Serie | 2
Pyramid hood: perfect performance
matching your kitchen.
●
Push buttons: simply modify the desired power level settings
with mechanic control.
●
Extraction rate: at 570 m3/h, it quickly ensures optimal
kitchen air quality.
●
Silent: maximal extractor performance with little noise
Technical Data
Color chimney : Stainless steel
Typology : Chimney
Approval certificates : Australia Standards, VDE
Length electrical supply cord (cm) : 130
Height of the chimney (mm) : 553-730/573-730
Height of product, without chimney (mm) : 246
Minimum distance above an electric hob : 550
Minimum distance above a gas hob : 650
Net weight (kg) : 8.399
Type of control : mechanical
Number of speed settings : 3
Maximum output air extraction (m3/h) : 570
Maximum output recirculating air (m3/h) : 400
Number of lights : 2
Noise level (dB) : 69
Diameter of air outlet (mm) : 150 / 120
Grease filter material : Washable aluminium
EAN code : 4242005100637
Connection Rating (W) : 220
Current (A) : 10
Voltage (V) : 220-240
Frequency (Hz) : 50; 60
Plug type : AU plug
Installation typology : Wall-mounted
'!2E20AF-baagdh!
DWP66BC50A
Canopy Rangehood, 60 cm
1/3
Serie | 2 Ventilation
DWP66BC50A
Canopy Rangehood, 60 cm
Pyramid hood: perfect performance
matching your kitchen.
Design
Pyramidal
-
For Wall mounted installation
-
Appliance colour: Stainless steel
-
3 Power settings via push buttons
-
Operating and power
Ducted extraction rate according to DIN/EN 61591max. 570
-
m³/h
Extraction rate in recirculation mode:
-
Max. normal use: 400 m³/h
Noise level in recirculation mode:
-
Max. normal use: 75 dB(A) re 1 pW (63 dB(A) re 20 µPa sound
pressure)
Noise min./max. Normal Level: 49/69 dB*
-
Comfort & Convenience
Supplied with 2 dishwasher safe metal grease filters Metal
-
grease filter
Technical Information
Suitable for ducted or recirculating operation
-
Dimensions exhaust air (HxWxD): 799-975 x 600 x 500 mm
-
Dimensions recirculating (HxWxD): 799-975 x 600 x 500 mm
-
2 x 1.5W LED
-
220 W total connected load
-
