WTC-600 Thin Client
Easily Deployed, Centrally Managed, Secure
Overview
Powered by Microsoft Windows CE.Net, the BOSaNOVA WTC-600
provides cost-effective and secure access to applications residing on an
iSeries or pSeries host, and/or Microsoft Windows, Unix, or Citrix
servers.
Unlike other CE.Net-based Thin Clients, which support only full-screen
applications, the BOSaNOVA WTC-600 allows management of multiple
browser windows within a single browser instance. As a result, even
pop-up windows (which typically require the user to close the new win-
dow in order to revert to the parent window) are no longer a distraction
to the standard user’s workflow. This capability, alongside unique 5250
split screen support (a first for CE.Net implementations), provides users
with more flexibility and increased productivity.
Advantages
Fast processor gives this entry-level Thin Client the benefit of excel-
lent performance in an economical solution
Windows CE.Net operating system with embedded Internet Explorer
6.0 compact browser to access web-based applications — with win-
dow manager, web mail icon, and kiosk mode
PCI compliant embedded GUI TN5250e/TN3270e terminal emulation
display (up to four sessions) and SCS printing, as well as the follow-
ing ASCII emulations: VT100, VT220, VT400, SCO, Xterm R6, and
Telnet with SSH
Supports connection to Windows Terminal Servers and Citrix servers
using the Remote Desktop Protocol (RDP), Citrix Independent
Computing Architecture (ICA) client software, Citrix Web Client,
Tarantella, Propalms and VNC Client
Automatic 5250 session termination on power-down, preventing
“session in use” problems normally associated with Ethernet terminals
Support for touch screen and USB printing
Optional internal 802.11 b/g wireless.
Contains full array of embedded applications such as Word, Excel and
PowerPoint viewers; POP-3 e-mail; media player; and a PDF reader
GUI setup and centralized configuration, management, and security
via the BOSaNOVA Remote Management utility for low TCO (Total
Cost of Ownership)
Enterprise Class Remote Administration
The BOSaNOVA WTC-600 Thin Client is simple to
configure either locally or remotely using the BOSaNOVA
Manager, which enables the following tasks:
Complete terminal configuration from a central
location
User lock-out from configuration changes
Scheduling of firmware updates
Cloning of user environments
Control over which applications run on a
particular terminal
The BOSaNOVA WTC-600 supports 5250 split screen
allowing use of two full sessions at the same time with-
out the normal full screen hot keying associated with
other CE.Net devices.
The BOSaNOVA
WTC-600 supports
one parallel printer
port, two serial ports,
three USB 2.0 ports,
two PS/2 ports,
10/100 base-T
Ethernet interface,
and audio.
Page 2
WTC-600 Thin Client
Ordering Information
PID
7620
8122x
Description
WTC-600 with 5250/3270, CE.Net, IE 6, RDP, ICA,
Office Viewers, PDF Reader, POP3
122-key 5250/PC Keyboard, Driverless
(x = ‘B’ for Black or ‘W’ for White)
8104x
104-Key PC Keyboard (x = ‘B’ for Black,‘W’ for White)
9009
Internal Mini PCI b/g Wireless adapter
Hardware Configuration
Form Factor
Standard Flash/RAM
CPU
Audio
Mic In/Line Out
Internal Speaker
Networking
Networking
Browser
I/O and Expansion
Serial Port – D-Sub
9-Pin Male Connector
Parallel Port – D-Sub
25-Pin Female Conn.
USB Ports – Type 2
PS/2 Ports
Physical Specifications
Dimensions
Shipping Weight
Environmental
Operating Temperature
Operating Humidity
Operating Altitude
Power Requirements
Safety Certifications
Security
Options
Compact stand-alone metal case
VIA Eden 600MHz
Autosensing, 10/100 Ethernet,
RJ-45, WakeOnLAN, PXE boot,
USB 802.11g support
2
1
3
1 Keyboard/1 Mouse
1.75” W x 9.5” H x 9.0” D
4.3 mm x 24.8 mm x 22.3 mm
6.2 lbs.
32-104
o
F (0-40oC)
20-90% non-condensing
0-20,000 ft (0-6,096 m)
100-240 VAC, 50-60 Hz
Max AC Input Power: 30 W
UL, UL1950, FCC Class B, cUL,
CSA-C22.2, No. 950-M89, CE
Mark; EMC/LVD, TUV-GS
Kensington Security Lock Slot
Software Configuration
Operating System
Security Features
Client Software
Citrix ICA
Secure Gateway
VNC Shadowing
BOSmanager
ThinPrint
Special Features
Options
CE.Net 5.0
Read-only file system,
locked-down user account,
administrative passwords
Autostart/auto-restart connection,
multiple level lock-down user
interface
Management
BOSmanager Support
Push/Pull Updates
VNC
Software/Configuration
Cloning
Options
Options
8X AGP
Supports 8 TN5250e and TN370e
sessions,Telnet with SSH, SSL,
Wyse 60, VT100 and VT200, xTerm, and Optional SCO
Up to 1280x1024 @ 75 Hz
Up to 1600x1200 @ 60 Hz
7620
128MB/256MB
Version 9
Web Client (NFuse)
5.5
IE6 CE Version
Up to 1280x1024 @ 75 Hz
Up to 1024x768 @ 85 Hz
Up to 1280x1024 @ 75 Hz
Up to 1024x768 @ 85 Hz
••
Part Number
Standard Flash/Ram
Standard Client Software
ICA
Web Interface
RDP
Host Access
Browser
Propalms
Video
Maximun Video
Resolution and
Refresh Rate
@ 8-Bit Color
@16-Bit Color
@24-Bit Color
Easily Deployed, Centally Managed, Secure
