WTC-550 Thin Client
Easily Deployed, Centrally Managed, Secure
Overview
Powered by Microsoft Windows CE.Net, the BOSaNOVA WTC-550
provides cost-effective and secure access to applications residing on an
iSeries or pSeries host, and/or Microsoft Windows, Unix, or Citrix
servers.
Unlike other CE.Net-based Thin Clients, which support only full-screen
applications, the BOSaNOVA WTC-550 allows management of multiple
browser windows within a single browser instance. As a result, even
pop-up windows (which typically require the user to close the new window in order to revert to the parent window) are no longer a distraction
to the standard user’s workflow. This capability, alongside unique 5250
split screen support (a first for CE.Net implementations), provides users
with more flexibility and increased productivity.
Advantages
O
Fast processor gives this entry-level Thin Client the benefit of excellent performance in an economical solution
O
Windows CE.Net operating system with embedded Internet Explorer
6.0 compact browser to access web-based applications — with window manager, web mail icon, and kiosk mode
O
Embedded GUI TN5250e/TN3270e terminal emulation display (up
to four sessions) and SCS printing, as well as the following ASCII
emulations: VT100, VT220, VT400, SCO, Xterm R6, and Telnet
with SSH
O
Supports connection to Windows Terminal Servers and Citrix servers
using the Remote Desktop Protocol (RDP), Citrix Independent
Computing Architecture (ICA) client software, Citrix Web Client,
Tarantella, Propalms and VNC Client
O
Automatic 5250 session termination on power-down, preventing
“session in use” problems normally associated with Ethernet terminals
O
Support for touch screen, USB printing, and optional 802.11 b/g wireless.
O
Contains full array of embedded applications such as Word, Excel and
PowerPoint viewers; POP-3 e-mail; media player; and a PDF reader
O
GUI setup and centralized configuration, management, and security
via the BOSaNOVA Remote Management utility for low TCO (Total
Cost of Ownership)
Enterprise Class Remote Administration
The BOSaNOVA WTC-550 Thin Client is simple to
configure either locally or remotely using the BOSaNOVA
Manager, which enables the following tasks:
O
Complete terminal configuration from a central
location
O
User lock-out from configuration changes
O
Scheduling of firmware updates
O
Cloning of user environments
O
Control over which applications run on a
particular terminal
The BOSaNOVA WTC-550 supports 5250 split screen
allowing use of two full sessions at the same time without the normal full screen hot keying associated with
other CE.Net devices.
The BOSaNOVA
WTC-550 supports
one parallel printer
port, two serial ports,
three USB 2.0 ports,
two PS/2 ports,
10/100 base-T
Ethernet interface,
and audio.
Page 2
BOSaNOVA, Inc. Phone: 866-865-5250 Email: [email protected] Web: www.bosanova.net
BOSaNOVA LTD (Europe) Phone: +44 1509 276252 Email: [email protected]
WTC-550 Thin Client
Authorized Distributor:
Ordering Information
PID
7520
8122x
Description
WTC-550 with 5250/3270, CE.Net, IE 6, RDP, ICA,
Office Viewers, PDF Reader, POP3
122-key 5250/PC Keyboard, Driverless
(x = ‘B’ for Black or ‘W’ for White)
8104x
104-Key PC Keyboard (x = ‘B’ for Black,‘W’ for White)
9004
USB 802.11b/g adapter
Hardware Configuration
Form Factor
Standard Flash/RAM
CPU
Audio
Mic In/Line Out
Internal Speaker
Networking
Networking
Browser
I/O and Expansion
Serial Port – D-Sub
9-Pin Male Connector
Parallel Port – D-Sub
25-Pin Female Conn.
USB Ports – Type 2
PS/2 Ports
Physical Specifications
Dimensions
Shipping Weight
Environmental
Operating Temperature
Operating Humidity
Operating Altitude
Power Requirements
Safety Certifications
Options
Compact stand-alone metal case
VIA Eden 533MHz
Q
Q
Autosensing, 10/100 Ethernet,
RJ-45, WakeOnLAN, PXE boot,
USB 802.11g support
2
1
3
1 Keyboard/1 Mouse
1.75” W x 9.5” H x 9.0” D
4.3 mm x 24.8 mm x 22.3 mm
6.2 lbs.
32-104
o
F (0-40oC)
20-90% non-condensing
0-20,000 ft (0-6,096 m)
100-240 VAC, 50-60 Hz
Max AC Input Power: 30 W
UL, UL1950, FCC Class B, cUL,
CSA-C22.2, No. 950-M89, CE
Mark; EMC/LVD, TUV-GS
Software Configuration
Operating System
Security Features
Client Software
Citrix ICA
Secure Gateway
VNC Shadowing
BOSmanager
ThinPrint
Special Features
Options
CE.Net 5.0
Read-only file system,
locked-down user account,
administrative passwords
Q
Q
Q
Q
Q
Autostart/auto-restart connection,
multiple level lock-down user
interface
Management
BOSmanager Support
Push/Pull Updates
VNC
Software/Configuration
Cloning
Options
Q
Q
Q
Q
Options
4X AGP
Supports 8 TN5250e and TN370e
sessions,Telnet with SSH,Wyse 60,
VT100 and VT200, x-Term, and
Optional SCO
Up to 1280x1024 @ 75 Hz
Up to 1600x1200 @ 60 Hz
7520
32MB/128MB (Flash/Ram)
Version 9
Web Client (NFuse)
5.5
IE6 CE Version
Up to 1280x1024 @ 75 Hz
Up to 1024x768 @ 85 Hz
Up to 1280x1024 @ 75 Hz
Up to 1024x768 @ 85 Hz
•
Part Number
Standard Flash/Ram
Standard Client Software
ICA
Web Interface
RDP
Host Access
Browser
Propalms
Video
Maximun Video
Resolution and
Refresh Rate
@ 8-Bit Color
@16-Bit Color
@24-Bit Color
Easily Deployed, Centally Managed, Secure
