ACOUSTIC WAVE
| | |
FOR THE BOSE
®
ACOUSTIC WAVE® MUSIC SYSTEM II
®
SOUNDLINK® ADAPTER
Owner’s Guide | Bedienungsanleitung | Guía de usuario | Notice d’utilisation | Manuale di istruzioni
Gebruiksaanwijzing |
Safety Information
Please complete and retain for your records:
Serial Number: _________ _____ ____ ____ ___________
Model Number:_________________________________
Please read this owner’s guide
Please take the time to follow the instruc tions in this owner’s
guide carefully. It will help you set up and operate your
system properly and enjoy all of its advanced features. Please
save this owner’s guide for future reference.
WARNING: To reduce the risk of fire or electrical shock, do not expose the product to rain ormoisture.
WARNING: Do not expose this apparatus to dripping or splashing, anddo not place objects filled with
liquids, such as vases, on or near the apparatus. As with any electronic products, use care not to spill
liquids into any part of the system. Liquids can cause a failure and/or a fire hazard.
The lightning flash with arrowhead symbol within an equilateral triangle alerts the user to the presence of uninsulated dangerous voltage within the system enclosure th at may be ofsufficient magnitude to constitute a risk of electrical shock.
The exclamation point within an equilateral triangle, as marked on the system, is intended to alert the user to the presence of important operating and maintenance instructions in this owner’s guide.
©2011 Bose Corporation. No part of this work may be reproduced, modified, distr i buted, or otherwise used without prior written
permission.
2
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
CAUTION: Make no modifications to the system or accessories. Unauthorized alterations may compromise safety,
regulatory compliance, and system performance and may void the product warranty.
CAUTION: Do not use any liquid cleaning solutions, solvents, chemicals, alcohol, ammonia, or abrasives.
CAUTION: Do not allow liquids to spill into any openings in the enclosure. If liquids get into the unit, turn it off immediately.
Call Bose® Customer Support as soon as possible to arrange for service. See the address list on the inside back cover.
WARNING: Keep the remote control battery away from children. It may cause a fire or chemical burn if mishandled. Do not recharge,
disassemble, heat above 100ºC (212ºF), or incinerate. Dispose of used batteries promptly. Replace only with a battery of the correct
type and model number.
WARNING: Danger of explosion if battery is incorrectly replac ed. Replace on ly with Duracell, Everea dy, Energizer , Maxell, Toshiba,
or Shun Wo CR2032 or DL2032 3-volt lithium battery.
Please dispose of used batteries properly, following any local regulations. Donot incinerate.
WARNING: Do not place any naked flame sources, such as lighted candles, on or near theapparatus.
WARNING: Contains small parts that may be a choking hazard. Not suitable for children under age 3.
Note: The product label is located on the bottom of the product.
Note: Where the mains plug or appliance coupler is used as the disconnect device, such disconnect device shall remain readily
operable.
Note: Operating temperature range: 0 to 35°C.This product is intended for indoor use only.
Note: This product is intended for use only with the power supply provided.
3
This product conforms to all EU Directive requirements as applicable by law. The complete Declaration of Conformity
Names and Contents of Toxic or Hazardous Substances or Elements
Toxic or Hazardous Substances and Elements
Part
Name
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
(CR(VI))
Polybrominated
Biphenyl (PBB)
Polybrominated
diphenylether (PBDE)
PCBs
X0 0 0 0 0
Metal
parts
X0 0 0 0 0
Plastic
parts
00 0 0 0 0
Speakers
X0 0 0 0 0
Cables
X0 0 0 0 0
O: Indicates that this toxic or hazardous substance contained in all of the homogeneo us materials for
this part is below the limit requirement in SJ/T 11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous
materials used for this part is above the limit requirement in SJ/T
11363-2006.
can be found at: www.Bose.com/static/compliance.
For the SoundLink® USB key:
This device complies with FCC and Industry Canada
RF radiation exposure li mits set forth for general population. It must not be co-located in conjun cti on with
any other antenna or transmitter within a host d evice.
This device complies with Part 15 of the FCC Rules,
Operation is subject to the following two conditions:
(1) This device may not cause harmful inter ference,
and (2) this device must accept any interfere nc e
received, including interference that may cause
undesired operation.
In Canada, operation is subject to the following two
conditions: (1) this device may not cause interference
and (2) this device must accept any intervenes,
including interference that may caus e u nd esired
operation of the device.
For the SoundLink® adapter:
T o comply with FCC and Industry Canada RF radiation exposure requirements, this device must be installed to produce a
separation distance of 20 cm from all persons. It must not be co-located or operating in conjunction with any other antenna
or transmitter.
This product complies with the Canadian ICES-003 Class B and RSS-210 specifications.
In the U.S. only , th is product complies with CFR 47 Part 15 specificatio ns.
Additional safety information:
enclosed in the shipping carton.
4
See the additional instructions on the Impo rta nt Safety Instructions sheet (North America only)
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
Contents
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
Product parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting your SoundLink
Using SoundLink
®
with your computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Manually linking the SoundLink
If you don’t hear audio from the Acoustic Wave
Setting your computer’s audio output device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Pairing a Bluetooth
®
Using multiple Bluetooth
®
adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
®
adapter and USB key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
®
devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
®
music system: . . . . . . . . . . . . . . . . . . . . . . . 11
Remote control functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Battery replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Upgrading your Acoustic Wave
®
music system, as needed . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
If your kit includes an adapter power pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Technical information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
SoundLink® USB key for use with computer
SoundLink
®
remote control
(battery installed)
SoundLink
®
adapter
Basic contents
Adapter
power pack
100-240V
Upgrade contents
Upgrade CD
AC Power
cord
Product parts
There are two versions of the SoundLink® kit. The version you chose for your specific
Acoustic Wave
Identify your kit as A or B (below) and follow the instructions that apply.
A. Using a kit with basic contents only
If you have only the basic contents kit
directly below:
Proceed with “Connecting your SoundLink
adapter” on page 7.
6
®
music system determines which steps you follow in making the connections.
B. Using a kit with basic contents and optional upgrade contents
If you have all of the contents shown below:
®
1. Begin with “Upgrading your Acoustic W ave
music system, as needed” on page 19.
2. Pr ocee d with “Connecting your SoundLink
adapter” on page 7.
®
®
Bose link cable
Bose link
connector
SoundLink®
adapter
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
Connecting your SoundLink® adapter
The SoundLink® adapter connects directly to your Acoustic Wave® system.
1. Plug the SoundLink
connector on the rear of the system.
2. Place the adapter in a convenient location. It does not need to be within view.
If the adapter is on the right of the system (as you face it), be sure the two are at least
2 in. (5 cm) apart to eliminate any interference with FM or AMreception.
®
adapter cable (with the words Bose link facing up) into the Bose link
7
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
To locate a USB port on your
computer , look for the i dentifying
symbol.
If you are using a USB hub with
your computer, make sure it is a
powered hub.
USB key
antenna
USB key
power light
and button
USB port
Using SoundLink® with your computer
1. Using the provided SoundLink® remote control, press the SoundLink/CD button 1-2 times until SOUNDLINK appears on the front panel display.
CONNECTING, and DISCOVERABLE will then appear in sequence on the front
panel display.If no text appears, see “Troubleshooting” on page 16.
2. With your computer turned on, lift the antenna on the SoundLink
position and plug the key into a USB port on your computer.
®
USB key to the vertical
8
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
3. Check to be sure the SoundLink® USB key power light turns on and begins to flash.
®
4. Wait for your computer to recognize the SoundLink
the first time.
CONNECTING appears on the Acoustic Wave
and SoundLink
the SoundLink® connection is ready for use.
5. After the connection is made, you may need to set your computer’s audio output device. See page 12.
Note: If PRESS PLAY TO CONNECT appears on the front panel display, try making the
connection manually. See “Manually linking the SoundLink® adapter and USB key” on page 10.
®
adapter flash rapidly. The Acoustic Wave® system emits a brief beep when
USB key. It may take up to 20 seconds
®
system display, and lights on the USB key
Disconnecting the computer
Press the button on the end of the SoundLink
computer USB port.
Reconnecting the computer
Make sure your Acoustic Wave
system display. When you plug the SoundLink® USB key into the USB port on your computer,
it will automatically reconnect to your Acoustic Wave
see “Troubleshooting” on page 16.
®
music system is turned on and COMPUTER appears on the
®
USB key. Then remove the USB key from the
®
system. If you have problems connecting,
9
USB key button
USB key
antenna
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
Manually linking the SoundLink® adapter and USB key
If you are using a replacement USB key, or if you are having trouble pairing your computer with
the SoundLink
1. Using the SoundLink
SOUNDLINK appears on the front panel display.
2. Press and hold the Presets 5 button on the remote control until DISCOVERABLE is
displayed and flashing on the Acoustic Wave
3. With your computer turned on, lift the antenna on
the SoundLink
plug the key into a USB port on your computer.
4. Press and hold the button on the USB key for more than 3 seconds until the light begins to flash.
When the USB power light changes from flashing to
solid and the Acoustic Wave
linking is complete.
COMPUTER appears on the front panel display.
Multi-disc changers
The SoundLink
conjunction with a multi-disc changer because the
Acoustic Wave® music system has only one Bose link
input.
10
®
system, you may need to link the devices manually.
®
adapter cannot be used in
®
remote control, press the SoundLink/CD button 1-2 times until
®
music system display.
®
USB key to the vertical position and
®
system emits a beep,
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
If you don’t hear audio from the Acoustic Wave® music system:
Restart the music application
If you don’t hear music from the Acoustic Wave
USB key, you may need to quit and restart your music application.
Set the audio output device
If you still have no audio from the Acoustic Wave
computer’s audio output device. See page 12 for more information.
®
music system after successfully connecting the
®
music system, you may need to set your
Check the volume controls
For best performance, make sure:
• Your Acoustic Wave
®
music system volume is turned up and the sound is not muted.
• The volume on your computer is turned up and is not muted.
• Your music application is running and the volume is turned up and not muted.
Note: While listening to music from your computer, no sound plays through the computer’s internal
speakers or sound card. On some computers, you can choose a separate audio output for your
music and still hear computer alerts on its internal speakers.
11
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
Setting your computer’s audio output device
Mac users:
1. Go to System Preferences and select Sound Settings.
2. Make sure “Bose SoundLink Audio” is the selected Output device.
PC users (Windows 7):
1. Go to the Control Panel and choose Hardware and Sound.
2. Select Manage Audio Devices.
3. Under the Playback tab, select “Bose SoundLink Audio” and set it as the default.
Note: After setting the audio source, you may need to restart your music application.
Note: See page 23 for computer requirements.
12
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
Pairing a Bluetooth® device
To play music from your phone, tablet, computer, or other Bluetooth device, you will not need
the SoundLink
The Wave
your mobile phone, tablet computer, or other Bluetooth enabled device.
1. Make SoundLink
Using the Wave® SoundLink® remote control, press the SoundLink/CD
button until SOUNDLINK appears on the Acoustic Wave® system display
panel. Press and hold down the Presets 5 button for 5 seconds.
The indicator on the SoundLink
DISCOVERABLE flashes on the Aco ustic Wave
2. Select SoundLink
Turn on your phone, tablet computer, or other device and locate its Bluetooth device list.
Scroll through the device list and select “Bose SoundLink Audio”.
3. Enter Passcode
If prompted for passcode, enter 0000. Some devices ask you to accept the connection.
4. Complete Pairing
The Acoustic Wave
panel when the connection is ready for use.
Note: To pair an additional device (up to 6), repeat steps 2-4 above. Only one device can be used
at a time.
®
USB key and should set it aside for now.
®
SoundLink® adapter can wirelessly connect your Acoustic Wave® music system to
®
Discoverable
®
adapter flashes steadily and
®
from the Device List
®
system emits a brief beep and SOUNDLINK appears on the display
®
system display panel.
13
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
Using multiple Bluetooth devices
If you have paired the Wave® system with more than one Bluetooth device, you can easily switch
between devices by following these tips:
Disconnect one source before connecting another
• To disconnect a Bluetooth device, turn off the device’s Bluetooth feature.
The device will remain in the SoundLink
you turn on the device’s Bluetooth feature. (Be sure the USB key is removed from the
computer before connecting with a Bluetooth device.)
®
Wait for the Wave
When powered on, the Wave
Bluetooth devices in its memory. If you have multiple paired devices, there may be a short delay
while the system searches through the list.
system to find your device
®
system will always search for the USB key first, then each of the
Clearing the memory
Press and hold the Presets 6 button on the remote for 10 seconds until you hear a tone. the
®
Wave
system clears all devices from its memory and returns to Discoverable mode.
14
®
memory and will automatically reconnect when
Remote control functionality
SoundLink/CD
• Press: Selects the audio from your
computer or Bluetooth device, or
the CD player.
• Press again: Switches between
your computer or Bluetooth device,
and the CD player.
Play/Pause*
• Begins music track play.
• Pauses a playing track.
Mute
• Press to silence audio.
• Press again to restore audio.
Volume
• Press: Turns the volume up or down.
• Press and hold: Adjusts the volume
faster.
*May not work with Internet radio and some music applications.
Seek/Track*
• Press: Skips to the previous or next
CD track or music track.
• Press and hold: Scans back or ahead
through the current track.
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
15
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
Battery replacement
WARNING: Keep the remote control battery away from children. It may cause a fire or chemical burn
if mishandled. Do not recharge, disassemble, heat above 212ºF (100ºC), or incinerate. Dispose of a
used battery promptly. Replace only with a battery of the correct type and model number.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with Duracell,
Eveready, Energizer, Maxell, Toshiba, or Shun Wo CR2032 or DL2032 3-volt lithium battery.
Troubleshooting
Problem What to do
Computer and Acoustic
®
Wave
music system do not
connect.
Symptom A:
SOUNDLINK or
COMPUTER do not
appear on the Wave
tem display and no lights
blink.
16
®
sys-
• Press the SoundLink/CD button to turn on the Acoustic Wave
select the computer.
• Make sure the SoundLink
tem.
•Unplug the Wave
• If you received an upgrade CD with your kit and have not used it, be sure
to run it now.
• If problem persists, contact Bose Customer Service. Refer to the address
list included in the carton.
®
adapter is connected to the Acoustic Wave® sys-
®
system for 30 seconds and plug it back in.
®
system and
Problem What to do
Symptom B:
The Wave
reads NO SIGNAL and
PRESS PLAY TO
CONNECT
No sound when the
computer music plays.
®
system display
• Make sure the USB key is plugged in and your computer is turned on.
• Decrease the distance between the Acoustic Wave
computer. See “Connection range” on page 22.
• Move the Acoustic Wave
ence such as another wireless device, microwave oven, or wireless network
router.
• If you are using a desktop computer, try moving the USB key to a port that
provides a more direct path to the adapter. Or use a USB extension cable,
available for purchase at computer stores.
• Remove the USB key from computer, wait 30 seconds and insert it again.
• Unplug the Acoustic Wave
• Try making the connection manually. Refer to “Manually linking the
SoundLink
• Press the SoundLink/CD
computer as the source. COMPUTER should be displayed.
• Make sure your Acoustic Wave
is not muted.
• Make sure the volume on your computer is turned up and is not muted.
• Make sure your music application is running and the volume is turned up
and not muted.
• Check your computer sound settings to make sure “Bose SoundLink Audio”
is selected as the audio output device. Refer to page 12.
• Close or quit the music application on your computer and restart it.
• Restar t your computer.
®
adapter and USB key” on page 10.
®
button on the SoundLink
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
®
system and your
system away from possible sources of interfer-
®
system for 30 seconds and plug it back in.
®
remote to select your
®
system volume is turned up and the sound
17
Problem What to do
Computer does not recognize the SoundLink
key (in its list of
connected devices).
Reception of sound from
the computer is poor or the
sound is dropping out.
18
®
USB
• Remove the SoundLink
insert it again.
• If you are using a USB hub, make sure the hub is powered.
• Try a different USB port. If you are using a powered USB hub, try moving the
SoundLink
• Remove the SoundLink
key again.
• Check your computer sound settings to make sure “Bose SoundLink Audio”
is selected as the audio output device. Refer to page 12.
• Refer to the owner ’s guide, help system, or technical suppor t for your computer to learn how to detect and install new hardware.
®
USB key to a USB port on the computer.
• Move the SoundLink
• Change the angle of the antenna on the SoundLink
• Decrease the distance between the Acoustic Wave
computer. See “Connection range” on page 22.
• Try moving the Acoustic Wave® system away from possible sources of
interference such as another wireless device, a microwave oven, or
wireless computer network router.
• Use a USB extension cable, available for purchase at computer stores. Plug
the USB key into the appropriate end of the cable and the computer into the
other end.
• Close other applications that can tax your computer memory.
• If you continue to experience reception problems, contact Bose
Customer Service. Refer to the address list included in the carton.
®
®
®
adapter farther from the Acoustic Wave® system.
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
USB key from your computer, wait 30 seconds, and
USB key, restart your computer, and insert the USB
®
USB key.
®
system and your
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
Problem What to do
Play/Pause and Seek
buttons do not control
music on the computer.
• Make sure your computer media player or Internet radio application is
selected as the active window.
Note: Not all players and Internet radio services support this form of playback
control.
Upgrading your Acoustic Wave® music system, as needed
If your kit includes an upgrade CD, it is important to use the CD before making any SoundLink®
kit connections.
Follow this procedure:
1. Make sure your Acoustic Wave
ready to use. For detailed instructions, refer to the Bose
guide that came with the system.
2. Insert the update CD, label side up, into the disc drive on the
Acoustic Wave
The update process begins automatically and UPDATING appears
on the Acoustic Wave
3. When UPDATE COMPLETED appears on the display, lift the CD player lid and remove the disc.
®
system.
®
Your system is now compatible with the SoundLink
®
music system is plugged in and
system display.
®
owner’s
®
adapter.
19
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
Adapter
power
pack
SOUNDLINK POWER
CABLE UNPLUGGED
scrolls across the Acoustic
Wave
®
music system display if
the required power pack is not
connected when you press
the SoundLink/CD button.
AC
power
cord
DC power
connector
If your kit includes an adapter power pack
1. On the rear of the SoundLink® adapter, insert the adapter power pack plug into the DC power connector.
2. Connect the AC power cord into the adapter power pack.
3. Plug the AC power cord into an AC (mains) outlet.
20
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
Customer service
For additional help in solving problems, see notes about the product at: Owners.Bose.com.
To contact Bose Customer Service for help, or to replace a lost remote control, see the phone
numbers on the inside the back cover of your Acoustic Wave
all servicing to qualified service personnel. Refer to the contact information listed on the inside
back cover of your Acoustic Wave
®
music system owner's guide.
®
music system owner’ s guide. Re fer
Limited warranty
Your Bose® SoundLink® kit is covered by a limited warranty. Details of the limited warranty are
provided on the product registration card that is included in the carton. Please complete the
information section on the card and mail it to Bose. Failure to do so will not affect your limited
warranty rights.
What you must do to obtain Limited Warranty Service:
Return product, with proof of purchase from an authorized Bose dealer, using the following
procedures:
1. Contact the Bose organization in your country/region (visit Global.Bose.com for Bose contact information in your country/region) for specific return and shipping instructions;
2. Label and ship the product, freight prepaid, to the address provided by the Bose organization in your country; and
3. Place any necessary return authorization number prominently on the outside of the carton. Cartons not bearing a return authorization number, where required, will be refused.
21
Tab 3, 11Tab 8, 16 Tab 7, 15 Tab 6, 14 Tab 5, 13 Tab 4, 12 EnglishTab2, 10
Technical information
Adapter power rating
100-240VAC, 50-60 Hz, Output: 5VDC, 500mA
Connection range
Wireless capability covers a range of up to 60ft. (18.5 m), which can vary according to the type
of home construction and signal obstructions (multiple walls, metal appliance, etc.). It can also
be affected by the presence of other wireless devices (such as network routers or microwave
ovens).
Dimensions
SoundLink
(9.1 cm H x 7.6 cm D x
Weight
SoundLink
(150 gm. +/– 10 gm.)
Computer requirements
Compatible with computers running Windows XP or Vista systems or MAC OSX (10.4 or later).
Requires use of a USB port on a computer ora powered USB hub connected to the computer.
22
®
adapter: 3.6" H x 2.6" D x 1" W
2.3 cm W)
®
adapter: 0.33 lb.
Tab 6, 14English Tab 2, 10 Tab 3, 11 Tab 4, 12 Tab 5, 13 Tab 8, 16Tab 7, 15
Bose® system requirement Exclusive use of the Bose link connector on the rear of the Acoustic Wave Bluetooth QD ID
SoundLink
SoundLink
The Bluetooth
and any use of such marks by Bose Corporation is under license.
®
USB key: B015403
®
Adapter: B015665
®
word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
®
music system.
23
| | |
©2011 Bose Corporation, The Mountain,
Framingham, MA 01701-9168 USA
AM323699 Rev.01
Loading...
