inch
DC 12V
3W
A: Right 2.8MHz Left 2.3MHz
B: Right 3.8MHz Left 3.2Mhz
Active Matrix TFT
NTSC/PAL auto select
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his
own expense.
The lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to presence of
“dangerous voltage” within the product’s enclosure that may be
WARNING
CAUTION
Do not try and service these
products yourself. Seek only
a qualified service center or
factory service center.
Be careful not to drop or apply
pressure to the front panel of
your video monitor. If the screen
cracks due to misuse, your
warranty will be void!
Be careful not to overload your
cigarette lighter plug by adding
more than one device at a time.
of sufficient magnitude to constitute a risk of electric shock to
people.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the product.
WARNING
Use extra caution with any liquids
in your car. If you or your child
spills any liquid on these products,
pull your vehicle to the roadside
and turn the key off to disconnect
or wipe the products with a towel. Do not
operate the equipment until all liquids have
either evaporated or you have had the monitor
inspected at a service center by a qualified
technician, Severe harm or danger can occur.
Use only a damp cloth to clean
the screen and use only purified
water on the cloth. Wring out all
excess water prior to wiping the
screen. Do not use any cleaners
or chemicals to clean the screen.
In most cases a dry cloth will do!
9
2
PRECAUTIONS A/V AND POWER CONNECTIONS
Quality installations are best
performed by qualified and
certified installers.
Do not cover heater ducts or vents.
This may cause a fire or an electric
shock.
Check Point
CAUTION
On a towel or soft cloth, gently place the monitor assembly “face down” on a stable
work surface.
Using the wires provided, complete the audio, video and power connections in
your vehicle as shown in the diagram below.
Watching the monitor for an
extended period of time
with the engine turned off
may deplete the vehicle’s
battery.
This product is designed for
operation with a 12 Volt DC,
negative ground vehicle. It
is not suitable for operation
under other conditions or
voltages.
1.The operating temperature of this product is limited to 14°F~140°F
(-10℃~60℃）
2.When your vehicle is extremely hot or cold you must allow time for your air
conditioner or heater to cool or heat the vehicle and for operating temperatures
to return to normal operating ranges. Your monitor will return to its normal
functions when operating ranges are achieved.
3.Optimum picture quality is achieved when you are directly in front of the monitor
(+/-45 degrees).
3 8
(Yellow) Video 1 input
(Yellow) Video 2 input
(Red) Audio right input
(White) Audio left input
(Black) chassis ground
(Red) +12V DC battery
FEATURES AND CONTROLS OSD
1.Power switch
2.V1 switch
3.V2 switch
4.Decrease
5.Menu
6.Increase
7.Mode switch
8.Sys switch
9.Remote sensor
2
BRIGHT
CONTRAST
COLOR
1
7
2
1
2
1
4
3
POWER
Press to turn unit ON or OFF.
A/V SELECT
Use this button to switch between
Video source1 and Video source 2.
6
5
9
8
TINT
SOURCE
ZOOM
ROTATE
ZOOM
LANGUAGE
RESET
IR
3
MENU
3
4
5
This button enables the on-screen
display menu system. Once enabled,
this button is used as an ENTER button.
4
UP/DOWN BUTTONS
This buttons are used to increase
or decrease parameters in the onscreen display menu system.
5
MODE SELECT
This button switch display
ratio between 4:3 and 16:9.
ROTATE Adjustment
47
INSTALLATION
INSTALLATION
ZOOM
1
2
1.Tubes could be adjusted from left and right.
50
50
▲
B
50
ROTATE
50
2.Tubes could be adjusted from front and back.
105mm
5 6
