Video | AUTODOME Series Mounts and Accessories
AUTODOME Series Mounts and
Accessories
www.boschsecurity.com
u 24 VAC, 120 VAC, and 230 VAC power supply boxes
u Pendant Wall, Corner, Mast, Roof, and Pipe mounts
The AUTODOME Series cameras represent the latest
advancements in video surveillance technology. The
cameras ship fully assembled in a pendant or an inceiling housing.
Bosch offers a host of mounts, power supplier boxes,
and accessories so you can tailor your installation for a
variety of applications and environments. These items
are sold separately so you purchase only the items you
need; saving you money and simplifying purchases.
System overview
Mounting Options and Support Kits
Bosch offers a series of mounting options and support
kits to tailor your AUTODOME installation to various
environments.
Pendant Mounts
The AUTODOME indoor/outdoor pendant housings can
be connected to an arm, a roof, or to a pipe mount.
Pendant arm mounts are available with a connected
power supply box or as a separate arm with connected
wiring. All pendant arm mounts can be connected to a
corner or mast (pole) adapter, extending the
installation options.
u In-ceiling support kits for suspended ceilings and for
IP54 certification
u Analog and IP Fiber Optic Communication Units
u Rugged polycarbonate and high-resolution acrylic
bubble options
In addition to the arm mounts, Bosch offers a pipe
mount and a roof parapet mount. The pipe mount
allows an AUTODOME pendant housing to be attached
to a 1-1/2 inch (NPS) pipe (user-supplied). The roof
parapet mount is an aluminum pole that secures an
AUTODOME pendant to a roof surface. In addition,
accessories are available to secure the parapet mount
to a flat roof surface.
In-ceiling Support Kits
AUTODOME in-ceiling housings do not require optional
accessories when mounting to drywall ceilings, but
support kits are available for specific installation
needs.
For suspended or drop ceilings, Bosch offers a kit that
provides the necessary support to secure the in-ceiling
housing to a ceiling tile.
Bosch also offers a kit that offers IP54 ingress
protection for in-ceiling installation.
Power Supplies
Bosch offers a variety of stand-alone power supply
boxes that are available without a transformer (for
24 VAC power input) and with either a 120 VAC or a
2 | AUTODOME Series Mounts and Accessories
230 VAC transformer. Each power supply box offers
100 W output and the power supply box enclosures
are NEMA-rated.
Also available are a trim skirt to improve the aesthetics
of the power supply box and a replacement power
supply box cover.
Fiber Optic Kits
The VGA-FIBER-AN (multimode) is an analog, fiber
optic conversion kit for use with 100 and 600 Series
AUTODOMEs. This module is a video transmitter/data
receiver modules designed to be mounted directly into
an AUTODOME power supply box.
The VG4-SFPSCKT is a unique media converter module
for use with 700 and 800 Series AUTODOMEs. This
media converter is designed to accept a wide-range of
10/100 Mbps Small Form-factor Pluggable (SFP)
modules for use with Multimode or Singlemode optical
fiber with LC or SC connectors. The media converter
module along with the SFP module is user-installed
directly into the AUTODOME's power supply box to
provide an integrated fiber optic solution.
Bubbles
Bosch offers a range of bubbles for in-ceiling and
pendant housings.
AUTODOME impact-resistant rugged polycarbonate
bubbles protect your camera from vandalism.
Designed to meet stringent strength standards without
compromising optical clarity, rugged bubbles can
withstand impacts equivalent to a 10 pound (4.5
kilograms) weight dropped from a height of 10 feet (3
meters).
AUTODOME low-impact, high-resolution acrylic
bubbles offer enhanced image clarity.
Both the rugged polycarbonate and the high-resolution
acrylic bubbles are available in clear or tinted versions.
The clear bubble offers maximum sensitivity by
allowing as much light through as possible. The tinted
bubbles offer covertness by making it difficult to see
the direction the camera is looking from the outside.
Cold Weather Accessory
The optional VG4-SHTR-XT extreme temperature kit
allows an AUTODOME 600 outdoor pendant to operate
in temperatures down to -60°C (-76°F), ensuring
reliable operation in even the harshest environments.
Installation/configuration notes
AUTODOME Series cameras are available as fullyassembled pendant or in-ceiling units. These units are
packaged without mounting hardware or accessories
so that you can choose only the parts needed for your
application and environment.
Pendant Mounts
Pendant housings must be mounted to an arm or to a
pipe using one of the options below. Various mounting
accessories are also available to extend these
mounting options to a host of applications.
VG4-A-PA0
VG4-A-PA1 Arm mount with power supply box, 120 VAC
VG4-A-PA2
VGA-PEND-ARM Arm mount with wiring, no power supply box
VG4-A-9543 Pipe mount for a 1-1/2 inch (NPS) pipe
VG4-A-9230
VGA-ROOF-MOUNT Roof mount with parapet only
Arm mount with power supply box, no
transformer
transformer
Arm mount with power supply box, 230 VAC
transformer
Roof mount with parapet and VG4-A-9543 pipe
mount
Pendant Mount Accessories
Accessory Description For Use With
VGA-PENDWPLATE
VG4-A-9541 Mast (Pole) mount
VG4-A-9542
LTC 9230/01
Mounting plate VGA-PEND-ARM
adapter
Corner mount adapter VG4-A-PA0
Flat roof mount adapter VG4-A-9230
VG4-A-PA0
VG4-A-PA1
VG4-A-PA2
VGA-PEND-ARM
VG4-A-PA1
VG4-A-PA2
VGA-PEND-ARM
VGA-ROOF-MOUNT
In-ceiling Support Kits
In-ceiling housings can be mounted to a drywall ceiling
out of the box, but Bosch offers various kits to attach
an in-ceiling housing to a suspended or to a drop
ceiling. Kits are also available to add IP54
environmental protection to these housings.
Support Kit Description For Use With
VGA-IC-SP Bracket for suspended or drop
VJR-A3-SP
ceilings
(AUTODOME 100/600 Series)
Bracket for suspended or drop
ceilings
(AUTODOME 700/800 Series)
VG5-161CT0
VG5-162CT0
VG5-163CT0
VG5-164CT0
VG5-613CCS
VG5-613CTS
VG5-723CCE2
VG5-713CCE2
VG5-825CCEV
3 | AUTODOME Series Mounts and Accessories
VGA-IP54K-IC Gasket kit for IP54 certification
VGA-IP54KIC78
(AUTODOME 100/600 Series)
Gasket kit for IP54 certification
(AUTODOME 700/800 Series)
VG5-161CT0
VG5-162CT0
VG5-163CT0
VG5-164CTO
VG5-613CCS
VG5-613CTS
VG5-723CCE2
VG5-713CCE2
VG5-825CCEV
Power Supply Boxes
Bosch offers power supply boxes for all mounting
options and power supply accessories to enhance the
aesthetics of the boxes.
Power Supply Description For Use With
VG4-A-PSU0 No transformer (24 VAC input),
VG4-A-PSU1 120 VAC transformer, 100 W
VG4-A-PSU2
100 W
230 VAC transformer, 100 W
VGA-PEND-ARM
VG4-A-9543
VG4-A-9230
VGA-ROOFMOUNT
Power Supply Box Accessories
Accessory
VG4-SHTR-XF Extended temperature heater
VG4-MTRN-C
Description For Use With
module
Alternative Protocol
Communications Module
VG5-613-ECS
VG5-614-ECS
VG5-623-ECS
VG5-624-ECS
All
AUTODOME
600 Series
Housings
Bubbles
Bubble Description For Use With
In-ceiling
VGA-BUBBLE-CCLR
VGA-BUBBLE-CTIR Tinted rugged
Pendant
VGA-BUBBLE-PCLR
VGA-BUBBLE-PTIR Tinted rugged
VGA-BUBBLE-PCLA Clear high-
VGA-BUBBLE-PTIA
Notes:
1. Rugged bubbles are made of impact-resistant polycarbonate.
2. High-resolution bubbles are made of low-impact acrylic.
Clear rugged AUTODOME
100/600/700 Series
Clear rugged All AUTODOME Series
pendant housings
resolution
Tinted highresolution
Accessory
VG4-A-TSKIRT Trim skirt VG4-A-PSU0
VGA-SBOX-COVER Replacement power supply
Description For Use With
VG4-A-PSU1
cover
VG4-A-PSU2
Fiber Optic Kits
The fiber optic kits extend the range that the
AUTODOME camera can receive commands and
transmit video and data. Both fiber optic kits are
designed to fit inside an AUTODOME power supply
with all necessary connections.
Kit Description For Use With
VGA-FIBER-AN Analog Multimode Fiber
VG4-SFPSCKT
Optic Kit
Ethernet Media Converter Kit AUTODOME
AUTODOME
100/600 Series
700/800 Series
AUTODOME 600 Series Accessories
These accessories fit inside certain AUTODOME 600
Series housings and extend the AUTODOME’s
installation and usage options.
Technical specifications
Pendant Mounts
Dimensions
Indoor Pendant Mounts1 (W x H x D)
VG4-A-PA0
VG4-A-PA1
VG4-A-PA2
VGA-PEND-ARM
Outdoor Pendant Mounts1 (W x H x D)
VG4-A-PA0
VG4-A-PA1
VG4-A-PA2
VGA-PEND-ARM
Pendant Mount Accessories
VGA-PEND-WPLATE
(W x H)
VG4-A-9541
(W x H x D)
169.5 x 366.4 x 469.1 mm
(6.67 x 14.43 x 18.47 in.)
169.5 x 366.4 x 460.1 mm
(6.67 x 14.43 x 18.12 in.)
224.0 x 366.4 x 549.6 mm
(8.82 x 14.43 x 21.64 in.)
224.0 x 366.4 x 477.6 mm
(8.82 x 14.43 x 18.8 in.)
169.5 x 216.4 mm
(6.67 x 8.52 in.)
175.0 x 183.0 x 58.9 mm
(6.9 x 7.6 x 2.3 in.)
VG4-A-9542
(W x H x D)
219.1 x 236.0 x 216.4 mm
(6.83 x 9.3 x 5.25 in.)
4 | AUTODOME Series Mounts and Accessories
VGA-ROOF-MOUNT
(W x H)
LTC 9230/01
(W x H)
1. Dimensions include the mount and the connected pendant housings.
1,022.4 x 1,190.8 mm
(40.25 x 46.88 in.)
254.0 x 254.0 mm
(10.0 x 10.0 in.)
Power Supplies
Model
VG4-APA0
Input Output
Rating
Camera Heate
24 VAC,
50/60 Hz
24 V @
96 VA
Input
Output Fuses
Fuses
5.0 A 2.0 A 3.15
VG4-APSU0
VG4-APA1
120 VAC,
50/60 Hz
24 V @
96 VA
1.6 A 2.0 A 3.15
VG4-APSU1
VG4-APA2
230 VAC,
50/60 Hz
24 V @
96 VA
0.8 A 2.0 A 3.15
VG4-APSU2
Mechanical
Certifications UL, CE, Plenum Rated
Dimensions (W x H x D),
all models
2
170.0 x 216.4 x 105.0 mm
(6.69 x 8.52 x 4.13 in.)
Construction Material Cast Aluminum
Standard Color
White (RAL9003)
Standard Finish Powder coated, sand finish
2. Dimensions for power supplies include the cover.
Optical Budget 14 dB
Connector One (1) ST connector
Wavelength
850 nm / 1310 nm
(video/data)
VG4-SFPSCKT
Description Fiber Optic Ethernet Media Converter kit.
Requires a small form-factor pluggable (SFP)
module (sold separately).
Data Interface
Ethernet
r
Data Rate 10/100 Mbps
IEEE 802.3 Compliant
A
Full Duplex or Half Duplex Electrical Port
Full Duplex Optical Port
Compatible Receiver
A
Installation Installed inside a VG4-A-PA1, VG4-A-PA2,
CNFE2MC
VG4‑A‑PSU1 or a VG4‑A‑PSU2 power supply
box with supplied mounting hardware
A
SFP Modules
Description
Interchangeable modules available for use
with MMF or SMF optical fiber.
Data Interface Ethernet
Data Rate 10/100 Mbps
IEEE 802.3 Compliant
Mechanical
Dimensions (W x H x D)
• SFP-2 and SFP-3
• SFP-23, SFP-24,
13.5 x 8.5 x 55.5 mm (0.5 x 0.3 x 2.2 in.)
13.5 x 8.5 x 63.8 mm (0.5 x 0.3 x 2.5 in.)
SFP-25, SFP-26
Weight (all SFP modules) 0.23 kg (.05 lb)
Environmental
Operating Temperature –60°C to 50°C (–76°F to 122°F)
Humidity 0% to 100%, condensing
Environmental Protection
IP 66, IK 8 (IEC 62262)
Fiber Optic Kits
VGA-FIBER-AN
Description Multimode Fiber Optic Module
Compatible
LTC 4629 Series
Receiver
Optical Fiber
Compatibility
50/125 µm, 62.5/125 µm, low loss multimode
glass fiber, rated for a minimum system
bandwidth of 20 MHz
Max. Distance 4.0 km (2.5 miles)
Type ConnectorWavelength
(transmit/receive)
SFP-2
SFP-3 SMF Duplex
SFP-2
3
SFP-24SMF Single
SFP-2
5
SFP-26MMF Single
MMF Duplex
LC
LC
SMF Single
SC
SC
MMF Single
SC
SC
1310 nm /
1310 nm
1310 nm /
1310 nm
1310 nm /
1550 nm
1550 nm /
1310 nm
1310 nm /
1550 nm
1550 nm /
1310 nm
Fiber Compatibility
Max.
Distance
2 km
(1.2 miles)
20 km
(12.4 miles)
60 km
(37.3 miles)
60 km
(37.3 miles)
2 km
(1.2 miles)
2 km
(1.2 miles)
5 | AUTODOME Series Mounts and Accessories
Optical Fiber Compatibility,
MMF
Optical Fiber Compatibility,
SMF
Optical Distance
Specifications
50/125 µm MMF. For 50/125 µm
fiber, subtract 4 dB from the specified
optical budget value. Must meet or
exceed fiber standard ITU-T G.651.
8–10/125 µm SMF. Must meet or
exceed fiber standard ITU-T G.652.
Specified transmission distances are
limited to the optical loss of the fiber
and any additional loss introduced by
connectors, splices, and patch panels.
The modules are designed to operate
over the entire optical loss budget
range, so they do not require a
minimum loss in order to operate.
Heating Module
VG4-SHTR-XT Extended temperature heater module extends
temperature range to –60°C (–76°F);
for AUTODOME 600 Series Outdoor Pendants only
1.90
0.75
201.8
7.94
204.3
8.04
77.0
3.03
R
94.1
3.70
176.0
6.93
86.7
3.42
22.6
0.90
299.4
11.79
76.6
3.01
R
188.9
7.44
88.9
3.50
88.9
3.50
10.2
0.40
201.2
7.92
216.4
8.52
469.1
18.47
R
374.8
14.75
188.0
7.40
76.6
3.01
11.0
0.43
160.0
6.30
184.0
7.25
134.6
5.30
1
3
4
6
2
5
mm
in.
216.4
8.52
460.1
18.12
1a
134.6
5.30
(4)
11.0
0.43
160.0
6.30
185.7
7.31
169.5
6.67
366.4
14.43
R
76.6
3.01
2a
3a
6 | AUTODOME Series Mounts and Accessories
Dimensions: Indoor AUTODOMEs with Mounting Options
Indoor System Dimensions
Reference Description
1 Wall Mount – Side with power supply
1a Wall/Mast Mount – Side with VGA-PEND-WPLATE
2 Wall Mount – Front with power supply and trim skirt
2a Wall Mount – Front with power supply
3 Wall Mount – Back with power supply and trim skirt
3a Wall Mount – Back with power supply
4 Pipe Mount
5 In-ceiling Mount – Front
6 In-ceiling Mount – Side
3
6
2
76.6
3.01
R
374.8
14.75
188.0
7.40
134.6
5.30
(4)
11.0
0.43
160.0
6.30
184.0
7.25
175
6.9
193
7.6
5
236
9.3
203
8.0
133.4
5.25
133.4
5.25
219.1
8.63
178
7.0
38
1.5
mm
in.
152.4
6.0
1-1/2 NPT
69.9
2.75
101.6 Typ.
4.0
10.4
8 x 0.41
114.3
4.50 Typ.
228.6
9.0
279.4
11.0
1022.4
40.25
976.1
38.43
88.1
3.47
1190.8
46.88
616
24.25
346.2
13.63
549.6
21.64
235.8
9.28
224.0
8.82
58
2.3
1
22.9
0.90
86.7
3.42
299.4
11.79
224.0
8.82
4
7
8
Ø
11.0
04.3
216.4
8.52
170.0
6.69
134.6
5.30
160.0
6.30
50.8
2.00
105.0
4.13
9
Ø 10.4
0.41
16.0 T
yp.
0.63
111 Typ.
4.37
6.35 Typ.
0.25
279.4
11.00
6.35
0.25
378
14.88
254
10.00
477.6
18.80
216.4
8.52
224.0
8.82
134.6
5.30
160.0
6.30
185.7
7.31
(4)
11.0
0.43
169.5
6.67
366.4
14.43
76.6
3.01
R
1a
2a
3a
7 | AUTODOME Series Mounts and Accessories
Dimensions: Outdoor AUTODOMEs with Mounting Options and Power Supply Box
Outdoor System Dimensions
Reference Description
1 Wall Mount – Side with power supply and trim skirt
1a Wall/Mast Mount – Side with VGA-PEND-WPLATE
2 Wall Mount – Front with power supply and trim skirt
2a Wall Mount – Front with power supply
3 Wall Mount – Back with power supply and trim skirt
3a Wall Mount – Back with power supply
4 Pipe Mount
5 Mast (Pole) Mount Adapter
6 Corner Moun Adaptert
7 Roof Mount
8 Roof Mount Adapter
9 Power Supply for Pipe and Roof Mounts
8 | AUTODOME Series Mounts and Accessories
Ordering information
VG4-A-PA0 Pendant Arm Mount
Pendant arm mount with power supply box for a
AutoDome Series cameras, no transformer, white
Order number VG4-A-PA0
VG4-A-PA1 Pendant Arm Mount with 120 VAC Transformer
Pendant arm mount with power supply box for
AutoDome Series cameras with a 120 VAC
transformer, white
Order number VG4-A-PA1
VG4-A-PA2 Pendant Arm Mount with 230 VAC Transformer
Pendant arm mount with power supply box for
AutoDome Series cameras with a 230 VAC
transformer, white
Order number VG4-A-PA2
VGA-PEND-ARM Pendant Arm with Wiring
Compatible with an AutoDome Series pendant housing
Order number VGA-PEND-ARM
VGA-PEND-WPLATE Mounting Plate
Mounting plate for VGA-PEND-ARM, compatible with
an AutoDome Series camera
Order number VGA-PEND-WPLATE
VGA-ROOF-MOUNT Roof Mount
Roof parapet mount, white
(VG4-A-9543 Pipe Mount Cap required. Available
separately.)
Order number VGA-ROOF-MOUNT
LTC 9230/01 Flat Roof Mount Adapter
For mounting a unit in an upright position on a flat
surface for roof parapet mount VGA-ROOF-MOUNT
Order number LTC 9230/01
VG4-A-9541 Pole Mount Adapter
Pole mount adapter for a for an AutoDome Series
pendant arm or a VEI-30 or NEI-30 Dinion Infrared
Imager, designed for poles with a diameter of
100‑380 mm (4‑15 in.), white
Order number VG4-A-9541
VG4-A-9542 Corner Mount Adapter
Corner mount adapter for an AutoDome Series
pendant arm or a VEI-30 or NEI-30 Dinion Infrared
Imager
Order number VG4-A-9542
VG4-A-9543 Pipe Mount
Pipe mount, white, for an AutoDome Series pendant
housing
Order number VG4-A-9543
VGA-IP54K-IC IP54 In-ceiling Gasket Kit for AutoDome
100/600 Series
Gasket kit for AutoDome 100 and 600 Series
AutoDome In-ceiling mounts required for IP54
environmental rating
Order number VGA-IP54K-IC
VGA-IP54K-IC78 IP54 In-ceiling Gasket Kit for AutoDome
700/800 Series
Gasket kit for AutoDome 700 and 800 Series In-ceiling
mounts required for IP54 environmental rating
Order number VGA-IP54K-IC78
VGA-IC-SP In-ceiling Support Kit for Various Bosch
Dome Cameras
Suspended ceiling support kit for various families of
Bosch dome cameras
Order number VGA-IC-SP
VJR-A3-SP In-ceiling Support Kit for AutoDome 700/800
Series and AutoDome Junior HD
Suspended ceiling support kit for AutoDome 700 and
800 Series and AutoDome Junior HD In-ceiling mounts
Order number VJR-A3-SP
VG4-A-PSU0 24 VAC Power Supply Unit
24 VAC, 100 W, white, for an AutoDome Series camera
Order number VG4-A-PSU0
VG4-A-PSU1 120 VAC Power Supply Unit
120 VAC, 100 W, white, for an AutoDome Series
camera
Order number VG4-A-PSU1
VG4-A-PSU2 230 VAC Power Supply Unit
230 VAC, 100 W, white, for an AutoDome Series
camera
Order number VG4-A-PSU2
VGA-SBOX-COVER Cover for AutoDome Power Supply
Boxes
Order number VGA-SBOX-COVER
VG4-SFIBER-MM Analog Multimode Fiber Optic Kit
Analog multimode video transmitter/data receiver fiber
optic kit
Order number VG4-SFIBER-MM
VGA-FIBER-AN Analog Multimode Fiber Optic Kit
Analog multimode video transmitter/data receiver fiber
optic kit
Order number VGA-FIBER-AN
VG4‑SFPSCKT Fiber Optic Ethernet Media Converter Kit
Ethernet media converter video transmitter/data
receiver fiber optic kit
Order number VG4-SFPSCKT
9 | AUTODOME Series Mounts and Accessories
VG4-A-TSKIRT Trim Skirt for AutoDome Power Supply
Boxes
Trim skirt for the following AutoDome Series power
supply boxes:
VG4-A-PSU0, VG4-A-PSU1, and VG4-A-PSU2
Order number VG4-A-TSKIRT
VG4-SHTR-XT Heating Module
Extended temperature heater module extends
temperature range to –60°C (–76°F) for AutoDome
100 and 600 Series Outdoor Pendants only
Order number VG4-SHTR-XT
VGA-BUBBLE-CCLR Clear Rugged Bubble for an In-ceiling Housing
Impact resistant polycarbonate bubble
Order number VGA-BUBBLE-CCLR
VGA-BUBBLE-CTIR Tinted Rugged Bubble for an In-ceiling Housing
Impact resistant polycarbonate bubble
Order number VGA-BUBBLE-CTIR
VGA-BUBBLE-CCLA Clear High-resolution Bubble for an
In-ceiling Housing
Low-impact acrylic bubble
Order number VGA-BUBBLE-CCLA
VG4-MTRN-C Alternative Protocol Communications
Module
Supports the American Dynamics (AD) Manchester
and the American Dynamics (AD) Sensormatic RS-422
protocols.
Order number VG4-MTRN-C
VGA-BUBBLE-CTIA Tinted High-resolution Bubble for an
In-ceiling Housing
Low-impact acrylic bubble
Order number VGA-BUBBLE-CTIA
VGA-BUBBLE-PCLR Clear Rugged Bubble for a Pendant
Housing
Impact resistant polycarbonate bubble
Order number VGA-BUBBLE-PCLR
VGA-BUBBLE-PTIR Tinted Rugged Bubble for a Pendant
Housing
Impact resistant polycarbonate bubble
Order number VGA-BUBBLE-PTIR
VGA-BUBBLE-PCLA Clear High-resolution Bubble for a
Pendant Housing
Low-impact acrylic bubble
Order number VGA-BUBBLE-PCLA
VGA-BUBBLE-PTIA Tinted High-resolution Bubble for a
Pendant Housing
Low-impact acrylic bubble
Order number VGA-BUBBLE-PTIA
VGA-BUBHD-CCLA Clear HD High-Resolution Acrylic
Bubble for In-Ceiling AUTODOME cameras
Order number VGA-BUBHD-CCLA
VGA-BUBHD-CTIA Tinted HD High-Resolution Acrylic
Bubble for In-Ceiling AUTODOME cameras
Order number VGA-BUBHD-CTIA
10 | AUTODOME Series Mounts and Accessories
Represented by:
Americas: Europe, Middle East, Africa: Asia-Pacific: China: America Latina:
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: +1 800 289 0096
Fax: +1 585 223 9180
security.sales@us.bosch.com
www.boschsecurity.us
Bosch Security Systems B.V.
P.O. Box 80002
5617 BA Eindhoven, The Netherlands
Phone: + 31 40 2577 284
Fax: +31 40 2577 330
emea.securitysystems@bosch.com
www.boschsecurity.com
Robert Bosch (SEA) Pte Ltd, Security
Systems
11 Bishan Street 21
Singapore 573943
Phone: +65 6571 2808
Fax: +65 6571 2699
apr.securitysystems@bosch.com
www.boschsecurity.asia
Bosch (Shanghai) Security Systems Ltd.
201 Building, No. 333 Fuquan Road
North IBP
Changning District, Shanghai
200335 China
Phone +86 21 22181111
Fax: +86 21 22182398
www.boschsecurity.com.cn
Robert Bosch Ltda Security Systems Division
Via Anhanguera, Km 98
CEP 13065-900
Campinas, Sao Paulo, Brazil
Phone: +55 19 2103 2860
Fax: +55 19 2103 2862
latam.boschsecurity@bosch.com
www.boschsecurity.com
© Bosch Security Systems 2013 | Data subject to change without notice
2478531851 | en, V9, 04. Oct 2013
Loading...
