BOSCH WTG86400UC User Manual
en-us Use and Care Manual, Installation Instructions
Dryer
WTG86400UC
Welcome to Your New Dryer!
Congratulations on your selection of a new Bosch dryer
for your laundry needs. We are confident you will enjoy the
superior performance and reliability.
Please do not hesitate to contact our Customer Service
department if you have any questions or comments about
your new dryer.
Thank you for choosing Bosch.
Visit our web site at www.bosch-home.com for more
information and to view a selection of our products.
2
Table of contents
en-us Use and Care Manual, Installation Instructions
Important information ................................................... 4
Purchase information ........................................................... 4
Customer service ................................................................. 4
Your dryer is intended for ............................................. 5
Importance and meaning of symbols .......................... 5
IMPORTANT SAFETY INSTRUCTIONS ........................ 6
Introduction to your new dryer ..................................... 7
Standard features and helpful information ...................... 7
Special features .................................................................... 7
Environmentally friendly use of your dryer ...................... 7
Dimensions and clearances required .......................... 8
Installation for best performance ....................................... 8
Appliance dimensions ......................................................... 8
Length of power cord and drain hose .............................. 8
Minimum clearances ............................................................ 9
Installation Instructions .............................................. 10
Introduction ......................................................................... 10
Before installing the dryer ................................................ 11
Waste disposal .................................................................. 11
Parts provided with your dryer ........................................ 11
Accessories for your appliance ...................................... 12
Installation - step by step ................................................. 12
Electrical Connections ...................................................... 14
Leveling the dryer .............................................................. 15
Check heating system ...................................................... 16
Preparing to transport the dryer - step by step ........... 16
Getting to know your appliance ................................. 17
Control panel ...................................................................... 17
Operating Instructions ................................................ 18
Your new dryer ................................................................... 18
Before using the dryer for the first time ....................... 19
Temporary disconnection of the dryer .......................... 19
Using the program selector to choose a drying cycle 20
Program selection ............................................................. 20
Selecting program settings and additional options .... 20
Loading the laundry .......................................................... 21
Starting the program ......................................................... 21
Indicator of program sequence ...................................... 22
Childproof lock .................................................................. 22
Selecting a different program ......................................... 22
Cancel program ................................................................. 22
Program end ...................................................................... 22
Removing laundry/switching the appliance off ........... 22
Signal ............................................................................ 22
Laundry ........................................................................ 23
Preparing the laundry ....................................................... 23
Sorting the laundry ............................................................ 23
Drying tips ........................................................................... 23
Program selection table ............................................. 24
Default Program and Option settings ....................... 25
Dry Level ............................................................................. 25
Time Dry .............................................................................. 25
Finish in ............................................................................... 25
Additional Program Option settings .......................... 25
Wrinkle Block ..................................................................... 25
Low Heat ............................................................................. 25
Spin speed ................................................................... 25
Cleaning and care ....................................................... 26
Cleaning the housing and control panel ...................... 26
Cleaning the lint filter ........................................................ 26
Cleaning the heat exchanger .......................................... 27
Cleaning the moisture sensors ...................................... 28
Cleaning the lint filter area .............................................. 28
Maintenance of drain hose ............................................. 28
Troubleshooting .......................................................... 29
Introduction ........................................................................ 29
General Troubleshooting ................................................. 29
STATEMENT OF LIMITED PRODUCT WARRANTY ... 31
Bosch Clothes Dryer ........................................................ 31
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com
4XHVWLRQV"
ZZZERVFKKRPHFRP
0DLQ6WUHHW6XLWH
,UYLQH&$
:HORRNIRUZDUGWRKHDULQJIURP\RX
3
Important information
Purchase information
Please take a moment to record the following basic
information about the purchase of your new Bosch dryer.
This information will be helpful in the event you need to
contact Customer Service or would like to order
accessories or replacement parts for your dryer.
(1U
The E-Nr. (model number) and the FD (serial) number
are found on the rating plate label.
The model number includes the slash and a two digit
number (eg: "/01"). Please be sure to include the final 2
digit number when filling in your model number. This
helps make sure any parts you may need are correctly
matched to your specific machine.
Date of Purchase:___/___/_____
Where Purchased:___________________________
E-Nr. :_______________/____ (ex: WTG86402UC/01)
FD :__________-_________ (ex: FD 9304|90007,
provides production date)
The manufacturer reserves the right to make changes in
the product or manual without notification.
)'
(1U
)'
Customer service
Your dryer does not require any special care other than
the maintenance and care mentioned in this manual. If
you have a problem with your dryer, please consult
~ Troubleshooting; Page 29.
This may save you money. If a technician comes out to
advise you of information that is in the Troubleshooting
table you may be charged, even if your dryer is still under
warranty.
If problems persist and service becomes necessary,
contact your dealer, installer or an authorized service
center. Do not attempt to repair the appliance yourself.
Any work performed by unauthorized personnel may void
the warranty.
If you are having a problem with your dryer and are not
pleased with the service you have received, please follow
these steps:
1.
Contact your installer or the Authorized Service Provider in your area and explain to them why you are not satisfied. This will usually correct the problem.
2.
If after working with your installer or service technician the problem still has not been resolved to your satisfaction, please let us know either by writing to us at:
BSH Home Appliances
1901 Main Street, Suite 600
Irvine, CA 92614
or calling us at:
1-800-944-2904
When writing or calling please have the following
information available:
▯ E-Nr. (model number, example: WTG86402UC/01)
▯ FD (serial number, example: 9304|90007)
▯ Date of Original Purchase (receipt required)
▯ Date Problem Occurred
▯ Explanation of Problem
If writing, please also include a daytime telephone
number and a copy of the sales invoice.
When calling Customer Service, please be ready to
provide the model number E-Nr. and FD number. This
information will help provide the best support for your
dryer.
Additional information is available at our website:
www.bosch-home.com
4
Your dryer is intended for
▯ Only household use and in a non-commercial
environment.
▯ Household use only for drying washable textiles.
▯ Children must not do any laundry without supervision.
▯ Keep pets away from the dryer.
▯ Recommended operating conditions:
▯ Installation by qualified installers.
▯ Installation in accordance with all regulatory
requirements; if in doubt have the appliance installed
by a specialist familiar with these requirements.
Read the use and set-up instructions and all other
information included with the dryer and act accordingly.
Ambient temperature: 41-95°F / 5-35°C
Relative humidity: under 95%
Keep documents for future use.
Importance and meaning of symbols
Important safety information is contained in this manual
and on the warning labels located on your dryer.
Standard symbols and headings are used to identify
areas where you should take precautions to avoid injury
or damage. Please take a moment to become familiar
with each of these symbols and what they mean before
proceeding.
9 WARNING
This indicates that death or serious injuries may
occur as a result of non-observance of this warning.
9 CAUTION
This indicates that minor or moderate injuries may
occur as a result of non-observance of this warning.
NOTICE: This indicates that damage to the appliance or property may occur as a result of non-observance of this warning.
Tip: This symbol is used to draw the user's attention to important matters.
5
9 IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INS READ AND SAVE THESE INSTRUCTIONS
WARNING
When properly cared for, your new appliance has been
designed to be safe and reliable. Read all instructions
before using the appliance. These precautions will
reduce the risk of burns, electric shock, fire, and injury to
persons. When using laundry appliances, basic safety
precautions must be followed, including those in the
following pages.
Examine the appliance after unpacking it. In the event of
transport damage, do not plug it in.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
SERIOUS INJURY OR DEATH WHEN USING YOUR
DRYER, FOLLOW BASIC PRECAUTIONS INCLUDING
THE FOLLOWING
▯ Bosch dryers are provided with an Use and Care
Manual with Installation Instructions. Read and
understand all instructions before using the dryer.
▯ Do not dry articles that have been previously cleaned,
washed, soaked, or spotted with gasoline, dry cleaning
solvents, other flammable or explosive substances as
they give off vapors that could ignite or explode.
▯ Before the appliance is removed from service or
discarded, remove the door (to the drying
compartment) to prevent children from playing or
hiding inside. Also remove the power cord/plug.
▯ Do not allow anyone to climb, lean or hang on any part
of the dryer including any protruding components such
as the appliance door or a pullout shelf.
▯ Do not reach into the appliance if the drum is moving.
▯ Do not tamper with the controls.
▯ Do not repair or replace any part of the appliance or
attempt any service unless specifically recommended
in the user maintenance instructions or in published
user-repair instructions that you understand and have
the skills to carry out.
▯ Do not use fabric softeners or products to eliminate
static unless recommended by the manufacturer or the
fabric softener or product.
▯ Always unplug the dryer from the power supply before
attempting any service. Disconnect the power cord by
grasping the plug, not the cord.
▯ To reduce the risk of fire, clothes, cleaning rags, mop
heads and the like which have traces of any flammable
substance, such as vegetable oil, cooking oil,
petroleum based oils or distillates, waxes, fats, etc.,
must not be placed in the dryer. These items may
contain some flammable substance(s) even after
washing, which may smoke or catch fire by itself.
▯ Do not place items exposed to cooking oils in your
dryer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a
load to catch fire.
▯ Do not use heat to dry articles containing foam rubber
(may be labeled latex foam) or similarly textured
rubber-like materials or equivalent. Foam rubber
materials can ignite by spontaneous combustion.
▯ Keep flammable materials and vapors, such as
gasoline, away from the dryer.
▯ Clean lint filter before or after each load.
▯ Do not install or store this appliance where it will be
exposed to the weather. Hoses and internal parts may
be damaged if exposed to freezing temperatures.
▯ Do not use the dryer if it has a worn power cord or
loose plug.
▯ The dryer must only be used for its intended purpose.
▯ Always follow the fabric care instructions
recommended by the clothing manufacturer.
▯ Do not operate the dryer if parts are missing or broken.
▯ Do not sit on top of the dryer.
▯ To reduce the risk of fire or electrical shock, DO NOT
use an extension cord or an adapter to connect the
dryer to the electrical power supply.
▯ Use the integrated socket only for listed appliances.
▯ Always check pockets and remove any objects.
Cigarette lighters are particularly hazardous.
▯ Do not operate the dryer if any guards and/or panels
have been removed.
▯ Do not bypass any safety devices.
▯ Do not operate this dryer until you are sure that:
▯ All services connected to the dryer (power, drain,
etc.) have been installed according to the
Installation Instructions.
▯ Installation and grounding are in compliance with all
local regulations and/or other applicable
regulations and requirements.
▯ Failure to install, maintain and/or operate the dryer
according to the manufacturer’s instructions may result
in injury and/or damage.
▯ To avoid floor damage and mold growth, do not let
spills or splashout cause standing water around or
under the appliance.
▯ See the Installation Instructions section in this manual
for grounding requirements.
~ Electrical Connections; Page 14
▯ The IMPORTANT SAFEGUARDS and WARNINGS
presented in this manual do not cover all possible
conditions that may occur. Common sense,
caution and care must be exercised when
installing, maintaining or operating the dryer.
▯ Always contact your dealer, distributor, service agent or
the manufacturer about any problems or conditions
that you do not understand.
▯ Follow the Safety Information in the INSTALLATION
INSTRUCTIONS and the OPERATING INSTRUCTIONS.
6
9 IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
WARNING
WARNINGS FOR CHILDREN
▯ Do not allow children to play on or in the appliance.
Close supervision of children is necessary when the
appliance is used near children.
▯ Make sure to utilize all child lock/safety features of your
appliance, and be sure to turn the appliance Off when
not in use.
▯ Appliances are not intended for use by children,
however when children become old enough to operate
the appliance, it is the responsibility of the parents or
legal guardians to ensure they are instructed in safe
practices by qualified persons.
Introduction to your new dryer
9 WARNING
RISK OF FIRE, ELECTRIC SHOCK OR INJURY
To reduce the risk of fire, electric shock or injury to
persons, read the IMPORTANT SAFETY
INSTRUCTIONS of this manual before installing or
operating this appliance.
~ IMPORTANT SAFETY INSTRUCTIONS; Page 6
▯ Keep all laundry aids (including detergents, bleach,
fabric softeners, etc.) out of the reach of children.
WARNING
STATE OF CALIFORNIA PROPOSITION 65 WARNINGS
This product contains chemicals known to the State of
California to cause cancer, birth defects or other
reproductive harm.
SAVE THESE INSTRUCTIONS!
Keep These Instructions for Future Reference.
In case of change of ownership, manual should be
conveyed with the dryer.
About this manual
These operating and installation instructions apply to
more than one model of dryer. Illustrations used may
show details that differ from your particular model.
Read your user manual. It contains valuable information
about safety, installation and operation of your new
appliance.
This can save you time, make it easier to correctly install
and use your dryer, and improve your overall satisfaction
with your new appliance.
Standard features and helpful information
Thank you for choosing Bosch for your laundry
appliance needs.
Please read and follow the use and care, important
safety instructions and troubleshooting information
contained in this manual. Please retain this manual for
future reference.
~ Troubleshooting; Page 29
This dryer complies with UL 2158 Electric Clothes
Dryers.
Standard features
▯ Sensor controlled auto cycles.
▯ 15.4 lb (7 kg) large drum capacity (for regular cotton
loads).
▯ Large door opening, 180° opening angle.
Quality tested
Each dryer which leaves our factory has undergone a
thorough performance test and is in full working
condition.
Web Site
Visit our web site at www.bosch-home.com for more
information and to view a selection of our products.
Special features
▯ A distinctive feature of your dryer is low energy
consumption.
▯ Bosch dryers feature advanced operation philosophy,
customized drying programs and a solid touch and
feel making them a user-friendly household assistant.
▯ Bosch load sensing feature controls power
consumption for each cycle based on the amount and
type of laundry. This automatic feature optimizes
energy efficiency.
Environmentally friendly use of your dryer
Your new Bosch dryer is designed to use energy in a
highly efficient way to help reduce operating costs,
conserve resources and protect the environment.
To save energy, money and time, Bosch recommends
the following:
▯ Spin the laundry thoroughly
Before drying, spin the laundry thoroughly in the
washing machine. Use the highest possible spin
speed for the type of laundry. Higher spin speeds
reduce the drying time and the energy consumption.
7
▯ Use optimum load
Utilize the maximum amount of laundry for the
appropriate cycle. However, do not exceed
recommended loads.
▯ Clean filter
Clean the lint filter before or after each drying process.
~ Cleaning the lint filter; Page 26
▯ Air inlet on the dryer
Do not cover or allow any articles/items to restrict the
air inlet on the front of the dryer.
▯ Energy-saving mode
The display panel lighting goes out after a few minutes
and Start/Pause flashes. To activate the display, touch
any button.
Energy-saving mode is not activated if a program is
running.
Dimensions and clearances required
Installation for best performance
9 CAUTION
DO NOT INSTALL THE DRYER:
▯ outdoors,
▯ in an environment with dripping water,
▯ near flammable materials,
▯ in rooms which are at risk of frost,
▯ in rooms which may contain gas or other fuels,
▯ on carpets.
The dryer should be installed in an open area with no
restrictions to ambient air for the best drying results.
Space allowances to fully open the door should also be
considered.
Do not operate the dryer at temperatures above 95°F
(35°C) or below 41°F (5°C). Low temperatures affect
the drying process and may prolong the drying times.
The installation surface (floor) must be level and
structurally sound. Using the bubble level and the heightadjustable feet installed on the appliance, level the
appliance side to side and front to back.
Appliance dimensions
E
Label Dimension U.S.
a Width 23.6 60
b Depth (to front of door) 25 63.5
c Height (minimum)
Height (maximum)
d Side clearance
(door open 180°)
e
Depth (door open 90°)
D
H
F
G
Metric
Inches
cm
33.23484.3
86.4
16 40.6
42.9 109
Length of power cord and drain hose
To Left* To Right*
U.S.
Inches
Power Cord 42 106.7 60 152.4
Drain Hose 76 193 55 139.7
* Facing the front of the dryer
8
MetriccmU.S.
Inches
Metric
cm
Minimum clearances
)
Closet: Stacked
(
+
)
*
Label Dimension U.S.
Inches
Metric
cm
E & F are minimum area size!
%
E Top Vent 63 sq. 404 sq.
F Bottom Vent 63 sq. 404 sq.
Vent spacing is actual (not minimum dimensions)
G3794
H2666
J 3 7.6
K 29 73.6
Under counter (Preferred)
&
$
'
Closet: Stand alone (shown) or Side by Side
(
&
.
-
)
$
&
%
Front of the appliance fully open.
No doors or coverings.
Minimum opening dimensions
A 28 in. 71.1 cm
B 23.8 in. 60.5 cm
C 35.5 in. 90.2 cm
$
'
Label Dimension U.S.
Inches
Metric
cm
A Both Sides 0.6 1.5
B Top 6.3 16
C Rear 2.5 6.2
D Front 2.4 6
9
Under counter (Less Desirable)
(
+
If front of the appliance is covered ventilation openings
must be installed.
E & F are minimum area sizes
E 63 sq.in. 404 sq. cm
F 63 sq.in. 404 sq. cm
G & H
actual spacing dimensions for min. open area sizes
G 3 in. 7.6 cm
H 14 in. 35.6 cm
*
)
Installation Instructions
READ AND SAVE THESE INSTRUCTIONS
Introduction
Read these installation instructions completely and
carefully before starting to install your new dryer. The
information contained can save you time and effort and
will help to ensure optimum performance of your new
dryer. Be sure to observe all warnings and cautions.
9 WARNING
RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS
▯ To reduce the risk of fire, electric shock or injury
to persons, read the Important Safety Instructions
at the beginning of this manual before installing
or operating this appliance.
▯ To reduce the risk of severe injury or death, follow
all installation instruction.
▯ Clothes dryer installation must be performed by a
qualified installer, according to these instructions
and according to all local codes.
▯ In addition to the installation and safety
information in this manual, the local water and
electric authorities (services) may have special
requirements that must be followed.
▯ Install the clothes dryer according to the
manufacturer’s instructions and local codes.
9 CAUTION
▯ Dryer is heavy. Do not lift it by yourself, use
additional help and care when lifting and
positioning.
▯ If in doubt, have the appliance installed by an
authorized technican.
▯ Take care to not damage the appliance. Do not
hold on to protruding parts (e.g. door) when
lifting. Do not push against the appliance door
glass due to risk of damage.
▯ Do not install the appliance outdoors or in an
area exposed to freezing condtions.
▯ If freezing conditions exist where appliance is
located all drain water must be removed from
hoses, sumps, pumps, etc.
▯ Hidden surfaces may have sharp edges. During
service use caution when reaching inside the
dryer housing.
These installation instructions are intended for use by
qualified installers. In addition to these instructions, the
installation must comply with:
▯ for the United States - National Electrical Code, ANSI/
NFPA70 - and latest editions of the State and
Municipal and/or local regulations.
▯ for Canada - Canadian Electrical Code C22.1 - and the
latest editions of the Provincial, Municipal and/or local
regulations.
10
Before installing the dryer
:7;;;8&
Unpacking the appliance
9 CAUTION
Remove the appliance packaging carefully to
prevent damage to the surfaces.
After removing the packaging, immediately remove
any objects from the drum.
Check the dryer for transportation damage. Do not
connect the utilities (power or drain) to a dryer which is
visibly damaged. If in doubt, contact your dealer.
Waste disposal
Disposal of Packaging Materials
After unpacking your new appliance dispose of the
protective packaging materials in an environmentally
friendly way. Ask your dealer or inquire with your local
authority regarding currently acceptable means of
disposal.
9 WARNING
WARNINGS FOR CHILDREN
Do not let children play with packaging and
associated parts to avoid risk of choking or
suffocation.
Disposal of Your Old Appliance
Your old appliance can be recycled if it is no longer to be
used. Prior to disposing of your old appliance observe
the following precautions to reduce safety risks.
Parts provided with your dryer
Back side of the dryer
power cord with plug
(
drain hose connected to the dryer
0
elbow to form the hose to fit the drain
8
Dryer drum contents
A literature pack and drain hose pack are shipped in the
dryer drum. Be sure to remove these items before using
the dryer.
9 WARNING
TO AVOID RISK OF INJURY OR DEATH, DO THE FOLLOWING
▯ after unplugging the old appliance, remove the
electric power cord and dispose of properly.
▯ remove the door or permanently disable the door
lock to prevent children from being locked inside.
:7;;;8&
11
