Page 1
XTC-600 Thin Client
Easily Deployed, Centrally Managed, Secure
Overview
Deliver Windows® applications simply, securely, and cost-effectively
throughout your organization with the BOSaNOVA XTC-600 Thin Client.
Powered by a VIA Ester 600 Mhz processor and featuring the state-of-the-
art Windows XP-embedded operating system, the BOSaNOVA XTC-600
offers the award-winning BOSaNOVA TCP/IP emulation and an optional
122-key driverless PC keyboard, providing iSeries customers with a unique
opportunity to obtain a complete thin client solution from a single, industry-
renowned manufacturer.
The BOSaNOVA XTC-600 includes a full array of embedded programs, such
as the full-featured Microsoft Internet Explorer, Office Viewers, Shockwave
Version 10, Flash Player, Adobe Acrobat Reader version 7 (** 8 available
upon request), Microsoft Outlook Express, Java Virtual Machine (JVM),
Remote Desktop Protocol (RDP), and Independent Computing Architecture
(ICA) or Citrix Specific Image ‘7616C’.
Advantages
G
PCI compliant embedded TN5250e based terminal emulation software for
connection to IBM iSeries (AS/400) including display, printing with Host
Explorer
TM
, SQL-based data transfer, and MorphExpressTMGUI
G
Windows XPe operating system with VIA Ester 600 Mhz processor and
Write Protected Flash system.
G
Connections to Windows Terminal Servers and Citrix servers using the Remote
Desktop Protocol (RDP) or Citrix Access Client
.
G
Keyboard support for full-featured 104-key or 122-key driverless PC keyboards,
enabling efficient work with host applications.
G
Embedded full - featured Internet Explorer 6 SP2 (** 7 available upon request)
with JVM 1.4.2 (** 1.6 available upon request.)
G
Support for USB-attached barcode equipment, parallel printer port, one serial port,
mouse port, 3 USB ports, microphone in and audio out for connection versatility
G
Centralized configuration, management, and security via the Remote Terminal
Administrator utility for low Total Cost of Ownership (TCO)
G
Internal 802.11 b/g wireless WEP and WPA ready. Additonal encryption support
upon request, (Leap, Peap and WPA2)
BOSaNOVA, Inc. 2012 W. Lone Cactus Drive, Phoenix, AZ 85027
Tel: (866) 865-5250 GFax: (623) 516-8697 [email protected]
Enterprise Class Remote Administration
The BOSaNOVA Remote Manager, an integral part
of the BOSaNOVA XTC-600, enables quick and easy
installation, upgrade, and user/group configuration.
Some of the features include:
G
5250 emulations can be centrally defined and pushed
down to the thin client.
G
Devices can be subdivided into groups based on IP
ranges for easier management of large installations.
G
Ability to remote enable or disable write protection, as
well as committing cached changes to disk when write
protection is enabled.
G
Capable of cloning post deployment software
installation and settings, pushing out only the
additional files, not a new complete image.
Intelligence of a PC with the security
and TCO of a Thin Client
Unlike most Thin Clients that contain only compact versions
of their browsers, the BOSaNOVA XTC-600 delivers the full
version of the IE browser. With its embedded applications,
such as Outlook Express, Adobe Acrobat Reader, and JVM,
the end user will not be able to distinguish between the
deliverability of the XTC-600 and a full PC. The XTC-600
delivers all of this functionality while still providing the
security and ease of maintenance of BOSaNOVA’s award-
winning Thin Clients.
The BOSaNOVA
XTC-600 supports
one parallel printer
port, two serial ports,
three USB 2.0 ports,
two PS/2 ports,
10/100 base-T
Ethernet interface,
and audio.
Page 2
Supports 32 TN5250e, SSL and
*optional Ericom emulations
8X AGP, 1600x1200 dpi, 32 bit color
IE6 SP2 (** 7 available upon request)
XTC-600 Thin Client
Easily Deployed, Centrally Managed, Secure
BOSaNOVA, Inc. 2012 W. Lone Cactus Drive, Phoenix, AZ 85027
Tel: (866) 865-5250 GFax: (623) 516-8697 [email protected]
Ordering Information
PID
7616
8008
8104x
Description
1 GB DOM ( call for information on customization and other
embedded applications
9009
Internal b/g wireless adapter (supports WPA and WEP)
104-key PC Keyboard
8122x
122-key Driverless PC Keyboard
Options
7616
512MB - 1GB DDR2
Version 10
•
6.0
Part Number
RAM (Standard/MAX)
Standard Client Software
ICA
Web Interface
Host Access
Browser
Video
Storage (Standard/MAX)
Wide Screen Support
XPe SP2
Read-only file system,
locked-down user account,
administrative passwords
Software Configuration
Operating System
Security Features
Client Software
Special Features
•
•
•
Management
BOS Remote Manager
Push Updates
VNC
Compact stand alone metal case
VIA Ester 600 MHz
Autosensing, 10/100 Ethernet,
RJ-45, WakeOnLan, PXE boot,
USB 802.11g support
2
1
3
1 Keyboard/1 Mouse
1.75” W x 9.5” H x 9.0” D
4.3 mm x 24.8 mm x 22.3 mm
6.2 lbs.
32-104
0
F (0-400 C)
20-90% non-condensing
0-20,000 ft (0-6,096 m)
100-240 VAC, 50-60 Hz
Max AC Input Power: 30 W
UL, UL1950, FCC Class B, cUL,
CSA-C22, No. 950M89, CE
Mark: EMC/LVD, TUV-GS
••
••
Form Factor
CPU
Audio
Mic In/Line Out
Internal Speaker
Networking
Serial Port – D-Sub
9-Pin Male Connector
Parallel Port – D-Sub
25-Pin Female Conn.
USB Ports – Type 2
PS/2 Ports
Physical Specifications
Dimensions
Shipping Weight
Operating Temperature
Operating Humidity
Operating Altitude
Power Requirements
Safety Certifications
Hardware Configuration
Enviornmental
External Power Option
Adobe PDF Viewer Version 7
(** 8.10 available on request
Windows Media Player 10
(** 11 available on request)
Sun JVM
Microsoft JVM
MS Office Viewers
Microsft Outlook Express
VNC Shadowing
Lotus Notes, iSeries Access and
additional customization available.
** Requires
1 GB DOM
IE 7, MP11, SunJVM 1.6, Adobe 8
512MB - 4GB FLASH
up to 1280x960 @ 32 bit. Plus 17
other video modes with 32 bit color
RDP
*Ericom Emulations supported include: 5250, 3270, 3151, AIXTerm, Wyse 50, Wyse 50+, VT52, VT220, VT320, VT420,
VT525, TVI910, TVI920, TVI925, TVI950, TVI955, Linux Console, SCO ANSI, BBS, ANSI, AT386, Siemens 97801,
ADDS VP A2, DG210, DG410, HZ1500, HP 700/92, HP 700/96, Tandem 6530
7616C
XTC-600, XPe, IE 6 SP2, Sun JVM, MS JVM, RDP, ICA, Windows
Media Player, Shockwave, Flash Player, Citrix Access Client, Critix
Password Manager
Featured software from the 7616C plus Adobe Acrobat Reader,
Office Viewers and Microsoft Outlook Express
8016
2 GB DOM
Security
Kensington Security Lock Slot
V0508
