Dishwasher
SM… SB…
[en] User manual
Register your
new device on
MyBosch now and
get free benefits:
bosch-home.com/
welcome
en
Table of contents
Safety...............................................4
General information..........................4
Intended use.....................................4
Restriction on user group.................4
Safe installation ................................5
Safe use ...........................................6
Damaged appliance .........................8
Risk to children ................................9
Safety systems ...............................10
Preventing material damage ........11
Safe installation ..............................11
Safe use .........................................11
Childproof lock1............................12
Door lock........................................12
Environmental protection and
saving energy................................13
Disposing of packaging .................13
Saving energy.................................13
AquaSensor1...................................13
Installation and connection..........13
Scope of supply .............................13
Installing and connecting the ap-
pliance ............................................14
Drainage connection ......................14
Drinking water connection .............14
Electrical connection ......................15
Familiarising yourself with
your appliance...............................16
Appliance .......................................16
Controls ..........................................17
Programmes ..................................19
Information for test institutes ..........20
Additional functions .....................21
Features.........................................21
Top basket .....................................22
Bottom basket ................................23
Cutlery basket ................................23
Cutlery drawer ................................23
Etagere ...........................................24
Folding prongs ...............................25
Small items holder .........................25
Knife shelf.......................................26
Basket heights................................26
Before using for the first time ......27
Performing initial start-up ...............27
Water softening system................27
Overview of water hardness set-
tings................................................27
Setting water softening system ......28
Special salt .....................................28
Switching off water softening
system ............................................28
Regeneration of the water
softening system ............................29
Rinse aid system...........................30
Rinse aid ........................................30
Setting the amount of rinse aid......30
Switching rinse aid system off .......30
Detergent .......................................31
Suitable detergents ........................31
Unsuitable detergents ....................32
Information on detergents ..............32
Adding detergent ...........................32
Tableware ......................................33
Damage to glass and tableware ....33
Arrange tableware ..........................34
Removing tableware.......................35
1
Depending on the appliance specifications
2
Basic operation .............................35
Opening appliance door ................35
en
Switching on the appliance ............35
Setting a programme .....................35
Setting additional functions ............36
Setting timer programming ............36
Starting the programme .................36
Interrupting programme .................36
Terminate programme....................36
Switching off appliance ..................36
Basic settings................................38
Overview of basic settings .............38
Changing basic settings.................38
Cleaning and servicing.................39
Cleaning the tub .............................39
Self-cleaning interior1......................39
Cleaning products ..........................39
Tips on appliance care...................39
Filter system ...................................39
Cleaning spray arms ......................40
Troubleshooting............................42
Appliance safety.............................42
Error code / Fault display / Sig-
nal...................................................42
Washing results..............................44
Information on display panel..........50
Malfunctions ...................................51
Mechanical damage.......................52
Noise ..............................................52
Clean wastewater pump.................53
Technical specifications...............55
Transportation, storage and
disposal .........................................53
Removing the appliance ................53
Protect appliance from frost...........53
Transporting the appliance ............54
Disposing of old appliance ............54
Customer Service..........................54
Product number (E-Nr.) and pro-
duction number (FD) ......................55
AQUA-STOP guarantee1.................55
1
Depending on the appliance specifications
3
en Safety
Safety
Please read the safety information to ensure that you use the appliance safely.
General information
You can find general information about this instruction manual
here.
¡ Read this instruction manual carefully. Only this ensures you will
use the appliance safely and efficiently.
¡ This manual is intended for the user of the appliance.
¡ Follow the safety instructions and warnings.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Check the appliance after unpacking it. Do not connect the ap-
pliance if it has been damaged in transit.
Intended use
Please read the information on intended use to ensure you use
the appliance correctly and safely.
Only use this appliance:
¡ As specified in this instruction manual.
¡ For cleaning household tableware.
¡ In private households and in enclosed spaces in a domestic en-
vironment.
¡ Up to an altitude of max. 4000m above sea level.
Restriction on user group
Avoid risks to children and vulnerable persons.
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Do not let children play with the appliance.
4
Safety en
Cleaning and user maintenance must not be performed by children unless they are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
Safe installation
Follow these safety instructions when installing the appliance.
WARNING‒Risk of injury!
Improper installation may cause injury.
▶
When installing and connecting the appliance, follow the instructions in the manual and installation instructions.
WARNING‒Risk of electric shock!
Improper installation is dangerous.
▶
Connect and operate the appliance only in accordance with
the specifications on the rating plate.
▶
Connect the appliance to a power supply with alternating
current only via a properly installed socket with earthing.
▶
The protective conductor system of the domestic electrical
installation must be properly installed.
▶
Never equip the appliance with an external switching
device, e.g. a timer or remote control.
▶
When the appliance is installed, the mains plug of the
power cord must be freely accessible. If free access is not
possible, an all-pole isolating switch must be installed in the
permanent electrical installation according to the installation
regulations.
▶
When installing the appliance, check that the power cable is
not trapped or damaged.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord and non-approved adapters.
▶
Do not use extension cables or multiple socket strips.
▶
If the power cord is too short, contact Customer Service.
▶
Only use adapters approved by the manufacturer.
5
en Safety
WARNING‒Risk of electric shock!
Cutting through the supply hose or immersing the Aqua-Stop
valve in water is dangerous.
▶
Never immerse the plastic housing in water. The plastic
housing on the supply hose contains an electric valve.
▶
Never cut through the supply hose. The supply hose contains electric power cables.
WARNING‒Risk of injury!
Hinges move when opening and closing the appliance door
and can cause injury.
▶
If built-under or integrable appliances are not in a cavity so
that one side is accessible, the hinge area must be covered
at the side. Covers are available from Customer Service or
specialist outlets.
WARNING‒Risk of tipping!
Improper installation may cause the appliance to tip up.
▶
Only install built-under or integrable appliances under a
continuous worktop that is securely connected to adjacent
cabinets.
WARNING‒Risk of burns!
If the appliance is not installed properly, this may result in
burns.
▶
With free-standing appliances, ensure that they are installed
with the back panel against a wall.
Safe use
Follow these safety instructions when using the appliance.
WARNING‒Risk of serious harm to health!
Failure to comply with safety instructions and directions for
use on packagings of detergent and rinse aid products may
cause serious harm to health.
▶
Follow the safety instructions and directions for use on the
packagings of detergent and rinse aid products.
6
Safety en
WARNING‒Risk of explosion!
¡ Adding solvents to the interior of the appliance may cause ex-
plosions.
▶
Never add solvents to the interior of the appliance.
¡ Highly caustic alkaline or highly acidic cleaning agents in con-
junction with aluminium parts in the interior of the appliance
may cause explosions.
▶
Never use highly caustic alkaline or highly acidic cleaning
agents, in particular commercial or industrial products, e.g.
for the Machine Care programme, in conjunction with aluminium parts.
▶
Do not put any aluminium parts in the interior of the appliance.
WARNING‒Risk of injury!
¡ Leaving the appliance door open may result in injury.
▶
Only open the appliance door to load or unload tableware
in order to prevent accidents, e.g. through tripping.
▶
Do not sit or stand on the appliance door when open.
¡ Knives and utensils with sharp points can cause injuries.
▶
Arrange knives and utensils with sharp points in the cutlery
basket with the points downwards, on the knife shelf or in
the cutlery drawer.
WARNING‒Risk of scalding!
If you open the appliance door while the programme is running, hot water may splash out of the appliance.
▶
Open the appliance door carefully if the programme is still
running.
WARNING‒Risk of tipping!
Overfilling the Baskets may cause the appliance to tip up.
▶
Never overfill the Baskets with free-standing appliances.
WARNING‒Risk of electric shock!
¡ An ingress of moisture can cause an electric shock.
▶
Only use the appliance in enclosed spaces.
▶
Never expose the appliance to intense heat or humidity.
7
en Safety
▶
Do not use steam- or high-pressure cleaners to clean the
appliance.
¡ If the insulation of the power cord is damaged, this is danger-
ous.
▶
Never let the power cord come into contact with hot appliance parts or heat sources.
▶
Never let the power cord come into contact with sharp
points or edges.
▶
Never kink, crush or modify the power cord.
Damaged appliance
Follow the safety instructions if the appliance is damaged.
WARNING‒Risk of electric shock!
¡ If the appliance or the power cord is damaged, this is danger-
ous.
▶
Never operate a damaged appliance.
▶
Never operate an appliance with a cracked or fractured surface.
▶
Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains.
▶
If the appliance or the power cord is damaged, immediately
unplug the power cord or switch off the fuse in the fuse box
and turn off the water tap.
▶
Call Customer Service. →Page54
▶
Repairs to the appliance should only be carried out by
trained specialist staff.
¡ Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out by
trained specialist staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be
replaced with a special connection cable, which is available
from the manufacturer or his Customer Service.
8
Safety en
Risk to children
Follow the safety instructions if there are children in your home.
WARNING‒Risk of suffocation!
¡ Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material.
¡ Children may breathe in or swallow small parts, causing them
to suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
WARNING‒Risk of harm to health!
Children can lock themselves in the appliance, thereby putting
their lives at risk.
▶
With redundant appliances, unplug the power cord. Then
cut through the cord and damage the lock on the appliance
door beyond repair so that the appliance door will no longer
close.
WARNING‒Risk of crushing!
With higher-level appliances, children can become crushed
between the appliance door and cabinet doors underneath.
▶
Keep an eye on children when opening and closing the appliance door.
WARNING‒Risk of chemical burns!
Rinse aid and detergent may cause chemical burns to the
mouth, throat and eyes.
▶
Keep children away from detergent and rinse aid products.
▶
Keep children away from the appliance when open. The water in the interior of the dishwasher is not drinking water. It
may contain residues of detergents and rinse aid.
9
en Safety
WARNING‒Risk of injury!
Children may get their fingers caught in the slots of the tablet
collecting tray and injure themselves.
▶
Keep children away from the appliance when open.
WARNING‒Risk of suffocation!
Children may become trapped in the appliance and suffocate.
▶
Use the childproof lock if fitted.
▶
Never let children play with or operate the appliance.
Safety systems
Protect children from possible hazards resulting from the appliance.
Depending on the features of the model, the appliance comes
with a
→"Childproof lock", Page12.
10
Preventing material damage en
Preventing material damage
Preventing material damage
Follow these instructions to prevent
material damage to your appliance,
accessories or other objects in your
kitchen.
Safe installation
Follow the instructions when installing
the appliance.
ATTENTION!
¡ Improper installation of the appli-
ance may cause damage.
▶
If the dishwasher is installed
above or below other domestic
appliances, follow the information on installation in combination with a dishwasher in the installation instructions for the individual appliances.
▶
If there is no information or if the
installation instructions do not include the relevant information,
contact the manufacturer of
these appliances to check that
the dishwasher can be installed
above or below these appliances.
▶
If no information is available
from the manufacturer, the dishwasher should not be installed
above or below such appliances.
▶
To ensure the safe operation of
all domestic appliances, continue following the installation instructions for the dishwasher.
▶
Do not install the dishwasher under a hob.
▶
Do not install the dishwasher
near heat sources, e.g. radiators, heat storage tanks, ovens
or other appliances that generate heat.
¡ Modified or damaged water hoses
may result in material damage and
damage to the appliance.
▶
Never kink, crush, modify or cut
through water hoses.
▶
Only use the water hoses supplied with the appliance or genuine spare hoses.
▶
Never re-use water hoses that
have been used before.
¡ If the water pressure is too high or
too low, this may impair functioning of the appliance.
▶
Make sure that the water pressure in the water supply system
is min. 50kPa (0,5bar) and
max. 1000kPa (10bar).
▶
If the water pressure exceeds
the maximum value specified, a
pressure-reducing valve must be
installed between the drinking
water connection and the hose
set of the appliance.
Safe use
Follow the instructions when using
the appliance.
ATTENTION!
¡ Escaping water vapour can dam-
age fitted units.
▶
When the programme ends,
leave the appliance to cool
down for a while before opening
the door.
¡ Special salt can damage the tub
due to corrosion.
▶
To make sure that any special
salt that escapes is washed out
of the tub, add the special salt
to the dispenser for special salt
immediately before the programme starts.
¡ Detergent may damage the water
softening system.
▶
Only fill the dispenser of the water softening system with special
dishwasher salt.
11
en Childproof lock
1
2
1
2
¡ Unsuitable cleaning agents may
damage the appliance.
▶
Do not use a steam cleaner.
▶
So as not to scratch the finish
on the appliance, do not use
sponges with a rough surface or
abrasive cleaning agents.
▶
To prevent corrosion, do not use
sponge cloths on dishwashers
with a stainless steel front or
rinse such cloths thoroughly
several times before using them
for the first time.
Childproof lock
Childproof lock
1
The childproof lock lets you protect
children from possible hazards resulting from the appliance.
Depending on the features of the
model, the appliance comes with a
door lock.
Door lock
The door lock is a mechanical safety
system and makes it more difficult to
open the appliance door.
You can activate or deactivate the
door lock.
2. Pull the catch of the childproof
lock forwards and close the appliance door .
Deactivating the door lock
1. Open the appliance door.
2. Push the catch of the childproof
lock to the right and slide it
backwards .
WARNING
Risk of suffocation!
Children may become trapped in the
appliance and thus suffocate.
▶
Activate the door lock and close
the appliance door.
→"Opening appliance door",
Page35
Activating the door lock
Note:The door lock remains activ-
ated until it is deactivated manually.
1. Open the appliance door.
1
12
Depending on the appliance specifications
3. Close the appliance door.
Environmental protection and saving energy en
Environmental protection and saving energy
Environmental protection
and saving energy
Help protect the environment by using your appliance in a way that conserves resources and by disposing of
reusable materials properly.
Disposing of packaging
The packaging materials are environmentally compatible and can be recycled.
▶
Sort the individual components by
type and dispose of them separately.
Information about current disposal
methods are available from your
specialist dealer or local authority.
Saving energy
If you follow these instructions, your
appliance will use less electricity and
less water.
Use the Eco 50° programme.
The Eco 50° programme is energy efficient and environmentally
friendly.
→"Programmes", Page19
If you do not have much tableware to
wash, use the additional Half Load
function.
1
The programme will adjust to a
lower load and consumption will
be reduced.
→"Additional functions", Page21
AquaSensor
1
The AquaSensor is an optical measuring device (light barrier) which
measures the turbidity of the washing
water. You can save water with the
AquaSensor.
Use of the AquaSensor depends on
the programme. If the soiling level is
low, the washing water is used in the
next wash cycle, so reducing water
consumption by 3-6 litres. If the soiling level is is greater, the washing
water is drained off and replaced with
fresh water. In the automatic programmes the temperature and running time are additionally adjusted to
the level of soiling.
Installation and connection
Installation and connection
To ensure proper operation, connect
the appliance to the power and water
supply correctly. Observe the specified criteria and the installation instructions.
Scope of supply
After unpacking all parts, check for
any damage in transit and completeness of the delivery.
If you have any complaints, contact
the dealer who sold you the appliance or our Customer Service.
Note:The appliance was tested at
the factory to check it is in working
order. It is possible that water has left
marks on the appliance. These
marks will disappear after the first
wash cycle.
The delivery consists of the following:
¡ Dishwasher
1
Depending on the appliance specifications
13
en Installation and connection
¡ Instruction manual
¡ Installation instructions
¡ Warranty
¡ Installation material
¡ Steam guard plate
¡ Rubber apron
¡ Mains cable
¡ Quick reference guide
1
1
1
1
Installing and connecting the appliance
You can position your built-under or
integrable appliance in a fitted kitchen between wooden and plastic
walls. If you subsequently install your
dishwasher as a free-standing appliance, you must stop it from tipping
over, e.g. by screwing it to the wall or
installing it under a continuous worktop that is securely connected to adjacent cabinets.
1. Follow the safety instructions.
→Page4
2. Follow the instructions for electrical
connection. →Page15
3. Check the Scope of supply
→Page13 and the condition of
the appliance.
4. Consult the installation instructions
for the installation dimensions required.
5. Make the appliance level using the
height-adjustable feet.
Make sure that the appliance is
standing on the floor securely.
6. Install the drainage connection.
→Page14
7. Install the drinking water connec-
tion. →Page14
8. Connect the appliance to the elec-
tricity supply.
Drainage connection
Connect your appliance to drainage
connection so dirty water is discharged via the wash cycle.
Installing the drainage connection
1. Consult the installation instructions
supplied for the steps required
here.
2. Connect the wastewater hose to
the outlet connection of the siphon
using the enclosed parts.
3. When doing so, check that the
wastewater hose is not kinked,
crushed or twisted.
4. Also check that there is no cover
in the drainage system preventing
the wastewater from being discharged.
Drinking water connection
Connect your appliance to a drinking
water connection.
Installing the drinking water connection
Note:If you are replacing the appli-
ance, you must use a new water supply hose.
1. Consult the installation instructions
supplied for the steps required
here.
2. Connect the appliance to the drink-
ing water connection using the enclosed parts.
Observe the Technical data
→Page55.
3. When doing so, check that the
drinking water connection is not
kinked, crushed or twisted.
1
Depending on the appliance specifications
14
Electrical connection
Connect your appliance to the power
supply.
Connecting the appliance to the electricity supply
Notes
¡ Follow the Safety instructions
→Page5.
¡ Connect the appliance to alternat-
ing current only, in the range of
220 - 240V and 50Hz or 60Hz.
¡ Please note that the water safety
system is only functional if there is
a power supply.
1. Insert the non-heating appliance
plug of the power cable into the
appliance.
2. Insert the mains plug of the appli-
ance into a nearby socket.
The connection data for the appli-
ance can be found on the rating
plate.
3. Check that the mains plug is inser-
ted properly.
Installation and connection en
15
en Familiarising yourself with your appliance
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
Familiarising yourself with your appliance
Familiarising yourself with your appliance
Familiarise yourself with the parts of your appliance.
Appliance
You can find an overview of the parts of your appliance here.
Rating plate Rating plate with E number and FD number
→Page55.
1
Depending on the appliance specifications
16
The data you need for Customer Service →Page54.
Familiarising yourself with your appliance en
2
3
4
5
6
7
8
9
10
11
12
13
14
Detergent dispenser Detergent →Page31 is added to the detergent dis-
penser.
Bottom basket Bottom basket →Page23
Dispenser for special salt Add special salt for the Water softening system
→Page27 to the dispenser for special salt.
Lower spray arm The lower spray arm washes the tableware in the bot-
tom basket.
If the tableware has not been washed properly, clean
the spray arms.
→"Cleaning spray arms", Page40
Tablet collecting tray During the wash cycle tablets automatically fall out of
the detergent dispenser into the tablet collecting tray
where they can fully dissolve.
Top basket Top basket →Page22
Cutlery drawer
EmotionLight
Etagere Etagere →Page24
Upper spray arm The upper spray arm washes the tableware in the top
Filter system Filter system →Page39
Cutlery basket
1
1
1
Cutlery drawer →Page23
Interior lighting of the appliance.
→"Overview of basic settings", Page38
basket.
If the tableware has not been washed properly, clean
the spray arms.
→"Cleaning spray arms", Page40
Cutlery basket →Page23
Dispenser for rinse aid Add rinse aid for the Rinse aid system →Page30 to
1
Depending on the appliance specifications
the dispenser for rinse aid.
Controls
The controls are used to configure all functions of your appliance and to obtain
information about the operating status.
With some buttons you can perform different functions.
17
en Familiarising yourself with your appliance
1 2 3 4 5
78910 6
1
2
3
4
5
6
7
8
9
10
ON/OFF button Switching on the appliance →Page35
Programme selector Programmes →Page19
Start button and reset button Starting the programme →Page36
Display The display shows information about the remain-
Timer programming Setting timer programming →Page36
Additional functions
1
Switching off the appliance →Page36
Terminating the programme →Page36
ing running time or the basic settings. You can
change the basic settings via the display and the
setting buttons.
→"Changing basic settings", Page38
Additional functions →Page21
Water supply display Display for water supply lights up →Page43
1
18
Rinse aid refill indicator Rinse aid system →Page30
Special salt refill indicator Water softening system →Page27
Door opener
Depending on the appliance specifications
1
Opening the appliance door →Page35
Programmes
Programmes
Programmes en
You can find an overview of the programmes that can be selected here.
Different programmes, which can be
found on the control panel of your
appliance, are available depending
on the appliance configuration.
The running time may vary depending on the programme selected. The
running time depends on the water
temperature, the quantity of tableware, the level of soiling and the Ad-
ted. The running time will change if
the rinse aid system is switched off
or rinse aid needs to be added.
The consumption values can be
found in the quick reference guide.
The consumption values relate to
normal conditions and a water hardness of 16-20°°E. Different influencing factors such as water temperature or pipe pressure may result in
deviations.
ditional function →Page21 selec-
Programme Use Programme se-
quence
Intensive 70°
Tableware:
¡ Washing pots and
pans, non-fragile
tableware and cutlery.
Level of soiling:
Intensive:
¡ PreRinse
¡ Cleaning 70°C
¡ Intermediate rinse
¡ Rinsing 69°C
¡ Drying
¡ Removing stubborn
burned or dried-on
food remnants containing starch and
protein.
When using powder detergent, you can also
apply a little to the inside of the appliance
door.
Mix 65°
Tableware:
¡ Cleaning mixed
tableware and cut-
lery.
Level of soiling:
¡ Removing common
Intensive:
¡ Pre Rinse
¡ Cleaning 65°C
¡ Intermediate rinse
¡ Rinsing 69°C
¡ Drying
household food rem-
nants normally to
firmly dried-on.
Additional functions
All
→"Additional functions", Page21
All
→"Additional functions", Page21
19
en Programmes
Programme Use Programme se-
quence
Eco 50°
Tableware:
¡ Cleaning mixed
tableware and cut-
lery.
Level of soiling:
¡ Removing common
household food rem-
Most economical programme:
¡ Pre-Rinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Rinsing 66°C
¡ Drying
nants lightly dried-
on.
Glass 40°
Tableware:
¡ Cleaning delicate
tableware, cutlery,
temperature-sensit-
ive plastics, glasses
and stemware in the
Particularly gentle:
¡ PreRinse
¡ Cleaning 40°C
¡ Intermediate rinse
¡ Rinsing 60°C
¡ Drying
stemware basket.
Level of soiling:
¡ Removing lightly ad-
hering fresh food
remnants.
1 hr Programme
Tableware:
¡ Cleaning mixed
tableware and cut-
lery.
Level of soiling:
Time-optimised:
¡ Cleaning 65°C
¡ Intermediate rinse
¡ Rinsing 70°C
¡ Drying
¡ Removing common
household food rem-
nants lightly dried-
on.
Tableware:
¡ Cleaning all types of
Cold rinse suitable:
¡ Pre-Rinse
tableware.
PreRinse
Level of soiling:
¡ Cold rinsing, inter-
mediate cleaning.
Additional functions
All
→"Additional functions", Page21
IntensiveZone
VarioSpeed
Half Load
ExtraDry
→"Additional functions", Page21
ExtraDry
→"Additional functions", Page21
None
Information for test institutes
Test institutes are provided with information for comparability tests, e.g.
according to EN60436.
These are the conditions for conducting the tests, however they are not
the results or consumption values.
20
E-mail enquiries to: dishwasher@testappliances.com
The product number (E-Nr.) and the
production number (FD) are required
here. They can be found on the rating plate on the appliance door.
Additional functions en
Additional functions
Additional functions
You can find an overview of the additional functions that can be selected
here. Different additional functions,
which can be found on the control
panel of your appliance, are available
depending on the appliance configuration.
Additional function
VarioSpeed
Half Load
Hygiene
Use
¡ The running time is
shortened by 20% to
50% depending on the
washing programme.
¡ Energy and water con-
sumption are increased.
¡ Switch on with small
loads.
¡ It is recommended
adding less detergent
to the detergent dispenser than for a full
machine load.
¡ The running time is
shortened.
¡ Energy and water con-
sumption are reduced.
¡ To ensure a higher hy-
giene status for the appliance and tableware,
the temperature is
raised and maintained
for an extra-lengthy
period.
¡ Especially suitable for
cleaning chopping
boards or baby bottles.
¡ Continuous use of this
function increases the
hygiene status.
¡ This will increase the
running time and energy consumption.
Additional func-
Use
tion
¡ Switch on with mixed
IntensiveZone
loads containing tableware with different soiling levels, e.g. place
very soiled pots and
pans in the bottom basket and normally soiled
tableware in the top
basket.
¡ The spray pressure in
the bottom basket is increased and the maximum programme temperature held longer.
This will increase the
running time and energy consumption.
¡ For a better drying res-
ExtraDry
ult the final rinse temperature is increased
and the drying phase
extended.
¡ Especially suitable for
drying plastic parts.
¡ There is a slight in-
crease in energy consumption and the running time is extended.
Features
Features
You can find an overview of the possible features of your appliance and
how to use them here.
These features depend on the model
of your appliance.
21
en Features
a
Top basket
Arrange cups and glasses in the top
basket.
Knife shelf
1
You can adjust the height of the top
basket to make room for larger items
of tableware.
Adjusting top basket with side levers
To wash large items of tableware in
the baskets, adjust the shelf position
of the top basket.
1. Pull out the top basket.
2. To prevent the basket from sud-
denly dropping down, hold the
side of the basket by the top edge.
3. Press in the levers on the right and
left on the outside of the basket.
The basket can then slip down
slightly.
4. Raise or lower the basket evenly to
the right level.
→"Basket heights", Page26
Check that the basket is level on
both sides.
5. Slide the basket back in.
Adjusting top basket with pairs of rollers
To wash large items of tableware in
the baskets, adjust the shelf position
of the top basket.
1. Pull out the top basket.
2. Remove the basket.
1
Depending on the appliance specifications
22
3. Insert the basket at the right bas-
ket height.
→"Basket heights", Page26
Check that the basket is level on
a
both sides.
4. Slide the basket back in.
Bottom basket
Arrange pans and plates in the bottom basket.
Features en
Cutlery basket
Arrange cutlery in the cutlery basket,
always without sorting it and with the
sharp points downwards.
Cutlery basket
1
Large plates up to a diameter of
31/34cm1 can be arranged as
shown.
1
Depending on the appliance specifications
Cutlery drawer
Arrange cutlery in the cutlery drawer.
23
en Features
1
2
3
Arrange cutlery with the points and
sharp edges downwards.
You can reorganise the cutlery
drawer to make more space for
longer/wider items of cutlery.
Reorganising cutlery drawer
1
1
You can fold down the side shelves
and front prongs to make more
space for longer/wider items of cutlery.
1. To fold down a side shelf, push the
lever forwards and fold down
the side shelf .
2. To fold down the front prongs,
push the lever forwards and fold
down the prongs .
Etagere
Use the etagere and space underneath for small cups and glasses or
for large items of cutlery, e.g.
wooden spoons or serving cutlery.
Tip
If you want to return the cutlery
drawer to the original position, fold
the side shelf back up until it clicks
into position.
1
Depending on the appliance specifications
24
You can adjust the height of the
etagere.
1
If you do not need the etagere, you
can fold it up.
Adjusting etagere
1
You can adjust the height of the
etagere.
1. Position the etagere vertically and
pull it upwards .
Features en
2
3
1
1
2
1
2
2. Position the etagere at a slight
angle and move to the right height
.
3. Push the etagere down.
a The etagere clicks into position.
Folding prongs
Use the folding prongs to position
tableware securely, e.g. plates.
You can fold the prongs down to position pans, bowls and glasses
1
better.
Folding down prongs
If you do not need the prongs, fold
them down.
1. Push the lever forwards and fold
down the prongs .
1
2. To use the folding prongs again,
fold them back up.
a The folding prongs click in posi-
tion.
Small items holder
Use the small items holder to position small items of tableware, e.g.
light plastic parts.
1
Depending on the appliance specifications
25
en Features
Knife shelf
Use the knife shelf for long, sharp objects and long items of cutlery.
Basket heights
Set the baskets at the right height.
Appliance height 81.5cm with cutlery basket
Level Top basket Bottom basket
1 max. ø 22 cm 31 cm
2 max. ø 24.5 cm 27.5 cm
3 max. ø 27 cm 25 cm
Appliance height 81.5cm with cutlery drawer
Level Top basket Bottom basket
1 max. ø 16 cm 31 cm
2 max. ø 18.5 cm 27.5 cm
3 max. ø 21 cm 25 cm
Appliance height 86.5cm with cutlery basket
Level Top basket Bottom basket
1 max. ø 24 cm 34 cm
2 max. ø 26.5 cm 30.5 cm
3 max. ø 29 cm 28 cm
Appliance height 86.5cm with cutlery drawer
Level Top basket Bottom basket
1 max. ø 18 cm 34 cm
2 max. ø 20.5 cm 30.5 cm
3 max. ø 23 cm 28 cm
26
Before using for the first time en
Before using for the first time
Before using for the
first time
4. Set the water softening system.
→Page28
5. Set the amount of rinse aid to be
dispensed. →Page30
Configure the settings for initial startup.
Performing initial start-up
On initial start-up or after a reset to
the factory settings, you will need to
make settings.
Requirement:The appliance has
been installed and connected.
→Page13
1.
Add special salt. →Page28
2.
Add rinse aid. →Page30
3. Switch on the appliance.
→Page35
Tip:You can change these settings
and other Basic settings →Page38
at any time.
Water softening system
Water softening system
Hard water leaves limescale on the
tub and tableware and parts of the
appliance may become blocked.
To ensure good dishwashing results,
you can treat the water with special
salt and the water softening system.
To avoid damage to the appliance,
water with a hardness above 9 °E
must be softened.
Overview of water hardness settings
You can find an overview of the water hardness values that can be selected
here.
You can find out how hard your water is from your local water company or by
using a water hardness tester.
Water hardness °E Hardness range mmol/l Setting value
0 - 8 Soft 0 - 1.1 H:00
9 - 10 Soft 1.2 - 1.4 H:01
11 - 12 Medium 1.5 - 1.8 H:02
13 - 15 Medium 1.9 - 2.1 H:03
16 - 20 Medium 2.2 - 2.9 H:04
21 - 26 Hard 3.0 - 3.7 H:05
27 - 38 Hard 3.8 - 5.4 H:06
39 - 62 Hard 5.5 - 8.9 H:07
Note:Set the water hardness determined on your appliance.
With a water hardness of 0 - 8°E
you can dispense with special salt
and switch off the water softening
system.
27
en Water softening system
a
Setting water softening system
Set the water hardness on your appliance.
1. Determine the water hardness and
the appropriate setting value.
→"Overview of water hardness set-
tings", Page27
2. Press .
3. Press and hold .
4. Turn the programme selector until
the display shows H:04.
5. Release the button.
6. Turn the programme selector until
the required level has been set.
The appliance is set to H:04 at the
factory.
7. Press to save the setting.
Special salt
You can use special salt to soften
water.
Adding special salt
If the special salt refill indicator lights
up, add special salt to the dispenser
for special salt just before the programme starts. The amount of special salt required depends on the water hardness: the higher the water
hardness, the greater the amount of
special salt required.
ATTENTION!
¡ Detergent may damage the water
softening system.
▶
Only fill the dispenser of the water softening system with special
dishwasher salt.
¡ Special salt can damage the tub
due to corrosion.
▶
To make sure that any special
salt that escapes is washed out
of the tub, add the special salt
to the dispenser for special salt
immediately before the programme starts.
1. Unscrew the lid of the dispenser
for special salt and remove.
2. On initial start-up: Fill the dispenser
right up with water.
3. Note:Only use special salt for
dishwashers.
Do not use salt tablets.
Do not use table salt.
Add the special salt to the dispenser.
Funnel
1
Fill the dispenser right up with special salt. The water in the dispenser is displaced and forced
out.
4. Place the lid back on the dis-
penser and turn to close.
Switching off water softening system
Note
To avoid damage to the appliance, only
switch off the water softening system in
the following cases:
¡ The water hardness is max. 26°E
and you are using combined detergents with salt replacement substances. According to manufactur-
1
Depending on the appliance specifications
28
Water softening system en
ers, combined detergents with salt
replacement substances can generally only be used up to a water
hardness of 26°E without adding
6. Press to save the setting.
a The water softening system is
switched off and the salt refill indicator is deactivated.
special salt.
¡ The water hardness is 0 - 8°E.
You do not need to use special
salt.
1. Press .
2. Press and hold .
3. Turn the programme selector until
the display shows H:04.
4. Release the button.
5. Turn the programme selector until
the display shows H:00.
Regeneration of the water softening system
In order to obtain fault-free function of
the water softening system, the appliance performs reheating of the water
softening system at regular intervals.
Regeneration of the water softening
system takes place before the end of
the main rinse cycle in all programmes. It will increase the run time
and consumption values, e.g. water
and electricity.
Overview of consumption values with regeneration the water softening system
Here you can find an overview of the maximum additional running time and
consumption values during regeneration of the water softening system.
You can find the column applicable to your model in the quick reference guide
according to its water consumption in the Eco50° programme.
Water consumption in litres (depending on
model)
6.5 / 6.7 8 7 5 0.05
7.5 / 7.7 7 7 5 0.05
9.5 6 7 5 0.05
above 10.5 5 7 5 0.05
Regeneration of
the water softening system after
x rinse cycles
Additional running time in
minutes
Additional water
consumption in
litres
Additional power
consumption in
kWh
The consumption values specified
are laboratory measurements determined in accordance with the currently
applicable standard and using the
Eco 50° programme and the factory
value of the water hardness is set to
16 - 20°E.
29
en Rinse aid system
1
2
max
Rinse aid system
Rinse aid system
You can use the rinse aid system
and rinse aid to get tableware and
glasses rinsed perfectly without
marks.
Rinse aid
For optimum drying results, use rinse
aid.
Only use rinse aid for domestic dishwashers.
Adding rinse aid
If the rinse aid refill indicator lights
up, top up with rinse aid. Only use
rinse aid for domestic dishwashers.
1. Press the catch on the lid of the
dispenser for rinse aid and lift
.
Spilled rinse aid can cause excessive frothing during the wash
cycle.
4. Close the lid of the dispenser for
rinse aid.
a The lid clicks into position.
Setting the amount of rinse aid
If there are streaks or water marks on
tableware, change the amount of
rinse aid.
1. Press .
2. Press and hold .
3. Turn the programme selector until
the display shows r:05.
4. Release the button.
5. Turn the programme selector until
the right amount of rinse aid has
been set.
The factory setting is level r:05.
– A low setting adds less rinse aid
during the wash cycle and reduces streaking on tableware.
– A higher setting adds more
rinse aid during the wash cycle,
reduces water marks and improves the drying result.
6. Press to save the setting.
2. Add rinse aid up to the max mark.
3. If rinse aid spills out, remove it
from the tub.
30
Switching rinse aid system off
If you find the rinse aid refill indicator
irritating, e.g. when using combined
detergents with a rinse aid component, you can switch the rinse aid system off.
Tip:The function of rinse aid is limited with combined detergents. You
will generally get better results using
rinse aid.
1. Press .
2. Press and hold .
3. Turn the programme selector until
the display shows r:05.
4. Release the button.
Detergent en
5. Turn the programme selector until
the display shows r:00.
6. Press to save the setting.
a The rinse aid system is switched
off and the rinse aid refill indicator
is deactivated.
Detergent
Detergent
Find out which detergents are suitable for your appliance.
Suitable detergents
Only use detergents that are suitable
for dishwashers. Both separate and
combined detergents are suitable.
For optimum washing and drying results, use separate detergent, adding
Special salt →Page28 and Rinse aid
→Page30 separately.
Modern, powerful detergents mainly
use a low-alkaline formulation with
enzymes. Enzymes break down
starch and remove protein. Oxygenbased bleaching agents are generally
used to remove coloured marks, e.g.
tea or ketchup.
Note:Follow the manufacturer's instructions for each detergent.
Detergent Description
Tabs Tabs are suitable for all
cleaning functions and do
not need to be measured
out.
With shorter Programmes
tabs sometimes do not dissolve entirely and leave
residues of detergent. This
may impair the cleaning effect.
Powder detergent
Powder detergent is recommended for shorter
Programmes.
The dosage can be adjusted to the level of soiling.
Detergent Description
Liquid detergent Liquid detergent works
faster and is recommended for shorter Programmes without PreRinse.
Sometimes liquid detergent may leak out despite
the detergent dispenser
being closed. This is not a
fault and is non-critical if
you remember the following:
¡ Only choose a pro-
gramme without PreRinse.
¡ Do not select timer pro-
gramming for starting
the programme.
The dosage can be adjusted to the level of soiling.
Tip:Suitable detergents are available
online via our website or from Customer Services →Page54.
Separate detergents
Separate detergents are products
that do not contain components other
than detergent, e.g. powder detergent or liquid detergent.
With powder and liquid detergent the
dosage can be individually adjusted
to the level of soiling of the tableware.
For better washing and drying results
and to avoid damage to the appliance, please additionally use Special
salt →Page28 and Rinse aid
→Page30.
Combined detergent
Besides conventional separate detergents, a number of products are
available with additional functions.
These products contain not only detergent but also rinse aid and salt replacement substances (3in1) and,
31
en Detergent
15 ml
25 ml
50 ml
depending on the combination (4in1,
5in1,...), additional components such
as glass protection or stainless steel
cleaner.
According to manufacturers, combined detergents generally only function up to a water hardness of 26°E.
With a water hardness above 26°E
you will need to add special salt and
rinse aid. For the best washing and
drying results we recommend using
special salt and rinse aid from a water hardness of 17°E. If you are using combined detergent, the washing
programme is adjusted automatically
to ensure the best possible washing
and drying result.
Unsuitable detergents
Do not use detergent which could
cause damage to the appliance or
present a risk to health.
Detergent Description
Hand washing-up
liquid
Detergent containing chlorine
Hand washing-up liquid
can cause increased frothing and damage the appliance.
Chlorine residue on tableware may present a risk to
health.
¡ According to manufacturers, com-
bined detergents with salt replacement substances can only be used
up to a certain water hardness,
usually 26°E, without adding special salt. For the best washing and
drying results we recommend using special salt from a water hardness of 17°E.
¡ To prevent sticking, only touch de-
tergents in a water-soluble pouch
with dry hands and only ever place
them in a dry detergent dispenser.
¡ Even if the rinse aid and special
salt refill indicators light up, washing programmes will run properly
with combined detergents.
¡ The function of rinse aid is limited
with combined detergents. You will
generally get better results using
rinse aid.
¡ Use tablets with a special drying
performance.
Adding detergent
1. To open the detergent dispenser,
press the locking latch.
2. Add the detergent to the dry deter-
gent dispenser.
Information on detergents
Follow the instructions on detergents
in everyday use.
¡ Detergents marked as "organic" or
"ecological" (environmentally
friendly) generally contain lower
levels of active agents or completely dispense with certain substances. The cleaning effect may
be restricted here.
¡ Set the rinse aid and the water
softening system to the separate
detergent or combined detergent
in use.
32
If you are using tablets, one is
enough. Insert the tablets in a horizontal position.
Tableware en
If you are using powder or liquid
detergent, follow the manufacturer's instructions and quantities
for dosage in the detergent dispenser.
20ml–25ml detergent is sufficient for normal soiling. If tableware is only lightly soiled, slightly
less than the amount of detergent
specified is usually sufficient.
3. Close the lid of the detergent dis-
penser.
a The lid clicks into position.
a The detergent dispenser will open
automatically at the optimum time
during the programme. Powder or
liquid detergent will spread around
the washing tank and dissolve
there. Tablets will fall into the tablet
collecting tray and dissolve in the
right dosage. In order to ensure
that tablets can dissolve evenly, do
not place any other objects in the
tablet collecting tray.
Tableware
Tableware
Only clean tableware that is suitable
for dishwashers.
Note:Decorated glassware and parts
made of aluminium or silver may
fade or discolour with dishwashing.
Delicate types of glass may turn
cloudy after a few washing cycles.
Damage to glass and tableware
Avoid damage to glass and tableware.
Cause Recommendation
The following tableware is not dishwasher-safe:
¡ Items of cutlery
and tableware
made from wood
¡ Decorated glass-
ware, antique and
hand-crafted tableware
¡ Plastic parts not
resistant to heat
¡ Tableware made
from copper or tin
¡ Tableware soiled
with ash, wax, lubricating grease or
paint
¡ Very small items of
tableware
Glass and tableware
was not dishwashersafe.
The chemical composition of the detergent causes damage.
Highly caustic alkaline
or highly acidic cleaning agents, in particular commercial or industrial cleaning
agents, are not suitable for dishwashers
in conjunction with
aluminium.
Only put tableware in
the dishwasher if it is
marked as dishwasher-safe by the
manufacturer.
Only put glasses and
china in the dishwasher if it is marked
as dishwasher-safe by
the manufacturer.
Use a detergent
marked as gentle on
tableware by the manufacturer.
If you are using highly
caustic alkaline or
highly acidic cleaning
agents, in particular
commercial or industrial cleaning agents,
do not put aluminium
parts in the dishwasher interior.
33
en Tableware
Cause Recommendation
The water temperature of the programme
is too high.
Select a programme
with lower temperatures.
After the programme
has ended, take glassware and cutlery out
of the appliance
without delay.
Arrange tableware
Arrange the tableware correctly to
optimise the dishwashing result and
prevent damage to both the appliance and tableware.
Tips
¡ Using the appliance allows you to
save energy and water compared
to washing-up by hand.
¡ See our website for examples of
how to load your appliance efficiently, free of charge.
¡ To save energy and water, load
the machine with the number of
place settings specified.
→"Technical specifications",
Page55
¡ For better washing and drying res-
ults, position items with curves or
recesses at an angle so the water
can run off.
To save resources, do not prerinse tableware under running water.
2. Observe the following when arran-
ging tableware:
– Put heavily soiled tableware in
the bottom basket, e.g. pans.
The more powerful the spray jet,
the better the dishwashing result
will be.
– To prevent damage to table-
ware, arrange it so it is stable
and cannot tip over.
– To prevent injury, arrange cut-
lery with the points and sharp
edges downwards.
– Position containers with the
openings facing down so no water can collect in them.
– Do not block the spray arms -
make sure that they can turn
freely.
– Do not place small parts in the
tablet collecting tray and do not
block it with tableware so as not
to obstruct the lid of the detergent dispenser.
1. Remove large remnants of food
from your tableware.
34
Removing tableware
2
1
WARNING
Risk of injury!
Hot tableware can cause burns to the
skin. When hot, tableware is sensitive
to shock, may crack and can result in
injury.
▶
When the programme has ended,
do not empty the appliance until
the tableware has cooled down for
a while.
1. To prevent water dripping on the
tableware, unload it starting at the
bottom and working up.
2. Check the washing tank and ac-
cessories for soiling and clean if
necessary.
→"Cleaning and servicing",
Page39
Basic operation
Basic operation
You can find out everything you need
to know about operating your appliance here.
Opening appliance door
1. If the childproof lock
ated, open the appliance door.
2. If the childproof lock
press the catch of the lock to the
right and open the appliance
door .
1
is not activ-
1
is activated,
Basic operation en
Switching on the appliance
▶
Press .
The Eco 50° programme is set by
default.
The Eco 50° programme is an especially environmentally friendly
programme and ideal for normally
soiled tableware. It is the most efficient programme for the combination of energy/water consumption
for this type of tableware and evidences conformity with the EU Ecodesign Order.
If you do not perform any actions
on the appliance for 15 minutes,
the appliance will automatically
switch off.
Setting a programme
To adjust the wash cycle to the soiling level of the tableware, select a
suitable programme.
▶
Turn the programme selector until
the right programme has been selected.
→"Programmes", Page19
a The remaining running time of the
programme appears on the display.
1
Depending on the appliance specifications
35
en Basic operation
Setting additional functions
You can set additional functions to
complete the washing programme
selected.
Note:The additional functions which
can be used depend on the programme selected.
→"Programmes", Page19
▶
Press the button for the relevant
additional function.
→"Additional functions", Page21
a The additional function is set and
the additional function button
flashes.
Setting timer programming
You can delay the start of the programme by up to 24hours.
1. Press .
a "h:01" appears in the display.
2. Use to set the required start
time for the programme.
3. Press .
a This activates timer programming.
Note:To deactivate timer programming, press repeatedly until "h:00"
appears in the display.
Starting the programme
▶
Press .
a The programme has ended when
the display shows "0:00".
Notes
¡ If you want to add more tableware
while the appliance is running, do
not use the tablet collecting tray as
a handle for the top basket. You
might touch the partially dissolved
tablet.
¡ You can only change a pro-
gramme when running if you cancel it.
→"Terminate programme",
Page36
¡ The appliance switches off auto-
matically 1minute after the end of
the programme to save energy. If
you open the appliance door immediately after the programme has
ended, the appliance will switch off
after 4 seconds.
Interrupting programme
Note:When you open the appliance
door once the appliance has heated
up, leave the door slightly ajar for a
few minutes and then close it. This
will help prevent excess pressure
building up in the appliance and stop
the appliance door bursting open.
1. Press .
a The programme is saved and the
appliance switches off.
2. Press to resume the pro-
gramme.
Terminate programme
To end a programme early or to
switch from a programme that has
already started, you will need to terminate it first.
▶
Press for approx.
3seconds.
a The programme is terminated and
ends after approx. 1minute.
Switching off appliance
1. Please note the information on
Safe use →Page11.
2. Press .
3. To prevent damage from dripping
water, turn the water tap off tight
(not applicable to appliances with
Aqua-Stop).
36
Tip:If you press during the wash
cycle, the programme currently running will be interrupted. When you
switch the appliance back on, the
programme continues automatically.
Basic operation en
37
en Basic settings
Basic settings
Basic settings
You can configure the appliance to meet your needs.
Overview of basic settings
The basic settings depend on the features of your appliance.
Basic setting Display text Selection Description
Water hardness H:04
1
H:00 - H:07 Set the water softening system to
your water hardness.
→"Setting water softening system",
Page28
Level H:00 switches the water
softening system off.
Rinse aid dispensing r:05
1
r:00 - r:06 Set the amount of rinse aid to be dis-
pensed.
→"Setting the amount of rinse aid",
Page30
Switch the rinse aid system off with
level r:00.
Intensive drying d:00
1
d:00 - d:01 The temperature is increased during
the final rinse, which improves the
drying result. This may increase the
running time slightly.
Note:Not suitable for delicate items
of tableware.
Switch Intensive drying on "d:01" or
off "d:00".
Hot water A:00
1
A:00 - A:01 Set cold water or hot water connec-
tion. Only set the appliance to hot
water if this can be prepared with
little energy and a suitable installation is available, e.g. solar heating
system with circulation line. The water temperature should be at least
40°C and max. 60°C.
Switch hot water on "A:01" or off
"A:00".
1
Factory setting (may vary according to model)
Changing basic settings
1. Press .
2. Press and hold .
38
3. Turn the programme selector until
the display shows the required setting.
4. Release the button.
Cleaning and servicing en
1
2
3
1
2
3
5. Turn the programme selector until
the display shows the right value.
6. Press to save the setting.
Cleaning and servicing
Cleaning and servicing
To keep your appliance working efficiently for a long time, it is important
to clean and maintain it carefully.
Cleaning the tub
WARNING
Risk of harm to health!
Using detergents containing chlorine
may result in harm to health.
▶
Never use detergents containing
chlorine.
1. Remove any coarse soiling in the
interior with a damp cloth.
2. Add detergent to the detergent dis-
penser.
3. Select the programme with the
highest temperature.
→"Programmes", Page19
4. Start the programme without table-
ware. →Page36
Cleaning products
Only use suitable cleaning products
to clean your appliance.
→"Safe use", Page11
Tips on appliance care
Follow the tips on appliance care to
make sure your appliance functions
properly at all times.
Action Benefit
Wipe the door seals,
the front of the dishwasher and the control panel regularly using a damp cloth and
washing-up liquid.
If the appliance is not
going to be used for a
while, leave the door
slightly ajar.
This ensures the parts
of the appliance will
remain clean and hygienic.
This will prevent unpleasant odours.
Filter system
The filter system removes coarse
soiling from the dishwashing cycle.
Self-cleaning interior
To remove deposits, the appliance
self-cleans the interior at regular intervals.
The programme sequence is automatically adjusted for self-cleaning,
e.g. the cleaning temperature is
briefly increased. Consumption values, e.g. water and electricity, may
also increase.
If the interior is no longer self-cleaned
adequately and deposits occur, see
this information:
→"Cleaning the tub", Page39.
1
1
Depending on the appliance specifications
Micro filter
Fine filter
Coarse filter
39
en Cleaning and servicing
1
2
1
2
1
2
Cleaning filters
Soiling in the dishwashing water may
block the filters.
1. After each wash check the filters
for residue.
2. Turn the coarse filter anticlockwise
and remove the filter system .
‒ Check that no foreign objects
fall into the sump.
3. Pull down the micro filter to re-
move.
5. Clean the filter elements under run-
ning water.
Carefully clean the rim of dirt
between the coarse and the fine filter.
6. Re-assemble the filter system.
Make sure that the locking catches
on the coarse filter click into position.
7. Insert the filter system into the ap-
pliance and turn the coarse filter
clockwise.
Make sure that the arrow markings
match up.
4. Press the locking catches to-
gether and lift the coarse filter out
.
40
Cleaning spray arms
Limescale and soiling in the dishwashing water may block the nozzles
and bearings on the spray arms.
Clean the spray arms regularly.
1. Unscrew the upper spray arm
and pull down to remove .
2. Pull up the lower spray arm to re-
move.
3. Check the outlet nozzles on the
spray arms for blockages under
running water and remove any foreign bodies.
4. Insert the lower spray arm.
a The spray arm clicks into position.
5. Insert the upper spray arm and
screw it firmly in place.
Cleaning and servicing en
41
en Troubleshooting
Troubleshooting
Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-sales service. This will avoid unnecessary costs.
WARNING
Risk of electric shock!
Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out by trained specialist
staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be replaced with a
special connection cable, which is available from the manufacturer or his
Customer Service.
Appliance safety
Fault Cause troubleshooting
Appliance door will not open
Childproof lock is activated.
or cannot be opened easily.
Error code / Fault display / Signal
Fault Cause troubleshooting
E:12 lights up. Heating element is furred
up.
E:14 lights up. Water protection system is
activated.
E:15 lights up. Water protection system is
activated.
E:16 lights up. Water is continuously run-
ning into the appliance.
E:18 or indicator for water
supply lights up.
Supply hose is kinked.
Water tap is turned off.
Water tap is jammed or
furred up.
▶
Open the appliance door.
→Page35
1. Descale the appliance.
2. Operate the appliance with the Wa-
ter softening system.
1. Turn off the water tap.
2. Call Customer Service
→Page54.
1. Turn off the water tap.
2. Call Customer Service
→Page54.
1. Turn off the water tap.
2. Call Customer Service
→Page54.
▶
Install the supply hose without
kinks.
▶
Turn on the water tap.
▶
Turn on the water tap.
The flow rate must be at least 10 l/
min when the water supply is open.
42
Fault Cause troubleshooting
E:18 or indicator for water
supply lights up.
Filter in the water supply is
blocked.
1. Switch off the appliance.
2. Pull out the mains plug.
3. Turn off the water tap.
4. Unscrew the water connection.
5. Remove the filter from the supply
hose
6. Clean the filter.
7. Re-insert the filter in the supply
hose.
8. Screw the water connection back
on.
9. Check the water connection for
leaks.
10. Restore the power supply.
11. Switch the appliance on.
E:22 lights up.
1
Filters are soiled or blocked.▶Clean the filters.
→"Cleaning filters", Page40
E:24 lights up. Wastewater hose is blocked
or kinked.
Siphon connection is still
sealed.
Cover of the wastewater
pump is loose.
1. Reposition the wastewater hose
without kinks.
2. Remove residues.
▶
Check the connection to the siphon
and open if necessary.
▶
Secure the cover of the Wastewater
pump →Page53 so it clicks into
position.
E:25 lights up. Wastewater pump is
blocked.
▶
Clean the wastewater pump.
→"Clean wastewater pump",
Page53
Troubleshooting en
1
Depending on the appliance specifications
43
en Troubleshooting
Fault Cause troubleshooting
E:25 lights up. Cover of the wastewater
pump is loose
▶
Secure the cover of the Wastewater
pump →Page53 so it clicks into
position.
E:27 lights up. Mains voltage is too low. This is not a fault on the appliance.
1. Contact an electrician.
2. Have the mains voltage and elec-
trical installation checked by an
electrician.
Another error code appears
on the display.
E:01 to E:30
A technical fault is present. 1. Press .
2. Unplug the appliance or switch off
the fuse.
3. Wait at least 2minutes.
4. Insert the mains plug of the appli-
ance in a socket or switch on the
fuse.
5. Switch the appliance on.
6. If the problem occurs again:
‒ Press .
‒ Turn off the water tap.
‒ Pull out the mains plug.
‒ Contact Customer Service
→Page54 and give the er-
ror code.
Washing results
Fault Cause troubleshooting
Tableware is not dry. No rinse aid used or dosage
set too low.
Selected programme has no
drying phase
Water collects in recesses of
the tableware or cutlery.
44
1. Add Rinse aid →Page30.
2. Set the amount of rinse aid to be
dispensed.
▶
Select a programme with drying.
▶
Position tableware at an angle
where possible.
Fault Cause troubleshooting
Tableware is not dry.
Troubleshooting en
The combined detergent
used has a poor drying performance.
Extra Dry not activated to improve drying performance.
Tableware removed too
early or drying process not
yet ended.
Rinse aid used has a limited
drying performance.
Plastic tableware is not dry. Not a fault. As plastic does
not store heat so well, it also
does not dry as well.
Cutlery is not dry. Cutlery not arranged prop-
erly in the cutlery basket or
cutlery drawer.
Appliance interior still wet
after wash cycle.
Not a fault. The condensation drying principle causes
water droplets in the tub –
they are indeed desirable
here. The moisture in the air
condenses on the inside
walls, runs off and is
pumped out.
Remnants of food on tableware.
Tableware was placed too
close together.
1. Use rinse aid to improve drying per-
formance.
2. Use a different combined detergent
with a better drying performance.
▶
Activate Extra Dry.
1. Wait until the programme ends.
2. Only remove tableware 30minutes
after the programme has ended.
▶
Use a name-brand rinse aid.
Eco products may have limited ef-
fectiveness.
▶
No remedial action possible.
1. Arrange the cutlery properly.
→"Arrange tableware", Page34
2. Arrange cutlery individually where
possible.
3. Avoid points of contact.
No action required.
1. Arrange tableware with sufficient
space in between.
The spray jets must reach the sur-
faces of the tableware.
2. Avoid points of contact.
45
en Troubleshooting
Fault Cause troubleshooting
Remnants of food on tableware.
Basket is overfilled. 1. Arrange tableware with sufficient
space in between.
The spray jets must reach the sur-
faces of the tableware.
2. Avoid points of contact.
Spray arm rotation is
blocked.
Spray arm nozzles are
▶
Arrange tableware so that it does
not obstruct spray arm rotation.
▶
Clean the Spray arms →Page40.
blocked.
Filters are soiled.
▶
Clean the filters.
→"Cleaning filters", Page40
Filters are inserted incorrectly and/or not engaged.
Washing programme selected too weak.
Tableware has been precleaned too intensely. The
1. Insert the filters properly.
→"Filter system", Page39
2. Engage the filters.
▶
Select a more intensive washing
programme.
▶
Adjust the sensitivity of the sensors.
▶
Only remove large remnants of food
and do not prerinse tableware.
sensors chose a weaker programme. Stubborn soiling
cannot be entirely removed.
Tall narrow receptacles in
corner areas are not rinsed
adequately.
Top baskets on right and left
are not set to same height.
▶
Do not position tall narrow recept-
acles at too great an angle or in
corner areas.
▶
Set the top baskets on the left and
right to the same level.
→"Top basket", Page22
Detergent residue in the appliance
Lid of the detergent dispenser is blocked by items
of tableware parts and will
not open.
1. Arrange tableware in the top basket
tableware so the tab collecting tray
is not obstructed by tableware.
→"Arrange tableware", Page34
Items of tableware are blocking the
dispenser lid.
2. Do not place tableware or fra-
grance dispensers in the tablet col-
lecting tray.
The lid of the detergent dispenser is blocked by the tab
▶
Position the tab in the detergent dis-
penser crosswise, not vertically.
and will not open.
46
Fault Cause troubleshooting
Detergent residue in the appliance
Tabs are used in the quick
or short programme. Dissolving time of the tab is not at-
▶
Select a more intensive Programme
or use Powder detergent
→Page31.
tained.
Washing effect and dissolv-
▶
Change your detergent →Page31.
ing performance are reduced after a prolonged
storage time or detergent is
very lumpy.
Water marks on plastic
parts.
Due to laws of physics
droplet formation on plastic
surfaces is unavoidable.
After drying water marks are
visible.
▶
Select a more intensive pro-
gramme.
▶
Position tableware at an angle.
→"Arrange tableware", Page34
▶
Use rinse aid.
→"Rinse aid", Page30
▶
Set the water softening system
higher.
Wipeable or water-soluble
coatings are present inside
the appliance or on the door.
Detergent substances are
deposited there. These coatings cannot generally be re-
▶
Change your detergent →Page31.
▶
Clean the appliance mechanically.
moved with chemicals.
White coating is deposited in
the appliance interior.
1. Set the water softening system cor-
rectly.
In most cases you will need to in-
crease the setting.
2. Change your detergent if required.
▶
Screw the special salt dispenser
tight.
▶
Change your detergent →Page31.
▶
Clean the appliance mechanically.
Stubborn white coatings are
present on tableware, inside
the appliance or the door.
Special salt dispenser is not
screwed tight.
Detergent substances are
deposited there. These coatings cannot generally be removed with chemicals.
The hardness range is set incorrectly or the water hardness is greater than 62°E
▶
Set the Water softening system
→Page27 to the water hardness
or add special salt.
(8,9mmol/l).
3in1/organic/eco detergent
is not effective enough.
▶
Set the Water softening system
→Page27 to the water hardness
and use separate detergents (pro-
prietary detergent, special salt,
rinse aid).
Troubleshooting en
47
en Troubleshooting
Fault Cause troubleshooting
Stubborn white coatings are
present on tableware, inside
the appliance or the door.
Tea residue or lipstick marks
on tableware.
Too little detergent is being
used.
Washing programme selected too weak.
Washing temperature is too
low.
Too little detergent is being
used or is unsuitable.
▶
Increase the amount of detergent
used or change Detergent
→Page31.
▶
Select a more intensive washing
programme.
▶
Adjust the sensitivity of the sensors.
▶
Select a programme with a higher
washing temperature.
▶
Use a suitable Detergent
→Page31 and follow the manufac-
turer's instructions for the amount
to be used.
Tableware has been precleaned too intensely. The
▶
Only remove large remnants of food
and do not prerinse tableware.
sensors chose a weaker programme. Stubborn soiling
cannot be entirely removed.
Coloured coatings (blue, yellow, brown) that are difficult
or impossible to remove are
present inside the appliance
or on stainless steel tableware.
The formation of films is due
to substances contained in
vegetables (cabbage, celery,
potatoes, noodles, etc.) or
tap water (manganese).
▶
Clean the appliance.
You can remove deposits with
Mechanical cleaning →Page39 or
a machine cleaning product. It may
not always be possible to com-
pletely remove deposits but they
are harmless to health.
The formation of films is due
to metal components on silver or aluminium tableware.
▶
Clean the appliance.
You can remove deposits with
Mechanical cleaning →Page39 or
a machine cleaning product. It may
not always be possible to com-
pletely remove deposits but they
are harmless to health.
Coloured deposits (yellow,
orange, brown) that are easy
to remove are present inside
the appliance (mainly at the
bottom).
The formation of films is due
to ingredients of food remnants and tap water (limescale) "soaplike".
1. Check the setting of the water
softening system.
2. Add special salt.
→"Adding special salt", Page28
3. If you are using combined deter-
gents (tabs), activate the water
softening system.
Follow the information about deter-
gents.
→"Information on detergents",
Page32
48
Fault Cause troubleshooting
Plastic parts inside the appliance are discoloured.
Plastic parts inside the appliance may become discoloured during the life of the
▶
Discolouration can come about and
will not impair functioning of the ap-
pliance.
dishwasher.
Plastic parts are discoloured.
Washing temperature is too
low.
Tableware has been precleaned too intensely. The
▶
Select a programme with a higher
washing temperature.
▶
Only remove large remnants of food
and do not prerinse tableware.
sensors chose a weaker programme. Stubborn soiling
cannot be entirely removed.
Removable streaks are
present on glasses, glassware with a metallic appearance and cutlery.
Amount of rinse aid to be
dispensed is set too high.
No rinse aid has been added.
Detergent residue is present
in the final rinse. Lid of the
detergent dispenser is
blocked by tableware items
and will not open fully.
▶
Set the rinse aid system to a lower
setting.
▶
→"Adding rinse aid", Page30
1. Arrange tableware in the top basket
tableware so the tab collecting tray
is not obstructed by tableware.
→"Arrange tableware", Page34
Items of tableware are blocking the
dispenser lid.
2. Do not place tableware or fra-
grance dispensers in the tablet col-
lecting tray.
Tableware has been precleaned too intensely. The
sensors chose a weaker programme. Stubborn soiling
▶
Only remove large remnants of food
and do not prerinse tableware.
▶
Adjust the sensitivity of the sensors.
cannot be entirely removed.
Irreversible clouding of
glassware.
Glasses are not dishwasherproof, only suitable for dishwashers.
▶
Use dishwasher-proof glasses.
▶
Avoid a lengthy steam phase
(standing time after wash cycle
ends).
▶
Use a programme with a lower tem-
perature.
▶
Set the softening system to the wa-
ter hardness.
▶
Use detergent with a glass protec-
tion component.
Troubleshooting en
49
en Troubleshooting
Fault Cause troubleshooting
Rust spots on cutlery. Cutlery is not sufficiently
▶
Use rust-resistant tableware.
rust-resistant. Knife blades
are often more severely affected.
Cutlery may also rust if
▶
Do not wash rusting items.
washed together with rusting items.
Salt content in washing water is too high.
1. Remove any spilled special salt
from the tub.
2. Screw the cap of the special salt
dispenser on tight.
Detergent residue is present
in the detergent dispenser
or the tablet collecting tray.
Spray arms were blocked by
tableware so detergent was
not rinsed out.
Detergent dispenser was
damp when detergent was
▶
Check that the spray arms are not
blocked and can rotate freely.
▶
Only add detergent to a detergent
dispenser when dry.
added.
Excessive formation of foam
occurs.
Hand washing-up liquid is
present in dispenser for
rinse aid.
Rinse aid has been spilled.
Detergent or appliance care
▶
Immediately add rinse aid to the
dispenser.
→"Adding rinse aid", Page30
▶
Remove the rinse aid with a cloth.
▶
Change the brand of detergent.
product used causes excessive foaming.
Information on display panel
Fault Cause troubleshooting
Special salt refill indicator
lights up.
Refill indicator for special
salt does not light up.
Refill indicator for rinse aid
lights up.
Refill indicator for rinse aid
does not light up.
50
Insufficient special salt.
Sensor does not detect special salt tablets.
Water softening system is
switched off.
Insufficient rinse aid. 1. Add Rinse aid →Page30.
Rinse aid system is switched
off.
▶
Add Special salt →Page28.
▶
Do not use special salt tablets.
▶
Setting water softening system
→Page28
2. Set the amount of rinse aid to be
dispensed.
▶
→"Setting the amount of rinse aid",
Page30
Fault Cause troubleshooting
Display flashes. Appliance door is not closed
properly.
▶
Close the appliance door.
‒ Arrange the tableware so
that no parts project beyond
the basket and prevent the
appliance door from closing
properly.
Malfunctions
Fault Cause troubleshooting
Water is left in the appliance
at the end of the programme.
Appliance cannot be
switched on or operated.
Appliance does not start. The mains fuse has tripped.
Programme starts automatically.
Appliance stops during the
programme or cuts out.
Filter system or area under
the filters is blocked.
1. Clean the Filters →Page40.
2. Clean the Wastewater pump
→Page53.
Programme has not yet
ended.
▶
Wait until the programme ends or
cancel the programme with reset.
▶
→"Terminate programme",
Page36
Appliance functions have
failed.
1. Pull out the mains plug or switch off
the fuse.
2. Wait at least 2minutes.
3. Connect the appliance to the power
supply.
4. Switch the appliance on.
▶
Check the relevant fuse.
Mains cable is not inserted. 1. Check whether the socket works.
2. Check whether the mains cable is
properly inserted in the socket and
on the rear of the appliance.
Appliance door is not closed
▶
Close the appliance door.
properly.
You did not wait until programme ended.
Appliance door is not closed
▶
→"Terminate programme",
Page36
▶
Close the appliance door.
properly.
Power and/or water supply
has been interrupted.
Top basket is pressing
against inner door and preventing appliance door from
being closed securely.
1. Check the power supply.
2. Check the water supply.
▶
Check whether the rear panel of the
appliance is being pressed in by a
socket or hose holder that has not
been removed.
Troubleshooting en
51
en Troubleshooting
Fault Cause troubleshooting
Appliance stops during the
programme or cuts out.
▶
Arrange the tableware so that no
parts project beyond the basket
and prevent the appliance door
from closing properly.
Mechanical damage
Fault Cause troubleshooting
Appliance door cannot be
closed.
Door lock has been activated.
Door cannot be closed due
to installation method.
▶
Close the appliance door with
greater force.
▶
Check whether the appliance has
been installed properly.
When closed, the appliance door,
its decor or attached parts should
not knock against adjacent cabin-
ets or the worktop.
Lid on the detergent dispenser cannot be closed.
Detergent dispenser or lid
are blocked by sticky deter-
▶
Remove detergent residue.
gent residue.
Noise
Fault Cause troubleshooting
Filling valves making knocking noises.
Caused by the domestic installation. No appliance fault
present. Does not affect
functioning of the appliance.
Knocking or rattling noise. Spray arm is striking table-
ware.
With a small load the water
jets directly strike against
the tub.
Light items of tableware
move about during the wash
cycle.
▶
Can only be remedied in the do-
mestic installation.
▶
Arrange tableware so that the spray
arms do not strike tableware.
▶
Distribute the tableware evenly.
▶
Load the appliance with more table-
ware.
▶
Position light items of tableware se-
curely.
52
Clean wastewater pump
1
2
Large remnants of food or foreign
bodies can block the wastewater
pump. As soon as the washing water
no longer drains properly, the
wastewater pump must be cleaned.
WARNING
Risk of injury!
Sharp and pointed objects or fragments of glass may block the waste
water pump and cause injury.
▶
Remove any foreign bodies carefully.
1. Disconnect the appliance from the
power supply.
2. Remove the top and bottom bas-
ket.
3. Remove the filter system.
4. Scoop out any water.
Use a sponge if necessary.
5. Prise off the pump cover using a
spoon and grip it by the
crosspiece.
Transportation, storage and disposal en
a The pump cover clicks into posi-
tion.
9. Install the filter system.
10.Insert the top and bottom basket.
Transportation, storage and disposal
Transportation, storage
and disposal
You can find out here how to prepare
your appliance for transportation and
storage. You will also find out how to
dispose of old appliances.
Removing the appliance
6. Lift the pump cover inwards at an
angle and remove.
7. Remove any remnants of food and
foreign bodies in the area of the
impeller.
8. Insert the pump cover and press
down .
1. Disconnect the appliance from the
power supply.
2. Turn off the water tap.
3. Detach the drainage connection.
4. Detach the drinking water connec-
tion.
5. Loosen any screws fastening the
appliance to cabinet parts.
6. Remove the base panel if fitted.
7. Pull the appliance out carefully,
along with the hose behind it.
Protect appliance from frost
If there is a risk of frost where the appliance will be standing, e.g. in a holiday home, empty the appliance completely.
▶
Empty the appliance. →Page54
53
en Customer Service
Transporting the appliance
To avoid damage to the appliance,
empty it before transporting.
Note:Always transport the dishwasher upright to prevent residual
water getting into the machine's controls and damaging the appliance.
1. Remove tableware from the appli-
ance.
2. Secure loose parts.
3. Turn on the water tap.
4.
Switch on appliance. →Page35
5. Select the programme with the
highest temperature.
→"Programmes", Page19
6.
Start the programme. →Page36
7. To drain the appliance, terminate
the programme after approx.
4minutes.
→"Terminate programme",
Page36
8. Switch off the appliance.
→Page36
9. Turn off the water tap.
10.To empty the residual water out of
the appliance, detach the supply
hose and let the water drain out.
Disposing of old appliance
Valuable raw materials can be reclaimed by recycling.
WARNING
Risk of harm to health!
Children can lock themselves in the
appliance, thereby putting their lives
at risk.
▶
With redundant appliances, unplug
the power cord. Then cut through
the cord and damage the lock on
the appliance door beyond repair
so that the appliance door will no
longer close.
1. Unplug the appliance from the
mains.
2. Cut through the power cord.
3. Dispose of the appliance in an en-
vironmentally friendly manner.
This appliance is labelled in accordance with European Directive 2012/19/EU concerning
used electrical and electronic
appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the
framework for the return and recycling of used appliances as
applicable throughout the EU.
Customer Service
Customer Service
If you have any queries, are unable to
rectify faults on the appliance yourself or if your appliance needs to be
repaired, contact Customer Service.
You can solve many problems yourself by consulting the information on
troubleshooting in these instructions
or on our website. If this is not the
case, contact our Customer Service.
We will always find an appropriate
solution and try to avoid unnecessary
visits being made by a Customer Service technician.
With any warranty claims we will
make sure that your appliance is repaired by trained Customer Service
technicians using genuine spare
parts, including after the manufacturer's warranty has expired.
For safety reasons repairs to the appliance should only be carried out by
trained specialist staff. The warranty
claim becomes void if repairs or interventions have been carried out by
persons not authorised by us for that
purpose or if our appliances have
been fitted with spare, supplementary
54
Technical specifications en
or accessory parts that were not
genuine parts and then resulted in a
defect.
Function-relevant genuine spare parts
according to the corresponding Ecodesign Order can be obtained from
Customer Service for a period of at
least 10 years from the date on
which your appliance was placed on
the market within the European Economic Area.
Note:Under the terms of the manufacturer's warranty the use of Customer Service is free of charge.
Detailed information about the warranty period and terms of warranty in
your country are available from Customer Service, your dealer or our
website.
When contacting Customer Service,
you will need the product number (ENr.) and the production number (FD)
of your appliance.
The contact details for Customer Service can be found in the enclosed
Customer Service directory or on our
website.
Product number (E-Nr.) and production number (FD)
The product number (E-Nr. ) and the
production number (FD) can be
found on the rating plate of the appliance.
The rating plate is located inside the
appliance door.
Make a note of your appliance's details and the Customer Service telephone number to find them again
quickly.
AQUA-STOP guarantee
1
In addition to warranty claims against
the seller under the purchase agreement and in addition to our manufacturer's warranty, we will provide a replacement under the following conditions.
¡ If our Aqua-Stop system is defect-
ive and causes water damage, we
will make good the damage for
private users. To ensure protection
from water damage, the appliance
must be connected to the power
supply.
¡ The liability guarantee is valid for
the service life of the appliance.
¡ A claim can only be made under
the guarantee if the appliance has
been correctly installed and connected with Aqua-Stop according
to our instructions; this also includes correctly fitting the AquaStop extension (genuine accessory). Our guarantee does not cover
defective supply lines or fittings up
to the Aqua-Stop connection on
the tap.
¡ If your appliance is fitted with
Aqua-Stop, you can leave your appliance unattended during operation and the tap turned on afterwards. The tap only needs to be
turned off if you are away from
home for a long period, e.g. on
holiday for several weeks.
Technical specifications
Technical specifications
Facts and figures for your appliance
can be found here.
Weight Max.: 60kg
Voltage 220 - 240V, 50Hz or
60Hz
1
Depending on the appliance specifications
55
en Technical specifications
Power rating 2000 - 2400W
Fuse 10 - 16A
Power consumption Off mode/standby
mode: 0.10W
Left-on mode: 0.10W
Networked standby: W
Time in left-on mode:
0min
Time after which appliance is switched to
networked standby
mode: -min
Complies with the
latest regulations (EU)
for energy labels and
ecodesign at the time
of placing on the market.
Additional functions
and settings may increase power consumption and times.
Water pressure ¡ Min. 0.05MPa
(0.5bar)
¡ Max. 1MPa
(10bar)
Inlet rate Min. 10l/min
Water temperature Cold water.
Hot water max.: 60°C
Capacity 12-15place settings
More information about your model
can be found online at https://
www.bsh-group.com/energylabel1.
This web address is linked to the official EU EPREL product database. At
the time of printing its web address
had not yet been published. Please
then follow the instructions on
searching for models. The model
identifier is made up of the characters before the slash in the product
number (E-Nr.) on the rating plate. Al-
ternatively you can also find the
model identifier in the first line of the
EU energy label.
1
Only applies to countries in the European Economic Area
56
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service directory.
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
www.bosch-home.com
*9001519648*
9001519648 (000108) 640 EG
en
Loading...
