Bosch SMV46NX00G Product spec sheet
Gentle - even to your ear. Our SilencePlus.
●
ExtraDry: extra drying option for difficult-to-dry loads.
●
Silence Plus: pleasantly quiet at 46 dB.
●
Glass 40°C: protective programme for gently cleaning and
drying glasses.
●
VarioFlex-baskets and VarioDrawer: enhanced flexibility
options with more space on all levels.
●
InfoLight: a red infolight on the floor indicates whether the
dishwasher is switched on or off.
Technical Data
Water consumption (l) : 9.5
Construction type : Built-in
Height of removable worktop (mm) : 0
Dimensions of the product (HxWxD) : 815 x 598 x 550
Required niche size for installation (HxWxD) :
815-875 x 600 x 550
Depth with open door 90 degree (mm) : 1150
Adjustable feet : Yes - front only
Maximum adjustability feet (mm) : 60
Adjustable plinth : both horizontal and vertical
Net weight (kg) : 34.812
Gross weight (kg) : 37.0
Connection rating (W) : 2400
Current (A) : 10
Voltage (V) : 220-240
Frequency (Hz) : 50; 60
Length of electrical supply cord (cm) : 175
Plug type : GB plug
Length inlet hose (cm) : 165
Length outlet hose (cm) : 190
EAN code : 4242005170715
Number of place settings : 14
Energy efficiency rating : A++
Energy consumption annual (kWh/annum) - NEW (2010/30/EC) :
266.00
Energy consumption (kWh) : 0.93
Power consumption in left-on mode (W) - NEW (2010/30/EC) :
0.10
Power consumption in off-mode (W) - NEW (2010/30/EC) : 0.10
Water consumption annual (l/annum) - NEW (2010/30/EC) :
2660
Drying performance : A
Reference programme : Eco
Total cycle time of reference programme (min) : 225
Noise level (dB(A) re 1 pW) : 46
Installation type : Full-integrated
'!2E20AF-bhahbf!
Serie | 4, Fully-integrated dishwasher,
60 cm
SMV46NX00G
Optional accessories
SGZ1010 : inlet and outlet hose extention
SMZ5003 : Retractable hinge f. high corpus dimens.
SMZ5005 : Compensating + fixing kit, stainl. steel
SMZ5035 : Decor conversion kit, stainless steel
SMZ5100 : Vario-cutlery basket
SMZ5300 : GlassSecure Tray
1/3
Serie | 4, Fully-integrated dishwasher, 60 cm
SMV46NX00G
Gentle - even to your ear. Our SilencePlus.
Performance
Energy Efficiency Class:A++
-
Capacity: 14 place settings. VarioDrawer on 3rd level
-
Energy consumption in programmeEco50 °C:266 kWhper year,
-
based on 280 standard cleaning cycles using cold water fill
and the consumption of the low power modes. Actual energy
consumption will depend on how the appliance is used.
Water consumption in Eco50programme:2660litres per year,
-
based on 280 standard cleaning cycles
Programme time inEco50programme:225 minutes
-
Arated performance for washing andAfor drying
-
Noise level dB (A) re 1pW:46 dB
-
Noise level (silence programme):not available(A) re 1 pW
-
Energy consumption inEco50programme:0.93 kWh
-
Water consumption inEco50programme:9.5 litres
-
Design features
Push button top edge controls
-
Red Info light,Acoustic end of cycle indicator,Time remaining
-
indicator (min),water inlet indicator
Electronic time delay: 1-24 hours
-
Stainless steel interior
-
Display colour:Red LED indicators
-
LED salt refill indicator,LED rinse aid refill indicator
-
Alternating spray arms
-
Child safety - Childproof door lock
-
Large item spray head,steam protection plate
-
Self-cleaning filter systemwith 3 piece corrugated filter
-
Acoustic end of cycle indicator
-
Front-adjustable rear foot
-
Dimensions (HxWxD):81.5x59.8x55cm
-
Efficiency information relates to the Eco50programme. This
-
programme is suitable for cleaning normally soiled tableware
and is the most efficient programme in terms of combined
energy and water consumption.
Programmes/functions
6programmes:Intensive70 °C,Auto45-65 °C,Eco50 °C,Glass40
-
°C,1 hour65 °C,Quick45 °C
3 special options:VarioSpeed Plus,Hygiene Plus,Extra Dry
-
Special program 1: Machine Care
-
5 temperatures
-
Flexible design elements
VarioFlex basket system
-
VarioDrawer - loading of cutlery on 3rd level
-
3 stage Rackmatic height-adjustable top basket
-
Lower rack handle: BO plastic-middle grey-red
-
2 foldable plate racks in top basket
-
4 foldable plate racks in bottom basket
-
Upper rack cup shelf
-
Innovations and technology
Heat exchanger - Hygienic and efficient drying
-
DosageAssist detergent dispenser
-
Automatic detergent detection
-
ActiveWater hydraulic water system
-
EcoSilence BLDC drive
-
AquaSensor III,Load Sensor
-
AquaMix - Glass protection system
-
AquaStop: Bosch warranty in case of water damage - for
-
the lifetime of the appliance. Please find warranty terms
under https://www.bosch-home.co.uk/customer-service/careprotection-and-parts/additional-warranties
Curved spray arms - Optimum water distribution
-
2/3
