H.265
Video | AUTODOME IP starlight 7000i
AUTODOME IP starlight 7000i
www.boschsecurity.com
u Starlight technology with excellent low-light
performance and High dynamic range of 120 dB to
see detail in difficult light conditions
u Incorporates the latest H.265 video compression
technology to reduce bandwidth and storage
requirements
The AUTODOME IP starlight 7000i camera
incorporates the latest in Video Analytics, starlight
technology, and video streaming. With starlight
imaging technology for excellent low-light sensitivity
and the most robust Intelligent Video Analytics on the
market, the camera delivers unmatched picture
quality. Even under the most challenging light
conditions, the 30x PTZ dome camera delivers highdefinition (HD) 1080p video. Easy to install, the
camera is available in either a field-proven, outdoor
pendant housing or an indoor, in-ceiling housing.
Functions
Exceptional low-light performance
The latest sensor technology combined with the
sophisticated noise suppression results in an
exceptional sensitivity in color. The low-light
performance is so good that the camera continues to
provide excellent color performance even with a
minimum of ambient light.
u Built-in Intelligent Video Analytics alert operators in
case of unusual scene activity
u Edge intelligence with Intelligent Tracking and
object detection even when the camera is moving
u Exceptional reliability with 3-year warranty
(including on moving parts)
High dynamic range
The dynamic range of the camera is outstanding and is
obvious in real-world performance comparisons. In
extended dynamic range mode, the camera uses an
electronic shutter to capture four images with
different exposure time and reproduce a high-contrast
frame. The result is that you can view details in both
the bright areas (highlights) and the dark areas
(shadows) of a scene at the same time. You can easily
distinguish objects and features (for example, faces)
with bright backlight.
H.265 high-efficiency video encoding
The camera is designed on the most efficient and
powerful H.264 and H.265/HEVC encoding platform.
The camera is capable of delivering high-quality and
high-resolution video with very low network load. With
a doubling of encoding efficiency, H.265 is the new
compression standard of choice for IP video
surveillance systems.
Snap to zoom
Drawing a box in the image will trigger the camera to
zoom to the correct position.
Page 2
| AUTODOME IP starlight 7000i
2
Intelligent Video Analytics on the edge
With built-in video content analysis (VCA), the camera
reinforces the Intelligence-at-the-Edge concept where
edge devices become increasingly intelligent.
The camera comes with the state-of-the-art VCA
method by Bosch, Intelligent Video Analytics, that
reliably detects, and analyzes moving objects while
suppressing unwanted alarms from spurious sources
in the image.
With this method, the camera is able to detect idle
and removed objects as well as loitering, multiple line
crossing, and trajectories. This method also supports
BEV (Bird’s Eye View) People counting.
Video analytics while camera is moving
Outside of pre-positions and even while the PTZ
camera is moving, whether on guard tours or manually,
the Intelligent Video Analytics application can detect
and start alarms when objects are in alarm fields.
These alarm fields are defined once across all PTZ
camera views. The camera can automatically trigger an
alarm if any part of a field within the camera's view
becomes active while on a guard tour sweeping across
the monitored areas.
Camera Trainer
Based on examples of target objects and non-target
objects, the new Camera Trainer program uses
machine learning to allow the user to define objects of
interest and generate detectors for them. In contrast
to the moving objects that the Intelligent Video
Analytics application detects, the Camera Trainer
program detects both moving and non-moving objects
and classifies them immediately. Using Configuration
Manager, you can configure the Camera Trainer
program using both live video as well as recordings
available through the respective camera. The resulting
detectors can be downloaded and uploaded for
distribution to other cameras.
Intelligent Tracking
The camera utilizes the built-in Intelligent Video
Analytics to follow an individual or an object
continuously.
When Intelligent Video Analytics detects objects while
the camera is in a stationary position, the camera
activates the Intelligent Tracking feature. This feature
controls the pan/tilt/zoom actions of the camera to
track the objects and keep them in view in the scene.
The new Intelligent Tracking is based on robust flow
detection algorithms which can reliably track moving
objects even under challenging scenes.
The tracking and detection reliability can be enhanced
further with virtual masking for scenes with a lot of
background motion such as trees or other objects
creating constant motion in the scene.
The camera supports three modes for Intelligent
Tracking:
Auto mode
actively analyzes the video to detect any moving
object. If it detects movement, it begins to track the
object. This mode is most useful for scenarios where
normally no motion is expected.
One Click mode: In this mode, users can click an
object moving in the live video image to enable the
camera to track the movement of the selected object.
This mode is most useful for scenarios where normal
scene activity is expected.
Triggered mode: In this mode, the camera
continuously analyzes the scene for alarms or rule
violations. If a rule is violated, it triggers the advanced
tracking feature of the camera to start following the
object / person that triggered the alarm.
This unique combination of robust Intelligent Video
Analytics and Intelligent Tracking allows the camera to
track moving objects of interest without getting
distracted by other moving objects in the scene.
Intelligent streaming reduces bandwidth and
storage requirements
The low-noise image and the efficient H.265
compression technology provide clear images while
reducing bandwidth and storage by up to 80%
compared to standard H.264 cameras. With this new
generation of cameras an extra level of intelligence is
added with Intelligent Streaming. The camera provides
the most usable image possible by cleverly optimizing
the detail-to-bandwidth ratio. The smart encoder
continuously scans the complete scene as well as
regions of the scene and dynamically adjust
compression based on relevant information like
movement. Together with Intelligent Dynamic Noise
Reduction, which actively analyzes the contents of a
scene and reduces noise artifacts accordingly, bitrates
are reduced by up to 80%. Because noise is reduced at
the source during image capture, the lower bitrate
does not compromise image quality. This results in
substantially lower storage costs and network strain
and still retain a high image quality and smooth
motion.
Image Stabilization
As PTZ cameras continue to increase their optical
zoom capabilities, image stabilization becomes critical
to eliminate movement caused by unstable camera
mounts. Minor movement of the camera mount can
shift the field of view by a large distance when the
camera is zoomed to a high value. This can render
images unusable. The camera incorporates an Image
Stabilization algorithm; when turned on, the camera
detects continuous vibration. If it detects vibration,
the camera dynamically corrects the shaky video in
both the vertical and horizontal axis, resulting in
improved image clarity and a stable field of view on
the monitor.
: When configured in this mode, the camera
Page 3
| AUTODOME IP starlight 7000i
3
Auto Exposure (AE) region and Focus region
With the Auto Exposure (AE) function, the camera
computes the lighting condition of the entire scene.
Then the camera determines the optimum level of iris,
gain, and shutter speed.
In AE region mode, users can designate a specified
area of the scene, based on pre-positions. The camera
computes the lighting condition of the specified area.
Then the camera determines the optimum level of iris,
gain, and shutter speed to get an image.
Focus region mode, unlike normal auto focus mode,
allows users to focus on a specified area of the scene.
Users have the ability to customize these modes, if
necessary, for the specific requirements of the site.
Simple set-up
The camera has a very intuitive user interface that
allows fast and easy configuration. Configurable scene
modes are provided with the best settings for a variety
of applications.
• Standard
This mode is optimized for most standard scenes both
indoor and outdoor.
• Color Only (Traffic)
In this mode, the camera does not switch to
monochrome mode at low light levels. The mode is
optimized to minimize motion artifacts and to capture
the color of vehicles/pedestrians and traffic lights,
even at night, for scenarios such as city surveillance
and traffic monitoring.
• Indoor
This mode is ideal for indoor applications where
lighting is constant and does not change. Auto white
balance will be mainly focused on low color
temperature 3200K.
• Sensitivity boost
This mode provides maximum sensitivity in low light
scenes by using longer exposure times, resulting in
bright images even in extreme low light.
• Fast movement
This mode is used for monitoring fast moving objects
like cars in traffic scenes. Motion artifacts are
minimized and the image is optimized for a sharp and
detailed picture in color and monochrome.
• Vibrant
This mode provides a more vivid image with increased
contrast, sharpness, and saturation.
Sophisticated alarm responses
The camera supports advanced alarm control that uses
sophisticated rules-based logic to determine how to
manage alarms. In its most basic form, a “rule” could
define which input(s) should activate which output(s).
In a more complex form, inputs and outputs can be
combined with pre-defined or user-specified
commands to perform advanced camera functions.
Pre-positions and tours
The camera supports 256 pre-positions and two styles
of Guard Tours: Preset and Record/ Playback. Users
can easily adjust the image setting for individual
preposition if necessary, to see the detail for specific
requirement of the sites. Totally users can also
configure the preset standard tour with as many as
256 sequential pre-positions, with a configurable dwell
time between pre-positions. The camera also provides
support for two recorded tours, which are recorded
macros of an operator’s movements, including pan,
tilt, and zoom activities, and can be played back with
the click of a button.
Data security
Special measures are necessary to ensure the highest
level of security for device access and data transport.
On initial setup, the camera is only accessible over
secure channels. You must set a service-level
password in order to access camera functions.
Web browser and viewing client access can be
protected using HTTPS or other secure protocols that
support state-of-the-art TLS 1.2 protocol with updated
cipher suites including AES encryption with 256 bit
keys. No software can be installed in the camera, and
only authenticated firmware can be uploaded. A threelevel password protection with security
recommendations allows users to customize device
access. Network and device access can be protected
using 802.1x network authentication with EAP/TLS
protocol. Superior protection from malicious attacks is
guaranteed by the Embedded Login Firewall, on-board
Trusted Platform Module (TPM) and Public Key
Infrastructure (PKI) support.
The advanced certificate handling offers:
• Self-signed unique certificates automatically created
when required
• Client and server certificates for authentication
• Client certificates for proof of authenticity
• Certificates with encrypted private keys
Power options
The camera can be powered by either PoE+ (IEEE
802.3at) capable network switch or a High Power-overEthernet Midspan. In a PoE configuration, a single
(Cat5e/Cat6e) cable connection provides power while
simultaneously supporting data and video
transmission. For maximum reliability, the camera can
operate with 24 VAC power source a redundant power
system of PoE and a separate connected
simultaneously. If either the PoE or 24 VAC power
source fails, the camera seamlessly transitions to the
remaining power source. The camera can also accept a
standard 24 VAC power source if a PoE network
interface will not be used.
For pendant models used in outdoor applications that
require heaters, a High PoE Midspan (60 W) by Bosch
is required to power both the camera and its internal
heaters.
For in-ceiling or indoor pendant applications that don’t
require heater power, standard PoE+ (IEEE 802.3at)
midspans or switches can be used to power the
camera.
Page 4
4 | AUTODOME IP starlight 7000i
System integration and ONVIF conformance
The camera conforms to the ONVIF (Open Network
Video Interface Forum) specification which guarantees
interoperability between network video products
regardless of manufacturer. The ONVIF Profile S
specification allows easy integration with other
conformant devices and VMS. ONVIF conformant
devices are able to exchange live video, audio,
metadata, and control information, and ensure that
they are automatically discovered and connected to
network applications such as video management
systems.
PTZ drive and mechanism
The camera offers a reliable drive platform, designed
for continuous tours for at least three years. It
provides an unlimited three-year warranty. Its design
provides optimum smoothness in motion when used at
low speeds or with a joystick.
Pan and tilt preset repeatability are accurate to within
±0.1 degrees to ensure that the correct scene is
captured every time. The camera delivers variable pan/
tilt speeds from a crawl speed of only 0.1 degrees per
second to a full 400 degrees per second. The camera
is capable of pan speeds of 400 degrees per second
and tilt speeds of 300 degrees per second between
pre-positions. The camera provides a tilt angle 18
degrees above the horizon, and a pan range of up to
360 degrees continuous rotation.
Design for challenging environments
Pendant housings are rated to provide IP66 protection
and offer an operating temperature range down to
-40 °C (-40 °F). The pendant model comes fully
assembled with a sunshield which can be easily
removed for use in indoor applications. In addition,
both pendant and in-ceiling camera models have a
high-resolution acrylic bubble for enhanced image
clarity.
Ease of installation and servicing
The camera has been designed for quick and easy
installation, a key feature from Bosch IP video
products. All housings feature recessed screws and
latches for increased tamper resistance.
Bosch offers a full complement of hardware and
accessories (sold separately) for wall, corner, mast,
roof, and pipe mount for indoor and outdoor
environments, which allow the camera to be adapted
easily to individual site requirements.
Remotely upgrade the camera whenever new firmware
becomes available. This ensures up-to-date products,
thus protecting investment with little effort.
Fiber Optic Kit
Bosch offers the optional VG4-SFPSCKT, a unique
media converter module for use with various Bosch
devices. This media converter module is designed to
accept a wide-range of 10/100 Mbps SFP modules for
use with Multimode or Single-mode optical fiber with
LC or SC connectors.
The media converter module along with the SFP
module is user-installed directly into the camera‘s
power supply box to provide an integrated fiber optic
solution.
Camera Diagnostics
The camera has several built-in sensors / advanced
diagnostics that display warnings on the camera’s
OSD about the health of the camera. The diagnostics
log records the events such as:
• Low voltage - a drop in incoming power below the
level where the camera becomes non-functional
• High temperature - the internal temperature exceeds
specifications
• Low temperature - the internal temperature exceeds
minimum levels
• High humidity - the internal humidity exceeds 70%
• Total hours of camera operation
Certain events also appear on the camera’s OSD.
These diagnostic records are available for the
installation or service technician to review.
Certifications and approvals
For a full list of all related certifications/standards,
refer to the Product Tests Report, available on the
online catalog, on the Documents tab of the product
page for your device. If the document is unavailable on
the product page, contact your sales representative.
Electromagnetic
compatibility (EMC)
Product Safety Complies with UL, CE, CSA, EN, and IEC
Marks UL, CE, WEEE, RCM, EAC, VCCI, FCC, RoHS
FCC Part 15, ICES-003
EN 55024:2010 + A1:2015
EN 55032:2015/AC:2016
EN 61000-3-2:2014
EN 61000-3-3:2013
standards including:
UL 62368-1
EN 62368-1
EN 60950-1
CAN/CSA-C22.2 No. 62368-1-14
IEC 62368-1 Ed.2
IEC 60950-1 Ed.2
IEC 60950-22 Ed.2
Technical specifications
AUTODOME IP starlight 7000i
Imager
Effective Picture
Elements (Pixels)
Lens 30x motorized Zoom
Field of View (FOV) 2.3° to 64.7°
1/2.8 in. CMOS sensor
1944 x 1212 (2.35 MP)
4.3 mm to 129 mm
F1.6 to F4.7
Page 5
5 | AUTODOME IP starlight 7000i
Focus Automatic with manual override
Iris Automatic with manual override
Digital Zoom 12x
Day/Night switch Automatic IR cut filter
Video performance - Sensitivity
(3100K, reflectivity 89%, 1/30, F1.6, 30 IRE)
Color 0.0077 lx
Monochrome 0.0008 lx
Video performance - Dynamic range
High dynamic range 120 dB WDR
Measured according
to IEC 62676 Part 5
100 dB WDR
Additional Camera Settings
Gain control AGC, Fixed
Aperture correction Horizontal and vertical
Shutter 1 to 1/10000sec
Signal-to-Noise Ratio
(SNR)
Backlight
compensation (BLC)
White balance 2000 K to 10,000 K
Defog mode feature Improves visibility when viewing foggy or
Noise Reduction Intelligent Dynamic Noise Reduction
DORI DORI definition Distance to object
WIDE 1X TELE 30X Scene
Detect 25 px/m
(8 px/ft)
Observe 63 px/m
(19 px/ft)
Recognize 125 px/m
(38 px/ft)
>55 dB
On/Off
ATW, indoor, outdoor, AWB Hold, Extended
ATW, Manual, Sodium Lamp Auto, Sodium
Lamp
other low-contrast scenes.
width
61 m
(200 ft)
24 m
(79 ft)
12 m
(410 ft)
1913 m
(6276 ft)
765 m
(2510 ft)
383 m
(1255 ft)
77 m
(252 ft)
31 m
(100 ft)
15 m
(50 ft)
Video content analysis
Analysis type Intelligent Video Analytics
Configurations Off / Global VCA / Profiles 1 - 16
Calibration Automatic self-calibrating when height is set
Alarm rules
(combinable)
Object filters Duration, Size, Aspect ratio v/h, Speed, Direction,
Any object, Object in field, Crossing line, Entering
field, Leaving field, Loitering, Following route, Idle
object, Removed object, Counter, Occupancy,
Crowd detection, Condition change, Similarity
search, Tampering
Object classes (Upright persons, Bikes, Cars,
Trucks), Color
Miscellaneous
Sectors/Title 4, 8, 12, or 16 user-selectable, independent
Sectors, each with 20 characters per Title
Privacy Masks 32 individually configurable Privacy Masks;
maximum 8 per Pre-position; programmable
with 3, 4 or 5 corners; selectable color of Black,
White, Gray, “Auto” (average background color)
Virtual Masking 24 individually configurable Virtual Masks to
hide parts of the scene (background motion
such as moving trees, pulsating lights, busy
roads, etc.) which should not be considered for
flow analysis to trigger Intelligent Tracking.
Pre-positions 256 Pre-positions, each with 20 characters per
Title
Guard Tours Custom Recorded Tours - two (2), total duration
30 minutes: Pre-position tour - one (1),
consisting of up to 256 scenes consecutively,
and one (1) customized with up to 64 userdefined scenes
Supported
Languages
English, Czech, Dutch, French, German, Italian,
Polish, Portuguese, Russian, Spanish,
Japanese, Chinese
Network
Video compression H.265, H.264, M-JPEG
Streaming Four (4) streams: Two (2) configurable
streams in H.264 or H.265; One (1) I-framesonly stream based on first stream; One (1) MJPEG Stream
Frame rate 1080p: 30fps; 720p: 60fps
Identify 250 px/m
(76 px/ft)
6 m
(20 ft)
191 m
(628 ft)
8 m
(25 ft)
Page 6
6 | AUTODOME IP starlight 7000i
Protocols IPv4, IPv6, UDP, TCP, HTTP, HTTPS, RTP/
RTCP, IGMP V2/V3, ICMP, ICMPv6, RTSP,
FTP, ARP, DHCP, APIPA (Auto-IP, link local
address), NTP (SNTP), SNMP (V1, V3, MIB-II),
802.1x, DNS, DNSv6, DDNS (DynDNS.org,
selfHOST.de, no-ip.com), SMTP, iSCSI,
UPnP (SSDP), DiffServ (QoS), LLDP, SOAP,
Dropbox™, CHAP, digest authentication
Interoperability ONVIF Profile S, ONVIF Profile G, ONVIF
Profile T, Auto-MDIX
Ethernet 10BASE-T/100BASE-T, auto-sensing, half/full
duplex
Encryption TLS 1.2, DES, 3DES, AES
Ethernet connector RJ45
GOP Structure IP, IBP, IBBP
Data Rate (H.265,
1080P)
Overall IP Delay 60 fps: 166 ms (typical)
Resolutions (H x V)
1080p HD 1920 x 1080
720p HD 1280 x 720
61 kbps to 2.8 Mbps (depending on the
scene, the frame rate, and the quality settings)
30 fps: 233 ms (typical)
Electrical
In-Ceiling Pendant
Power 24 VAC
High PoE (using a Bosch model of High PoE Midspan;
required to power the heater)
PoE+ (IEEE 802.3at, class 4 standard) (when used
without powering the heater)
Power
Consumption
(typical)
19.2 W /
33.6 VA
51.0 W / 54.0 VA (heaters on)
or
19.2 W / 33.6 VA (heaters off /
without heater connected in 24 V
power supply box)
Audio
Audio
- Standard G.711, 8 kHz sampling rate
L16, 16 kHz sampling rate
AAC, 16 kHz sampling rate
- Signal-to-Noise
Ratio
- Audio Streaming Bidirectional (full-duplex)
>50 dB
Local Storage
Memory Card Slot User-supplied SD/SDHC/SDXC memory card
(maximum 2TB – SDXC)
1.3 MP 5:4
(cropped)
D1 4:3 (cropped) 704 x 480
640x 480 640 x 480
432p SD 768 x 432
288p SD 512 x 288
144p SD 256 x 144
1280x 1024
Mechanical
In-Ceiling Pendant
Pan Range 360° cont. 360° cont.
Tilt Angle 1° above horizon 18° above horizon
Pre-position Speed Pan: 400°/s
Tilt: 300°/s
Pan/Tilt Modes
• Turbo mode
(Manual Control)
• Normal Mode 0.1°/s-120°/s 0.1°/s-120°/s
Pre-position Accuracy ± 0.1° typ. ± 0.1° typ.
Pan: 400°/s
Tilt: 300°/s
Pan: 0.1°/s - 400°/s
Tilt: 0.1°/s - 300°/s
Recording Continuous recording of video and audio,
alarm/events/schedule recording
Fiber Optic Kit
VG4-SFPSCKT
Description Fiber Optic Ethernet Media Converter kit 6.
Requires a small form-factor pluggable (SFP)
module (sold separately).
Data Interface Ethernet
Data Rate 10/100 Mbps
IEEE 802.3 Compliant
Full Duplex or Half Duplex Electrical Port
Full Duplex Optical Port
Compatible Receiver CNFE2MC
Installation Installed inside a VG4-A-PA0, VG4-A-PA1,
VG4-A-PA2, VG4‑A‑PSU1, or a VG4‑A‑PSU2
power supply box with supplied mounting
hardware
6. Kit available separately and must be installed inside the AUTODOME power supply box.
SFP Modules
Description
Interchangeable modules available for use with
MMF or SMF optical fiber.
Intelligent Tracking
Speed
>0.2°/second (minimum)
Data Interface Ethernet
Page 7
7 | AUTODOME IP starlight 7000i
Data Rate 10/100 Mbps
IEEE 802.3 Compliant
Weight (all SFP
modules)
Dimensions (LxWxH) SFP-2, SFP-3: 55.5 x 13.5 x 8.5 mm (2.2 x
Type Connector Wavelength
SFP-2 MMF Duplex LC 1310 nm /
SFP-3 SMF Duplex LC 1310 nm /
SFP-25 MMF Single SC 1310 nm /
SFP-26 MMF Single SC 1550 nm /
Fiber Compatibility
Optical Fiber
Compatibility, MMF
Optical Fiber
Compatibility, SMF
0.23 kg (0.05 lb)
0.5 x 0.3 in.)
SFP-25, SFP-26: 63.8 x 13.5 x 8.5 mm (2.5 x
0.5 x 0.3 in.)
Max.
(transmit /
receive)
1310 nm
1310 nm
1550 nm
1310 nm
50/125 µm MMF. For 50/125 µm fiber,
subtract 4 dB from the specified optical
budget value. Must meet or exceed fiber
standard ITU-T G.651.
8–10/125 µm SMF. Must meet or exceed
fiber standard ITU-T G.652.
Distance
2 km
(1.2 miles)
20 km
(12.4 miles)
2 km
(1.2 miles)
2 km
(1.2 miles)
Environmental
In-Ceiling Pendant
NDP-7512-Z30C
NDP-7512-Z30CT
Ingress
Protection
Rating/
Standard
Operating
temperature
(with heater
wired)
Storage
temperature
Operating
Humidity
Vibration IEC 60068-2-6 IEC 60068-2-6
Shock IEC 60068-2-27 IEC 60068-2-27
IP54, Plenum rated IP66, NEMA 4X ¹
-10 to +40 °C
(+14 to +104 °F)
-40 to +60 °C
(-40 to +140 °F)
0% to 90% RH, (noncondensing)
NDP-7512-Z30
NDP-7512-Z30K
(Rugged)
-40 to +55 °C (-40 to
+131 °F)
-10 to +55 °C (+14 to
+131 °F) (without
heater wired)
Maximum temperature:
74 °C (165 °F) in
accordance with NEMA
TS 2-2003 (R2008)
-40 to +60 °C
(-40 to +140 °F)
0% to 100% RH,
condensing
NEMA TS2 Section
2.2.8
NEMA TS2 Section
2.2.9
Optical Distance
Specifications
Specified transmission distances are limited to
the optical loss of the fiber and any additional
loss introduced by connectors, splices, and
patch panels. The modules are designed to
operate over the entire optical loss budget
range, so they do not require a minimum loss
in order to operate.
User Connections
Power, Network RJ45 10Base-T/100Base-T
Power, Camera 24VAC, 50/60Hz
Alarm Inputs (7) 2 supervised, 5 non-supervised
Alarm Outputs (4) 1 dry contact relay, 3 open collector/
transistor outputs
Programmable for “normally open” or
"normally closed"
32 VDC @ 150 ma max.
Audio 1 x mono line in, 1 x mono line out
Signal line in: 20 kOhm typical, 0.707 Vrms
Signal line out: 0.707 Vrms at 16 Ohm, typical
Salt Mist Spray
(Corrosion Test)
External
Mechanical
Impact
1. NEMA 4X for:
-Access to Hazardous parts
-Ingress of solid foreign objects (falling dirt, circulating dust, settling
dust)
-Ingress of water (dripping and light splashing, hose down and
splashing)
-Corrosive agents
Meets requirements for NEMA 4X certification (NDP-7512-Z30K).
Meets requirements for NEMA 4X, except impact test (NDP-7512-Z30).
IEC 60068-2-52
IEC 60068-2-75: IK10
(NDP-7512-Z30K
only)
Construction
Dimensions
Weight In-ceiling: 2.6 kg (5.7 lb)
Bubble Size 153.1 mm diameter (6.03 in.)
Construction Material ,
Housing
224 mm (8.8 in.) x 299.4 mm (11.8 in.)
Pendant: 3.2 kg (7 lb)
In-ceiling: Magnesium
Pendant: Cast aluminum
Page 8
206.89
[8.145]
175.99
[6.929]
21.29
[0.838]
99.76
[3.928]
IP
78.04
[3.072]
IP
204.49
[8.051]
ø
74.65
[2.939]
HD
95.88
[3.775]
HD
mm
[in.]
ø
mm
[in.]
134.6
[5.30]
366.9
[14.44]
11.0
[0.43]
160.0
[6.30]
186.1
[7.33]
169.9
[6.69]
188.0
[7.40]
158.0
[6.22]
R 76.6
[3.01]
189.0
[7.44]
224.0
[8.82]
549.6
[21.64]
532.1
[20.95]
469.1
[18.47]
201.2
[7.92]
216.4
[8.52]
233.0
[9.17]
22.86
[0.90]
86.7
[3.42]
299.4
[11.79]
R 76.6
[3.01]
189.0
[7.44]
224.0
[8.82]
8 | AUTODOME IP starlight 7000i
Construction Material ,
Bubble
In-ceiling: acrylic
Pendant: acrylic
Pendant (IK10): nylon
Standard Color White (RAL 9003)
Standard Finish Powder coated, sand finish
Mounts/Accessories
Bubbles
In-ceiling
Clear HD high-resolution acrylic VGA-BUBHD-CCLA
Tinted HD high-resolution acrylic
VGA-BUBHD-CTIA
(Included with in-ceiling camera models.)
Pendant
Clear high-resolution acrylic
VGA-BUBBLE-PCLA
(Included with pendant camera models.)
Tinted high-resolution acrylic VGA-BUBBLE-PTIA
Clear rugged IK10-rated nylon* VGA-BUBBLE-IK10
*Included with NDP-7512-Z30K
Mounts
Dimensional Drawings
AUTODOME 7000 series In-ceiling
Pendant Arm Mounts
Wall Arms VG4-A-PA0 (no
transformer)
VG4-A-PA1 (120 VAC
transformer)
VG4-A-PA2 (230 VAC
transformer)
Pendant Arm with Wiring VG4-PEND-ARM
Mounting plate for VG4-PEND-ARM VG4-PEND-WPLATE
Trim skirt for VG4 Series Power
VG4-A-TSKIRT
Supplies
Optional Mounting Plates for Arm Mounts
Corner Mounting Plate VG4-A-9542
Pole Mounting Plate VG4-A-9541
Pendant Pipe Mounts
VGA-ROOF-MOUNT (with
1.5-inch NPT tapered male
threads)
Pipe Mount Kit VG4-A-9543
Pendant Roof Mounts
Roof (Parapet) Mount
(VG4-A-9543 Pipe Mount Kit required. Available separately.)
Optional Mounting Plates for Roof Mounts
Flat Roof Adapter for Parapet Mount LTC 9230/01
In-ceiling Support Kits VGA-IC-SP (Bracket for
suspended or drop ceilings)
AUTODOME 7000 series Pipe, Pendant mounts
1 Power supply box and
4 Power supply box
sunshield
2 Sunshield removed 5 Trim skirt
3 Mounting plate
Page 9
175
6.9
193
7.6
58
2.3
236
9.3
203
8.0
133.4
5.25
133.4
5.25
219.1
8.63
178
7.0
38
1.5
mm
in.
88.9
3.50
88.9
3.50
10.2
0.40
152.4
6.0
1-1/2 NPT
69.9
2.75
101.6 Typ.
4.0
10.4
8 x 0.41
114.3
4.50 Typ.
228.6
9.0
279.4
11.0
1022.4
40.25
976.1
38.43
88.1
3.47
1190.8
46.88
616
24.25
346.2
13.63
Ø 10.4
0.41
16.0 Typ.
0.63
111 Typ.
4.37
6.35 Typ.
0.25
279.4
11.00
6.35
0.25
378
14.88
254
10.00
11.0
04.3
216.4
8.52
170.0
6.69
134.6
5.30
160.0
6.30
50.8
2.00
105.0
4.13
9 | AUTODOME IP starlight 7000i
Indoor, in-ceiling mount, tinted bubble
Order number NDP-7512-Z30CT
NDP-7512-Z30K PTZ 2MP HDR 30x clear IK10 pendant
PTZ dome camera; 1080 (2MP) HD, 30x, starlight
imaging, H.265, IVA.
Outdoor pendant mount, IK10
Order number NDP-7512-Z30K
AUTODOME 7000 series Optional Mounts
1 Pole (Mast) Mount 4 Roof Mount
2 Corner Mount 5 Roof Mount Adapter
3 Pipe Mount 6 Power Supply for Pipe and
Roof Mounts
Ordering information
NDP-7512-Z30 PTZ 2MP HDR 30x clear IP66 pendant
PTZ dome camera; 1080 (2MP) HD, 30x, starlight
imaging, H.265, IVA.
Outdoor pendant mount
Order number NDP-7512-Z30
NDP-7512-Z30C PTZ 2MP HDR 30x clear IP54 in-ceiling
PTZ dome camera; 1080 (2MP) HD, 30x, starlight
imaging, H.265, IVA.
Indoor, in-ceiling mount, clear bubble
Order number NDP-7512-Z30C
NDP-7512-Z30CT PTZ 2MP HDR 30x tinted IP54 inceiling
PTZ dome camera; 1080 (2MP) HD, 30x, starlight
imaging, H.265, IVA.
Page 10
10 | AUTODOME IP starlight 7000i
Accessories
NPD-6001B High PoE midspan
60 W indoor midspan for cameras without illuminators
Order number NPD-6001B
VG4-A-PSU0 Power supply, 24VAC
Power supply, 24 VAC input, for a PTZ camera in the
AUTODOME Series. White, aluminum enclosure with
cover, rated IP66 and IK 08. 100 W output. Optional
trim skirt (sold separately).
Order number VG4-A-PSU0
VG4-A-PSU1 PSU, 120VAC, for AUTODOME, MIC7000
Power supply for AUTODOME 7000, MIC IP cameras
without illuminators.
120VAC in, 24VAC out
Order number VG4-A-PSU1
VG4-A-PSU2 Power supply, 230VAC, AUTODOME,
MIC7000
Power supply for AUTODOME 7000, MIC IP cameras
without illuminators.
230VAC in, 24VAC out
Order number VG4-A-PSU2
VGA-SBOX-COVER Cover for AUTODOME power supply box
Cover for AUTODOME Power Supply Boxes, white
Order number VGA-SBOX-COVER
VG4-SFPSCKT ETHERNET TO SFP INTERFACE KIT
Ethernet media converter video transmitter/data
receiver fiber optic kit for AUTODOME cameras, for
MIC-IP-PSU for MIC analog cameras and for the
Surveillance cabinets (NDA-U-PA0, NDA-U-PA1 and
NDA-U-PA2).
Order number VG4-SFPSCKT
SFP-2 Fiber module, multimode, 1310nm, 2LC
SFP Fiber Optic Module, 2 km (1.2 miles), 2 LC
connectors.
Multi-mode
1310 mm
Order number SFP-2
SFP-3 Fiber module, single-mode, 1310nm, 2LC
SFP Fiber Optic Module, 20 km (12.4 miles), 2 LC
connectors.
Single-mode
1310 nm
Order number SFP-3
SFP-25 Fiber module, 1310/1550nm, 1SC
SFP Fiber Optic Module, 2 km (1.2 miles), 1 SC
connector
Multi-mode
1310/1550 nm
Order number SFP-25
SFP-26 Fiber module, 1550/1310nm, 1SC
SFP Fiber Optic Module, 2 km (1.2 miles), 1 SC
connector
Multi-mode
1550/1310 nm
Order number SFP-26
VG4-A-PA0 Pendant arm, power box, 24VAC, AUTODOME
Pendant arm mount with power supply box for an
AUTODOME Series camera, no transformer, white
Order number VG4-A-PA0@1
VG4-A-PA1 Pendant arm, power box, 120VAC, AUTODOME
Pendant arm mount with power supply box for an
AUTODOME Series camera with a 120 VAC
transformer, white
Order number VG4-A-PA1
VG4-A-PA2 Pendant arm, power box, 230VAC, AUTODOME
Pendant arm mount with power supply box for an
AUTODOME Series camera with a 230 VAC
transformer, white
Order number VG4-A-PA2@1
VGA-PEND-ARM Pendant arm with wiring, for AUTODOME
Compatible with an AutoDome Series pendant housing
Order number VGA-PEND-ARM@1
VGA-PEND-WPLATE Mounting plate for VGA-PENDARM
Mounting plate for VGA-PEND-ARM, compatible with
an AutoDome Series camera
Order number VGA-PEND-WPLATE
VGA-ROOF-MOUNT Roof parapet mount for AUTODOME series
Roof parapet mount, white
VG5-6xx/7xxx cameras require VG4-A-9543 Pipe Mount
(sold separately).
NEZ-5130-/NEZ-5230- cameras require NDA-ADPTRNPTMET (sold separately)
Order number VGA-ROOF-MOUNT
LTC 9230/01 Roof mount adapter
Flat Roof Mount Adapter for mounting a unit in an
upright position on a flat surface.
Order number LTC 9230/01
VG4-A-9541 Pole mount adapter
Pole mount adapter for an AUTODOME pendant arm or
a DINION imager, designed for poles with a diameter
of 100‑380 mm (4‑15 in.), white
Order number VG4-A-9541
VG4-A-9542 Corner mount adapter for AUTODOME
Corner mount adapter for an AUTODOME pendant arm
or a DINION imager
Order number VG4-A-9542
VG4-A-9543 Pipe mount for AUTODOME , white
Pipe mount, white, for an AutoDome Series pendant
housing
Order number VG4-A-9543
Page 11
11 | AUTODOME IP starlight 7000i
Represented by:
Europe, Middle East, Africa: Germany: North America: Asia-Pacific:
Bosch Security Systems B.V.
P.O. Box 80002
5600 JB Eindhoven, The Netherlands
Phone: + 31 40 2577 284
emea.securitysystems@bosch.com
emea.boschsecurity.com
Bosch Sicherheitssysteme GmbH
Robert-Bosch-Ring 5
85630 Grasbrunn
Germany
www.boschsecurity.com
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: +1 800 289 0096
Fax: +1 585 223 9180
onlinehelp@us.bosch.com
www.boschsecurity.us
Robert Bosch (SEA) Pte Ltd, Security Systems
11 Bishan Street 21
Singapore 573943
Phone: +65 6571 2808
Fax: +65 6571 2699
apr.securitysystems@bosch.com
www.boschsecurity.asia
© Bosch Security Systems 2019 | Data subject to change without notice
57623773195 | en, V3, 23. Oct 2019
VGA-IC-SP Suspended ceiling support kit,7"
Suspended ceiling support kit for dome cameras.
Aperture Ø177 mm (Ø7 in). Maximum supported
weight 11.3 kg (25 lb).
Order number VGA-IC-SP
VG4-A-TSKIRT Trim skirt for AUTODOME power supply box
Trim skirt for the following AutoDome Series power
supply boxes:
VG4-A-PSU0, VG4-A-PSU1, and VG4-A-PSU2
Order number VG4-A-TSKIRT
VGA-BUBBLE-PCLA Bubble, pendant, clear
Low-impact acrylic bubble
Order number VGA-BUBBLE-PCLA
VGA-BUBBLE-PTIA Bubble, pendant, tinted
Low-impact acrylic bubble
Order number VGA-BUBBLE-PTIA
VGA-BUBLRG-CCLA Bubble, in-ceiling, large, clear
High-resolution bubble for AUTODOME in-ceiling
cameras, clear
Order number VGA-BUBLRG-CCLA
VGA-BUBHD-CTIA Bubble, in-ceiling, tinted
High-resolution acrylic bubble for AUTODOME HD inceiling cameras, tinted
Order number VGA-BUBHD-CTIA
VGA-BUBBLE-CTIR Bubble, in-ceiling, tinted, rugged
Impact resistant polycarbonate bubble
Order number VGA-BUBBLE-CTIR
VGA-BUBBLE-CCLR Bubble, in-ceiling, clear, rugged
Impact resistant polycarbonate bubble
Order number VGA-BUBBLE-CCLR
VGA-BUBBLE-IK10 Bubble, pendant, IK10-rated
IK10-rated bubble qualified for use with AUTODOME
7000 HD cameras with pendant housings
Order number VGA-BUBBLE-IK10
Software Options
MVC-CT-PTZ License for PTZs
Camera Trainer license for Intelligent Video
Analytics 7.10 on PTZ cameras.
Free-of-charge software module.
Order number MVC-CT-PTZ
Loading...
